Compu-aire CKC AYAN IV-IR NANO SERIES Quick start guide

Revision: 01 02/29/2016 Page 1
INSTALLATION AND OPERATIONAL
MAINTENANCE MANUAL
IN ROW NANO SYSTEMS
CKC AYAN IV-IR NANO SERIES
IN ROW COOLING
COMPU-AIRE, INC.
8176 BYRON ROAD, WHITTIER, CA 90606
PHONE: [phone] FAX: [phone]
Website: ww.compu-aire.com Email: [email protected]
ISO 9001-2008 REGISTERED COMPANY

Revision: 01 02/29/2016 Page 2
TABLE OF CONTENTS
SAFETY INSTRUCTIONS ................................................................................................................... 3
GENERAL ......................................................................................................................................... 4
TRANSPORTATION MODE............................................................................................................... 4
IMPORTANT –READ BEFORE INSTALLING ...................................................................................... 5
LOCATING THE UNIT.................................................................................................................... 5
ELECTRICAL DATA:....................................................................................................................... 5
NAMEPLATE DATA....................................................................................................................... 5
CONDENSATE DRAINS ................................................................................................................. 6
CONDENSATE PUMP ................................................................................................................... 6
IMPORTANT SUGGESTION* ............................................................................................................ 6
ABOUT COMPU-KOOL - AYAN IV SERIES......................................................................................... 6
TECHNICAL DATA ............................................................................................................................ 7
INSTALLATION................................................................................................................................. 8
UTILITY CONNECTIONS................................................................................................................ 8
AIR FLOW..................................................................................................................................... 8
CONNECTIONS............................................................................................................................. 8
STRUCTURAL SUPPORT ................................................................................................................... 8
ELECTRICAL SUPPORT ..................................................................................................................... 9
CONDENSATE DRAIN CONNECTION................................................................................................ 9
WATER CONNECTIONS.................................................................................................................... 9
REFERENCE.................................................................................................................................... 17
TABLE OF FIGURES
Figure 1 - System layout................................................................................................................ 10
Figure 2 –General wiring diagram................................................................................................ 11
Figure 3 - Ayan iv inrow cooling.................................................................................................... 12
Figure 4 - Front view ..................................................................................................................... 12
Figure 5 - Back view ...................................................................................................................... 13
Figure 6 - Control Panel ................................................................................................................ 13

Revision: 01 02/29/2016 Page 3
SAFETY INSTRUCTIONS
Only qualified personnel should install and service this equipment. The installation, start-up,
and servicing of heating, ventilating, and air conditioning equipment can be hazardous and
requires specific knowledge and training. Improperly installed, adjusted or altered equipment
by unqualified personnel could result in serious damage and/or death. When working on the
equipment, observe all precautions in this literature and on the tags, stickers, and labels that
are attached to the equipment as well as all local codes and safety requirements.
This user’s manual contains important safety instructions that should be followed to properly
install and maintain Compu-Aire system Compu Kool Chilled Water Ayan IV In Row Nano series.
Read this manual thoroughly before attempting to install or operate this unit. Store this
manual at safe place for future reference.
Adhere to all warnings, cautions and safety instructions on the unit and in this manual. Follow
all local codes and safety requirements to install and service this unit.
WARNING
Installation and service of this equipment should be done by qualified personnel who
have been specially trained and qualified in the installation of specific HVAC equipment.
Improper installation could result in unaccountable loss or damage. Compu Kool Chilled Water
In Row Nano series equipment requires a permanent power connection from an isolated circuit
breaker. Customer must provide earth ground to the unit per NEC, CEC and local codes as
applicable.
•Risk of high speed moving parts can cause injury or death.
•Risk of heavy unit falling over
•Risk of hot surfaces, sharp edges, splinters and exposed fasteners can cause injury
WARNING
High voltage danger!
Arc flash and electric shock hazard.
Disconnect main power supply from the feeder before working on this unit. Proceed with
caution and always wear protective equipment per NFPA 70E before working within electrical
control panel. Failure to comply can cause serious injury or death.
WARNING
Evaporator unit requires drain connections and water supply.
Do not locate these connections above any equipment that could
sustain water damage.

