Component Hardware Encore Intelli-Flo EZ-Electronic User manual

®
by Component Hardware
Electronic Faucets and
EZ-Electronic™Hand Wash Station
• INSTALLATION INSTRUCTIONS
• PARTS BREAKDOWN
• MOUNTING TEMPLATE

800-526-3694 • www.encoreplumbing.com 800-526-3694 • www.encoreplumbing.com
(A) KE19-1000 Series
MOUNTING HARDWARE
ELBOW
SENSOR
CABLE
SUPPLY
HOSES
(B) KE19-4000 Series
SPOUT
FAUCET
BODY
CONNECTOR
HOSE
MIXER
VALVE
SOLENOID
(C) KE21-7000 Series
(D) KE16 Series
(E) KE25 Series
WALL
BRACKET
DRAIN
AVOID CONTACT WITH WATER DURING ASSEMBLY
TO MINIMIZE CHANCE OF WATER DAMAGE.
1.
INSTALL SPOUT ONTO FAUCET BODY (A AND B). 2.
PREPARE SINK FOR ANTI-ROTATION PIN (OPTIONAL). 3.
MARK HOLE LOCATION AS USING SUPPLIED
TEMPLATE AND DRILL APPROPRIATELY SIZED HOLE
•
INSTALL ANTI-ROTATION PIN ONTO FAUCET BODY •
PASS SENSOR CABLE THROUGH MOUNTING HOLE
AND MOUNT FAUCET ONTO SINK WITH PROVIDED
MOUNTING HARDWARE.
4.
FOR WALL MOUNT FAUCET DESIGNS (A), CONNECT
90 DEGREE ELBOW AT THE FAUCET SHANK.
5.
CONNECT CONNECTOR HOSE TO THE ELBOW (A)
OR DIRECTLY TO FAUCET SHANK (B AND C).
6.
MOUNT BELOW DECK CONTROL BOX AT APPROPRIATE
DISTANCE BELOW SINK (SO SENSOR CABLE CAN
CONNECT)
7.
USING MINIMUMTWO MOUNTING SCREWS (NOT PROVIDED)
IN OPPOSITE CORNERS.
CONNECT OTHER END OF CONNECTOR HOSE TO
THE SOLENOID.
8.
CONNECT SUPPLY HOSES TO THE MIXING VALVE. 9.
REMOVE BLACK CAP FROM CONTROL BOX CABLE AND
CONNECT CABLE TO THE SENSOR.
10.
CONNECT POWER SUPPLY (IF PROVIDED) TO THE
WALL OUTLET.
11.
FAUCET WILL START WITHIN A COUPLE OF SECONDS. 12.
AVOID CONTACT WITH WATER DURING ASSEMBLY TO MINIMIZE
CHANCE OF WATER DAMAGE.
1.
PUNCH HOLE AS PER SUPPLIED TEMPLATE. 2.
PASS SENSOR CABLE THROUGH MOUNTING HOLE AND MOUNT
FAUCET ON THE SINK WITH PROVIDED
MOUNTING HARDWARE.
3.
CONNECT 90 DEGREE ELBOW AT THE FAUCET SHANK. 4.
CONNECT CONNECTOR HOSE TO THE ELBOW. 5.
MOUNT BELOW DECK CONTROL BOX AT APPROPRIATE DISTANCE
BELOW SINK (SO SENSOR CABLE CAN
CONNECT) USING MINIMUM
6.
TWO MOUNTING SCREWS (NOT PROVIDED) IN OPPOSITE CORNERS.
CONNECT OTHER END OF CONNECTOR HOSE TO THE SOLENOID. 7.
CONNECT SUPPLY HOSES TO THE MIXING VALVE. 8.
REMOVE BLACK CAP FROM CONTROL BOX CABLE AND CONNECT
CABLE TO THE SENSOR.
9.
CONENCT POWER SUPPLY (IF PROVIDED) TO THE WALL OUTLET. 10.
FAUCET SHOULD START WITHIN COUPLE OF SECONDS. 11.
AVOID CONTACT WITH WATER DURING ASSEMBLY
TO MINIMIZE
INSTALL DRAIN ONTO SINK.
CHANCE OF WATER DAMAGE.
1.
2.
MOUNT BRACKET (MOUNTING BRACKET) ONTO
WALL. CONNECT CONNECTOR HOSE TO THE
90 DEGREE
ELBOW BEHIND SINK.
3.
MOUNT SINK ONTO THE WALL BRACKET. 4.
MOUNT BELOW DECK CONTROL BOX AT APPROPRIATE
DISTANCE BELOW SINK (SO SENSOR CABLE CAN
CONNECT)
USING MINIMUM TWO MOUNTING SCREWS
(NOT PROVIDED) IN OPPOSITE CORNERS.
5.
CONNECT OTHER END OF CONNECTOR HOSE TO
THE SOLENOID.
6.
CONNECT SUPPLY HOSES TO THE MIXING VALVE. 7.
