Compaq AlphaServer 4100 s Instruction Manual

AlphaServer4100/4000
Firmware Release Notes
For Compaq Tru64
UNIX, DIGITAL UNIX and
OpenVMSCustomers
Revised September, 2001
SRM Console Version: V6.0-4
These release notes are for the V6.0-4 SRM console, and include documented
restrictions in V6.0-4. Firmware update instructions and other useful
information is also provided.
Firmware release notes for Windows NT AlphaServer 4100/4000 customers
are available separately. Information about where to obtain AlphaBIOS
console release notes is provided in Section 1.7 of this document.
IMPORTANT NOTE: Beginning with SRM V5.3 console firmware, the
AlphaBIOS console was relocated to a different sector in the flash rom to
accomodate Windows NT serviceability. Please read the update procedures
information, found in Chapter 2, carefully for the details on this change and
what new steps are required for updating firmware. These changes apply to
all systems and are independent of what operating system is in use.

January, 2001
The information in this publication is subject to change without notice.
COMPAQ, the Compaq log, DEC, the DEC logo, AlphaServer and VMS registered
in U.S. Patent and Trademark office. OpenVMS, Tru64, are trademarks of Compaq
Information Technologies Group, L.P. in the United States and/or countries. Microsoft
and Windows NT are trademarks of Microsoft Corporation in the United States
and/or other countries. Unix is a trademark of The Open Group in the United States
and/or other countries. PostScript is a registered trademark of Adobe Systems, Inc.
MEMORY CHANNEL is a trademark of Encore Computer. All other product names
mentioned herein may be trademarks or registered trademarks of their respective
companies.
Confidential computer software. Valid license from Compaq required for possession,
use or copying. Consistent with FAR 12.211 and 12.212, Commercial Computer
Software, Computer Software Documentation, and Technical Data for Commercial
Items are licensed to the U.S. Government under vendor’s standard commercial
license.
Compaq shall not be liable for technical or editorial errors or omissions contained
herein. The information in this document is subject to change without notice.
The limited warranties for Compaq products are exclusively set forth in the
documentation accompanying such products. Nothing herein should be
construed as constituting a further or additional warranty.
Copyright © Compaq Computer Corporation, 2001. All Rights Reserved.
FCC NOTICE: The equipment described in this manual generates, uses, and may
emit radio frequency energy. The equipment has been type tested and found to
comply with the limits for a Class A computing device pursuant to Subpart J of Part
15 of FCC Rules, which are designed to provide reasonable protection against such
radio frequency interference when operated in a commercial environment. Operation
of this equipment in a residential area may cause interference, in which case the user
at his own expense may be required to take measures to correct the interference.

Contents
PREFACE v
CHAPTER 1 FIRMWARE UPDATE INFORMATION 1–1
1.1 FIRMWARE AND OPERATING SYSTEM REVISION MATRIX 1–2
1.2 CONSOLE FIRMWARE COMPONENTS AND REVISION
INFORMATION 1–3
1.3 PCI I/O OPTION FIRMWARE COMPONENTS - REVISION
INFORMATION 1–4
1.4 CONFIGURATION UTILITY KIT AND VERSION INFORMATION 1–4
1.5 ALPHA SYSTEMS FIRMWARE QUARTERLY UPDATE KIT 1–5
1.6 ACCESSING FIRMWARE OVER THE INTERNET 1–5
1.6.1 Proper Transfer Types For Use With FAT-Format Floppy
Updates 1–6
1.7 FIRMWARE RELEASE NOTES FOR WINDOWS NT CUSTOMERS 1–6
1.8 ALPHASERVER 4100 DOCUMENTATION 1–6
CHAPTER 2 FIRMWARE UPDATE INSTRUCTIONS 2–1
2.1 UPDATING YOUR SYSTEM FIRMWARE 2–1
2.2 PREPARING FOR THE UPDATE 2–2
2.2.1 LFU command changes 2–2
2.2.2 Updating Using the Alpha Systems Firmware Update V6.0
CD 2–3
iii

