Connect Tech NVIDIA Jetson TX2 User manual

Cogswell Carrier for NVIDIA® Jetson™
TX2/TX2i/TX1
Users Guide
Connect Tech Inc. Tel: [phone]
42 Arrow Road Toll: 800-426-8979 (North America only)
Guelph, Ontario Fax: [phone]
N1K 1S6 Email: [e-mail]
www.connecttech.com [e-mail]
CTIM-00484 Revision 0.06 2019-03-20

Cogswell Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Document: CTIM-00484
Revision: 0.06
Page 2 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-03-20
Table of Contents
Table of Contents...................................................................................................................................2
Preface...................................................................................................................................................4
Disclaimer .......................................................................................................................................................4
Customer Support Overview...........................................................................................................................4
Contact Information ........................................................................................................................................4
Limited Product Warranty...............................................................................................................................5
Copyright Notice.............................................................................................................................................5
Trademark Acknowledgment..........................................................................................................................5
ESD Warning ..................................................................................................................................................6
Revision History ....................................................................................................................................6
Introduction...........................................................................................................................................7
Product Features and Specifications ......................................................................................................7
Product Overview..................................................................................................................................8
Block Diagram ................................................................................................................................................8
Connector Locations –Top Side.....................................................................................................................9
Connector Locations –Bottom Side..............................................................................................................10
Connector Summary......................................................................................................................................11
DIP Switch Summary & Locations ...............................................................................................................11
DIP Switch Summary & Locations ...............................................................................................................11
Jumper Summary & Locations......................................................................................................................12
Detailed Feature Description................................................................................................................13
Jetson™ TX2/TX2i/TX1 Board-to-Board Connector...................................................................................13
External Battery Header ................................................................................................................................14
HDMI Connector...........................................................................................................................................14
Gigabit Ethernet ............................................................................................................................................15
POE Gigabit Ethernet....................................................................................................................................15
GPIO/Serial/I2C............................................................................................................................................16
Serial .............................................................................................................................................................16
Mini-PCIe/mSATA Slots ..............................................................................................................................16
Half and Full Length Mini-PCIe/mSATA Module Installation..........................................................16
SIM Card Slot................................................................................................................................................18
microSD Card Slot ........................................................................................................................................18
USB 2.0 OTG and USB 2.0 ..........................................................................................................................19
USB 2.0 OTG Client Mode and USB MUX ......................................................................................19
USB 3.0/2.0...................................................................................................................................................20
CAN Bus.......................................................................................................................................................20
Power Input...................................................................................................................................................21
Auto Start............................................................................................................................................21
NVIDIA Jetson Fan.......................................................................................................................................21
Switch Description...............................................................................................................................22
SW1 DIP Switch –Carrier Power Control....................................................................................................22
SW2 DIP Switch –NVIDIA Jetson™ TX2/TX2i/TX1 Selection and OTG USB Control ...........................22
S2 Push Button Switch –Force Recover.......................................................................................................22
S3 Push Button Switch –Reset .....................................................................................................................23
S4 Push Button Switch –Power Button........................................................................................................23
J2 Jumper –RTC Battery..............................................................................................................................23

Cogswell Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Document: CTIM-00484
Revision: 0.06
Page 3 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-03-20
J5 Jumper –CAN Bus...................................................................................................................................23
Typical Installation..............................................................................................................................24
On-Board Indicator LED’s ..................................................................................................................25
Current Consumption Details ..............................................................................................................25
Software / BSP Details .........................................................................................................................26
Connect Tech’s Custom L4T BSP (CTI-L4T) ..............................................................................................26
NVIDIA Jetpack for L4T ..............................................................................................................................26
Force USB Recovery Mode ..........................................................................................................................26
Thermal Details ...................................................................................................................................27
Mechanical Details...............................................................................................................................28
Top View.......................................................................................................................................................28
Cables..................................................................................................................................................29
Cable .............................................................................................................................................................29
Power Supply.......................................................................................................................................29
Power Supply ................................................................................................................................................29

