Concept Seating 3142r1 HIGH BACK User manual

3205 N 124th St )BROOKFIELD, WI 53005 )800-892-5563 )[e-mail] )CONCEPTSEATING.COM
Division of Laacke & Joys Company, LLC.
3142r1 HIGH BACK
ASSEMBLY INSTRUCTIONS &
OPERATING MANUAL

3205 N 124th St )BROOKFIELD, WI 53005 )800-892-5563 )[e-mail] )CONCEPTSEATING.COM
Division of Laacke & Joys Company, LLC.
Please check that all parts listed are included:
The items pictured above (7 Leg Base with casters attached, Gas Cylinder and Grease Packet) are packed
together in the base box which is separate from your chair box.
C-Loop Arms Swing Arms
One (1) Left Armrest and one (1) Right Armrest are packaged in a separate box which can be found inside
the large chair box.
Two (2) Armrest Handwheels have already been installed on the bottom of the seat, which can be found
inside the large chair box.
OR
3142r1 HIGH BACK
CHAIR ASSEMBLY INSTRUCTIONS

3205 N 124th St )BROOKFIELD, WI 53005 )800-892-5563 )[e-mail] )CONCEPTSEATING.COM
Division of Laacke & Joys Company, LLC.
STEP 1
1. Open the base box.
2. Remove the 7 Leg Base with Casters attached and place on the floor.
3. Remove the plastic bag containing the Cylinder and Grease Packet from the box.
4. Apply ½ of Grease Packet around the inner surface of the base hub (the hole located in the center
of the base). SAVE THE BALANCE OF THE GREASE TO BE USED IN THE CHAIR ASSEMBLY.
5. Insert the cylinder into the base making sure it is snug.
NOTE: DO NOT POUND THE CYLINDER INTO THE BASE.
STEP 2
1. Open the Chair Box and remove the smaller armrest box from inside.
2. Remove the chair and place it flat on its back.
3. Remove the plastic bag from the lower portion of the chair and lay the bag on the floor to keep your
chair clean. NOTE: The Serial Number can be found on the bottom of the Chair Assembly for reference.
4. Turn the chair over so it is face-down on the plastic bag.
STEP 3
1. Unthread the Armrest Handwheels from the underside of the seat.
2. Slide the Left and Right Armrest brackets into their respective slots.
3. Rethread the Armrest Handwheels into the bottom of the chair, taking care not to strip the threads. If
properly aligned, the handwheel should turn with little effort.
STEP 4
1. Apply the balance of Grease Packet around the inner surface of the Tilt Mechanism where the
Cylinder will be placed.
2. Place the Chair Assembly onto the Cylinder/Base Assembly from STEP 1.
STEP 5
Adjust the Tilt Mechanism, Height and Tension Controls, as well as the Armrest and Lumbar to the desired
positions.

3205 N 124th St )BROOKFIELD, WI 53005 )800-892-5563 )[e-mail] )CONCEPTSEATING.COM
Division of Laacke & Joys Company, LLC.
To prevent damage while in transit, the headrest is not attached to the chair prior to shipping.
The headrest will be found at the bottom of the chair box after the chair is removed. The headrest can
be attached easily without tools. To attach the headrest:
STEP 1: Center the base of the headrest with the
molded plastic shell. You will notice four
mating pairs of Velcro®.
STEP 3: Press on the areas where the pairs of
mating Velcro®are located to secure the
headrest to the shell.
Enjoy your CONCEPTSEATING chair!
STEP 2: Tip the headrest backwards into position,
ensuring the edges of the headrest fit just
inside the ridge of the shell.
3142r1 HIGH BACK
HEADREST ASSEMBLY INSTRUCTIONS

3205 N 124th St )BROOKFIELD, WI 53005 )800-892-5563 )[e-mail] )CONCEPTSEATING.COM
Division of Laacke & Joys Company, LLC.
CHAIR ADJUSTMENTS FOR 3142r1 HIGH BACK CHAIR
SEAT ADJUSTMENT
The seat tilt locks into seven positions; slightly forward, level and five reclined.
TO UNLOCK
• Locate the gray button under the right side of the seat.
• Push the button in and release. DO NOT push in and move; wait for the chair to unlock.
NOTE – you will hear a loud clicking noise, indicating the chair has been unlocked
• Lean back, then forward to release the pin. The chair will be in a free float mode.
TO LOCK
• Determine the desired position.
• Push the button in and release.
NOTE – you will hear a loud clicking noise, indicating the chair has been locked into one of the
7 positions.
TENSION ADJUSTMENT
• Locate the large round knob under the seat on the front of the tilt mechanism.
• Turn the knob counterclockwise to reduce the recline tension.
• Turn the knob clockwise to increase the recline tension.
HEIGHT ADJUSTMENT
• Locate the paddle under the right side of the seat.
• Rotate the paddle to raise or lower the seat. NOTE: You must remove your weight when raising
the seat.
Enjoy your chair with confidence. It is a quality product backed by a great warranty. It is not
necessary to register your chair for warranty. We did that for you at the time of shipment.

24/7 Intensive Use Chair Warranty Policy
6/10 YEAR WARRANTY
800.892.5563
CONCEPTSEATING.COM Form # CS1002 Warranty Policy Rev. 2, 08/02/2017
Division of Laacke & Joys Company, LLC.
Laacke & Joys Company LLC purchased the name and assets of Concept Seating Inc. as of
February 29, 2012. All liabilities before this date are the responsibility of the previous owners. To
assist and support the previous customers of Concept Seating Inc. Laacke & Joys Company LLC
will warranty parts only on chairs produced between February 28, 2009 and February 28, 2012.
On chairs manufactured on and after February 29, 2012 our warranty is as follows. All components
of the 24/7 Intensive Use Chair are warranted for 6 years. Shipping costs are paid by Concept
Seating for the first 2 years of the warranty with the customer responsible for all shipping costs
after 2 years.
What will void the warranty?
1. Abuse of the chair or it’s components as determined by Concept Seating warranty department.
2. Use of models 3142, 3142r1, 3150(HR), or 3152(HR) by persons weighing over 550 lbs, or
use of model 3156(HR) by persons weighing more than 800 pounds
3. Not following manufacturer’s assembly, operating and maintenance procedures.
4. Any invoices not being paid in full and within terms.
Concept Seating warrants to the original purchaser, from the original date of manufacture, that
its steel seat pan shall be free from defects in material and workmanship under normal 24/7 use
for a period of 10 years.
The warranty further covers:
• All components of the chair shall be free from defects in material and workmanship under
normal 24/7 use for a period of 6 years from date of manufacture.
• The steel foot ring and 200mm cylinder on our 24/7 stool models for 2 years.
• Shipping charges on warranty parts within the continental US for 2 years.
Concept Seating will have no warranty obligation if our product has been subject to abuse,
alteration, misuse, negligence or accident or if the customer fails to perform the recommended
preventative maintenance.
Damage caused by the carrier in-transit is a freight claim which is handled separately.
All warranty claims must be submitted on our warranty claim form which can be found on our
website, www.conceptseating.com.