Contents
2.2.3 Updating Using a FAT-Formatted Floppy Diskette 2–3
2.2.4 Updating Using an ODS2-Formatted Floppy Diskette 2–4
2.2.5 Updating Off Network Via Your Local MOP Server 2–5
2.2.5.1 Updating Off Network via BOOT command • 2–5
2.2.5.2 Updating Off Network via LFU command • 2–5
2.3 PERFORMING THE UPDATE 2–6
CHAPTER 3 THINGS YOU SHOULD KNOW THE FIRST TIME YOU
POWER ON YOUR MACHINE 3–1
3.1 MEMORY TESTS CAN TAKE A VERY LONG TIME! 3–1
3.2 SELECTING WHICH CONSOLE IS LOADED AND YOUR DISPLAY
DEVICE 3–1
3.3 CONFIGURING YOUR MACHINE PRIOR TO BOOTING 3–2
3.4 SRM CONSOLE FIRMWARE SUPPORTED BOOT DEVICES 3–4
3.5 NEW FEATURES, CHANGES AND BUGS FIXED IN THE V6.0 SRM
CONSOLE 3–4
3.6 SRM CONSOLE FIRMWARE BUGS AND RESTRICTIONS 3–5
3.7 WINDOWS NT SERVICEABILITY INFORMATION 3–5
3.7.1 Software requirements 3–5
3.7.2 Effects of Window NT Serviceability support on the update
process 3–6
3.7.3 EEPROM commands for Windows NT error logging 3–6
3.7.3.1 Build eeprom • 3–6
3.7.3.2 Show eeprom • 3–6
3.7.3.3 Clear eeprom • 3–6
3.8 ADDITIONAL NOTES FOR KZPSA CHANGES IMPLEMENTED WITH
THE V5.1 RELEASE 3–7
3.9 DIGITAL FAST ETHERWORKS PCI 10/100 (DE500) ADAPTERS AND
AUTO-NEGOTIATION 3–7
iv

Contents
3.9.1 Set EW*0_Mode Auto-Negotiate 3–8
3.9.2 Behavior Note on Systems with Multiple DE500’s 3–8
3.10 NOTE ON UNIX INSTALLATIONS 3–9
CHAPTER 4 RUNNING EISA, RAID, AND OTHER CONFIGURATION
UTILITIES 4–1
4.1 SETTING UP YOUR SYSTEM TO RUN ARC-BASED UTILITIES 4–1
4.2 USING A SERIAL LINE INTERFACE TO RUN ARC-BASED UTILITIES 4–1
4.3 RESTRICTIONS WHEN RUNNING KZPSA UTILITIES 4–2
APPENDIX A RESTORE_NVRAM AND SAVE_NVRAM A–1
A.1 SAVE NVRAM DATA IN EEROM/TOY TO A FLOPPY FILE. A–1
A.2 RESTORE NVRAM DATA TO EEROM/TOY FROM A FLOPPY FILE. A–2
TABLES
1–1 AlphaServer 4100 Firmware/Software Revision Matrix 1–2
1–2 V6.0-4 SRM Console Firmware Components and Revisions 1–3
1–3 Fail-safe Loader Kit content 1–3
1–4 I/O Module Firmware Revision Matrix 1–4
1–5 Configuration Utility Revisions 1–5
1–6 Orderable Documentation for the AlphaServer 4100 1–6
3–1 Supported Boot Devices (SRM Console V4.8 or above) 3–4
4–1 KZPSA CNFGDIAG.EXE (V1.5) Issues/Bugs With SCSI Options 4–2
v

Preface
Purpose of These Release Notes
These release notes are intended for users of the AlphaServer 4100 and
AlphaServer 4000 cabinet- and pedestal-style systems. Henceforth in
these notes, "4100" will be used to refer to both the model 4100 and model
4000. These release notes also support the DIGITAL Server 7000 Models
7300, 7305 and 7310.
This document provides release note information for the following items:
• SRM Console - system FEPROM0, sectors 3 - 15
• Loadable Firmware Update (LFU) Utility - built into SRM console
• OpenVMS Alpha PALcode - system FEPROM0, sector 1
• DIGITAL UNIX PALcode - system FEPROM0, sector 1
• Extended SROM (XSROM) - system FEPROM0 sectors 0 and 2
• Fail-safe Loader (FSL) - aforementioned XSROM sectors
• EISA Configuration Utility (ECU) - floppy diskette
• RAID Configuration Utility (RCU) - floppy and Alpha FW CD
• KZPSA Configuration/Diagnostic Utilities - Alpha FW CD
• PCI I/O Adapter Firmware for ISP1020 - shipped in SRM console
• PCI I/O Adapter Firmware for KZPSA, DEFPA, and CIPCA - Alpha
FW CD
AlphaBIOS, which resides in system FEPROM1 and is used to boot
and support Windows NT on the AlphaServer 4100, ships release notes
separately. See Section 1.7 for information about where to find AlphaBIOS
release notes.
AlphaBIOS is also used to run ECU, RCU, and various other ARC-
based utilities which ship on floppy and/or the Alpha Firmware CD.
See Chapter 4 of these release notes and the AlphaServer 4100 System
Drawer User’s Guide for instructions on how to use AlphaBIOS and run
ARC-based utilities.
System flash parts (FEPROM0 and FEPROM1) reside on the PCI
motherboard and logically hang off the EISA/XBUS.
See Table 1–1 for current revision information.
v