REMOVE BLACK CAP FROM CONTROL BOX CABLE
AND CONNECT CABLE TO THE SENSOR.
8.
CONNECT POWER SUPPLY (IF PROVIDED) TO THE
WALL OUTLET.
9.
FAUCET WILL START WITHIN A COUPLE OF SECONDS. 10.
KE19 / KE21 SERIES INSTALLATION
KE16 SERIES INSTALLATION
KE25 / KE28 SERIES INSTALLATION
BELOW DECK
CONTROL BOX
CONTROL
BOX CABLE
(A) KE19-1000 Series
MOUNTING HARDWARE
ELBOW
SENSOR
CABLE
SUPPLY
HOSES
(B) KE19-4000 Series
SPOUT
FAUCET
BODY
CONNECTOR
HOSE
MIXER
VALVE
SOLENOID
(C) KE21-7000 Series
(D) KE16 Series
(E) KE25 Series
WALL
BRACKET
DRAIN
AVOID CONTACT WITH WATER DURING ASSEMBLY
TO MINIMIZE CHANCE OF WATER DAMAGE.
1.
INSTALL SPOUT ONTO FAUCET BODY (A AND B). 2.
PREPARE SINK FOR ANTI-ROTATION PIN (OPTIONAL). 3.
MARK HOLE LOCATION AS USING SUPPLIED
TEMPLATE AND DRILL APPROPRIATELY SIZED HOLE
•
INSTALL ANTI-ROTATION PIN ONTO FAUCET BODY •
PASS SENSOR CABLE THROUGH MOUNTING HOLE
AND MOUNT FAUCET ONTO SINK WITH PROVIDED
MOUNTING HARDWARE.
4.
FOR WALL MOUNT FAUCET DESIGNS (A), CONNECT
90 DEGREE ELBOW AT THE FAUCET SHANK.
5.
CONNECT CONNECTOR HOSE TO THE ELBOW (A)
OR DIRECTLY TO FAUCET SHANK (B AND C).
6.
MOUNT BELOW DECK CONTROL BOX AT APPROPRIATE
DISTANCE BELOW SINK (SO SENSOR CABLE CAN
CONNECT)
7.
USING MINIMUMTWO MOUNTING SCREWS (NOT PROVIDED)
IN OPPOSITE CORNERS.
CONNECT OTHER END OF CONNECTOR HOSE TO
THE SOLENOID.
8.
CONNECT SUPPLY HOSES TO THE MIXING VALVE. 9.
REMOVE BLACK CAP FROM CONTROL BOX CABLE AND
CONNECT CABLE TO THE SENSOR.
10.
CONNECT POWER SUPPLY (IF PROVIDED) TO THE
WALL OUTLET.
11.
FAUCET WILL START WITHIN A COUPLE OF SECONDS. 12.
AVOID CONTACT WITH WATER DURING ASSEMBLY TO MINIMIZE
CHANCE OF WATER DAMAGE.
1.
PUNCH HOLE AS PER SUPPLIED TEMPLATE. 2.
PASS SENSOR CABLE THROUGH MOUNTING HOLE AND MOUNT
FAUCET ON THE SINK WITH PROVIDED
MOUNTING HARDWARE.
3.
CONNECT 90 DEGREE ELBOW AT THE FAUCET SHANK. 4.
CONNECT CONNECTOR HOSE TO THE ELBOW. 5.
MOUNT BELOW DECK CONTROL BOX AT APPROPRIATE DISTANCE
BELOW SINK (SO SENSOR CABLE CAN
CONNECT) USING MINIMUM
6.
TWO MOUNTING SCREWS (NOT PROVIDED) IN OPPOSITE CORNERS.
CONNECT OTHER END OF CONNECTOR HOSE TO THE SOLENOID. 7.
CONNECT SUPPLY HOSES TO THE MIXING VALVE. 8.
REMOVE BLACK CAP FROM CONTROL BOX CABLE AND CONNECT
CABLE TO THE SENSOR.
9.
CONENCT POWER SUPPLY (IF PROVIDED) TO THE WALL OUTLET. 10.
FAUCET SHOULD START WITHIN COUPLE OF SECONDS. 11.
AVOID CONTACT WITH WATER DURING ASSEMBLY
TO MINIMIZE
INSTALL DRAIN ONTO SINK.
CHANCE OF WATER DAMAGE.
1.
2.
MOUNT BRACKET (MOUNTING BRACKET) ONTO
WALL. CONNECT CONNECTOR HOSE TO THE
90 DEGREE
ELBOW BEHIND SINK.
3.
MOUNT SINK ONTO THE WALL BRACKET. 4.
MOUNT BELOW DECK CONTROL BOX AT APPROPRIATE
DISTANCE BELOW SINK (SO SENSOR CABLE CAN
CONNECT)
USING MINIMUM TWO MOUNTING SCREWS
(NOT PROVIDED) IN OPPOSITE CORNERS.
