Condair US-Series Installation and operating instructions

IMPORTANT! Read and save these instructions. This manual to be left with the equipment.
2588705_A_EN_1811_UB_IOM
INSTALLATION, OPERATION,
AND MAINTENANCE MANUAL
Ultrasonic Blower Pack
US-Series
Humidification and Evaporative Cooling

Thank you for choosing Condair
Installation date (DD/ MM / YYYY):
Commissioning date (DD / MM / YYYY):
Site:
Model:
Serial number:
Proprietary Notice
This document and the information disclosed herein are proprietary data of Condair Ltd. Neither this
document, nor the information contained herein shall be reproduced, used, or disclosed to others
without the written authorization of Condair Ltd., except to the extent required for installation, operation
or maintenance of the customer's equipment.
Liability Notice
Condair Ltd. does not accept any liability due to incorrect installation, maintenance or operation of the
equipment, or due to the use of parts/components/equipment that are not authorized by Condair Ltd..
Copyright Notice
Copyright 2018, Condair Ltd., All rights reserved.
Technical modification rights reserved.

UB 2588705_A_EN_1811_UB_IOM Contents |3
CONTENTS
1 Introduction 5
1.1 Before You Start 5
1.2 General 5
1.2.1 Limitations of the Manual 5
1.2.2 Symbols Used in This Manual 5
1.2.3 Storage of Manual 5
1.2.4 Available Manuals and Languages 6
1.3 Receiving and Storage 6
1.3.1 Inspection 6
1.3.2 Storage, Packaging, and Transportation 6
1.4 Safety Precautions 7
1.5 Compliance 7
2 For Your Safety 8
3 Hygiene 10
3.1 Important Notes on Hygiene 10
3.2 Hygiene Risk Management 10
3.2.1 Guidelines to Keep a Clean System and Prevent Micro-organism Growth 10
3.3 Risk Monitoring and Assessment 11
4 Product Description 12
4.1 General Description 12
4.2 Model Designation 12
4.3 Functional Description 13
4.4 Options 14
4.5 Accessories 15
5 Product Specifications 16
5.1 Technical Data 16
5.1.1 Capacity 16
5.1.2 Weights 16
5.1.3 Dimensions 16
6 Specification Drawings 17
7 Installation and Planning 18
7.1 General 18
7.1.1 Installation Overview 19
7.2 Location Requirements 20
7.3 Clearance Requirements 20
7.4 Site Requirements 22
7.4.1 Mounting Requirements 22
7.4.2 Flexible Tube Requirements 22
7.4.3 Power Supply Requirements 22
7.5 Installation 23
7.5.1 Safety 23
7.6 Remote-Mounted Installation 24
7.7 Direct-Mounted Installation 29

8 Operation 34
8.1 General 34
8.2 Starting Up 34
8.3 Shutting Down the Unit 34
9 Maintenance 35
9.1 General 35
9.2 Cleaning and Disinfecting 35
9.3 Maintenance List 36
10 Troubleshooting 38
10.1 General 38
10.2 General Troubleshooting 38
11 Spare Parts List: Ultrasonic Blower 40
12 Commissioning 43
12.1 General 43
12.2 First-time Commissioning 43
13 Decommissioning 44
13.1 General 44
13.2 Removing Unit from Service 44
13.3 Disposing or Recycling the Unit 44
A Appendix: Installation Checklist 46
Contents |42588705_A_EN_1811_UB_IOM UB