Preface
Conventions Used in This Guide
This document uses the following conventions:
KEY Indicates a key on your keyboard.
CTRL/key Indicates control characters. For example, Control C is
shown as CTRL/C and indicates that both the CTRL and
the Cmust be pressed simultaneously.
vi

1FirmwareUpdateInformation
This chapter provides firmware and utility revision information, as well as
information on where to find firmware update images and documentation
for your AlphaServer 4100 system.
Firmware updates are performed using the SRM console’s built-in LFU
utility. Bootable LFU images are also supported, e.g. when booting the
firmware update CD. LFU supports multiple update devices: local SCSI
CD-ROM (CDA0), local floppy (DVA0), and local network (EWA0). Other
devices are supported for the advanced user. Refer to Chapter 2 and the
AlphaServer 4100 System Drawer User’s Guide for more information about
LFU and other console commands, environment variables to set when
performing updates off a network device, and firmware update procedures
and examples.
The SRM and AlphaBIOS consoles, and associated firmware files such as
I/O option firmware, are available via customer update kits (CD-ROM). For
order information of the customer update kit please reference the Release
Notes Overview booklet included in the firmware CD kit. A pointer to
the World Wide Web (WWW) pages, which can be used to obtain interim
firmware releases of AlphaServer 4100 firmware, is available later in this
chapter.
1–1

Firmware Update Information
1.1 Firmware and Operating System Revision Matrix
Table 1–1 lists operating system versions supported by SRM console.
The firmware from this release is on the Alpha Systems Firmware Update
V6.0 CD.
Table 1–1 AlphaServer 4100 Firmware/Software Revision Matrix
Alpha Systems Firmware Update CD
Release V6.0 V5.9 V5.8 V5.7
Date June-01 Jan.-01 Aug.-00 Apr.-00
AlphaServer 4x00 Firmware
SRM Firmware V6.0-4 V5.9-5 V5.8-2 V5.7-4
AlphaBIOS Firmware V5.70-0 V5.70-0 V5.70-0 V5.70-0
OpenVMS PAL V1.21-2 V1.21-2 V1.21-2 V1.21-2
DIGITAL UNIX PAL V1.23-2 V1.23-2 V1.23-2 V1.23-2
Operating Systems
OpenVMS V7.3 V7.3
V7.2-1 V7.2-1 V7.2-1 V7.2-1
V7.2 V7.2 V7.2 V7.2
V7.1-2 V7.1-2 V7.1-2 V7.1-2
V7.1-1H1 V7.1-1H1 V7.1-1H1 V7.1-1H1
V7.1 V7.1 V7.1 V7.1
V6.2-1H3 V6.2-1H3 V6.2-1H3 V6.2-1H3
Compaq Tru64 UNIX V5.2 V5.2
V5.1 V5.1 V5.1
V5.0 V5.0 V5.0 V5.0
V4.0F V4.0F V4.0F V4.0F
DIGITAL UNIX V4.0E V4.0E V4.0E V4.0E
V4.0D V4.0D V4.0D V4.0D
V4.0B V4.0B V4.0B V4.0B
V4.0A V4.0A V4.0A V4.0A
V3.2G V3.2G V3.2G V3.2G
V3.2F V3.2F V3.2F V3.2F
Windows NT V3.51 V3.51 V3.51 V3.51
V4.0 V4.0 V4.0 V4.0
1–2