5.
CONNECT OTHER END OF CONNECTOR HOSE TO
THE SOLENOID.
6.
CONNECT SUPPLY HOSES TO THE MIXING VALVE. 7.
REMOVE BLACK CAP FROM CONTROL BOX CABLE
AND CONNECT CABLE TO THE SENSOR.
8.
CONNECT POWER SUPPLY (IF PROVIDED) TO THE
WALL OUTLET.
9.
FAUCET WILL START WITHIN A COUPLE OF SECONDS. 10.
KE19 / KE21 SERIES INSTALLATION
KE16 SERIES INSTALLATION
KE25 / KE28 SERIES INSTALLATION
BELOW DECK
CONTROL BOX
CONTROL
BOX CABLE
INSTALLATION INSTRUCTIONS
(A) KE19-1000 Series
MOUNTING HARDWARE
ELBOW
SENSOR
CABLE
SUPPLY
HOSES
(B) KE19-4000 Series
SPOUT
FAUCET
BODY
CONNECTOR
HOSE
MIXER
VALVE
SOLENOID
(C) KE21-7000 Series
(D) KE16 Series
(E) KE25 Series
WALL
BRACKET
DRAIN
AVOID CONTACT WITH WATER DURING ASSEMBLY
TO MINIMIZE CHANCE OF WATER DAMAGE.
1.
INSTALL SPOUT ONTO FAUCET BODY (A AND B). 2.
PREPARE SINK FOR ANTI-ROTATION PIN (OPTIONAL). 3.
MARK HOLE LOCATION AS USING SUPPLIED
TEMPLATE AND DRILL APPROPRIATELY SIZED HOLE
•
INSTALL ANTI-ROTATION PIN ONTO FAUCET BODY •
PASS SENSOR CABLE THROUGH MOUNTING HOLE
AND MOUNT FAUCET ONTO SINK WITH PROVIDED
MOUNTING HARDWARE.
4.
FOR WALL MOUNT FAUCET DESIGNS (A), CONNECT
90 DEGREE ELBOW AT THE FAUCET SHANK.
5.
CONNECT CONNECTOR HOSE TO THE ELBOW (A)
OR DIRECTLY TO FAUCET SHANK (B AND C).
6.
MOUNT BELOW DECK CONTROL BOX AT APPROPRIATE
DISTANCE BELOW SINK (SO SENSOR CABLE CAN
CONNECT)
7.
USING MINIMUMTWO MOUNTING SCREWS (NOT PROVIDED)
IN OPPOSITE CORNERS.
CONNECT OTHER END OF CONNECTOR HOSE TO
THE SOLENOID.
8.
CONNECT SUPPLY HOSES TO THE MIXING VALVE. 9.
REMOVE BLACK CAP FROM CONTROL BOX CABLE AND
CONNECT CABLE TO THE SENSOR.
10.
CONNECT POWER SUPPLY (IF PROVIDED) TO THE
WALL OUTLET.
11.
FAUCET WILL START WITHIN A COUPLE OF SECONDS. 12.
AVOID CONTACT WITH WATER DURING ASSEMBLY TO MINIMIZE
CHANCE OF WATER DAMAGE.
1.
PUNCH HOLE AS PER SUPPLIED TEMPLATE. 2.
PASS SENSOR CABLE THROUGH MOUNTING HOLE AND MOUNT
FAUCET ON THE SINK WITH PROVIDED
MOUNTING HARDWARE.
3.
CONNECT 90 DEGREE ELBOW AT THE FAUCET SHANK. 4.
CONNECT CONNECTOR HOSE TO THE ELBOW. 5.
MOUNT BELOW DECK CONTROL BOX AT APPROPRIATE DISTANCE
BELOW SINK (SO SENSOR CABLE CAN
CONNECT) USING MINIMUM
6.
TWO MOUNTING SCREWS (NOT PROVIDED) IN OPPOSITE CORNERS.
CONNECT OTHER END OF CONNECTOR HOSE TO THE SOLENOID. 7.
CONNECT SUPPLY HOSES TO THE MIXING VALVE. 8.
REMOVE BLACK CAP FROM CONTROL BOX CABLE AND CONNECT
CABLE TO THE SENSOR.
9.
CONENCT POWER SUPPLY (IF PROVIDED) TO THE WALL OUTLET. 10.
FAUCET SHOULD START WITHIN COUPLE OF SECONDS. 11.
AVOID CONTACT WITH WATER DURING ASSEMBLY
TO MINIMIZE
INSTALL DRAIN ONTO SINK.
CHANCE OF WATER DAMAGE.
1.
2.
MOUNT BRACKET (MOUNTING BRACKET) ONTO
WALL. CONNECT CONNECTOR HOSE TO THE
90 DEGREE
ELBOW BEHIND SINK.
3.
MOUNT SINK ONTO THE WALL BRACKET. 4.
