Compaq Armada 6500 Installation guide

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 1
Overview 1-1
Overview
This chapter introduces the Compaq Armada 6500 notebook computer. It provides a
computer system overview and describes the controls, indicators, and hot keys.
1.1 System Overview
The computer is a high-performance portable computer designed for the mobile
professional.
CPU
The computer supports the Intel Mobile 300-MHz Pentium II processor. The following
is a list of the general features of this processor:
•Dynamic Execution micro architecture.
•Multiprocessing System Bus technology.
•Multiple low-power states (AutoHALT, Stop Grant, Sleep and Deep Sleep) to
conserve power during idle times.
•32-bit address bus.
•64-bit data bus.
•32KB internal write-back cache.
•Capable of executing two instructions per clock cycle using two pipelined integer
units.
•Multimedia extension (MMX) register set.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-2 Overview
Chip Set
The Intel 440BX AGPset is used to implement the core functions of the system. The
440BX AGPset includes the Intel 82443BX and the Intel PIIX4.
•The Intel 82443BX chip provides the core system functions.
−Processor/host bus support: Optimized for Pentium II processor at 100MHz;
support for 66MHz.
−3.3V core and mixed 3.3V and GTL I/O.
−Integrated DRAM controller.
−PCI bus interface.
−AGP interface.
−Advanced Power Management.
−Supporting I/O Bridge.
•The Intel PIIX4 provides the PCI to ISA bridge interface.
−Multifunction PCI-to-ISA bridge.
−Power Management Logic.
−Integrated PCI IDE Controller
−Enhanced DMA Controller.
−Interrupt Controller Based on two 82C59.
−Timers based on 82C54.
−USB
−Real-Time Clock
Memory
The system comes with 64MB of on-board SDRAM for system memory and 512KB of
L2 cache memory.
System memory can be upgraded to a total of 192MB or greater. The upgrade is
performed by installing 32MB or 64MB SDRAM SO-DIMMs. There are two slots for
additional memory. Memory can be upgraded one module at a time. Either slot can be
populated first.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overview 1-3
BIOS
The system has an Intel 28F004BV-T 4MBIT Boot block Flash ROM for system BIOS.
BIOS provides support for the following:
•Suspend to RAM.
•Save to Disk.
•APM 1.2, DMI2.0 and ACPI compliant.
•Password protection (System and Docking options).
•Auto-configured with docking options.
•Windows 95 ready with PnP.
•Various hot-keys for system control.
PCI Bus Devices
The internal PCI bus and PCI components operate at 3.3V.
CardBus Controller
CardBus support is provided by the TI PCI1221 PC CARD controller. This chip
provides the following functions:
•Support for Zoomed Video.
•Support for two PC Card/CardBus slots with hot removal/insertion.
•Uses burst transfers to maximize data throughput on the PCI/CardBus bus.
•Supports Parallel PCI Interrupts, Parallel ISA IRQ and Parallel PCI Interrupts, Serial
ISA IRQ with Parallel PCI Interrupts, and Serial ISA IRQ and PCI Interrupts.
•ACPI Compliant.
•Supports Ring Indicate, Suspend, PCI CLKRUN and CCLKRUN.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-4 Overview
Video Controller Chip
Video support is provided by the ATI Rage LT Pro-AGP Controller Chip. This chip
provides the following functions:
•Comprehensive support for Accelerated Graphics Port including 1X or 2X mode
with sidebands.
•TFT panel interface support for up to 1280 × 1024 resolutions.
•64-bit memory interface.
•4MB 3.3V Video SGRAM.
•Support for Zoomed Video.
•DDC1 and DDC2B+ support for PnP monitors.
•Advanced power management features minimize power consumption during:
−Normal operation
−Standby mode
−Panel-off
ISA Bus Devices
The ISA bus interface is provided by the Intel PIIX4 chip.
Audio
Audio support is provided by the ESS Maestro-2+ audio accelerator. This chip provides
the following functions:
•500-MIPS-equivalent dual-engine PCI audio accelerator.
•64-Voice wavetable synthesis.
•I2S Zoomed Video interface.
•DVD AC-3 (S/P DIF) audio decoding and AC-3 speaker virtualization.
•Docking solution backward compatible with ES978 mixer.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overview 1-5
BIOS
The system BIOS is implemented using the Intel 28F004BV-T 4MBIT Boot block
Flash ROM.
System Command Processor
The System Command Processor is implemented using the Hitachi H8/3434 processor.
This processor provides the following functions:
•Simultaneous support of two external PS/2 ports and the internal Touch pad.
•I2C bus master for communication to:
−Status LCD
−EEPROM
−Docking interface components
•Hot Key interface.
•Secure password protection.
•System power plane control and power sequencing.
•Battery management interface for charging and the Smart battery information.
•Status LCD and device monitoring interface.
•Active thermal interface for CPU thermal management.
•Internal keyboard scanning.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-6 Overview
Super I/O
I/O support is provided by the National Semiconductor PC97338 chip. This chip
supports the following functions:
•Floppy disk controller with Japanese floppy support.
•IEEE 1284 compliant bi-directional parallel port.
•Serial infrared support – IrDa 1.1 (115Kbps and 4Mbps).
•16550A and 16450 UARTs.
•Full Plug-and-Play support.
UMI Controller
The computer has an internal type II PCMCIA slot that is available as an UMI slot.
This feature provides a flexible method for the support of an internal modem/Ethernet
Combo card. This slot supports only Compaq approved ISA 16-bit cards. The UMI
interface is provided by the TI PCI1221 controller. This chip provides the following
features and functions:
•PCI Power Management, ACPI 1.0 and 1995 PC Card Standard compliant.
•Advanced Submicrion, Low-Power CMOS Technology.
•Pipelined architecture provides greater than 130-MB/s throughput.
•Five PCI memory windows and two I/O windows.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overview 1-7
1.2 Docking Options
The computer supports the docking options described below.
Mobile 6500 Expansion Unit
The Mobile 6500 Expansion Unit has the following features:
•Three speakers: two tweeters and one sub-woofer.
•Line-in and speaker out support.
•MIDI/Joystick port.
•Dolby Digital Surround Sound (S/P DIF).
•17mm MultiBay supporting CD-ROM, DVD-ROM, hard drive, LS-120, ZIP, and
diskette drives.
•Video output (NTSC/PAL selectable).
−Composite video using RCA jack
−S-Video
•Hardware Volume Control
Armada 6500 Convenience Base
The Armada 6500 Convenience Base has the following features:
•Battery charger
•Parallel port
•Serial port
•VGA/CRT port
•Two PS/2 connections for keyboard and mouse
•USB port
•RJ45 10/100BaseT Network Interface