Firmware Update Information
1.2 Console Firmware Components and Revision Information
The AlphaServer 4100 is shipped with two console images - the SRM
console for Compaq Tru64 UNIX, DIGITAL UNIX and OpenVMS Alpha
customers and the AlphaBIOS console for Windows NT customers
and for running ARC-based utilities. The SRM console update image
(RHSRMROM.SYS) is a compressed file which contains the following
individual firmware images:
Table 1–2 V6.0-4 SRM Console Firmware Components and Revisions
Component Revision Information
SRM Console V6.0-4
OpenVMS Alpha PALcode V1.21-2
DIGITAL UNIX PALcode V1.23-2
Extended SROM (XSROM) V6.0
Qlogic ISP1020 Firmware V5.57.
A World Wide Web (WWW) site is provided for firmware updates. Once
the Alpha Systems Firmware Update V6.0 CD-ROM becomes available,
update firmware for the AlphaServer 4100 will be available via this update
CD. At that time, a /V6.0 directory will be created on the World Wide Web
(see Section 1.6 for details).
Serial ROM (SROM) ships in a socketed part on each AlphaServer 4100
CPU. It is reponsible for initializing and testing enough of the machine to
load Extended SROM (XSROM) from system flash ROM. The latest SROM
revision for all AlphaServer 4100 CPU types/revisions is V3.0. Versions
V1.1 and V2.0 SROMs can be used on all CPU types/revisions unless you
will be bypassing the embedded remote console function and connecting to
a high speed modem, in which case, the minimum version needed is V2.0
SROMs for alternate (non-9600) COM1 baud rate support.
XSROM is reponsible for loading the SRM console and associated PAL
code. If SROM determines that the firmware image it is supposed to load
is corrupt (checksum fails), it attempts to load the system Fail-Safe Loader
(FSL) from flash ROM. The FSL is a simple floppy loader that can be used
to load an SRM console from a floppy diskette. This loaded console can
then be used to run the AlphaServer 4100 update utility (LFU). A kit with
the FSL diskette and release notes is available. The V5.0 kit contents are
listed in Table 1–3.
Table 1–3 Fail-safe Loader Kit content
Part Number Description
QZ-00WAA-HC.5.0 AlphaServer FSL V5.0 RX23 KIT
AK-R1FYB-CA AlphaServer FSL V5.0 RX23
AV-R1FZB-TE AlphaServer Fail Safe REL NTE
The AlphaBIOS console is loaded and started by the SRM console if the
SRM console’s OS_TYPE environment variable is set to "NT" or if the
1–3

Firmware Update Information
user enters the SRM console ALPHABIOS command at the SRM console
prompt. AlphaBIOS is a separate, compressed image and is separately
updatable using LFU.
In general, both the SRM and AlphaBIOS consoles should be updated at
the same time since the two images which ship on the update CD-ROM
are typically qualified against one another.
1.3 PCI I/O Option Firmware Components - Revision Information
You can also flash update firmware on certain PCI I/O options supported
by the AlphaServer 4100 using LFU. Version V6.0-4 of the SRM console
provides support for updating the following devices’ firmware:
Table 1–4 I/O Module Firmware Revision Matrix
Name Firmware Rev Update File Used By LFU
CIPCA A420 CIPCA420.SYS
DEFPA V3.20 DFXAA320.SYS
KZPSA A12 KZPSAA12.SYS
KZPDA V5.57 RHSRMROM.SYS, ships with SRM Console 1
KZPBA V5.57 RHSRMROM.SYS, ships with SRM Console 1
1On a power-up/reset, the SRM console loads adapter firmware from console’s system
flash ROM into NVRAM on the I/O module for all Qlogic ISP1020-based PCI options
such as the KZPDA and KZPBA. One updates SRM console firmware to update
ISP1020-based PCI option firmware. V6.0-4 console ships with V5.57 firmware for
ISP1020-based adapters. Note that this only applies for SRM console booting, i.e. for
customers running DIGITAL UNIX and/or OpenVMS Alpha.
Other options, such as the KZPSC RAID controller also provide firmware
update capability. However, LFU does not support KZPSC or KZPAC
firmware updates. Refer to the Controller Installation and Standalone
Utility User’s Guide for your particular StorageWorks RAID Array
subsystem should you need to update your RAID subsystem’s firmware.
1.4 Configuration Utility Kit and Version Information
The EISA Configuration Utility (ECU) is available on separate media
(floppy disks) for use on AlphaServer 4100 systems. The RAID
Configuration Utility (RCU) ships on both floppy and the Alpha Firmware
CD. The KZPSA Configuration Utility ships on the Alpha Firmware CD.
For compatibility with this firmware release, the minimum revisions of the
configuration utilities given in Table 1–5 must be used if required.
1–4