Revision: 01 02/29/2016 Page 4
NOTICE
•Improper storage can cause unit damage. Keep the unit upright and store it indoor.
Protect the unit from dampness, freezing temperatures and contact damage.
•Risk of overhead interference. The unit may be too tall to fit through a doorway.
Measure the unit and doorway heights and follow the installation plans to verify clearances
prior to moving the unit.
•Risk of clogged or leaking drain lines. Drain line must be inspected and maintained to
ensure that drain water runs freely through the drain system. Improper installation, application
and service practices can result in water leakage from the unit. Water leakage can cause severe
property damage and loss of critical data center equipment. Suitable leak detection system
shall be installed for the unit and water supply lines to minimize the damage.
•Risk of leaking unit coil/or piping due to freezing and/or corrosion can cause equipment
and building damage. Use proper antifreeze and inhibitors to prevent freezing and premature
coil corrosion. If required, the water or water/glycol solution shall be analyzed every six months
to determine the pattern of inhibitor depletion.
GENERAL
The Compu-Aire Compu-Kool Ayan IV In Row Nano series is a complete environmental control
system, factory wired, tested, and specially designed to provide temperature, humidity, and
dust control for computer room installations.
The unit as shipped from the factory includes a EC fan or blower/motor package, evaporator
with expansion valves, co-axial condensers, water control valve, and humidifier, reheat
elements, electrical control package, control monitor, and other specified special options.
The Ayan iV In Row Nano series captures high temperature air from the rear of the equipment
(hot aisle) and discharges conditioned air from the front of the equipment (cold aisle). All
service access is from the front or rear of the equipment. Operator controls are located on the
front of the equipment. The equipment comes completely factory assembled, piped, and wired.
TRANSPORTATION MODE
Visual inspection of the outer casing provides a simple indication of possible internal damage to
the equipment. Move the unit to the installation site in the upright position. FILE A CLAIM
WITH THE SHIPPING COMPANY IF THE SHIPMENT IS DAMAGED OR INCOMPLETE. FREIGHT
DAMAGE CLAIMS ARE THE RESPONSIBILITY OF THE RECEIVER.
Optional articles such as jack stand parts, condensate pump, and remote control panel are
packed inside the unit.

Revision: 01 02/29/2016 Page 5
IMPORTANT –READ BEFORE INSTALLING
Check the power supply. Voltage, frequency and phase must correspond to that specified on
the unit nameplate. The power supply must be able to handle the additional load imposed by
this equipment.
LOCATING THE UNIT
Consult local building codes and National Code for special installation requirements. When
installing the unit, allow sufficient space for air flow clearance, wiring and servicing the unit.
Front and rear of the unit should have a minimum clearance of 36 inches for servicing.
.
The unit you have received is very special. It is specifically designed for Computer Room
applications. Please read the following INSTRUCTIONS prior to working on the equipment.
ELECTRICAL DATA:
208v, 3 phase, 60 Hz, 460v, 3 phase, 60 Hz, 208v, 1 phase, 60 Hz, 575v, 3 phase, 60 Hz, 3 phase,
60 Hz, or 415/380v, 3 phase, 50 Hz.
Please check the voltage.
NAMEPLATE DATA
Refer to the unit name plate. It indicates all the electrical data for the unit. LOCAL ELECTRICAL
CODES OR ANY OTHER APPLICABLE CODES MUST BE COMPLIED WITH PRIOR TO WORKING IN
THE UNIT.

Revision: 01 02/29/2016 Page 6
Check you unit for the kind of reheat it has. For type C and D piping connections are required.
Make sure shut off valves are provided external to the unit.
CONDENSATE DRAINS
An internal condensate drains is provided in the unit and it should carry the water from
condensation to the drain.
CONDENSATE PUMP
(Optional): When provided it is mounted on the unit or shipped separately. To avoid any
flooding problems provide a separate power source. WIRE THE PUMP TO SHUT THE SYSTEM
OFF IN CASE OF OVERFLOW OR PUMP FAILURE. A SYSTEM CUT OFF TERMINAL IS PROVIDED IN
THE UNIT.
CHILLED WATER UNITS (CKC)
These units are factory piped with a two or three way water regulating valve. These systems
are designed for working pressure of 150 psig. Higher pressure- Refer to nameplate.
IMPORTANT SUGGESTION*
In order to have trouble free operation free operation please maintain the humidifiers,
regularly check the belts for proper tension and change filters when dirty.
For assistance, please call COMPU-AIRE, INC. at [phone]
ABOUT COMPU-KOOL -AYAN IV SERIES
The COMPU-KOOL –AYAN IV SERIES is designed to provide localized temperature and humidity
control in high heat load areas found in commercial and industrial setting. This free standing
unit operates independently of the central air conditioning system and provided auxiliary
cooling to a pre-selected environment. Completely factory assembled, piped, and wired, the
COMPU-KOOL offers flexibility features to meet virtually any floor plan.
Maintaining consistent temperature and humidity conditions requires quick response to
changing heat loads in the computer room. COMPU-KOOL meets this challenge through
constant fan operation, thus preventing stratification of room air. COMPU-KOOL constantly
monitors the return air steam for any change in space conditions; the appropriate air
conditioning mode is quickly initiated. All cooling, heating, humidification and dehumidification
controls are fully automatic. To keep noise levels at a minimum, thermal and sound barrier
insulation fully line cabinet. COMPU-KOOL is available as air, water or glycol cooled system.
COMPU-KOOL answers the need for localized environmental control.

