USERMANUAL
LBR100C
LOWBANDBASE/REPEATERSTATION
APRIL2016

42327RioNedo,SuiteA
Temecula,CA.92590951‐719‐3266
www.comtronixcommunications.com
NOTICESTOTHEUSER‐English
FCCPart15.19WarningStatement
THISDEVICECOMPLIESWITHPART15OFTHEFCCRULES.OPERATIONISSUBJECTTOTHEFOLLOWINGTWO
CONDITIONS:(1)THISDEVICEMAYNOTCAUSEHARMFULINTERFERENCE,AND(2)THISDEVICEMUSTACCEPTANY
INTERFERENCERECEIVED,INCLUDINGINTERFERENCETHATMAYCAUSEUNDESIREDOPERATION.
FCCPart15.21WarningStatement
NOTE:Thisequipmentgeneratesorusesradiofrequencyenergy.Changesormodificationstothisequipment
maycauseharmfulinterferenceunlessthemodificationsareexpresslyapprovedintheinstructionmanual.The
usercouldlosetheauthoritytooperatethisequipmentifanunauthorizedchangeormodificationismade.
GOVERNMENTLAWPROHIBITSTHEOPERTIONOFUNLICENSEDRADIOTRANSMITTERSWITHINTHE
TERRITORIESUNDERGOVERNMENTCONTROL.
ILLEGALOPERATIONISPUNISHABLEBYFINEORIMPRISIONMENTORBOTH.
REFERSERVICETOQUALIFIEDTECHNICIANSONLY.
Theantennasusedforthistransmittermustbefixed‐mountedonoutdoorpermanentstructuresand
installedtoprovideaseparationdistanceofatleast1.95mfromallpersons,andmustnotbeco‐located
oroperatinginconjunctionwithanyotherantennaortransmitter.
NOTE:Thisinstructionmanualcoversonlythebasicfunctionsofthetransceiver.Consult
yourdealerformoredetailedinformation.
SAFETY:Itisimportantthattheoperatorisawareof,andunderstands,hazardscommonto
theoperationofanytransceiver.
ICRSS‐GEN,Sec8.3WarningStatement‐
ThisradiotransmitterLBR100ChasbeenapprovedbyIndustryCanadatooperatewiththeantennatypeslisted
belowwiththemaximumpermissiblegainandrequiredantennaimpedanceforeachantennatypeindicated.
Antennatypesnotincludedinthislist,havingagaingreaterthanthemaximumgainindicatedforthattype,are
strictlyprohibitedforusewiththisdevice.
UnityGainpermanentlymountedantennawith50ohmsimpedance.

42327RioNedo,SuiteA
Temecula,CA.92590951‐719‐3266
www.comtronixcommunications.com
Avisàl'utilisateur‐Français
FCCPartie15.19Avertissement
Cetappareilestconformeàlapartie15desRèglesdelaFCC.Sonfonctionnementestsoumisauxdeuxconditions
suivantes:(1)cetappareilnedoitpasprovoquerd'interférencesnuisibles,et(2)cetappareildoitacceptertoute
interférencereçue,ycomprislesinterférencespouvantprovoquerunfonctionnementindésirable.
FCCPartie15.21Avertissement
Remarque:Cetéquipementproduitouutilisedel'énergiedefréquenceradio.Deschangementsoudes
modificationsapportésàcetéquipementpeutcauserdesinterférencesnuisiblesàmoinsquelesmodifications
sontexpressémentapprouvédanslemanueld'instructions.L'utilisateurpourraitperdrel'autorisation
d'exploitercetéquipementsiunemodificationnonautoriséeoutoutemodificationysoitapportée.
•LEGOUVERNEMENTLOIINTERDITL'opérationd'émetteursradiosanslicencedanslesterritoiressouscontrôle
gouvernemental.
•Opérationillégaleestpunissabled'uneamendeouIMPRISIONMENTOULESDEUX.
•CONSULTERLESERVICEÀDESTECHNICIENSQUALIFIÉSUNIQUEMENT.
•Nefaitespasfonctionnervotreémetteur‐récepteurlorsquequelqu'unestàmoinsde6piedsdel'antenne,
pouréviterlapossibilitédefréquenceradiobrûluresoublessuresphysiquesconnexes.
Remarque:Cemanuelcouvreuniquementlesfonctionsdebasedel'émetteur‐récepteur.Consultezvotre
revendeurpourdesinformationsplusdétaillées.
Sécurité:ilestimportantquel'opérateurconnaîtetcomprend,dangerscommunspourl'exploitationdetout
émetteur‐récepteur.
ICRSS‐GEN,Sec8.3Énoncéd'avertissement‐
Leprésentémetteurradio(identifierledispositifparsonnumérodecertificationousonnumérodemodèles'ilfait
partiedumatérieldecatégorieI)aétéapprouvéparIndustrieCanadapourfonctionneraveclestypesd'antenne
énumérésci‐dessousetayantungainadmissiblemaximaletl'impédancerequisepourchaquetyped'antenne.Les
typesd'antennenoninclusdanscetteliste,oudontlegainestsupérieuraugainmaximalindiqué,sontstrictement
interditspourl'exploitationdel'émetteur.
Gainunitairemontéenpermanenceantenneavecimpédancede50ohms.