Firmware Update Information
Table 1–5 Configuration Utility Revisions
Utility Kit No. Part No. Minimum Rev.
ECU (VMS/UNIX) QA-01YAA-HC AK-Q2CRH-CA V1.9
RCU QB-2XHAH-SB – V3.2
KZPSA Utilities
- FWUPDATE.EXE V1.4 1
- CNFGDIAG.EXE V1.5 1
1Using earlier versions of the KZPSA utilities on your AlphaServer 4100 will
corrupt your KZPSA adapter’s NVRAM and render your system unusable!
1.5 Alpha Systems Firmware Quarterly Update Kit
The Alpha Systems Firmware Update Kit ships on a CD-ROM. For
ordering information please reference the Release Notes Overview booklet
included in the firmware CD kit.
All the binary update images and release notes for the AlphaServer
4100 platform will be released in the [AS4X00], [OPTIONS], and [DOC]
directories of the Alpha Systems Firmware Update V6.0 CD-ROM.
1.6 Accessing Firmware Over the Internet
Many customers rely upon the Customer Firmware Kit quarterly update
service (includes Alpha Firmware Update CD-ROM) for their firmware
updates. Firmware updates can also be obtained via the Internet, at the
following address:
ftp://ftp.digital.com/pub/Digital/Alpha/firmware/readme.html
Using a World Wide Web browser, use the following URLs:
http://ftp.digital.com/pub/Digital/Alpha/firmware/readme.html
http://ftp.digital.com/pub/Digital/Alpha/firmware/v6.0/as4x00
http://ftp.digital.com/pub/Digital/Alpha/firmware/v6.0/options
http://ftp.digital.com/pub/Digital/Alpha/firmware/v6.0/doc
The Web pages are organized for the CD release for each platform. There
are directories for each AlphaServer platform as well as a common options
area for I/O option firmware. In addition, a /interim page is maintained
for products such as the AlphaServer 4100 which ship between Alpha
Firmware CD releases. Watch for firmware updates in the /interim/as4x00
directory as well as future CD-ROM releases.
Console firmware update images and associated files are located in the
/as4x00 directory. I/O option firmware files are accessible via the /options
directory. Release notes are accessible via the /doc directory.
1–5

Firmware Update Information
The above-mentioned readme.html file describes the overall firmware
directory structure and how the files can be downloaded and used.
Note: Make sure you copy all of the necessary files when downloading
firmware images. If updating via network (MOP), you will need
to modify the copied files’ attributes before they can be used
in a MOP server environment. See Chapter 2 for details on
downloading firmware and performing firmware updates.
1.6.1 Proper Transfer Types For Use With FAT-Format Floppy Updates
When copying files, via ftp, to be used for update via FAT-Formatted floppy
diskette you must use the ascii transfer type for the .txt files and the
binary transfer type for the .sys files. For example:
• Prior to copying the .txt files issue the ascii command at the ftp
prompt:
ftp> ascii
200 TYPE set to ASCII
ftp>
• Prior to copying the .sys files issue the bin command at the ftp prompt:
ftp> bin
200 TYPE set to IMAGE
ftp>
1.7 Firmware Release Notes for Windows NT Customers
Release notes for the AlphaBIOS console are shipped separately on the
Alpha Firmware CD in the DOC directory. The AlphaBIOS release notes
can also be found on the at the follwing URL:
http://www.compaq.com/support/files/alphant/index.html
1.8 AlphaServer 4100 Documentation
These release notes do not describe how to use the console or other
firmware. For further information about using and updating the firmware
on your machine, please refer to the orderable documentation listed in
Table 1–6.
Table 1–6 Orderable Documentation for the AlphaServer 4100
Document Title Initial Part Number
AlphaServer 4100/4000 Configuration and Installation
Guide EK-4100A-CG
AlphaServer 4000 System Drawer User’s Guide EK-4000A-UG
AlphaServer 4100 System Drawer User’s Guide EK-4100A-UG
AlphaServer 4100 Service Manual (hard copy) EK-4100A-SV
AlphaServer 4100 Service Manual (diskette) AK-QXBJA-CA
1–6