Revision: 01 02/29/2016 Page 7
TECHNICAL DATA
AYAN IV-IN ROW COOLING SYSTEM
UNIT MODEL: CKC-412-IR NANO
COOLING CAPACITY: At 105°F DB,70.6°F WB- Entering Air Temp.
Total Capacity BTU/HR: 124,700
Sensible Capacity-BTU/HR: 123,300
Leaving Coil 68.3° FBD; 58.7° FWB
COOLING CAPACITY: At 95°F DB,67.9°F WB- Entering Air Temp.
Total Capacity BTU/HR: 99,143
Sensible Capacity-BTU/HR: 94,186
Leaving Coil 67° FBD; 58.2° FWB
CHILLED WATER COIL DATA - Aluminum Fins, 3/8" OD Copper tubing
Face Area-Sq. Ft. 5.35
Rows/FPI 3/12
CHILLED WATER DATA–At 45°F Entering Water Temp.; 55°F Leaving Water Temp.
GPM 24.9
Pressure Drop: Ft of Water (coil) 18.4
BACKWARD INCLINED DIRECT DRIVE PLENUM FANS:
Quantity 6
CFM 3,100
External Static Pressure (Inch of Water) 0”
E.C MOTOR
kW/Fan .145
Qty. 6
ELECTRICAL DATA - @ 460V/3Ph/60Hz
Full Load Amps (FLA) 7.14
Min. Circuit Ampacity (MCA) 8.09
Max. Recomm. Fuse Size (MFS) 15A
PIPING DATA- All Connections are Copper O.D.

Revision: 01 02/29/2016 Page 8
Condensate Drains 3/4”
Chilled Water Supply 3/4”
Chilled Water Return 3/4”
PHYSICAL DATA
Length 12.00”
Width 46.38”
Height 78.75”
Unit Weight (Lbs.) 250
INSTALLATION
Prior to placing the unit make sure proper clearances are available:
Front 36”
Rear 36”
UTILITY CONNECTIONS
Electrical connection access for the unit is located on the left front of the top panel and piping
connection could be brought from the rear top panel of the unit. Provide isolation shut off
valves for all pipes external to the unit.
AIR FLOW
The return air is drawn through the back of the unit and discharged into the room through the
front of the unit.
CONNECTIONS
In connecting the unit, five items must be addressed. They are
1. Structural Support
2. Electrical Supply
3. Condensate Drain Connection
STRUCTURAL SUPPORT
The unit can be installed directly on the floor or on the raised floor without the need for any
special support. The floor should be level.

Revision: 01 02/29/2016 Page 9
ELECTRICAL SUPPORT
A fused disconnect of a HVAC approved circuit breaker must be field provided and installed per
the National Electric Code. There is access to the unit for electrical connection through the unit
bottom or the lower portion of the unit back. Be sure unit is properly grounded.
A fused disconnect must be provided for the air cooled condenser for air cooled condenser for
air cooled units and dry fluid cooler for the glycol cooled units.
CONDENSATE DRAIN CONNECTION
A submersible water pump is placed on the drain pan and will active when the pump detect
water condensation and pump the water condensation out from the condensate line located
rear top panel of the unit. Field install must connect the condensate line to building drain
system properly according to the building guidelines. See Figure 5 - Back view for location of the
condensate water pump.
WATER CONNECTIONS
For water cooled units where water supply shall be either city water or cooling tower. Provide
a shut off valve in supply and return line for isolation.