MOUNT BELOW DECK CONTROL BOX AT APPROPRIATE
DISTANCE BELOW SINK (SO SENSOR CABLE CAN
CONNECT)
USING MINIMUM TWO MOUNTING SCREWS
(NOT PROVIDED) IN OPPOSITE CORNERS.
5.
CONNECT OTHER END OF CONNECTOR HOSE TO
THE SOLENOID.
6.
CONNECT SUPPLY HOSES TO THE MIXING VALVE. 7.
REMOVE BLACK CAP FROM CONTROL BOX CABLE
AND CONNECT CABLE TO THE SENSOR.
8.
CONNECT POWER SUPPLY (IF PROVIDED) TO THE
WALL OUTLET.
9.
FAUCET WILL START WITHIN A COUPLE OF SECONDS. 10.
KE19 / KE21 SERIES INSTALLATION
KE16 SERIES INSTALLATION
KE25 / KE28 SERIES INSTALLATION
BELOW DECK
CONTROL BOX
CONTROL
BOX CABLE
KE19 / KE21 SERIES INSTALLATION
1. AVOID CONTACT WITH WATER DURING ASSEMBLY TO MINIMIZE CHANCE OF WATER DAMAGE.
2. INSTALL SPOUT ONTO FAUCET BODY (A AND B).
3. PREPARE SINK FOR ANTI-ROTATION PIN (OPTIONAL).
  •MARKHOLELOCATIONASUSINGSUPPLIEDTEMPLATEANDDRILLAPPROPRIATELYSIZEDHOLE
  •INSTALLANTI-ROTATIONPINONTOFAUCETBODY
4. PASS SENSOR CABLE THROUGH MOUNTING HOLE AND MOUNT FAUCET ONTO SINK WITH PROVIDED MOUNTING
HARDWARE.
5. FOR WALL MOUNT FAUCET DESIGNS (A), CONNECT 90 DEGREE ELBOW AT THE FAUCET SHANK.
6. CONNECT CONNECTOR HOSE TO THE ELBOW (A) OR DIRECTLY TO FAUCET SHANK (B AND C).
7. MOUNT BELOW DECK CONTROL BOX AT APPROPRIATE DISTANCE BELOW SINK (SO SENSOR CABLE CAN CONNECT)
USING MINIMUM TWO MOUNTING SCREWS (NOT PROVIDED) IN OPPOSITE CORNERS.
8. CONNECT OTHER END OF CONNECTOR HOSE TO THE SOLENOID.
9. CONNECT SUPPLY HOSES TO THE MIXING VALVE.
10. REMOVE BLACK CAP FROM CONTROL BOX CABLE AND CONNECT CABLE TO THE SENSOR.
11. CONNECT POWER SUPPLY (IF PROVIDED) TO THE WALL OUTLET.
12. FAUCET WILL START WITHIN A COUPLE OF SECONDS.

800-526-3694 • www.encoreplumbing.com 800-526-3694 • www.encoreplumbing.com
(A) KE19-1000 Series
MOUNTING HARDWARE
ELBOW
SENSOR
CABLE
SUPPLY
HOSES
(B) KE19-4000 Series
SPOUT
FAUCET
BODY
CONNECTOR
HOSE
MIXER
VALVE
SOLENOID
(C) KE21-7000 Series
(D) KE16 Series
(E) KE25 Series
WALL
BRACKET
DRAIN
AVOID CONTACT WITH WATER DURING ASSEMBLY
TO MINIMIZE CHANCE OF WATER DAMAGE.
1.
INSTALL SPOUT ONTO FAUCET BODY (A AND B). 2.
PREPARE SINK FOR ANTI-ROTATION PIN (OPTIONAL). 3.
MARK HOLE LOCATION AS USING SUPPLIED
TEMPLATE AND DRILL APPROPRIATELY SIZED HOLE
•
INSTALL ANTI-ROTATION PIN ONTO FAUCET BODY •
PASS SENSOR CABLE THROUGH MOUNTING HOLE
AND MOUNT FAUCET ONTO SINK WITH PROVIDED
MOUNTING HARDWARE.
4.
FOR WALL MOUNT FAUCET DESIGNS (A), CONNECT
90 DEGREE ELBOW AT THE FAUCET SHANK.
5.
CONNECT CONNECTOR HOSE TO THE ELBOW (A)
OR DIRECTLY TO FAUCET SHANK (B AND C).
6.
MOUNT BELOW DECK CONTROL BOX AT APPROPRIATE
DISTANCE BELOW SINK (SO SENSOR CABLE CAN
CONNECT)
7.
USING MINIMUMTWO MOUNTING SCREWS (NOT PROVIDED)
IN OPPOSITE CORNERS.
CONNECT OTHER END OF CONNECTOR HOSE TO
THE SOLENOID.
8.
CONNECT SUPPLY HOSES TO THE MIXING VALVE. 9.
REMOVE BLACK CAP FROM CONTROL BOX CABLE AND
CONNECT CABLE TO THE SENSOR.
10.