1 Introduction
UB 2588705_A_EN_1811_UB_IOM Introduction |5
1.1 Before You Start
Thank you for purchasing the Ultrasonic Blower Pack.
The Ultrasonic Blower Pack incorporates the latest technical advances and meets recognized safety
standards. Improper use of the Ultrasonic Blower Pack may result in danger to the user or third parties,
and/or damage to property.
To ensure safe, proper, and efficient operation of the Ultrasonic Blower Pack, please observe and com-
ply with all information and safety instructions contained in this manual, as well as all relevant doc-
umentation of components of the installed humidification system.
If you have additional questions, please contact your Condair representative. They will be glad to assist
you.
1.2 General
1.2.1 Limitations of the Manual
The subject of this manual is the Ultrasonic Blower Pack. It is intended as a supplement to the Ultra-
sonic Humidifier installation, operation and maintenance manuals.
This manual is restricted to the installation, operation, and maintenance of the Ultrasonic Blower Pack.
This manual is intended for well trained personnel who are suitably qualified for their respective tasks.
1.2.2 Symbols Used in This Manual
CAUTION!
The catchword "CAUTION" in conjunction with the general caution symbol is used to provide safety
instructions that, if neglected, may cause damage and/or malfunction of the unit or damage to prop-
erty.
WARNING!
The catchword "WARNING" in conjunction with the general warning symbol is used to provide safety
instructions that, if neglected, may cause injury to personnel. Other specific warning symbols may also
be used in place of the general symbol.
Danger!
The catchword "DANGER" in conjunction with the general danger symbol is used to provide safety
instructions that, if neglected, may cause severe injury to personnel or even death. Other specific
danger symbols may also be used in place of the general symbol.
1.2.3 Storage of Manual
Keep this manual in a place where it is safe and readily accessible. If the equipment is moved to
another location, please ensure that it remains with the equipment.
If the manual is lost or misplaced, please contact your Condair representative for a replacement.

6|Introduction 2588705_A_EN_1811_UB_IOM UB
1.2.4 Available Manuals and Languages
Installation
Manual
Operation and
Maintenance
Manual
Installation,
Operation, and
Maintenance
Manual
Spare Parts
List
Engineering
Manual
Ultrasonic
Humidifier US
2588786_A_EN_
1811_US_IM
2588787_A_EN_
1811_US_OM
—2588788_A_EN_
1811_US_SPL
—
Ultrasonic
Blower Pack
UB
— — 2588705_A_EN_
1811_UB_IOM
— —
Table 1: Document (Part) Numbers and Languages of Available Manuals
1.3 Receiving and Storage
1.3.1 Inspection
After receiving the shipment, inspect the goods as follows:
lInspect the shipping boxes for damage. Report any shipping box damages to the shipping com-
pany without delay.
lCheck the goods against the packing slip to ensure that all items have been delivered. Report
any shortages to your Condair representative within 48 hours of receipt of the goods. Condair
does not assume responsibilities for any shortages beyond this period.
lUnpack the parts/components and check for any damage. If parts/components are damaged,
notify the shipping company immediately.
lVerify the model type on the specification label to ensure that it is suitable for your installation.
Refer to "Model Designation" on page12.
1.3.2 Storage, Packaging, and Transportation
Storage
Store the Ultrasonic Blower Pack in its original packaging inside a protected area that meets the fol-
lowing requirements until it is installed, or if it needs to be stored for an extended period of time:
lRoom temperature: 5 to 40 °C (41 to 104 °F)
lRoom humidity: 10 to 95% RH (non-condensing)
Transportation
For optimum protection always transport the unit and components in their original packaging, and use
appropriate lifting/transporting devices.
Packaging
Keep the original packaging of the unit/components for later use.
If the packaging needs to be disposed, observe local regulations on waste disposal. Please recycle
packaging where possible.

1.4 Safety Precautions
Regard all safety precautions described in this manual.
For more information, refer to "For Your Safety" on page8.
1.5 Compliance
Follow all local guidelines and regulations regarding the installation and operation of the unit; this
includes (and not limited to) mounting, plumbing, water, gas, ventilation, and electrical connections.
Please consult your local Condair representative to learn more.
UB 2588705_A_EN_1811_UB_IOM Introduction |7