Cogswell Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Document: CTIM-00484
Revision: 0.06
Page 4 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-03-20
Preface
Disclaimer
The information contained within this user’s guide, including but not limited to any product specification, is
subject to change without notice.
Connect Tech assumes no liability for any damages incurred directly or indirectly from any technical or
typographical errors or omissions contained herein or for discrepancies between the product and the user’s
guide.
Customer Support Overview
If you experience difficulties after reading the manual and/or using the product, contact the Connect Tech
reseller from which you purchased the product. In most cases the reseller can help you with product installation
and difficulties.
In the event that the reseller is unable to resolve your problem, our highly-qualified support staff can assist
you. Our support section is available 24 hours a day, 7 days a week on our website at:
http://connecttech.com/support/. See the contact information section below for more information on how to
contact us directly. Our technical support is always free.
Contact Information
Mail/Courier
Connect Tech Inc.
Technical Support
42 Arrow Road
Guelph, Ontario
Canada N1K 1S6
Email/Internet
[email protected]m
[email protected]m
www.connecttech.com
Note:
Please go to the Connect Tech Resource Center for product manuals, installation guides, device drivers,
BSPs and technical tips. Submit your technical support questions to our support engineers.
Telephone/Facsimile
Technical Support representatives are ready to answer your call Monday through Friday, from 8:30 a.m. to
5:00 p.m. Eastern Standard Time. Our numbers for calls are:
Toll Free: 800-426-8979 (North America only)
Telephone: [phone] (Live assistance available 8:30 a.m. to 5:00 p.m. EST, Monday to Friday)
Facsimile: 519-836-4878 (on-line 24 hours)

Cogswell Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Document: CTIM-00484
Revision: 0.06
Page 5 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-03-20
Limited Product Warranty
Connect Tech Inc. provides a one year Warranty for the Cogswell Carrier. Should this product, in Connect
Tech Inc.'s opinion, fail to be in good working order during the warranty period, Connect Tech Inc. will, at its
option, repair or replace this product at no charge, provided that the product has not been subjected to abuse,
misuse, accident, disaster or non-Connect Tech Inc. authorized modification or repair.
You may obtain warranty service by delivering this product to an authorized Connect Tech Inc. business
partner or to Connect Tech Inc. along with proof of purchase. Product returned to Connect Tech Inc. must be
pre-authorized by Connect Tech Inc. with an RMA (Return Material Authorization) number marked on the
outside of the package and sent prepaid, insured and packaged for safe shipment. Connect Tech Inc. will
return this product by prepaid ground shipment service.
The Connect Tech Inc. Limited Warranty is only valid over the serviceable life of the product. This is defined
as the period during which all components are available. Should the product prove to be irreparable, Connect
Tech Inc. reserves the right to substitute an equivalent product if available or to retract the Warranty if no
replacement is available.
The above warranty is the only warranty authorized by Connect Tech Inc. Under no circumstances will
Connect Tech Inc. be liable in any way for any damages, including any lost profits, lost savings or other
incidental or consequential damages arising out of the use of, or inability to use, such product.
Copyright Notice
The information contained in this document is subject to change without notice. Connect Tech Inc. shall not
be liable for errors contained herein or for incidental consequential damages in connection with the furnishing,
performance, or use of this material. This document contains proprietary information that is protected by
copyright. All rights are reserved. No part of this document may be photocopied, reproduced, or translated to
another language without the prior written consent of Connect Tech, Inc.
Copyright

2019 by Connect Tech, Inc.
Trademark Acknowledgment
Connect Tech, Inc. acknowledges all trademarks, registered trademarks and/or copyrights referred to in this
document as the property of their respective owners. Not listing all possible trademarks or copyright
acknowledgments does not constitute a lack of acknowledgment to the rightful owners of the trademarks and
copyrights mentioned in this document.

Cogswell Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Document: CTIM-00484
Revision: 0.06
Page 6 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-03-20
ESD Warning
Electronic components and circuits are sensitive to
ElectroStatic Discharge (ESD). When handling any circuit
board assemblies including Connect Tech carrier
assemblies, it is recommended that ESD safety
precautions be observed. ESD safe best practices include,
but are not limited to:
Leaving circuit boards in their antistatic packaging
until they are ready to be installed.
Using a grounded wrist strap when handling circuit
boards, at a minimum you should touch a grounded
metal object to dissipate any static charge that may be
present on you.
Only handling circuit boards in ESD safe areas, which
may include ESD floor and table mats, wrist strap
stations and ESD safe lab coats.
Avoiding handling circuit boards in carpeted areas.
Try to handle the board by the edges, avoiding contact
with components.
Revision History
Revision
Date
Changes
0.00
2017/03/10
Initial Release
0.01
2017/08/10
Updated to Revision D Board, Added Cable Drawing Links
0.02
2018/03/08
Added GPIO KDB link
0.03
2018/05/11
Added BSP information, pinout corrections
0.04
2018/07/31
Added TX2i compatibility, Added ASG014
0.05
2018/11/29
Added TX2i Power Circuitry Note, Removed ASG014
0.06
2019/03/20
Updated P8 pinout for Rev E+