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-8 Overview
1.3 Components, Controls, and Indicators
This section shows the locations and provides a description of the different components
on the computer.
Front and Right Side Components
Item Component Description
1 Power LED
Battery Charging LED The green Power LED (lower) lights when the computer is on. The amber Battery Charging LED (upper) lights when the battery
is charging.
2 Lid Release One of two lid releases. Push in both releases at the same time
to open the LCD panel.
3 Speaker Right stereo speaker used to hear sound files and system
sounds.
4 MultiBay Supports CD-ROM, diskette, and optional drives (DVD-ROM,
LS-120, and hard drive).
5 Microphone In Input connection for external microphone.
6 Audio Out Connection for headphones or external speakers.
7 Suspend/Power Button Turns the computer On, and Suspends or Resumes the system.
Refer to the“Controlling Power” section of this chapter for
detailed instructions on using the Suspend/Power button.
8 Internal Microphone Used to record voice, music, and sound files.
9 Status Display Provides system operating status.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overview 1-9
Figure 1-1 Front and Right Side View

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-10 Overview
Top and Left Side Components
Item Component Description
1 Lid Release One of two lid releases. Push in both releases at the same time
to open the LCD panel.
2 Speaker Left stereo speaker used to hear sound files and system sounds.
3 PC Card Ejectors Ejects a PC Card. Top button releases a PC Card from the top
slot; the bottom button releases a PC Card from the bottom slot.
4 PC Card Slots Supports two Type I or Type II cards or one Type III card. Zoomed
Video cards are supported in the bottom slot only.
5 Keyboard Releases These latches release the keyboard to allow access to the
removable hard drive.
6 Removable Hard Drive Located under the keyboard, the hard drive is easily removable
and upgradeable.
7 Security Lock Attach a security locking device , such as a Kensington lock, to
this port.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overview 1-11
Figure 1-2 Top and Left Side View

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-12 Overview
Rear Components
Item Component Description
1 External Power In Input connection for Universal AC adapter.
2 Universal Serial Bus (USB) Port A USB device, such as a mouse, keyboard, or digital camera
connects to this port.
3 RJ45 Ethernet Network Port A 10 or 100BaseT Ethernet line connects to this port.
4 RJ11 Modem Port An analog telephone line connects to this port.
5 Serial Port A serial device, such as a mouse, graphics tablet or scanner
connects to this port.
6 Parallel Port A parallel device, such as a printer, connects to this port.
7 Video Port An external monitor connects to this port.
8 I/O Connector Cover and Notebook
Support Covers I/O connectors. It can be flipped down to support the computer to create a comfortable typing angle.
9 Fast IR Port Fast IR interface allows wireless data transfer between the
computer and another device with an IR interface.
10 Reset Button Resets the computer. All unsaved data will be lost.
11 External Keyboard/ Mouse Port An external keyboard or PS/2 mouse connects to this port.
Figure 1-3 Rear View

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overview 1-13
Bottom Components
Item Component Description
1 Battery Release Releases the LiIon battery from the computer.
2 LiIon Battery Provides power to the computer.
3 MultiBay Release Releases the drive installed in the MultiBay.
4 Memory Door Provides access to computer’s memory.
5 Docking Connector Door Provides access to the computer’s docking connector. This
connector is used when connecting the computer to the
Compaq Mobile 6500 Expansion Unit or the Compaq Armada
6500 Convenience Base.
Figure 1-4 Bottom View