2 For Your Safety
For Your Safety |82588705_A_EN_1811_UB_IOM UB
General
Every person who is tasked with the installation, operation and/or maintenance of the Ultrasonic Blower
Pack must read and understand this manual, as well as any respective installation, operation and/or
maintenance manuals before performing any work. Knowing and understanding the contents of these
manuals is a basic requirement for protecting personnel against any kind of danger, preventing faulty
operation, and operating the unit safely and correctly.
All labels, signs and markings applied to the Ultrasonic Blower Pack must be observed and kept in a
readable state.
Personnel Qualifications
All procedures described in this document must only be performed by personnel who are adequately
qualified, familiar with the unit, well trained, and are authorized by the customer.
For safety and warranty reasons, any activity beyond the scope of this manual must only be performed
by qualified personnel authorized by Condair.
All personnel working with the Ultrasonic Blower Pack unit must be familiar with, and comply with the
appropriate regulations on workplace safety and prevention of accidents.
Intended Use
The Ultrasonic Blower Pack is intended exclusively for air humidification using a Condair-approved
within specified operating conditions. Refer to "Technical Data" on page16 for details. Any other type of
application, without the express written consent of Condair, is considered to be NOT conforming to its
intended purpose, and may lead to dangerous operation and will void the warranty.
In order to operate the equipment in the intended manner all information contained in this manual, in
particular the safety instructions, must be observed closely.
Safety Precautions that Must be Observed
DANGER!
Risk of electric shock!
The unit is electrically powered by the humidifier. Using the On/Off switch on the humidifier to
shut down the unit will NOT shut off power to the control cabinet. Live parts may be exposed when
the access panels or doors are removed. Touching live parts may cause severe injury or even
death.
Prevention: The unit must be connected to the humidifier only after all mounting and installation work
has been completed and checked for correct workmanship. The humidifier MUST be connected from
the mains only after work has been completed on the humidifier or blower pack, and the access pan-
els/doors are closed and fastened securely.
Only qualified personnel should perform maintenance or repairs on the unit.
Follow any lockout procedures when servicing the unit.
DANGER!
Putting objects or body parts into the fan can result in serious injury or damage to equip-
ment!
The fan consists of rotating blades. Putting objects into the fan will affect the proper functioning of
the unit, causing damage to the object and the equipment, and will become a safety hazard for
people in the vicinity of the unit.
Prevention: Avoid placing objects and body parts into the fan, and if work must be performed, ensure
that the unit is properly shut down.

WARNING!
Risk to Hygiene and Health!
Improper and infrequent maintenance of the unit presents the risk of spreading pathogens (such
as bacteria , viruses, and parasites) originating from contaminated water, air, and equipment. Fail-
ure to reduce the risks increases the likelihood of causing injuries (requiring medical care), infec-
tion, and death.
Prevention: Use, regularly clean, and replace the air and water inlet filters. Regularly flush and dis-
infect the humidifier, the blower pack, and their components (tanks, hoses, reservoirs, etc.). Use pot-
able, treated water (potable, R.O., or D.I.).
Follow regular maintenance routines as described in "Maintenance List" on page36. Follow local reg-
ulations.
WARNING!
Do NOT leave the unit without power. Risk of contamination.
Do NOT leave the unit unpowered for more than 48 hours, or else a total system disinfect will be
required. Without power, the system will not flush properly, resulting in standing water and con-
ditions that may promote the growth of micro-organisms.
Prevention: Leave your unit powered on. If you do not need humidification during the 48 hours, set
the humidifier to standby or set the demand to 0.
Preventing Unsafe Operation
All personnel working with the Ultrasonic Blower Pack and humidifier must immediately report to the
customer any alterations or changes to the unit that may affect safety, and secure the unit against acci-
dental power-up.
If it is suspected that the unit cannot be operated safely for any of the reasons listed below, shut it down
immediately.
Alterations and changes that may affect safe operation include:
ldamage to the unit
lloose or damaged electrical connections
limproper operation
lleaks in the distribution system
Modifications to the Unit Prohibited
Modifications are NOT permitted on the Ultrasonic Blower Pack without the express written consent of
Condair.
UB 2588705_A_EN_1811_UB_IOM For Your Safety |9