Cogswell Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Document: CTIM-00484
Revision: 0.06
Page 7 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-03-20
Introduction
Connect Tech’s Cogswell Carrier for NVIDIA®Jetson™ TX2/TX2i/TX1 is ideal for use in Gigabit Ethernet Vision
applications. This product provides Gigabit Ethernet channels with built-in Power over Ethernet (POE) sourcing
capabilities, ideal for use with GigE Vision cameras.
Cogswell’s design includes a total of 5 Gigabit Ethernet Ports. Four of these ports can be used for IEEE 802.3af
(POE) 15.4W power sourcing or two of these ports can be used for IEEE 802.3at (POE+) 25.5W power sourcing.
Additionally the Cogswell Carrier also enables HDMI Video, USB 3.0, USB 2.0, USB OTG, Mini-PCIe/mSATA
expansion, and two RS-232 Serial Ports.
Product Features and Specifications
Feature
Cogswell Carrier for NVIDIA®Jetson™ TX2/TX2i/TX1
Module Compatibility
NVIDIA®Jetson™ TX2, NVIDIA®Jetson™ TX2i, NVIDIA®Jetson™ TX1
PCB Size / Overall Size
178mm x 147.5mm (7.0078” x 5.8071”)
3D STEP Model: download here
Display
1x HDMI
Ethernet
1x Gigabit Ethernet (10/100/1000)
4 x POE Gigabit Ethernet (10/100/1000)
-4x IEEE 802.3af (POE) 15.4W or 2x IEEE 802.3aft(POE+) 25.5W
USB
1x USB 3.0 Type A (Integrated USB 2.0)
1x USB 2.0 Type A/1x USB 2.0 OTG Micro-AB
1x USB 2.0 to Mini-PCIe Slot
SATA
1x mSATA Full Size
Audio
HDMI Integrated
Serial
2x RS-232
Mini-PCIe/mSATA
1x Mini-PCIe (PCIe & USB 2.0) Full Size
SD Card
1x microSD Card Slot
CAN Bus
1x CAN Bus Link
Misc.
1x I2C Link (+3.3V I/O)
1x System Control
4x GPIO
Power Requirements
+12V DC Input @ 9.5A
No External -48V Required, Carrier Generates its Own POE
Operating Temperature
-40oC to +85oC
Weight
245g
Accessories
Cables
Warranty and Support
1 Year Warranty and Free Support

Cogswell Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Document: CTIM-00484
Revision: 0.06
Page 8 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-03-20
Product Overview
Block Diagram

Cogswell Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Document: CTIM-00484
Revision: 0.06
Page 9 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-03-20
Connector Locations –Top Side

Cogswell Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Document: CTIM-00484
Revision: 0.06
Page 10 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-03-20
Connector Locations –Bottom Side

Cogswell Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Document: CTIM-00484
Revision: 0.06
Page 11 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-03-20
Connector Summary
Designator
Connector
Description
P1
NVIDIA®Jetson™
TX2/TX2i/TX1
NVIDIA Jetson™ TX2/TX2i/TX1 Module Connector
P2
External Battery
External Battery Header
P3
HDMI Port
HDMI Right Angle Vertical Connector
P4
NVIDIA®Jetson™
TX2/TX2i/TX1 Gigabit
Ethernet
RJ45 Gigabit Ethernet Connector (10/100/1000)
P5
POE Gigabit Ethernet
Ports 0-1
RJ45 Gigabit Ethernet Connectors (10/100/1000)
P6
POE Gigabit Ethernet
Ports 2-3
RJ45 Gigabit Ethernet Connectors (10/100/1000)
P7
GPIO/Serial Port
GPIO/RS-232 Samtec 2x6 Right Angle Header
P8
Serial Port
RS-232 Samtec 2x5 Vertical Header
P9
mSATA Slot
mSATA Full Sized Slot
P10
Mini-PCIe Slot
Mini-PCIe Full Sized Slot
P11
SIM Card Slot
Mini-PCIe SIM Card Slot
P12
microSD Slot
MicroSD Card Slot
P13
USB 2.0 OTG
USB 2.0 Link 0 OTG Micro-AB Connector (USB Link shared
with P14)
P14
USB 2.0 Type A
USB 2.0 Link 0 Type A Connector (USB Link shared with
P13)
P15
USB 3.0 Type A
USB 3.0 Link 1 Type A Connector
P16
CAN Bus
CAN Bus Header
P17
Power
Input Power TE Connector
P18
PWM Fan
Jetson Module Fan Connector for Active Cooling Solution
DIP Switch Summary & Locations
Designator
Function
Description
S2
Force Recovery
Button
Cogswell System Force Recovery Button (Used for NVIDIA
Jetson™ TX2/TX2i/TX1 System Reprogramming with USB
OTG Port)
S3
Reset Button
Cogswell System Reset Push Button
S4
Power Button
Cogswell System Power ON/OFF Button
DIP Switch Summary & Locations
Designator
Function
Description
SW1A
Power Override
Cogswell System Power Override Operation
SW1B
Auto Start Operation
Cogswell System Auto Start Operation
SW2A
NVIDIA®Jetson™
TX2/TX2i/TX1
Module Selection
NVIDIA Jetson™ TX2/TX2i/TX1 USB 3.0 MUX Selection
SW2B
USB OTG Mux
Control
USB OTG Override Operation Switch