2FirmwareUpdateInstructions
The following sections provide instructions for updating your system
firmware.
2.1 Updating Your System Firmware
The SRM console’s built-in loadable firmware update utility (LFU) is used
to update your console firmware (SRM and AlphaBIOS consoles). LFU
can also be booted as a monolithic image off an update CD (e.g. using the
Alpha Firmware Systems Update CD-ROM).
IMPORTANT NOTE:
Beginning with SRM V5.3 console firmware the AlphaBIOS image was
relocated to a different sector in flash ROM. Use of the built-in LFU
required that the update procedure be repeated a second time to ensure
the AlphaBIOS was properly relocated in flash ROM. Executing the update
twice applies to SRM V5.4 or later console firmware if updating from a
version of console earlier than V5.3. If updating from SRM V5.3 console
firmware then the update does not need to be executed twice. Please read
on for more details on the update changes listed in this chapter.
Note: The LFU update method to update SRM firmware to V5.4 or later
requires the system being updated to be at or above SRM firmware
version V5.2. LFU updates from a system with SRM firmware
version V5.1 or earlier will fail to update properly and should
not be attempted. There is no problem with the Boot command
methods of update (eg. booting the CD).
The SRM firmware V5.3 files are posted to the /interim webpage
for users that do not have access to the Alpha Systems Update
Firmware CD and are updating a system, running SRM V5.1 or
earlier, via the LFU update method.
The LFU utility can also be used to update KZPSA, DEFPA, and CIPCA
firmware. Mylex DAC960 RAID options such as KZPSC and KZPAC are
not supported by LFU. Refer to the Controller Installation and Standalone
Utility User’s Guide for your particular StorageWorks RAID Array
subsystem should you need to update your RAID subsystem’s firmware.
LFU supports multiple update devices: local SCSI CD-ROM (CDA0), local
floppy (DVA0), and local network - Ethernet (EWA0) and FDDI (FWA0).
Other load devices are supported for the advanced user. Refer to the
AlphaServer 4100 System Drawer User’s Guide for more information about
LFU and other console commands, environment variables to set when
performing updates off a network device, and update procedures.
Over time, you may wish to update to newer firmware versions as features
are added, new I/O option support is added, and bug fixes are made.
Updates are typically issued about once per quarter.
2–1

Firmware Update Instructions
2.2 Preparing For The Update
If you don’t have access to the Alpha Systems Firmware Update CD, you’ll
need to copy the appropriate firmware files to a local computer system.
You will first need to locate the appropriate firmware update files. Look in
http://ftp.digital.com/pub/Digital/Alpha/firmware/V6.0 for the /as4x00,
/options, and /doc subdirectories for the files you’ll need. The list of files
required is provided below.
The SRM console’s SHOW VERSION command can be used to determine
your SRM console version. The AlphaBIOS console’s version can be
determined either by starting the AlphaBIOS console via the ALPHABIOS
command or by starting LFU via the SRM console’s LFU command. You
can then bypass the update file load sequence by pressing RETURN when
LFU asks you to specify a load device. A LIST command at the UPD>
prompt will display the current revision of AlphaBIOS (and SRM) console
firmware.
If you’ll be updating via floppy, you’ll need either a PC with a 1.44MB
compatible floppy drive or an OpenVMS machine with access to a 1.44MB
floppy drive. If you’ll be updating via network (local MOP server), you’ll
need to copy the appropriate files to your local MOP server’s MOM$LOAD
area with appropriate file protection to allow your AlphaServer 4100
system to be served by the local MOP server. You will also need to modify
the file attributes of the downloaded files. See Section 2.2.5 for more
details.
Refer to Section 1.6 for pointers to the DIGITAL Web pages for firmware
release and update information.
2.2.1 LFU command changes
Beginning with V5.3 SRM console AlphaBIOS was relocated to a new
sector in flash ROM. This relocation change affects updates via the LFU
command. Use of the "LFU" command for updates from either CD-ROM,
floppy or the network will require the process to be executed twice if
updating a system running any SRM firmware version prior to V5.3. If 5.3
or later then the LFU need only be executed once.
Note: The LFU update method will fail to properly update to V5.4 or
later on systems running firmare versions V5.1 or earlier and
must be updated to V5.3 first. Please read the information under
Section 2.1 for more details.
For console firmware updates on systems running firmware prior to V5.3
the basic steps required are as follows:
1Run LFU
2Update SRM
3Exit LFU
4Run LFU
2–2