CONNECT POWER SUPPLY (IF PROVIDED) TO THE
WALL OUTLET.
11.
FAUCET WILL START WITHIN A COUPLE OF SECONDS. 12.
AVOID CONTACT WITH WATER DURING ASSEMBLY TO MINIMIZE
CHANCE OF WATER DAMAGE.
1.
PUNCH HOLE AS PER SUPPLIED TEMPLATE. 2.
PASS SENSOR CABLE THROUGH MOUNTING HOLE AND MOUNT
FAUCET ON THE SINK WITH PROVIDED
MOUNTING HARDWARE.
3.
CONNECT 90 DEGREE ELBOW AT THE FAUCET SHANK. 4.
CONNECT CONNECTOR HOSE TO THE ELBOW. 5.
MOUNT BELOW DECK CONTROL BOX AT APPROPRIATE DISTANCE
BELOW SINK (SO SENSOR CABLE CAN
CONNECT) USING MINIMUM
6.
TWO MOUNTING SCREWS (NOT PROVIDED) IN OPPOSITE CORNERS.
CONNECT OTHER END OF CONNECTOR HOSE TO THE SOLENOID. 7.
CONNECT SUPPLY HOSES TO THE MIXING VALVE. 8.
REMOVE BLACK CAP FROM CONTROL BOX CABLE AND CONNECT
CABLE TO THE SENSOR.
9.
CONENCT POWER SUPPLY (IF PROVIDED) TO THE WALL OUTLET. 10.
FAUCET SHOULD START WITHIN COUPLE OF SECONDS. 11.
AVOID CONTACT WITH WATER DURING ASSEMBLY
TO MINIMIZE
INSTALL DRAIN ONTO SINK.
CHANCE OF WATER DAMAGE.
1.
2.
MOUNT BRACKET (MOUNTING BRACKET) ONTO
WALL. CONNECT CONNECTOR HOSE TO THE
90 DEGREE
ELBOW BEHIND SINK.
3.
MOUNT SINK ONTO THE WALL BRACKET. 4.
MOUNT BELOW DECK CONTROL BOX AT APPROPRIATE
DISTANCE BELOW SINK (SO SENSOR CABLE CAN
CONNECT)
USING MINIMUM TWO MOUNTING SCREWS
(NOT PROVIDED) IN OPPOSITE CORNERS.
5.
CONNECT OTHER END OF CONNECTOR HOSE TO
THE SOLENOID.
6.
CONNECT SUPPLY HOSES TO THE MIXING VALVE. 7.
REMOVE BLACK CAP FROM CONTROL BOX CABLE
AND CONNECT CABLE TO THE SENSOR.
8.
CONNECT POWER SUPPLY (IF PROVIDED) TO THE
WALL OUTLET.
9.
FAUCET WILL START WITHIN A COUPLE OF SECONDS. 10.
KE19 / KE21 SERIES INSTALLATION
KE16 SERIES INSTALLATION
KE25 / KE28 SERIES INSTALLATION
BELOW DECK
CONTROL BOX
CONTROL
BOX CABLE
INSTALLATION INSTRUCTIONS
IMPORTANT:
When adjusting temperature, turn dial toward ‘C’ until it stops.
Then slowly begin turning toward ’H’ until desired temperature is reached.
NOTE: Dial will continue to turn past highest number.
MIXING VALVE INSTALLATION
KE25 / KE28 SERIES INSTALLATION
1. AVOID CONTACT WITH WATER DURING ASSEMBLY TO
MINIMIZE CHANCE OF WATER DAMAGE.
2. INSTALL DRAIN ONTO SINK.
3. MOUNT BRACKET (WALL BRACKET) ONTO WALL.
CONNECT CONNECTOR HOSE TO THE 90 DEGREE ELBOW
BEHIND SINK.
4. MOUNT SINK ONTO THE WALL BRACKET.
5. MOUNT BELOW DECK CONTROL BOX AT APPROPRIATE
DISTANCE BELOW SINK (SO SENSOR CABLE CAN CONNECT)
USING MINIMUM TWO MOUNTING SCREWS (NOT
PROVIDED) IN OPPOSITE CORNERS.
6. CONNECT OTHER END OF CONNECTOR HOSE TO THE
SOLENOID.
7. CONNECT SUPPLY HOSES TO THE MIXING VALVE.
8. REMOVE BLACK CAP FROM CONTROL BOX CABLE AND
CONNECT CABLE TO THE SENSOR.
9. CONNECT POWER SUPPLY (IF PROVIDED) TO THE WALL
OUTLET.
10. FAUCET WILL START WITHIN A COUPLE OF SECONDS.

800-526-3694 • www.encoreplumbing.com 800-526-3694 • www.encoreplumbing.com
Remove two boom screws as shown.
Remove boom cover exposing AC port.
Remove rubber grommet.
Connect AC power adapter.
Reinstall cover without rubber grommet.