Cogswell Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Document: CTIM-00484
Revision: 0.06
Page 12 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-03-20
Jumper Summary & Locations
Designator
Function
Description
J2
RTC Battery
Enable/Clear
External RTC Battery Enable or Clear
J5
CAN Bus
Termination
CAN Bus P to N 120 Ohm Termination

Cogswell Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Document: CTIM-00484
Revision: 0.06
Page 13 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-03-20
Detailed Feature Description
Jetson™TX2/TX2i/TX1 Board-to-Board Connector
With the NVIDIA®Jetson™TX2/TX2i/TX1, the processor and chipset are implemented on the Jetson™
TX2/TX2i/TX1 Module. This connects to the Cogswell Carrier via a Samtec SEARAY™ Board to Board
Connector.
Function
NVIDIA Jetson™ TX2/TX2i/TX1 Interface
Location
P1
Type
Samtec SEARAY™Connector
Carrier
Connector
P/N
SEAM-50-03.0-S-08-2-A-K-TR (8.0mm stacking height)
Manufacturer: Samtec
Mating
Connector
P/N
SEAF-50-05-S-08-02-A-K (installed on Jetson™
TX2/TX2i/TX1)
Manufacturer: Samtec
Pinout
Refer to NVIDIA’s Jetson™ TX2/TX2i/TX1 System-on-
Module datasheet for pinout details
Standoffs
8.0mm Standoffs Required between NVIDIA Jetson™
TX2/TX2i/TX1 Module and Cogswell (ASG007) Carrier

Cogswell Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Document: CTIM-00484
Revision: 0.06
Page 14 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-03-20
External Battery Header
Function
External Battery
Location
P2
Type
Molex Picoblade 1x3
P/N
53047-0310
Mating
51021-0300
Pinout
Pin
Description
1
RTC-BAT
2
-
3
GND
HDMI Connector
Function
HDMI Connector
Location
P3
Type
TE Connectivity HDMI Right Angle Vertical Connector
P/N
A35071TR-ND
Mating
HDMI Type A Plug
Cable
CBG145
Pinout
Pin
Description
Pin
Description
1
TMDS2+
2
GND
3
TMDS2-
4
TMDS1+
5
GND
6
TMDS1-
7
TMDS0+
8
GND
9
TMDS0-
10
TMDS_CLK+
11
GND
12
TMDS_CLK-
13
CEC
14
-
15
DDC_CLK
16
DDC_DATA
17
GND
18
+5V
19
HPD

Cogswell Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Document: CTIM-00484
Revision: 0.06
Page 15 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-03-20
Gigabit Ethernet
Function
Gigabit Ethernet
Location
P4
Type
RJ-45 Connector
P/N
1RJMG14-218LNL
Mating
Any RJ-45 Plug with Cat5/5e/6 Cabling
Pinout
Pin
Description
Pin
Description
1
GBE_GND
2
MDI2_N
3
MDI2_P
4
MDI1_P
5
MDI1_N
6
GBE_GND
7
GBE_GND
8
MDI3_P
9
MDI3_N
10
MDI0_N
11
MDI0_P
12
GBE_GND
13
GND
14
ACT#
15
GND
16
LINK#
POE Gigabit Ethernet
Function
POE Gigabit Ethernet
Location
P5, P6
Type
Amphenol Dual RJ-45 Connector
P/N
RJHSE-5381-02
Mating
Any RJ-45 Plug with Cat5/5e/6 Cabling
Pinout
Pin
Description
Pin
Description
1A
GBEA_MDI0_P
2A
GBEA_MDI0_N
3A
GBEA_MDI1_P
4A
GBEA_MDI2_P
5A
GBEA_MDI2_N
6A
GBEA_MDI1_N
7A
GBEA_MDI3_P
8A
GBEA_MDI3_N
9A
GBEA_LINK100#
10A
+3.3V
11A
GBEA_ACT#
12A
+3.3V
1B
GBEB_MDI0_P
2B
GBEB_MDI0_N
3B
GBEB_MDI1_P
4B
GBEB_MDI2_P
5B
GBEB_MDI2_N
6B
GBEB_MDI1_N
7B
GBEB_MDI3_P
8B
GBEB_MDI3_N
9B
LINK100#
10B
+3.3V
11B
ACT#
12B
+3.3V
Cogswell hardware Revision E and onward will have increased bandwidth for multiple camera streams. This is due
to CTI moving to an alternate Ethernet Chipset (Intel I210 series), the previous revisions A through D have been
found to have bandwidth limitations due to the ARM Linux4Tegra Ethernet drivers associated with the Intel 82574.
For further details please see the CTIU-00010 Product Change Notification