Revision: 01 02/29/2016 Page 10
FIGURE 1 - SYSTEM LAYOUT

Revision: 01 02/29/2016 Page 11
Wiring Diagram
FIGURE 2 –GENERAL WIRING DIAGRAM
628-450-111
MCP SYSTEM 2200+
CA-9362
COOL ONLY
AYAN IV NANO

Revision: 01 02/29/2016 Page 12
FIGURE 3 - AYAN IV INROW COOLING
Figure 4 - Front view
Return Air
Inlet
Leveling Feet
Graphical
Display
Supply Air
Supply Air
Ecofit Fan
EC Motor
Supply Grille
Locking latch

Revision: 01 02/29/2016 Page 13
FIGURE 5 - BACK VIEW
FIGURE 6 - CONTROL PANEL
Current
Sensor
Transformer
Aux Relay
Terminal
Block
Chilled Water
Coil
Chilled Water Valve
& Actuator
Piping
Connections
SMOKE
DETECTOR
Electrical Control Panel
Microprocessor
Controller
Condensate pump

Revision: 01 02/29/2016 Page 14
START-UP AND TEST PROCEDURE
A. With all power to unit off- Check that ALL WIRING IS CORRECT.
Check that properly sized fuses are installed in the disconnect switch. Correct fuse size
and minimum circuit ampacity are listed on the unit nameplate. Now, check the wiring
connections in the Main Control Panel to see if they are tight. It is best that this be
checked prior to operating the machine. After checking, close the Main Control Panel
cover and proceed as follows:
Microprocessor Control Panel –With the system switch in the “OFF” position, apply
power to the unit. The “Power ON” light should illuminate.
B. Check for Correct Phasing
The equipment should now be checked for correct phasing required to make the blower
motor turn in the correct directions. For this test it is necessary to open the right side
doors of the unit to observe the blower and blower motor. Now, momentarily switch
the system switch to the “ON” position and then back to “OFF”. The blower motor with
have started and it is therefore possible to determine rotation. On Compu-Aire units,
the blower should be rotating in a CLOCKWISE direction. Heaters and humidifiers are
not affected by phasing.
GENERAL MAINTENANCE
General maintenance must be performed in regular intervals to provide continued operation of
the entire unit. The maintenance intervals must be determined site specifically. Use the
maintenance checklist at the end of this manual when performing maintenance. Typically, air
filters should be replaced no less than two times per year.
The filters should be checked and changed periodically. When they become dirty, an alarm is
activated the filter pressure switch. If the filters are dirty, they must be changed for efficient
operation of your system. To check the alarm indicator, cover approximately 75% of the return
air opening; the alarm should energize. If the alarm energizes prematurely or does not energize
when it should, adjust the filter switch. All doors to machine should remain closed before
determining whether an adjustment is necessary. Spare filters should be kept in stock. Filters
should be checked monthly and replaced if necessary.
The maintenance intervals must be determined site specifically. Use the maintenance checklist
provided if available when performing maintenance. In order to ensure that the system runs
trouble free for many years, a follow-up maintenance program (consisting of a minimum of two
inspections per year) should be set up. A qualified service mechanic should carry out this semi-
annual inspection. The main power supply must be disconnected and locked off to avoid
accidental startup of the equipment.

