1 Product Introduction
1.1
Product overview
The Comset Router CM210Q-W is an industrial grade 3G/4G/4GX LTE WiFi Modem Router
with download speeds of up to 150 Mbps and upload speeds of up to 50 Mbps. It is one of the
few routers on the Australian market that support band B28 (700MHz)*.
The Comset Router CM210Q-W is designed to suit Australian conditions. It supports the latest
LTE Advanced technology that performs fast and reliable data communication. It enables
users to quickly create a secure and fast wireless network. It features built-in WiFi N300 with
speeds of up to 300 Mbps, dual SIM card slots for backup redundancy, one Ethernet WAN port
for fixed internet connection and two Ethernet LAN ports, as well as a GPIO with two digital
input ports and one digital output port. Other features include VPN IPSEC, PPTP (Server and
Client), L2TP and Open VPN to establish a secure connection over the 3G/4G network.
The durable and rugged design makes the CM210Q-W the router of choice for remote harsh
environments. The compact design, easy integration and rich built-in features make it suitable
for a wide range of industrial M2M applications, including industrial automation, building
automation, smart metering, security, surveillance, transportation, health, mining and
environmental monitoring.
* When it comes to mobile reception, low-frequencies are the Holy Grail. The B28 (700MHz) low-frequency
radio bandwidth, also known as Telstra 4GX and Optus 4G Plus, can reach much longer distances than high-
frequency bands and is better at penetrating solid obstacles like buildings, giving you much better indoor
reception.
1.2
Typical Application Diagram
The Comset CM210Q-W 3G/4G/4GX Router is suitable for a wide range of machine-to-
machine applications (M2M). A good example is the connection of ATM machines and POS
systems back to a server over a secure 4G connection using a secure VPN IPSEC tunnel.

CM210Q-W Router User Manual
http://www.comset.com.au
5
Figure 1-1 Network Topology
1.3
Features
The CM210Q-W supports the following:

LTE FDD B1/B2/B3/B4/B5/B7/B8/B28 and LTE TDD B40, with 3G fallback to DC-
HSPA+/HSPA+/HSPA/WCDMA B1/B2/B5/B8

IEEE802.11b/g/n N300 Wi-Fi AP function, extended support to Wi-Fi terminal,
WDS bridging, WEP, WPA/WPA2 Personal/Enterprise, TKIP/AES, Authenticated
encryption mode

Virtual data and private network (APN/VPDN）

RS-232 interface data transparent transmission and protocol conversion

On-demand dialing, including time on/off-line, voice or SMS control on/off-line,
data trigger online or link idle offline

Bandwidth limiter to limit Download and Upload speeds

TCP/IP protocol stack, Telnet, HTTP, SNMP, PPP, PPPoE, network protocol

VPN PPTP (Server and Client), L2TP, GRE, Open VPN, IPSec, HTTPs, SSH,
advanced VPN function

Configuration via a user-friendly interface using a web browser

IPv6 protocol stack (optional)

M2M terminal management platform (optional)

WDT watchdog design, keep system stable

CM210Q-W Router User Manual
http://www.comset.com.au
6
2 Hardware Installation
The images below might be slightly different from the actual product, but the specifications
are the same.
2.1
Panel:
Table 2-1 CM210 Interface
COMSET CM210
Front
Top
The Antenna interface and LED lights can be different depending on options
such as extended WiFi and GPS.

CM210Q-W Router User Manual
http://www.comset.com.au
7
Table 2-2 Router Interface
Port Instruction Remark
USIM Plug type SIM Slot, supports 1.8/3V/5V
automatic detection.
Main 3G/4G antenna, SMA connector, 50Ω.
Aux/GPS LTE MIMO antenna SMA connector,
50Ω.
GPS Optional
Wi-Fi Two Wi-Fi antennas, SMA connector.
LAN 10/100Base-TX，MDI/MDIX self-adaption.
WAN/LAN 10/100Base-TX，MDI/MDIX self-adaption. Default as LAN
Reset Reset button,(press and hold for at least 5 seconds)
PWR Power connector. 5 ～ 32V DC
I/O I/O-1 and I/O-2 are digital input. I/O-3 is digital
output.
Console RJ45-DB9 cable for CLI configuration.
2.2
LED Status
Table 2-3 Router LED indicator Status
silk-screen status Indication
Signal
Signal Solid Light LED1 indicates signal is weak (CSQ0~10).
LED2 indicates signal is good (CSQ11~19.
LED3 indicates signal is strong (CSQ20~31)
Signal 1
Blinking Dialing.
Solid Light Online.
PWR Solid Light System power operation.
WLAN
Solid light WLAN enabled, but no data communication.
Blinking quickly Data is being transmitted.
Dark WLAN disabled.
ERR
Dark System operation and LTE/3G online.
Solid Light(Red) System fail indicator. It indicates failure with SIM
card/module.
LAN Green Solid light Connected.