TO CONNECT TO AC POWER

800-526-3694 • www.encoreplumbing.com 800-526-3694 • www.encoreplumbing.com
REF. MODEL NO. DESCRIPTION
1KL19-Y006 BELOW DECK ENCLOSURE ASSEMBLY
2K19-X064-A GEN. 2 PCB BOARD, BELOW DECK
3KL19-Y007-A GEN. 2 ABOVE DECK SENSOR ASSEMBLY
4K19-X068 BATTERY HOLDER
5K90-X031 BATTERY, AA 1.5V (4 PACK) - DC ONLY
6KL19-X006 SOLENOID, ELECTRONIC FAUCET
7KL19-Y023 SWIVEL FITTING
8KL19-X025 THERMOSTATIC MIXING VALVE
9KL12-Y020 WATER SUPPLY HOSE, 1/2 FIP X 3/8 OD INLET
10 KL84-604145 WATER SUPPLY HOSE, 3/8 X 3/8 OD INLET
11 K19-X033 POWER ADAPTER, U.S., 9V, 800MA, UL - AC ONLY
12 K19-X021 WASHER
13 K19-X022 NUT
14 K19-X023 LOCK WASHER
15 KL19-X024 LOW LEAD FITTING, ELBOW, 90 DEGREE
16 KL19-X001-M WALL MOUNT BODY ASSEMBLY, FOR SMALL SENSOR
17 K19-X003 GASKET, WALL MOUNT FAUCET BODY
18
KS11-12-X000 3” GOOSENECK SPOUT
KS11-12-X002 6” GOOSENECK SPOUT
KS11-12-X001 8-1/2” GOOSENECK SPOUT
19 KN50-X201-A 0.5GPM VANDAL RESISTANT AERATOR
KN50-X201-F 1.5GPM LAMINAR AND VANDAL RESISTANT AERATOR
20 KN50-X201-K KEY FOR VANDAL RESISTANT AERATOR -
TAMPER PROOF ONLY
KE19-1000 Series Intelli-Flo™Electronic Faucet
3
4
5
2
1
11
10
8
7
6
9
12
14
13
15
16
20
18
19
17

800-526-3694 • www.encoreplumbing.com 800-526-3694 • www.encoreplumbing.com
REF. MODEL NO. DESCRIPTION
1KL19-Y006 BELOW DECK ENCLOSURE ASSEMBLY
2K19-X064-A GEN. 2 PCB BOARD, BELOW DECK
3KL19-Y007-A GEN. 2 ABOVE DECK SENSOR ASSEMBLY
4K19-X068 BATTERY HOLDER
5K90-X031 BATTERY, AA 1.5V (4 PACK) - DC ONLY
6KL19-X006 SOLENOID, ELECTRONIC FAUCET
7KL19-Y023 SWIVEL FITTING
8KL19-X025 THERMOSTATIC MIXING VALVE
9KL12-Y020 WATER SUPPLY HOSE, 1/2 FIP X 3/8 OD INLET
10 KL84-604145 WATER SUPPLY HOSE, 3/8 X 3/8 OD INLET
11 K19-X033 POWER ADAPTER, U.S., 9V, 800MA, UL - AC ONLY
12 K19-X021 WASHER
13 K19-X022 NUT
14 K19-X023 LOCK WASHER
15 KL19-X004-M DECK MOUNT BODY ASSEMBLY, FOR SMALL SENSOR
16 K19-X005 GASKET, DECK MOUNT FAUCET BODY
17
KS11-12-X000 3” GOOSENECK SPOUT
KS11-12-X002 6” GOOSENECK SPOUT
KS11-12-X001 8-1/2” GOOSENECK SPOUT
18 KN50-X201-A 0.5GPM VANDAL RESISTANT AERATOR
KN50-X201-F 1.5GPM LAMINAR AND VANDAL RESISTANT AERATOR
19 KN50-X201-K KEY FOR VANDAL RESISTANT AERATOR -
TAMPER PROOF ONLY
KE19-4000 Series Intelli-Flo™Electronic Faucet
4
5
2
1
11
17
18
19
3
16
12
14
13
9
6
7
8
10
15

800-526-3694 • www.encoreplumbing.com 800-526-3694 • www.encoreplumbing.com
REF. MODEL NO. DESCRIPTION
1KL19-Y006 BELOW DECK ENCLOSURE ASSEMBLY
2K19-X064-A GEN. 2 PCB BOARD, BELOW DECK
3KL19-Y007-A GEN. 2 ABOVE DECK SENSOR ASSEMBLY
4K19-X068 BATTERY HOLDER
5K90-X031 BATTERY, AA 1.5V (4 PACK) - DC ONLY
6KL19-X006 SOLENOID, ELECTRONIC FAUCET
7KL19-Y023 SWIVEL FITTING
8KL19-X025 THERMOSTATIC MIXING VALVE
9KL12-Y020 WATER SUPPLY HOSE, 1/2 FIP X 3/8 OD INLET
10 KL84-604145 WATER SUPPLY HOSE, 3/8 X 3/8 OD INLET
11 K19-X033 POWER ADAPTER, U.S., 9V, 800MA, UL - AC ONLY
12 K19-X021 WASHER
13 K19-X022 NUT
14 K19-X023 LOCK WASHER
15 KL21-Y001-M BODY AND SHANK ASSEMBLY
16 K21-X005 GASKET, RESTROOM DECK MOUNT FAUCET BODY
17 KL50-X203-S 0.5GPM VANDAL RESISTANT AERATOR
KL50-X204-S 1.5GPM LAMINAR AND VANDAL RESISTANT AERATOR
18 KN50-X201-KS KEY FOR VANDAL RESISTANT AERATOR -
TAMPER PROOF ONLY
KE21-7000 Series Intelli-Flo™Electronic Faucet