42327RioNedo,SuiteA
Temecula,CA.92590951‐719‐3266
www.comtronixcommunications.com
INTRODUCTION
ThismanualcoverstheComtronixCommunicationsVHFLowBandBase/RepeaterStation.The
stationfeatures110wattcontinuousdutypoweroutput,multiplechannels,andisbasedonthe
provenKenwood690seriesRFdeck.TheLBR‐100Ciscomprisedofseparatemodulesallhoused
withinone2RUequipmenthousing.Thereceiver,exciterandPAareeachenclosedwithintheir
ownmetalhousing.Eachoneisthenmounteddirectlyonthelargeupperheatsink.A
microprocessor‐controlledinterfacemodulecontrolsthechannelselection,LCDDisplay,timers,
interfacesandsignalingfeatures.
Allprogrammingandalignmentofthestationiscompletedbytheserviceshoptechnician.
Therearenointernaluseradjustmentsinthestation.
SpecificationsofLBR‐100VHFLowBandContinuousDutyBase/Repeater
FrequencyRange39.0–50.0Mhz
160channels
TransmitPowertechnicianprogrammablefrom45to110watts
FrequencyStability.0005%(‐22Fto+140F)
ChannelStep5khz
Emission16K0F3E
TX/RXSignalingCTCSSandDCS
ReceiverSensitivity.35uv(12dbSINAD)
ReceiverSelectivity85dB
ReceiverIMD80dB
Occupiesonly2RU(3.5”)
LocalSpeakerincluded
LocalHandMicrophoneincluded

42327RioNedo,SuiteA
Temecula,CA.92590951‐719‐3266
www.comtronixcommunications.com
Theoryofoperation
Theunithastwoexternalantennaportsontherearoftheunit.Oneisforthetransmitter(TX
Ant)andtheotherisforthereceiver(RXAnt).Theseportswouldbenormallyattachedtothe
customersuppliedduplexer.
WARNING:WHENTESTINGTHEUNITBESURETHEDUPLEXERISTUNEDPRIORTOAPPLYING
RFPOWERFROMTHETRANSMITTER,ASRFINEXCESSOF0DBMINTOTHERECEIVER
ANTENNAPORTWILLCAUSEDAMAGETOTHERECEIVERFROMEND.
TherepeaterisconfiguredwithoneRFPoweramplifierassemblywhichrequiresapproximately
100mwofdrivefromthemodulemarked“Transmitter”whichcontainsthecontrollogicand
theTX‐RXboard.The100mwofRFisthenroutedtothePAAmplifierassemblyandamplifies
thatsignalto45‐110watts,whichisthenroutedtotheTXAntennaport.
TherepeaterisconfiguredwithasecondcontrollogicandTX‐RXboardinwhichthereceiver
onlyisusedforfullduplexoperation.ThereceiverfrontendhastheadditionofaFrontend
protectorcircuitaddedtolimittheRFinput.ThereceivesignalenterstherepeaterfromtheRX
antennaport(fromduplexer)anditroutedtothemodulemarked“Receiver”.Thereceive
signalisprocessedandtherecoveredreceiveaudioisthenroutedtotheRearPanelPCBand
theRM‐1Repeatercontroller.
Stand‐aloneRepeater
Duringnormaloperationasastand‐alonerepeater,theunitwillrepeatalltrafficaslongasthe
properRFsignalwiththenecessaryCTCSSorDCScodeispresentandthe“RadioAuxI/O”
jumperplugisinplace.
DCPower
TheRadiorequiresagoodsourceof13.8VDCandshoulddrawlessthan20ampsduring
transmit.