CM210Q-W Router User Manual
www.comset.com.au
m
10
silk-screen status Indication
Green Blinking Data in being transmitted.
Green Dark Connection is lost.
The LED indicators can be different depending on additional options such as
extended Wi-Fi, GPS function or single/double SIM.
Dimensions
Figure 2-2 CM210 Series Router Dimensions
2.3
Powering up the CM210 router
2.3.1
SIM/UIM card installation
If you are configuring a dual-SIM router, you need to insert both SIMs prior to configuring
the router.

www.comset.com.au
m
11
CM210Q-W Router User Manual
Before connecting any cables, please disconnect the power source.
2.3.2
Ethernet Cable Connection
Use an Ethernet cable to connect the LAN port of the cellular Router to the LAN port of your
PC or laptop computer.
2.3.3
Serial Port Connection
If you want to connect the router via a serial port to your laptop or any other device, you
need to prepare a serial cable or a RJ45 cable. One end connects to the computer serial
port, the other end connects to the console port of the router or the terminal block.
Before connecting the serial cable, please disconnect any power source.
2.3.4
Power Supply
The CM210 router supports a wide range of DC voltage between 5VDC and 32VDC.
2.3.5
Review
After inserting the SIM/UIM card(s) and connecting the Ethernet cable and antennas,
please connect the power adaptor or the power cable.
Please connect the antennas prior to powering up the router, otherwise you
may get a poor signal due to a mismatching impedance.
Notice:
Step 1 Check the antennas’ connection.
Step 2 Check the SIM/UIM card is inserted.
Step 3 Power up the industrial Router.

www.comset.com.au
m
12
CM210Q-W Router User Manual
3 Router Configuration
The CM210Q-W can be configured via a web interface using a web browser such as
Internet Explorer, Firefox or Google Chrome.
3.1
Configuration from a local network
To configure the CM210Q-W, please connect an Ethernet cable between the router and
your PC computer. The IP address on your PC can be a static IP address, or you can select
DHCP so that your computer can obtain a Dynamic IP address. The default IP address of the
router is 192.168.1.1. The subnet mask is 255.255.255.0. Please follow the instructions
below:
Step 1 Click “start > control panel”, find “Network Connections” icon and double click it.
Select “Local Area Connection” corresponding to the network card on this page.
Refer to the figure below.
Figure 3-3 Network Connection
Step 2 Select “Obtain an IP address automatically” or set up a fixed IP address in the
range 192.168.1.xxx(XXX can be any number between 2～254)
Step 3 Run Internet Explorer, or any other web browser, and enter 192.168.1.1 in the
address bar and press “enter”.

www.comset.com.au
m
13
CM210Q-W Router User Manual
The username is “admin” and the password is “admin”.
Figure 3-4 User Interface
3.2
Basic Configuration
Below is a screenshot of the user interface of the CM210Q-W.
Figure 3-5 Router Status GUI

www.comset.com.au
m
14
CM210Q-W Router User Manual
3.2.1
Cellular Network Configuration
Please follow the instructions below:
Step 1 Select Basic Network> Cellular. Here you can enter the APN of your SIM card.
If you have a dual-SIM router, you will need to enter the APN for both SIM1 and
SIM2. Dual SIM mode can be “SIM 1 only”, “SIM 2 only”, “Backup” or “Failover”.
Figure 3-1 Dual SIM GUI
Table 3-1 Cellular Instructions
Item Description
Enable Enable SIM card dial.
ICMP check To enable or disable “ICMP check” rules. Enable the ICMP
check and setup a reachable IP address as a destination IP.
When “ICMP check” fails, the router will switch SIM cards.
SIM Mode Select the network type.
APN APN, provided by your ISP. I.e. “telstra.internet” if using a
Telstra SIM card.
Username SIM card username is provided by your ISP. Usually leave blank.
Password SIM card password is provided by your ISP. Usually leave blank.

www.comset.com.au
m
15
CM210Q-W Router User Manual
ICMP Check and Cellular Traffic Check are different.
【ICMP Check】
If you enable ICMP, the router will automatically check whether the defined IP
address is reachable every 60s. If the IP address is unreachable and the ICMP
check fails the first time, it will check twice again at a 3s interval. If the ICMP
check fails the third time, the router will implement the “fail action” as
configured.
The Check IP is a public IP or a company server IP address.
【Cellular Traffic Check】
【Check Mode】there are three modes, Rx(Receive), Tx(Transmit) and Rx/Tx
check modes.
【Rx】The router will check the 3G/LTE cellular traffic received. If no traffic is
received within the defined check interval time, the router will implement the “fail
action” selected, cellular reconnect or reboot.
【SIM Mode】
【Fail Over】When SIM 1 fails, the router will switch to SIM 2. When SIM 2
fails, the router will switch back to SIM 1.
【SIM1 Only】Just SIM1 is available.
【SIM2 Only】Just SIM2 is available.
【Backup】SIM1 is the primary SIM. When SIM 1 fails, the router will switch
to SIM 2 and stays on SIM 2 for a set period at the end of which it will switch
back to SIM 1.