3 Hygiene
Hygiene |10 2588705_A_EN_1811_UB_IOM UB
3.1 Important Notes on Hygiene
Observe the local health and safety executive's technical guidance on the control of Legionella in water
systems.
The user is responsible to ensure that the water system complies with local regulations, bylaws, and
guidelines (such as the HSE ACoP L8, VDI 6022, ISO 22000, HACCP, or equivalent). If inadequately
maintained, water systems, of which any humidifier is a part, can support the growth of microorganisms,
including the bacterium responsible for Legionnaires' disease.
Any risks or hazards relating to the system, including during installation and maintenance, should be
identified by a competent health and safety representative who is responsible for introducing effective
control measures.
3.2 Hygiene Risk Management
Cold water humidification presents the risk of spreading pathogenic microorganisms into the air. The
Ultrasonic Humidifier and Ultrasonic Blower Pack distribute tiny water droplets (mist) that are blown into
the space before being absorbed into the air. If the mist was contaminated before leaving the unit and
then evaporates, these contaminants are deposited onto surfaces in the space, or are otherwise
inhaled or redistributed into the ventilation system.
Pathogens include, and are not limited to, Legionella, E. coli, and viruses, and may originate from con-
taminated water, air, and equipment.
Regular cleaning and disinfecting is required to reduce health risks. Refer to "Hygiene Risk Man-
agement" above for more information on managing hygiene hazards.
Follow all safety precautions and local regulations. Refer to "For Your Safety" on page8.
There are multiple points in the humidification system where a contamination can occur. It is the
responsibility of the customer and of Condair to ensure that health hazards due to contamination are
reduced to acceptable levels. The use of a hygiene risk assessor is recommended.
Regularly clean and maintain the humidifier and its components, and do NOT miss or ignore the warn-
ings in this manual and service messages displayed on the humidifier.
Supply Air and Water
Pathogens can originate from the water supply, such as a tank or water line. It is important that standing
water in the tank or in the water line is flushed frequently to prevent the buildup of contaminants, and
the water is filtered and treated.
Pathogens may also enter the humidification system through the ventilation system or from within the
humidifier space. A fan blows air out of the water reservoir into flexible tubes, and further into a blower
pack and into the atmosphere. Contaminated air can join the mist, so it is recommended to use air filters
in the ventilation system, in the humidifier, and in the Ultrasonic Blower Pack. Ensure to use the sup-
plied air filters at all times and replace them regularly (as recommended in the Ultrasonic Humidifier
Maintenance and Operation Manual).
3.2.1 Guidelines to Keep a Clean System and Prevent Micro-organism Growth
lPerform a risk assessment of the water system using a competent person, and implement an
appropriate monitoring and control program.
lConnect a RO system to a clean, potable main water supply.
lEnsure that the system is cleaned and/or flushed regularly.
lEnsure that the buffer tank is clean and sterile before use.
lEnter a service contract that suits the needs of the company.
lStop the system if polluted drinking water is found in the area.

lAvoid water temperatures above 20 °C (68 °F). Temperatures between 20-60 °C (68-140 °F)
favor the growth of Legionella.
lDo not stop the system unless it is faulty or leaking (to avoid water stagnation).
lIf the power to the system is interrupted (such that the unit fails to flush or drain) for more than 48
hours, complete a total system disinfection.
lRefrain from closing sections of the system, unless there is a leakage or fault (to avoid water
stagnation).
lDisinfect at least once per year, and after every maintenance or repair.
lAnalyze the water and test for harmful bacteria at least once per year.
lConduct follow-up measurements until the system is clean if bacteria has been detected in the
system.
The Condair service team can help with expert technicians who can provide:
lBacteriological troubleshooting on-site*.
lCleaning and disinfecting.
lPreventative maintenance.
lRepair and fault finding.
lTraining and guidance.
Note: * Condair uses a quick method for measuring bacterial activity in the water with the use of
BactiQuant (BQ). Once the water sample has been taken, the bacteriological quality of the water is read
within 30 minutes, and the Condair service team will disinfect the system if necessary.
Please contact your local Condair representative for further information about our services.
3.3 Risk Monitoring and Assessment
Water hygiene assessments must be performed at the site to determine the risk and severity of hygiene
hazards that affect the health and safety of the public. Performing a risk assessment with regular mon-
itoring will allow procedures to be adjusted.
Ensure that the person conducting the assessment is qualified.
A typical assessment inspects the following:
lSupply water quality. Refer to "Technical Data" on page16.
lEnvironment around the humidifier.
lMaintenance procedures. Refer to "Maintenance List" on page36.
lWater pre-treatment options (such as using UV light, using reverse osmosis or deionized water,
etc.).
Proper maintenance procedures along with recommended site controls will help ensure compliance to
local regulations and protect the public.
It is recommended to monitor the humidification system weekly, and then monthly once satisfactory
levels are maintained.
Ensure that the results of every assessment is recorded.
IMPORTANT! Failure to make adequate provision against the outbreak of disease, such as Legion-
naires' disease, may cause fatalities, illness, and liabilities.
UB 2588705_A_EN_1811_UB_IOM Hygiene |11