42327RioNedo,SuiteA
Temecula,CA.92590951‐719‐3266
www.comtronixcommunications.com
LBR-100 C QUICK SETUP
1. Unpack unit from carton and Locate the DC Power cord, Hand Microphone for
testing and 9 Pin Molex jumper plug.
FRONT VIEW OF REPEATER
REAR VIEW OF REPEATER

42327RioNedo,SuiteA
Temecula,CA.92590951‐719‐3266
www.comtronixcommunications.com
ItemFunction
1DB‐25FRPTRXAccessoryInterfaceconnector(seechartbelowforfunctions)
2DB‐25FRPTTXAccessoryInterfaceconnector(seechartbelowforfunctions)
3ProgrammingPort
4DCPowerConnector
5RADIOAUXI/O
6DCPowerFuse(30A)
7 RFRXantennaconnector
8 RFTXAntennaconnector
DB‐25FAccessoryInterfaceConnectorFunctionsChart
PinNameI/OFunctionPin NameI/O Function
2AI1IAUXINPUT115RSV1‐ RESERVED
3AI2IAUXINPUT216RSV2‐ RESERVED
4AI3IAUXINPUT317AFOOLINELEVELRXAUDIO
5AI4IAUXINPUT4 18E‐ GROUND
6AI5IAUXINPUT5(EXTPTT)19DEOODETECTOROUT
7E‐ GROUND20AO1OAUXOUT1‐TOR
8AO20AUXOUT2‐COR21A03OAUXOUT3
9TXD2OSER.DATAOUT22AO4OAUXOUT4
10RXD2ISERDATAIN23SQOSQUELCH“L”BUSY
11TXSOHIONTX24SPMI“L”MUTESPK
12MCMILOTOMUTEMIC25ME‐ MICGROUND
13MI/DIIMI=600OHMREMMIC
IN

42327RioNedo,SuiteA
Temecula,CA.92590951‐719‐3266
www.comtronixcommunications.com
2. Remove 9 pin Molex Jumper plug from RADIO AUX I/O jack (#5) for simplex
operation. NOTE this is installed for Repeater Full Duplex operation only.
3. Install DC Power Cord to Jack on rear of repeater marked 12VDC (#4) Input-be
sure to observe polarity (should only fit correctly)
4. Connect DC Power cord to power supply and turn on power supply.
NOTE: THIS EQUIPMENT OPERATES ON 13 VDC NEGATIVE GROUND ONLY
5. Connect RF cables to the TX (8) and RX (7) ports to user supplied antennas or
duplexer.
6. Equipment is now ready to turn on.
ItemFunction
1Poweron‐offswitch
2ProgrammableFunction–Presson/offMonitor
3ProgrammableFunction–PressonthenuseCH/SQLtoadjustsquelchlevel
4ProgrammableFunction–NotassignedPF‐3
5ProgrammableFunction–NotassignedPF‐4
6ProgrammableFunction–NotassignedPF‐5
7ProgrammableFunction–NotassignedPF‐6
8LocalTestspeaker
9LocalTestMicrophone
10ChannelActivityIndicatorGREENLED
11TransmitFunctionREDLED
12LCDDisplay
13LocalVolumeControl
14CH/SQLRotaryswitchforchannelup/downorSquelchlevelup/down
15RedLEDPowerOnIndicator
16GreenLEDDCPoweravailablefrompowerDCsource
17HeadsetSpeakerJack

42327RioNedo,SuiteA
Temecula,CA.92590951‐719‐3266
www.comtronixcommunications.com
7. Press #1 Power on button on front panel as shown-Repeater should turn on.
8. Using #14, rotate and select the desired channel (see the display) (12).
9. If necessary adjust the local volume (13) to the desired level (does not effect
repeater audio level).
10.If local operation is used, locate the microphone and plug into Microphone jack
(9).
11.If repeater operation is desired be sure that the 9 Pin Molex jumper plug in in
place.
When the equipment is not working correctly contact your local service technician or
you may contact the manufacturer directly.
COMTRONIX COMMUNICATIONS INC.
42327 RIO NED SUITE A
TEMECULA, CA. 92590
951-719-3266
Email: [email protected]
April 2016