Revision: 01 02/29/2016 Page 15
(1) Check electrical components and tighten any loose connections.
(2) Check all wiring and electrical insulators.
(3) Check contactors to ensure proper operation and contact point for wear.
(4) Check that fan motors (if applicable) are operational, ensure fan blades are tight and all
mounting bolts are tight.
(5) Ensure that the condenser surface (if applicable) is cleaned and free of dirt and debris.
(6) Check the operation of the control system. Make certain that all of the safety controls are
operational and functioning properly.
(7) Check chilled water valve system. Make sure that all mechanical joints and flare nuts are
tight.
Service Parts Availability
Genuine replacement service parts should be used whenever possible. Parts may be obtained
by contacting your local sales representative or authorized distributor. Contact us 562.945.8971
TROUBLESHOOTING GUIDE
Complaint
Problem
Symptom
Action
1.
Chilled water valve is
not opening because of
loose or broken wiring.
Display shows chilled
water cooling is on or
economy cooling is on
but, the valve is closed.
Test for 24VAC at valve
motor. Check continuity
between chilled water
pins connection of the
microprocessor
controller and valve
motor. If no voltage,
replace microprocessor
setting. (refer to
supplied controller
manual-by other)
2. System does
not humidify
or does not do
so sufficiently.
Control parameters are
not set correctly or set
as expected.
System seems to
function okay
otherwise.
Refer to controller
setting and check that
all control parameters
are set correctly.
Loose or broken wiring
in low voltage circuits or
bad microprocessor
board.
Display shows
humidification
operating but, the
humidifier is not on.
Test for 24VAC at pin
connetion on controller.
If no voltage, check
wiring back to system.
3. System is on
but, no-thing
is operating.
The blower is
off.
No air flow, fire stat,
water on floor or smoke
detector alarm is
activated.
The display shows one
or more of these alarms
and the Alarm LED is on.
The system is
automatic-ally shut
down if any of these
conditions occur.
Determine what the

Revision: 01 02/29/2016 Page 16
cause is and remedy.
Then, press the Reset
button on the
controller.
4. System does
not run.
No 24VAC supply
voltage.
Power LED is not on.
Check circuit breaker in
system 24VAC circuit
and reset if necessary.
Check System cutout
switch. Test for 24VAC
at pins 1 and 2 of
controller.
TABLE 1 TROUBLESHOOTING GUIDE

Revision: 01 02/29/2016 Page 17
REFERENCE
8167 Byron Rd., Whittier, CA 90606
PH [phone] FAX [phone]
STANDARD ONE YEAR WARRANTY
Job
Name:
Job No.
Date:
We warranty this Compu-Aire, Inc. computer room unit to be free from defects in material and workmanship; our obligation being
limited to repairing or replacing at our factory any part (except as noted below) within one year from the date of shipment to the
original purchaser. Parts to be returned to us PREPAID. Proof of start-up date must be submitted to the factory.
This warranty is effective only if the unit has been installed in accordance with our instructions and connected to proper and adequate
electric, water and drain services, correctly dehydrated and placed into operation by a competent service representative.
Fan motor compressor warranty is covered by original manufacturer’s warranty and any repair or replacement should be made by the
local authorized service facility as listed the telephone book.
Maintenance and service such as replacing filters, humidifier cylinder, infra-red lamps, float valve assemblies, belts, cleaning,
lubrication, calibration and adjusting are NOT INCLUDED in this warranty.
Replacement or repair parts shall be shipped from the factory pre-paid and invoiced for the full amount. Upon receipt of warranteed
parts within 30 days with prepayment of the component and which our inspection discloses the parts are defective, and show no signs
of misuse, alterations, or abuse, full credit will be issued.
Compu-Aire, Inc. does not assume any responsibility for the labor expense for changing defective parts or replacement of any
refrigerant or other cooling medium such as glycol etc.
All parts and goods are thoroughly inspected and packed to meet the requirements of railroad freight classifications bureaus, and
under standard shippers risk, when they leave our factory. SHOULD GOODS ARRIVE DAMAGED, call the agents attention to
damage, and have same noted on freight bill. For concealed damage, demand immediate inspection from agent of the shipping
company and insist on a notation being made on freight bill.
Purchaser-User
Model Number
Serial Number
Serial Number
Serial Number
Serial Number

Revision: 01 02/29/2016 Page 18
FIELD TEST PLANS
THIS FORM MUST BE COMPLETED FOR EACH UNIT AND SENT BACK TO COMPU-AIRE.
TEST DATE START: TEST DATE COMPLETE
COMPANY PERFORMING TESTING:
ADDRESS:
PHONE NUMBER: FAX NO:
EMAIL:
TECHNICIAN’S NAME:
TECHNICIAN PHONE NO:
PROJECT NAME:
PROJECT ADDRESS:
CUSTOMER CONTACT:
UNIT MODEL:
UNIT SERIAL NO:
VOLTAGE:
UNIT TYPE:
CHILLED WATER AIR HANDLER
UNIT EQUIPPED WITH:
TYPE OF HUMIDIFIER:
HUMIDIFIER SN#: CYLINDER # KW:
TYPE OF HEAT: KW:
TYPE OF CHILLED WATER VONTROL VALVE:
CONDENSATE PUMP SN#:
FIELD CHECK
UNIT ALIGNMENT AND SECURELY MOUNTED
DOOR ALIGNMENT
NUTS FOR TIGHTNESS