3
4
5
2
1
11
10
8
7
6
9
13
14
12
16
18
17
15

800-526-3694 • www.encoreplumbing.com 800-526-3694 • www.encoreplumbing.com
REF. MODEL NO. DESCRIPTION
1KL19-Y006 BELOW DECK ENCLOSURE ASSEMBLY
2K19-X064-B GEN. 2 PCB BOARD, BELOW DECK
3KL19-Y007-B GEN. 2 ABOVE DECK SENSOR ASSEMBLY
4K19-X068 BATTERY HOLDER
5K90-X031 BATTERY, AA 1.5V (4 PACK) - DC ONLY
6KL19-X006 SOLENOID, ELECTRONIC FAUCET
7KL19-Y023 SWIVEL FITTING
8KL19-X025 THERMOSTATIC MIXING VALVE
9KL12-Y020 WATER SUPPLY HOSE, 1/2 FIP X 3/8 OD INLET
10 KL84-604145 WATER SUPPLY HOSE, 3/8 X 3/8 OD INLET
11 K19-X033 POWER ADAPTER, U.S., 9V, 800MA, UL - AC ONLY
12 K19-X021 WASHER
13 K19-X022 NUT
14 K19-X023 LOCK WASHER
15 KL19-X024 LOW LEAD FITTING, ELBOW, 90 DEGREE
16 FS20-101405B1 S/S HAND-SINK 10’’ X14’’ X 5’’
17 KL09-Y003 EZ SINK OUTLET (GEN 2)
18 KN50-X203-A 0.5GPM VANDAL RESISTANT AERATOR
KN50-X203-F 1.5GPM LAMINAR AND VANDAL RESISTANT AERATOR
19 KN50-X201-K KEY FOR VANDAL RESISTANT AERATOR -
TAMPER PROOF ONLY
KE25 Series Intelli-Flo™EZ Handwash Station
1
2
5
4
3
6
7
8
11
10
9
12
14
13
15
16
17
18
19

800-526-3694 • www.encoreplumbing.com 800-526-3694 • www.encoreplumbing.com
REF. MODEL NO. DESCRIPTION
1KL19-Y006 BELOW DECK ENCLOSURE ASSEMBLY
2K19-X064-B GEN. 2 PCB BOARD, BELOW DECK
3KL19-Y007-B GEN. 2 ABOVE DECK SENSOR ASSEMBLY
4K19-X068 BATTERY HOLDER
5K90-X031 BATTERY, AA 1.5V (4 PACK) - DC ONLY
6KL19-X006 SOLENOID, ELECTRONIC FAUCET
7KL19-Y023 SWIVEL FITTING
8KL19-X025 THERMOSTATIC MIXING VALVE
9KL12-Y020 WATER SUPPLY HOSE, 1/2 FIP X 3/8 OD INLET
10 KL84-604145 WATER SUPPLY HOSE, 3/8 X 3/8 OD INLET
11 K19-X033 POWER ADAPTER, U.S., 9V, 800MA, UL - AC ONLY
12 K19-X021 WASHER
13 K19-X022 NUT
14 K19-X023 LOCK WASHER
15 KL19-X024 LOW LEAD FITTING, ELBOW, 90 DEGREE
16 FS17D-10145AXZ S/S HAND SINK W/ SPLASH GUARDS
17 KL09-Y003 EZ SINK OUTLET (GEN 2)
18 KN50-X203-A 0.5GPM VANDAL RESISTANT AERATOR
KN50-X203-F 1.5GPM LAMINAR AND VANDAL RESISTANT AERATOR
19 KN50-X201-K KEY FOR VANDAL RESISTANT AERATOR -
TAMPER PROOF ONLY
KE28 Series Intelli-Flo™EZ Handwash Station
1
2
5
4
3
6
7
8
11
10
9
12
14
13
15
16
17
18
19

1.00in
25.4mm
(SINK HOLE)
.17in
4.4mm
(FOR PIN)
1.00in
25.4mm
1.00in
25.4mm
.70in
17.8mm
.88in
22.5mm
.98in
25mm
1.00in
25.4mm
1.00in
25.4mm
.17in
4.4mm
.17in
4.4mm
.18in
4.6mm
USE THIS TEMPLATE TO DRILL OR PUNCH HOLE FOR ANTI-ROTATION PIN
(WALL MOUNT FAUCET, DESIGN A)
(DECK MOUNT FAUCET, DESIGN B)
(DECK MOUNT RESTROOM FAUCET, DESIGN C)
800-526-3694 • www.encoreplumbing.com

TROUBLESHOOTING GUIDE
PROBLEM: Faucet will not turn on
POSSIBLE CAUSE DIAGNOSIS SOLUTION
LowBaery–SystemDisabled REDLEDDouble-FlashesEvery5Seconds ReplaceBaeries
PowerSupplyFailure
WeakorDeadBaeries ReplaceBaeries
OneorMoreBaeriesPolarity-Reversed CorrectlyInstallBaeries
AdapterisNotWorking VerifyOutletHasPower
ReplaceAdapter
CableNotConnected CableDisconnected ConnectCable
CableImproperlyMated ReconnectCableProperly
ElectronicPCBisDefecve PressFLUSHbuon;Watershouldow ReplacePCB
SensorisNotWorking WaveHandinFrontofSensor;LEDShouldBlink ReplaceSensor
SensorisOpcallyOccluded Soap,Scum,orObjectBlockingSensor CleanSensor
PROBLEM: Operaon Seems Errac / False Triggering Occurs
POSSIBLE CAUSE DIAGNOSIS SOLUTION