Firmware Update Instructions
5Update AlphaBIOS
6Exit LFU
If you update via the "BOOT" command from either the CD-ROM, (eg.
"P00>>>boot dka500") or from your local MOP server’s MOM$LOAD
directory (e.g. "P00>>>boot ewa0 -fi as4100_V6_0 -fl 0,0"), then it will not
be necessary to run the update twice.
NOTE:: A downgrade to any previous version of firmware will require
performing the update procedure twice for all methods of update.
2.2.2 Updating Using the Alpha Systems Firmware Update V6.0 CD
If you have a copy of the V6.0 (or greater) CD-ROM, simply insert it into
your AlphaServer 4100’s/4000’s local CD-ROM drive. To run the update
utility, boot the CD directly by typing "BOOT DKA500" (or equivalent
CD-ROM device name).
Alternatively, you can type "LFU" at the SRM console prompt and answer
"CDA0" and "AS4X00FW"; then perform the desired update(s).
NOTE:: The update procedure must be done twice if using the LFU
command method of update and updating a system running
firmware prior to V5.3. Please view the information under
Section 2.2.1.
A readme file is provided for your convenience. If booting the CD-ROM
directly, the readme is automatically displayed. If using console’s LFU
command, the readme is only displayed upon typing "README" at the
LFU update prompt (UPD> ).
2.2.3 Updating Using a FAT-Formatted Floppy Diskette
For version V5.4 or above, the console images no longer fit on one 1.44
MB floppy diskette. Depending upon what you wish to update, you’ll need
either one, two or three 1.44MB floppy diskettes. If you wish to update
I/O option firmware only, you’ll need only a single diskette. If you wish
to update console firmware only, you’ll need two diskettes. If you wish to
update both console and I/O firmware, you’ll need three separate diskettes.
Proper transfer type must be used when files are copied via ftp. Reference
Section 1.6.1 for copying files, via ftp, that are to be used for FAT-format
floppy updates.
If you’ll be using a FAT-formatted diskette or diskettes, perform the
following steps on your PC:
• Insert a 1.44MB FAT-formatted diskette in your floppy drive.
• Copy the following files to diskette #1:
as4x00cp.sys
as4x00fw.sys
rhreadme.sys
rharcrom.sys
2–3

Firmware Update Instructions
• Copy the following files to diskette #2:
rhsrmrom.sys
• Copy the following files to diskette #3 if you’ll be updating I/O option
firmware:
as4x00io.sys
rhreadme.sys
cipca420.sys
dfxaa320.sys
kzpsaa12.sys
Be sure to copy all of the aforementioned files for the diskette(s) you
need. Once created your diskettes can then be used to update firmware by
invoking the update utility via the LFU command.
2.2.4 Updating Using an ODS2-Formatted Floppy Diskette
For V5.4 or above, the console images no longer fit on one 1.44 MB floppy
diskette. Depending upon what you wish to update, you’ll need either one,
two or three 1.44MB floppy diskettes. If you wish to update I/O option
firmware only, you’ll need only a single diskette. If you wish to update
console firmware only, you’ll need two diskettes. If you wish to update
both console and I/O firmware, you’ll need three separate diskettes.
If you will be using an ODS2-formatted diskette or diskettes, use
the following OpenVMS command procedure(s) to create your floppy
diskette(s):
If creating a diskette for updating your console only:
$!
$! make_rhods2cp_1and2.com
$!
$ inquire ignore "Insert first blank HD floppy in DVA0, then continue"
$ set verify
$ set proc/priv=all
$ init /density=hd/index=begin dva0: rhods2cp1
$ mount dva0: rhods2cp1
$ create /directory dva0:[as4x00]
$ copy as4x00fw.sys dva0:[as4x00]as4x00fw.sys
$ copy as4x00cp.sys dva0:[as4x00]as4x00cp.sys
$ copy rhreadme.sys dva0:[as4x00]rhreadme.sys
$ copy rharcrom.sys dva0:[as4x00]rharcrom.sys
$ dismount dva0:
$ set noverify
$ inquire ignore "Insert second blank HD floppy in DVA0, then continue"
$ set verify
$ set proc/priv=all
$ init /density=hd/index=begin dva0: rhods2cp2
$ mount dva0: rhods2cp2
$ copy rhsrmrom.sys dva0:[as4x00]rhsrmrom.sys
$ dismount dva0:
$ set noverify
$ exit
2–4