Revision: 01 02/29/2016 Page 19
WIRES FOR CONNECTION TIGHTNESS
UNIT GROUND CONNECTED
HIGH AND LOW VOLTAGE WIRING CONDITION FOR ANY DAMAGE
EC FAN MOTOR ASSEMBLY
SMOKE DETECTOR
REMOTE SENSORS
CONDENSATE PUMP MOUNT
PIPING AND VALVE SUPPORTS AND AVOID ANY RUBBING PIPES
INSULATION (CHECK ALL PIPING, C.W. VALVES)
CONDENSATE DRAIN TRAP
ISOLATION VALVES INSTALLED
STRAINER INSTALLED
SUPPLY AND RETURN AIR CLERANCE AND AIR DISTRIBUTION
HUMIDIFIER WATER LINES FLUSHED
HUMIDIFIER CYLINDER IS SECURED
CHILLED WATER VALVES IS SECURED
SET CONTROLS to test operation:
TEMPERATURE SET POINT
HUMIDISTAT SETPOINT
HI LOW TEMPERATURE AND HUMIDITY SET POINTS
(NOTE ANY CHANGES MADE TO THE CONTROLLER SETTINGS)
UNIT POWER SUPPLY: Test Voltage
LINE VOLTAGE: L1-L2: L2-L3: L1-L3:
CONTROL VOLTAGE AT CONTROLLER: ___________
evap fan #1
MOTOR HP/KW: F.L.A: VOLTAGE:
MODEL # ___________________________________________________________________
AMP DRAW: L1 L2 L3
CONTROL INPUT SIGNAL MIN/MAX: VDC
evap fan #2
MOTOR HP/KW: F.L.A: VOLTAGE:
MODEL # ___________________________________________________________________
AMP DRAW: L1 L2 L3
CONTROL INPUT SIGNAL MIN/MAX: VDC
evap fan #3
MOTOR HP/KW: F.L.A: VOLTAGE:
MODEL # ___________________________________________________________________
AMP DRAW: L1 L2 L3
CONTROL INPUT SIGNAL MIN/MAX: VDC
evap fan #4
MOTOR HP/KW: F.L.A: VOLTAGE:
MODEL # ___________________________________________________________________

Revision: 01 02/29/2016 Page 20
AMP DRAW: L1 L2 L3
CONTROL INPUT SIGNAL MIN/MAX: VDC
evap fan #5
MOTOR HP/KW: F.L.A: VOLTAGE:
MODEL # ___________________________________________________________________
AMP DRAW: L1 L2 L3
CONTROL INPUT SIGNAL MIN/MAX: VDC
evap fan #6
MOTOR HP/KW: F.L.A: VOLTAGE:
MODEL # ___________________________________________________________________
AMP DRAW: L1 L2 L3
CONTROL INPUT SIGNAL MIN/MAX: VDC
REHEAT
TYPE: ELECTRIC: NO. OF STAGES: __________
HEATER AMP DRAW:
STAGE 1: L1: L2: L3:
STAGE 2: L1: L2: L3:
Humidifier
AMP DRAW: L1: ___ L2: L3:
VERIFY FILL VALVE OPERATION: ____________________
DRAIN VALVE OPERATION: ___________________________
CONDITION in 100% cooling TEST mode
SUPPLY AIR TEMPERATURE: °F RETURN AIR TEMPERATURE:
RETURN
RETURN AIR HUMIDITY: ____%
C.W. SUPPLY TEMPERATURE: _____________ ° F C.W. RETURN TEMPERATURE: _____________
° F
CHILLED WATER
WATER IN TEMP: °F WATER OUT TEMP: °F
CHILLED WATER VALVE PRT NUMBER:
______________________________________________________________________
CHILLED WATER VALVE OPERATION: MIN/MAX: VDC RANGE
Automatic Controls
CONTROLLER MODEL:
SOFTWARE REVISION: REVISION DATE:
CHECK ALL ALARMS
CALIBRATE SENSORS AS NEEDED
VERIFY POINTS LIST WITH CONTROLS CONTRACTOR
VERIFY OPERATION OF LONWORKS COMMUNICATION CARD WITH BMS
CHECK ALL ANALOG OUT PUTS