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-14 Overview
1.4 Controlling Power
The Suspend/Power button turns the computer on and off and accesses the built-n
power saving features.
Goal Action
On/Resume Press this button to turn the system On or resume normal operation from the Suspend
mode.
Suspend Press this button to place the system in Suspend mode.
Lid Switch Close the LCD panel to place the system into Suspend mode. If the Lid Switch option
in System Setup is set to Desktop/CRT, closing the LCD panel will turn off the LCD
screen and prevent the computer from entering Suspend mode. This allows the
computer to function as a desktop computer (computer LCD panel closed) using an
external display, keyboard, and mouse.
Off (Windows 95
and Windows NT)
fn
+
Press Fn + the Suspend/Power key combination to completely shut off the computer
from any state. If Windows is up and running, it is recommended that the computer
always be turned off as outlined in the Introducing Microsoft Windows user’s guide
which was packaged with the computer.
Off (Windows 98)
fn
+
Press Fn + Suspend/Power key combination to initiate an Off request and allow
Windows 98 to shut off the computer.
Power Button
Override Press and hold the Suspend/Power button for four seconds to completely shut Off the computer from any state. If Windows is up and running, it is recommended that the
computer always be turned off as outlined in the
Introducing Microsoft Windows user’s
guide which was packaged with the computer.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overview 1-15
1.5 LCD Status Display
Indicator Shows...
External power – The computer is connected to and operating from its external AC power
supply.
Standby – The computer is in Standby Mode. Any system activity such as, pressing a key on
the keyboard, touch pad, mouse, or other system activity resumes normal operation.
Hard drive/MultiBay activity– The hard drive or the drive installed in the MultiBay is being
accessed.
A
Caps lock – The Caps Lock function is enabled.
A
Blinking
Keyboard/mouse lock– When the caps lock icon is blinking, it indicates that the
keyboard/mouse lock is enabled. To resume keyboard/mouse activity, enter the User password
defined in the System Setup Program.
NUM lock – The NUM Lock function is enabled.
Video port enabled – The external monitor port is enabled.
Scroll lock– The Scroll Lock function is enabled.
Embedded numeric key pad lock – The keyboard’s embedded key pad is enabled.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-16 Overview
1.6 Keyboard Hot Keys
The hot keys are used to set up and control the computer. These keys are activated by
holding down the Fn key and pressing the desired function key. The following table
shows each hot key sequence and describes its function:
fn
+Function
esc
Places the computer in Standby Mode.
F1
Sets the computer’s operating mode to maximize battery life. A single beep is emitted when
the computer switches to this operating mode. If the computer is restarted, the system return
s
to the settings contained in the System Setup Program.
F2
Sets the computer’s operating mode to maximize performance. Two beeps are emitted when
the computer switches to this operating mode. If the computer is restarted, the system return
s
to the settings contained in the System Setup Program.
F3
Used during Power Up Self-Test (POST) to enter the System Setup Program.
F4
Enables and disables the computer’s external display port and the LCD display. There are three
display modes:
LCD Display
LCD Display and External Monitor (simulscan)
External Display
Each time this hot key combination is pressed, the computer changes to the next display
setting.
Reserved for future use.
Enables the Keyboard/Mouse Lock. To use this feature, a user password must be set. When
Keyboard/Mouse Lock is enabled, the Enter Password prompt will appear on the screen and
the Caps Lock icon found on the LCD Status Display will blink. Enter the user password t
o
disable the Keyboard/Mouse Lock.
F7
Toggles the system sound between mute and on.
F8
Enables and disables the keyboard’s embedded key pad.
continued

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overview 1-17
Keyboard Hotkeys (continued)
fn
+Function
F9
num lock
Toggles NUM Lock on and off. The computer offers two numeric input methods:
On-the-fly Numeric Input:
While Num Lock is enabled, press the Fn key to activate the embedded key pad for numeric
input. Release the Fn key to disable the embedded key pad and return the keyboard to norma
l
operation.
Intensive Numeric Input:
When Fn + F9 is used in conjunction with Fn + F8,
the embedded key pad is locked for
intensive numeric input. Disable the embedded keypad to return the keyboard to norma
l
operation.
F10
scroll lock
Toggles Scroll Lock On and Off. The Scroll Lock feature is application dependent; consult the
software user’s guide for more information on using Scroll Lock.
Increases the audio volume.
Decreases the audio volume.
Decreases the LCD screen brightness.
Increases the LCD screen brightness.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-18 Overview
1.7 Related Information
Documentation
Compaq Armada 6500 Family Reference Guide ER-PM1CC-UA
Quick Setup Guide ER-PM1CC-IM
World Wide Web
Information such as drivers, BIOS updates, and online documentation is available from
Compaq’s World Wide Web Site. The URL for the site is: http://www.compaq.com/