4 Product Description
Product Description |12 2588705_A_EN_1811_UB_IOM UB
4.1 General Description
The Ultrasonic Blower Pack is used along with an atmospheric mist generating humidifier to distribute
very fine water droplets directly into local areas or into spaces that do not have a built-in air distribution
system. The Ultrasonic Blower Pack must be mounted directly on the Ultrasonic Humidifier, or remotely
mounted on suitable surfaces in the space. Large ultrasonic humidifiers, with capacities 18 kg/h (40
lb/h) use two Ultrasonic Blower Pack units. Refer to Figure 1 - below.
1
1
1
22
1
2
Figure 1 - Ultrasonic Blower Pack Typical Remote and Direct Mounted Installations
1. Ultrasonic Blower Pack
2. Flexible tube
4.2 Model Designation
The specification label on the top face of the Ultrasonic Blower Pack shows its model type, serial num-
ber, manufacturing date, and electrical rating.

MODEL: UB XX S/N: # # # # # # # # # #
VOLTS: 24 VDC Watts: 90
DATE: YYWW Made in Canada
1
2
3
4
5
Figure 2 - Ultrasonic Blower Pack Specification Label
1. Model
2. Voltage
3. Date of manufacture
4. Serial Number
5. Wattage
4.3 Functional Description
The Ultrasonic Blower Pack consists of:
lmetal housing
lelectric cable (to connect to the humidifier)
ltwo 24 VDC fans (one top fan and one bottom fan)
lan optional air filter kit (comes with 4 metal-framed filters)
la pressurized box
la mist channel
When the Ultrasonic Humidifier is powered on, the safety relay closes and permits the humidifier to gen-
erate mist when it receives a demand signal. The Ultrasonic Blower Pack is controlled through the con-
trol board of the Ultrasonic Humidifier and receives an ON or OFF signal. The mist is generated in the
ultrasonic humidifier and travels through the connection tubes to the blower pack. From there, the mist
travels through the blower pack's mist channel and is discharged through the front of the blower pack.
The exiting mist is propelled into the space by the air blown out from the pressurized box. The turbulent
air causes mixing and quick absorption between the blown out air and mist streams.
Blower pack fans provide feedback to the ultrasonic humidifier through the connection cable. This feed-
back allows the humidifier to cease mist generation when a blower pack fan fails. This allows the entire
system to shut down safely and avoids wetting in the space. A warning message "Blower pack not con-
nected" will display on the humidifier LCD display.
UB 2588705_A_EN_1811_UB_IOM Product Description |13

14 |Product Description 2588705_A_EN_1811_UB_IOM UB
1
1
2
2
9
6
5
4
7
8
3
11
10
Figure 3 - Ultrasonic Blower Pack Components
1. Side panel
2. Foam filter and frame, side, assembly (optional)
3. Adjustable leg (to level the units that are remote-mounted)
4. Specification label (see "Model Designation" on page12)
5. Mist channel
6. Fan assembly
7. Pressurized box
8. Front panel
9. Terminal block
10. Wall mount bracket (for remote installation)
11. * Foam filter and frame, assembly (optional), top
4.4 Options
Options for the Ultrasonic Blower Pack:
lAir filter assembly
(PN: 2588764)
lFlexible Tubes.
(PN: 2594413 flexible tube for remote mount)
(PN: 2594409 flexible tube for direct mount)

4.5 Accessories
Accessories for the Ultrasonic Blower Pack:
lWall mounting brackets (supplied) to mount the unit remotely.
lUltrasonic Blower Pack Installation, Operation, and Maintenance Manual (P/N:2588705_A_
EN_1811_UB_IOM) (supplied).
UB 2588705_A_EN_1811_UB_IOM Product Description |15

