Computime SALUS Controls AT10 User manual

Contact thermostat / Capillary thermostat
Model: AT10, AT10F
Importer:
SALUS Controls Plc
Units 8-10 Northfield Business Park
Forge Way, Parkgate, Rotherham
S60 1SD, United Kingdom
SALUS CONTROLS DISTRIBUTOR:
QL CONTROLS Sp. z o.o., Sp. k.
ul. Rolna 4,
43-262 Kobielice,
Poland
www.salus-controls.eu
SALUS Controls is a member of the Computime Group.
Inaccordance withthe product developmentpolicy,SALUSControlsplcreservestheright tochange
specifications, design, and materials used in production, presented in this manual, without prior
notice.
User manual
IV 2020
Power supply 230V AC
Max. load 16 (4) A
Output signal terminals 1/C/2 (NO/COM/NC)
Temperature adjustment range 30 – 90 °C
Dimension [mm]
105 x 50 x 45
AT10F: length of the capillary:
1200, Øof the capillary: 7
Technical informations
Montage
Changing temperature setpoint
AT10: For installation, press the thermostat rmly to the heat pipe and
x it with the supplied elastic band so that the thermostat is in direct
contact with the pipe (remove any insulation at the installation spot
before xing the sensor). Excess elastic band can be trimmed.
AT10F: Fix the thermostat to a at surface using screws. Then place the
measuring element (capillary) in the measuring sleeve, e.g. located in
the hot water tank.
To set the temperature, pull the knob towards you to release it. Then
turn the knob to the position which indicates the required temperature.
To keep this setting, press the knob lightly in the inward direction until
a click is heard.

Introduction
The AT10 contact thermostat / AT10F capillary thermostat is a mechanical
thermostat, which can be very easily installed – to the surface of the pipe
or by placing the capillary in a sleeve, e.g. of a hot water tank. It allows
to control the temperature of hot water (DHW) or central heating. It can
be used to switch connected devices on or o in relation to the measured
temperature.These can include: pumps, switching valves or boilers.
The product is compliant with the following directives: Low Voltage
Directive LVD 2014/35/EU, RoHS Directive 2011/65/EU. Full information
is available at www.saluslegal.com
Use in accordance with national and EU regulations. Use the device as
intended and do not allow it to get wet. Product for indoor use only.
Installation must be carried out by a qualied person, in accordance with
national and EU regulations.
Remove the knob (1) and loosen the large
plastic screw (2). Remove the housing cover.
Connect the cable contacts as presented in the
diagram:
C-1 terminals
C-2 terminals
1 Underoor heating protection against overheating
in case of exceeding the temperature setpoint – C-1 terminals
are opened
2 Filling the hot water (DHW) tank if the temperature in the
tank drops below the set value – C-1 terminals are closed
Underoor
heating
Product compliance
Description of electrical connections
Installation
Safety informations:
Terminal Description
C Common contact
1 NO – normally open contact
2 NC – normally closed contact
Ground
ON
OFF
0°
0°
90°
90°
OFF
ON
SETPOINT
SETPOINT
1
L
AC 230V
N
2
C
AT10
MAX
16 (4) A
1
L
AC 230V
N
2
C
AT10F
MAX
16 (4) A
Hot water
tank
NC
NC
NO
NO