SensorisOpcallyOccluded Soap,Scum,orObjectBlockingSensor CleanSensor
RapidDriporSlightStream WaterShouldbe“OFF”WhenValveisclosed ReplaceValve
PROBLEM: Baeries Don’t Last Very Long
POSSIBLE CAUSE DIAGNOSIS SOLUTION
CheapBaeries LowBaeryREDLEDAlertOccursAeraRelavelyShort
PeriodofTime
ReplaceBaerieswithNewAlkaline
Baeriesand/orUseAdapter
BaeriesNearEnd-of-Life
INTELLI-FLO™ ELECTRONIC FAUCETS WARRANTY
Encore Plumbing Products are manufactured to a rigid code
of quality standards and subjected to extensive testing prior to
shipment. We ensure that each product that leaves our factory
is in perfect working order. With proper care this Encore Product
will provide its user years of satisfying service.
Component Hardware warrants that its Encore KE19, KE21 and
KE25 Series of electronic faucets will remain free from defects
in material and workmanship for three (3) years from the user’s
date of purchase. Liability under this limited warranty is restricted
to replacement of, or repair of, the Encore Series product or
part found to be defective. Component Hardware shall not be
responsible for labor costs or any other damages, either direct
or consequential. Encore Series products or parts which have
been altered in any manner after purchase are excluded from
this limited warranty. Component Hardware does not assume
responsibility for any damage incurred as a result of shipping.
Those claims must be led with the shipper. This warranty does
not apply in states or provinces, which do not permit restrictions
on the length of warranty or on the exclusion of direct or
consequential damages.
Replacement or repair of a product or part under this limited
warranty will be made within a reasonable time after Component
Hardware is notied of the alleged defect or, if Component
Hardware desires to inspect the allegedly defective product or
part, within a reasonable time after that inspection.
ANY WARRANTIES, REPRESENTATIONS OR STATEMENTS
BY AN AGENT OF COMPONENT HARDWARE THAT DIFFER IN
ANY WAY FROM THE TERMS OF THIS WRITTEN AGREEMENT
SHALL HAVE AND SHALL BE GIVEN NO FORCE OR EFFECT.
No defective product or part should be shipped to Component
Hardware without authorization obtained from it in advance.
Claims for unauthorized shipping expenses will not be honored.
At Component Hardware’s option, it may request return of the
allegedly defective product or part for inspection. Permitted
returns of allegedly defective products or parts under this limited
warranty shall be delivered to Component Hardware, 1890
Swarthmore Avenue, Lakewood, NJ 08701. Please mark carton
Attn: ENCORE WARRANTY DEPARTMENT.
THIS LIMITED WARRANTY IS GIVEN EXPRESSLY AND IN LIEU
OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, OF
MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE,
OR OTHERWISE, AND CONSTITUTES THE ONLY WARRANTY
MADE BY COMPONENT HARDWARE.
1890 Swarthmore Avenue • PO Box 2020, Lakewood, New Jersey 08701-4530 U.S.A.
www.componenthardware.com
®
FOR ADDITIONAL INFORMATION ON REPLACEMENT PARTS OR A LIST OF LOCAL DISTRIBUTORS
PLEASE VISIT OUR WEBSITES: www.encoreplumbing.com • www.componenthardware.com

1890 Swarthmore Ave • Lakewood, NJ • 800-526-3694 • www.componenthardware.com
®
REV. 05/2018 INS-INTELLI-FLO