5 Product Specifications
Product Specifications |16 2588705_A_EN_1811_UB_IOM UB
5.1 Technical Data
5.1.1 Capacity
Table 2: Ultrasonic Blower Pack Capacity
Model Capacity
UB 7 3 kg/h (6.6 lb/h) 90 W
UB 13 6 kg/h (13.2 lb/h) 90 W
UB 20 9 kg/h (19.8 lb/h) 90 W
Note: The large Ultrasonic Humidifier, US 40, is equipped with dual stainless steel reservoirs –
each with its own dedicated driver board. The large unit must be equipped with two Ultrasonic
Blower Packs.
5.1.2 Weights
Table 3: Ultrasonic Blower Pack Packaged Weight
Model Weight
Ultrasonic Blower Pack (all models) 17.7 kg (39lb)
5.1.3 Dimensions
Table 4: Ultrasonic Blower Pack Dimensions
Model Dimensions
height x width x depth
Ultrasonic Blower Pack (all models) 371 x 483 x 432 mm
(14.6 x 19.0 x 17.0 in)

6 Specification Drawings
Product Specifications |17 2588705_A_EN_1811_UB_IOM UB
AB
C
D
E
G
H
KJ
L
I
O N
M
F
P
Q
R
S
Figure 4 - Ultrasonic Blower Pack Overall Dimensions in millimeters and (inches)
A. 409 (16.1)
B. 428 (16.8)
C. 470 (18.5)
D. 375 (14.8)
E. 339 (13.3)
F. 432 (17)
G. 180 (7.1)
H. 80 (3.1)
I. 48 (1.9)
J. 90 (3.5)
K. 92 (3.6)
L. 78 (3.1)
M. 55 (2.2)
N. 235 (9.3)
O. 148 (5.8)
P. 417 (16.4)
Q. 228 (9)
R. 228 (9)
S. Inner Diameter 74 (2.9); Outer Diameter 78 (3.1)

7 Installation and Planning
UB 2588705_A_EN_1811_UB_IOM Installation and Planning |18
7.1 General
Strictly observe and perform all installation tasks including the mounting of the unit and connection of
the water and power supplies as described in this manual. Observe and comply with all local and
national codes dealing with water and electrical installations. Condair does not accept any liability for
installation of humidification equipment by unqualified personnel, or the use of equipment and parts
that are not authorized by Condair.
Personnel Qualifications
All installation work must be performed only by licensed personnel authorized by the customer. It is the
customer’s responsibility to verify qualifications of the personnel.
Safety
Observe the following safety precautions:
DANGER!
Risk of electric shock!
The unit is electrically powered by the humidifier. Using the On/Off switch on the humidifier to
shut down the unit will NOT shut off power to the control cabinet. Live parts may be exposed when
the access panels or doors are removed. Touching live parts may cause severe injury or even
death.
Prevention: The unit must be connected to the humidifier only after all mounting and installation work
has been completed and checked for correct workmanship. The humidifier MUST be connected from
the mains only after work has been completed on the humidifier or blower pack, and the access pan-
els/doors are closed and fastened securely.
Only qualified personnel should perform maintenance or repairs on the unit.
Follow any lockout procedures when servicing the unit.
DANGER!
Putting objects or body parts into the fan can result in serious injury or damage to equip-
ment!
The fan consists of rotating blades. Putting objects into the fan will affect the proper functioning of
the unit, causing damage to the object and the equipment, and will become a safety hazard for
people in the vicinity of the unit.
Prevention: Avoid placing objects and body parts into the fan, and if work must be performed, ensure
that the unit is properly shut down.
WARNING!
Risk to Hygiene and Health!
Improper and infrequent maintenance of the unit presents the risk of spreading pathogens (such
as bacteria , viruses, and parasites) originating from contaminated water, air, and equipment. Fail-
ure to reduce the risks increases the likelihood of causing injuries (requiring medical care), infec-
tion, and death.
Prevention: Use, regularly clean, and replace the air and water inlet filters. Regularly flush and dis-
infect the humidifier, the blower pack, and their components (tanks, hoses, reservoirs, etc.). Use pot-
able, treated water (potable, R.O., or D.I.).
Follow regular maintenance routines as described in "Maintenance List" on page36. Follow local reg-
ulations.