Firmware Update Instructions
If creating a diskette for updating your I/O option firmware only:
$!
$! make_rhods2io.com
$!
$ inquire ignore "Insert blank HD floppy in DVA0, then continue"
$ set verify
$ set proc/priv=all
$ init /density=hd/index=begin dva0: rhods2io
$ mount dva0: rhods2io
$ create /directory dva0:[as4x00]
$ create /directory dva0:[options]
$ copy as4x00fw.sys dva0:[as4x00]as4x00fw.sys
$ copy as4x00io.sys dva0:[as4x00]as4x00io.sys
$ copy rhreadme.sys dva0:[as4x00]rhreadme.sys
$ copy cipca420.sys dva0:[options]cipca420.sys
$ copy dfxaa320.sys dva0:[options]dfxaa320.sys
$ copy kzpsaa12.sys dva0:[options]kzpsaa12.sys
$ dismount dva0:
$ set noverify
$ exit
Once created your diskettes can then be used to update firmware by
invoking the update utility via the LFU command. Please read Section 2.1
for details on the LFU update method for systems being update from
version V5.1 or earlier.
2.2.5 Updating Off Network Via Your Local MOP Server
Use one of the following methods for Network updates.
2.2.5.1 Updating Off Network via BOOT command
Copy the following file to your local MOP server’s MOM$LOAD directory,
for using the BOOT command, e.g. "P00>>>boot ewa0 -fi as4100_V6_0 -fl
0,0":
as4100_V6_0.sys
2.2.5.2 Updating Off Network via LFU command
Copy all of the following files to your local MOP server’s MOM$LOAD
directory, if using the LFU command, e.g. "P00>>>lfu". Answer the
update utility questions for your load device with the network controller,
eg. "ewa0" and for the firmware files list with the default filename, eg.
"as4x00fw". Please read Section 2.1 for details on the LFU update method
for systems being update from version V5.1 or earlier.
as4x00cp.sys
as4x00fw.sys
as4x00io.sys
cipca420.sys
dfxaa320.sys
kzpsaa12.sys
rharcrom.sys
rhreadme.sys
rhsrmrom.sys
2–5

Firmware Update Instructions
Make sure the files will be accessible via your target AlphaServer 4100
system. Also, be sure not to change the names of any files if using the
SRM console LFU command update method. Downloaded files require an
additional step for MOP loads; the file attributes must be modified to a
proper VMS fixed-record format. Use the following OpenVMS command on
each downloaded file before using the files for MOP booting.
$ set file/attr=(rfm:fix,lrl:512,mrs:512,rat:none) *.sys
2.3 Performing The Update
If your machine is currently running an operating system, issue the
appropriate shutdown command to gracefully shut down your operating
system. You may need to use the front-panel Halt button (depressed, so
Halt LED is on) and a subsequent system reset to halt your machine at
the SRM console.
If running Compaq Tru64 UNIX, DIGITAL UNIX or OpenVMS Alpha, once
halted at the SRM console, reset the machine and wait for console to come
back up. Firmware updates may not work following an operating system
shutdown without a subsequent system reset. Always reset the machine
following a UNIX/VMS shutdown if you plan on performing a firmware
update. At the SRM console prompt, issue the appropriate BOOT or LFU
command to start the update process.
If running Windows NT, either select the "Update AlphaBIOS" menu item
in the Setup menu to run LFU automatically or select the SRM console
( UNIX or OpenVMS operating system) and then reset your machine to
manually start LFU via the SRM BOOT or LFU command.
The LFU command will ask you to specify a load device - the device from
which LFU will load the console and/or I/O option firmware update files.
• If local CD-ROM, answer "CDA0".
• If floppy, answer "DVA0".
• If network, answer "EWA0" if DIGITAL PCI Ethernet or "FWA0" if
DIGITAL PCI FDDI (DEFPA).
LFU will then prompt for a firmware files list file name. Use the following
guide to ensure that you have provided the appropriate response:
• If local CD-ROM, answer "AS4X00FW".
• If floppy, answer "AS4X00CP" or "AS4X00IO" depending upon whether
you wish to update only console or only I/O option firmware. You must
have the diskette with the corresponding files list in your drive.
Note: if using three diskettes, after updating off one floppy, you can
perform remaining updates off diskette #3 by re-invoking LFU via
the LFU command at the utility’s UPD> prompt and providing the
alternate firmware files list file name when requested for input.
2–6