www.comset.com.au
m
16
CM210Q-W Router User Manual
Step 2 To save your configuration, please click on the “save” button.
3.2.2
LAN Settings
Please follow the instructions below:
Step 1 Select “ Basic Network>LAN”
Figure 3-2 LAN Settings GUI
Table 3-2 LAN Settings Instructions
Item Description
Router IP Address Router IP address, default IP is 192.168.1.1
Subnet Mask Router subnet mask, default mask is 255.255.255.0
DHCP Dynamic allocation IP service. When enabled, it will show
the IP address range and lease option
IP Address Range IP address range within the LAN
Lease The valid time
Step 2 Please click “save” to save the configuration. The device will reboot.

www.comset.com.au
m
17
CM210Q-W Router User Manual
3.2.3
Dynamic DNS Settings
Please follow the instructions below:
Step 1 Select “Basic Network>DDNS” to enter the DDNS settings page.
Figure 3-3 Dynamic DNS Settings
Table 3-3 DDNS Settings Instructions
Item Description
IP address The default is standard DDNS protocol. For a customised protocol,
please contact Comset. Usually, use default IP 0.0.0.0
Auto refresh
time
Set the interval for the DDNS client to obtain a new IP. We
suggest 240s or above
Service
provider
Select the DDNS service provider from the list.
Step 2 Please Click “Save” to finish.

www.comset.com.au
m
18
CM210Q-W Router User Manual
3.2.4
Routing Settings
Please follow the instructions below:
Step 1 Select “Basic Network>Routing”.
Figure 3-4 Routing Settings
Table 3-4 Routing Settings Instructions
Item Description
Destination Destination IP address.
Gateway Next hop IP address which the router will reach.
Subnet Mask Subnet mask for destination IP address.
Metric Metrics are used to determine whether one particular route should
be chosen over another.
Interface Interface from router to gateway.
Description Describes the routing function.
Step 2 Please Click “Save” to finish.

www.comset.com.au
m
19
CM210Q-W Router User Manual
3.3
WLAN Settings
3.3.1
Basic Settings
Please follow the instructions below:
Step 1 Select “WLAN>Basic Settings”
Figure 3-5 WLAN Basic Settings GUI
Table 3-5 Basic Settings Instruction
Item Description
Enable wireless Enable or Disable WiFi
Wireless mode Supports AP, AP+WDS, Bridge, Client, WDS
Wireless Network
protocol
Supports Auto, IEEE 11b/g/n selectable
SSID The default is router, but this can be changed.
Channel The channel of wireless network. We suggest to keep the default.
Channel Width 20MHZ and 40MHZ alternative
Security Supports various encryption methods
Step 2 Please click “Save” to finish.

www.comset.com.au
m
20
CM210Q-W Router User Manual
3.3.2
Wireless Filter Settings
Please follow the instructions below:
Step 1 Select “WLAN > Wireless Filter”.
Figure 3-6 Wireless Client Filter Settings GUI
The Wireless Filter allows you to permit only some clients and /or prohibit others from
connecting to the WiFi network. This feature is invalid on a wired connection.
Table 3-6 ”Wireless Client Filter” Settings Instructions
Item Description
Disable Filter Choose to disable.
Permit only the following
clients
Allows only the listed MAC addresses to connect to the
router via WiFi.
Block the following clients Prevents the listed MAC addresses from
connecting to the
router via WiFi.
Step 2 Please click “save” to finish.

www.comset.com.au
m
21
CM210Q-W Router User Manual
3.3.3
Wireless Survey
Please follow the instructions below:
Step 1 Select “WLAN> Wireless Survey” to check survey.
Figure 3-7 Wireless Survey Settings GUI
3.4
Advanced Network Settings
3.4.1
Port Forwarding
Please follow the instructions below:
Step 1 Select “Advanced Network > Port Forwarding”
Figure 3-8 Port Forwarding GUI
Table 3-7 “Port Forwarding” Instructions

www.comset.com.au
m
22
CM210Q-W Router User Manual
Item Description
Protocol Supports UDP, TCP, both UDP and TCP.
Src. Address Source IP address. Forwards only if from this IP address.
Ext. Ports
External ports. The ports to be forwarded, as seen from the
WAN.
Int. Port Internal port. The destination port inside the LAN. If blank,
the destination port is the same as Ext Ports. Only one port
per entry is supported when forwarding to a different
internal port.
Int. Address Internal Address. The destination address inside the LAN.
Description Rule brief description.
Step 2 Please click “save” to finish.
3.4.2
DMZ Settings
Please follow the instructions below:
Step 1 Select “Advanced Network> DMZ” to check or modify the relevant parameters.
Figure 3-9 DMZ GUI
Table 3-8 “DMZ” Instructions
Item Description
Destination
Address
The destination address inside the LAN.
Source
Address
Restriction
If no IP address is entered, it will allow access to all IP
addresses. If defined IP addresses are entered, it will just
allow access to the defined IP addresses.
Leave Remote
Access