19 |Installation and Planning 2588705_A_EN_1811_UB_IOM UB
WARNING!
Do NOT leave the unit without power. Risk of contamination.
Do NOT leave the unit unpowered for more than 48 hours, or else a total system disinfect will be
required. Without power, the system will not flush properly, resulting in standing water and con-
ditions that may promote the growth of micro-organisms.
Prevention: Leave your unit powered on. If you do not need humidification during the 48 hours, set
the humidifier to standby or set the demand to 0.
7.1.1 Installation Overview
The Ultrasonic Blower Pack can be installed remotely with any Ultrasonic Humidifier, or mounted dir-
ectly onto the Ultrasonic Humidifier (large units excluded -- the Ultrasonic Blower Pack can only be
installed remotely on large Ultrasonic Humidifiers). Direct-mounting is currently unavailable for large
Ultrasonic Humidifiers. Figure 5 - below shows typical mounting configurations of the Ultrasonic Blower
Pack and humidifier. Learn how to install the unit in "Installation " on page23.
1
1
1
4
5
3
6
7
2
2
1
2
Figure 5 - Ultrasonic Blower Pack Typical Installation with the Humidifier (Medium Humidifier
Shown)
1. Ultrasonic Blower Pack
2. Flexible tubes
3. Electrical disconnect
4. Air gap funnel (for drain line)
5. Trap
6. Expansion tank (optional)
7. R.O. system
Note: The drain line should have a minimum internal diameter of 22 mm (7/8 in), with a constant
downslope (minimum 1.2°) to the air gap funnel, and must not touch the sides or bottom of the funnel.
Use stainless steel or plastic pipe if using D.I. or R.O.water.
Note: Flexible tubes should be as short as possible – the maximum length varies depending on the
humidifier capacity and material used (refer to "Model Designation" on page12). The flexible tube must

have a constant slope (minimum incline of 10° or minimum decline of 2°), and have no restrictions in
the line, and be no longer than 2 m in equivalent length (ex. bends in the tubing affect the equivalent
length).
Note: Flexible tubes must not merge. Merging multiple tubes to supply an individual blower pack will
lead to water droplets forming inside the mist channel and the risk of spitting out, wetting the floor in
front of the unit, any adjacent equipment, and walls. If a humidifier capacity higher than 9 kg/h (19.8
lb/h) is needed, use a separate Ultrasonic Blower Pack (one for each 9 kg/h (19.8 lb/h) required).
7.2 Location Requirements
The installation of the Ultrasonic Blower Pack depends largely on the location of the Ultrasonic Humid-
ifier.
For medium size Ultrasonic Humidifiers, the Ultrasonic Blower Pack may be mounted directly on the
unit, or it may be installed remotely. For large size Ultrasonic Humidifiers, the Ultrasonic Blower Pack
may only be installed remotely and connected by flexible tubes. To reduce condensate losses in remote
installations, Condair recommends installing the Ultrasonic Blower Pack as close to the humidifier as
possible. Distances longer than an equivalent straight-length of 2 m (6.6 ft) reduces the mist output
drastically. Refer to "Mounting Requirements" on page22.
Refer to the Ultrasonic Humidifier Installation Manual (P/N: 2588786_A_EN_1811_US_IM).
The clearance requirements ensure that mist does not come into contact with any surfaces before it is
absorbed into the air. Refer to "Clearance Requirements" below.
IMPORTANT! For installations where the humidified space is separate from the humidifier, ensure that
there is adequate air flow to the humidifier, and adequate air flow out of the space to be humidified,
such that the atmospheric pressure in these spaces are equal. For example, if the humidifier is in a
separate room from the Ultrasonic Blower Pack, provide air from the humidified space to the air intake
of the humidifier.
7.3 Clearance Requirements
The clearances for the Ultrasonic Blower Pack in Figure 6 - on the next page and in Table 5 on the next
page are shown for reference only, and are the minimums required for the proper functioning of the
equipment. Consult local and national installation codes. Condair does not accept responsibility for viol-
ations of installation codes.
Adjacent Ultrasonic Blower Pack units should be separated by distance, D. For clearance requirements
for the Ultrasonic Humidifier, consult the Ultrasonic Humidifier Installation Manual (P/N:2588786_A_
EN_1811_US_IM).
UB 2588705_A_EN_1811_UB_IOM Installation and Planning |20
