Comprehensive CSW-RGBHV88A User manual

PTN
Electronics
CSW-RGBHV88A Matrix Switchers System
m
User Manual

Notice：
This RGBHV Matrix Switchers User Manual takes example of the Matrix model
MRG88A. It can be use d as user ’s manual of other RGBHV matrix switcher
models.
This manual is only an instruction for operators, not for any maintenance u sage.
The functions described in this version are updated till Jan 2010. Any changes of
functions and parameters sin ce then will be informed separat ely. Please refer to
the dealers for the latest details.
This manual is copyright PTN Electro nics Limited. All rights reserved. No p art of
this publication may be copied or reproduced without the prior written consent of
PTN Electronics Limited.
All product function is valid till 2010-1-1

RGBHV/Stereo Audio Matrix Switcher
ii
!
Safet
y
O
p
eration Guide
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate this
equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this equipment:
• Always follow basic safety precaution to reduce the risk of re, electrical shock
and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain, moisture or install
this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any openings or
empty slots in the unit, as you may damage parts inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if it is damaged.
• Do not allow anything to rest on the power cabling or allow any weight to be
placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or openings in
the unit housing that provide ventilation and allow for sufficient space for air
circulate around the unit.

RGBHV/Stereo Audio Matrix Switcher
iii
Contents
1. INTRODUCTION................................................................................................................................ 1
1.1 About MRG Matrix Switcher System ...................................................................................... 1
1.2 MRG Matrix Switcher Models.................................................................................................. 1
2. PACKING OF THE PRODUCT........................................................................................................... 3
3. INSTALLATION .................................................................................................................................. 3
4. FRONT VIEW AND REAR VIEW OF THE PRODUCT....................................................................... 4
4.1 Front View of the 5*%+9$ ................................................................. 4
4.2 Rear View of the 5*%+9$ .................................................................. 4
4.3 Front View of the5*%+9$................................................................................ 5
4.4 Rear View of the 5*%+9$................................................................................. 5
4.5 Front View of the 5*%+9$.................................................................................................. 6
4.6 Rear View of the 5*%+9$ ................................................................................................... 6
5. EXTERNAL CONNECTION ............................................................................................................... 7
5.1 Introduction of the Input and Output Connectors................................................................. 7
5.2 Connection of RS-232 Communication Port.......................................................................... 7
5.2.1 Connection with Control Systems........................................................................................ 8
5.2.2 Connection with Computer .................................................................................................. 8
5.3 How to Connect with the Input and Output Terminals ................................................................ 8
6. OPERATION OF THE CONTROL PANEL.......................................................................................... 9
6.1 Front Panel Description........................................................................................................... 9
6.2 Command Format of the Switching Operation .................................................................... 10
6.3 Examples of Operation ............................................................................................................ 10
7. USAGE OF THE REMOTE CONTROLLER..................................................................................... 10
8. COMMUNICATION PROTOCOL AND COMMAND CODES............................................................ 11
9. TECHNICAL SPECIFICATIONS....................................................................................................... 14
10. SYSTEM DIAGRAM....................................................................................................................... 14
11. TROUBLESHOOTING & MAINTENANCE ..................................................................................... 15

RGBHV/Stereo Audio Matrix Switcher
1
1. Introduction
1.1 About MRG Matrix Switcher System
MRG series Matrix switcher is a high-performance professional computer and audio signal switcher that
can be used for cross switching of multi computer and audio signal. Independent RGBHV component
and balanced/unbalanced I/O terminals make each component signal transmit and switch separately;
this design can reduce attenuation of signal transmission to minimum and output the image and audio
signal in high-fidelity quality.
MRG series switcher mostly apply in broadcasting TV engineering, multi-media meeting room, big
screen display engineering, television education, command control center etc. It provides power-fail
locale protection function, LED indicating, A/V timing & separating switching function. With RS232
interface, it can be worked with PC, remote control system and any other far-end control system
devices. The user manual takes MRG88A as example, other models can take reference from it too.
F 1-1
1.2 MRG Matrix Switcher Models
According to different situation and users, the MRG series can be classified into the following models:
Specifications
Models Video Inputs Video Outputs Audio Inputs Audio Outputs RS232
Interface
MRG82 8 2 × × √
MRG82A 8 2 8 2 √
MRG84 8 4 × × √
MRG84A 8 4 8 4 √
MRG88 8 8 × × √
MRG88A 8 8 8 8 √
MRG164 16 4 × × √
MRG164A 16 4 16 4 √

RGBHV/Stereo Audio Matrix Switcher
Specifications
Models Video Inputs Video Outputs Audio Inputs Audio Outputs RS232
Interface
MRG168 16 8 × × √
MRG168A 16 8 16 8 √
MRG1616 16 16 × × √
MRG1616A 16 16 16 16 √
MRG248 24 8 × × √
MRG248A 24 8 24 8 √
MRG2416 24 16 × × √
MRG2416A 24 16 24 16 √
MRG2424 24 24 × × √
MRG2424A 24 24 24 24 √
MRG328 32 8 × × √
MRG328A 32 8 32 8 √
MRG3216 32 16 × × √
MRG3216A 32 16 32 16 √
MRG3224 32 24 × × √
MRG3224A 32 32 32 24 √
MRG3232 32 32 × × √
MRG3232A 32 32 32 32 √
All modules above are for combined case design.
MRG4824 48 24 × × √
MRG4832 48 32 × × √
MRG4848 48 48 × × √
MRG6424 64 24 × × √
MRG6432 64 32 × × √
MRG6448 64 48 × × √
MRG6464 64 64 × × √
MRG9664 96 64 × × √
MRG9696 96 96 × × √
MRG12864 128 64 × × √
MRG12896 128 96 × × √
MRG128128 128 128 × × √
All modules above are for separated case design, audio case is the optional accessory. There will be
wider bandwidth.

RGBHV/Stereo Audio Matrix Switcher
3
2. Packing of the Product
MRG Matrix Switcher
RS-232 Communication Cord
Power Supply Cord
CD with Application SWITCHER 2.0
3. Installation
MRG matrix switchers adopt metal shell and can be stacked with other device. Moreover, they are
rack-mountable enclosure and can be installed in the standard 19 inches case.

RGBHV/Stereo Audio Matrix Switcher
4
4. Front View and Rear View of the Product
4.1 Front View of the CSW-RGBHV88A、
4.2 Rear View of the CSW-RGBHV88A、

RGBHV/Stereo Audio Matrix Switcher
5
4.3 Front View of the CSW-RGBHV88A
4.4 Rear View of the CSW-RGBHV88A

RGBHV/Stereo Audio Matrix Switcher
6
4.5 Front View of the CSW-RGBHV88A
4.6 Rear View of the CSW-RGBHV88A