Cogswell Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Document: CTIM-00484
Revision: 0.06
Page 16 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-03-20
GPIO/Serial/I2C
Function
GPIO/Serial/I2C
Location
P7
Type
Samtec High-Temp Shrouded Terminal Strip
P/N
HTSS-106-04-G-D-RA
Mating
Any 0.1” Pitch Connector
Cable
CBG258
Pinout
Pin
Description
Pin
Description
1
GPIO1
2
GPIO3
3
GPIO0
4
GPIO2
5
GND
6
-
7
GND
8
-
9
I2C_SDA
10
RS-232_0_RX
11
I2C_SCL
12
RS-232_0_TX
The RS232_0 by default is used as a Debug serial port for
the TX2/TX2i/TX1, to disable console Debug please
reference our KDB
Please reference our GPIO KDB for TX2/TX2i/TX1
values.
Serial
Function
Serial
Location
P8
Type
Samtec High-Temp Terminal Strip
P/N
TSW-105-07-L-D
Mating
Any 0.1” Pitch Connector
Cable
N/A
Pinout
Pin
Description
Pin
Description
1
-
2
-
3
RS-232_1_RTS#
4
RS-232_1_RX
5
RS-232_1_CTS#
6
RS-232_1_TX
7
-
8
-
9
GND
10
-
Mini-PCIe/mSATA Slots
The Cogswell Carrier has a single Mini-PCIe and a single mSATA slot. These slots can accept a Mini-PCIe
module or an mSATA SSD module respectively. The Mini-PCIe slot contains a USB 2.0 link as per the Mini-
PCIe specification.
Half and Full Length Mini-PCIe/mSATA Module Installation
The Cogswell Carrier is designed with mounting holes to allow for the population of full length modules. To
install a half-length module you must use a Mini-PCIe Half to Full Size Extension Bracket.

Cogswell Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Document: CTIM-00484
Revision: 0.06
Page 17 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-03-20
Function
Mini-PCIe/mSATA Slots
Location
P9, P10
Type
Molex Card Edge Connector
P/N
48338-0065
Pinout
Pin
Mini-PCIe Description
mSATA Description
1
-
-
2
+3.3V
+3.3V
3
-
-
4
GND
GND
5
-
-
6
+1.5V
+1.5V
7
CLKREQ#
-
8
UIM_PWR
-
9
GND
GND
10
UIM_DATA
-
11
PCIe CLK+
-
12
UIM_CLK
-
13
PCIe CLK-
-
14
UIM_RESET
-
15
GND
GND
16
UIM_VPP
-
17
-
-
18
GND
GND
19
-
-
20
W_DISABLE#
-
21
RESV
RESV
22
-
-
23
PCIe RX+
SATA TX+
24
+3.3V
+3.3V
25
PCIe RX-
SATA TX-
26
GND
GND
27
GND
GND
28
+1.5V
+1.5V
29
GND
GND
30
SMB_CLK
-
31
PCIe TX-
SATA RX-
32
SMB_DATA
-
33
PCIe TX+
SATA RX+
34
GND
GND
35
GND
GND
36
USB D-
-
37
GND
GND
38
USB D+
-
39
+3.3V
+3.3V
40
GND
GND
41
+3.3V
+3.3V
42
-
-
43
RESV
RESV
44
-
-
45
-
-
46
-
-
47
-
-
48
+1.5V
+1.5V
49
-
-
50
GND
GND
51
-
-
52
+3.3V
+3.3V

Cogswell Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Document: CTIM-00484
Revision: 0.06
Page 18 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-03-20
SIM Card Slot
Function
SIM Card Slot
Location
P11
Type
Molex SIM Card Connector
P/N
0475530001
Pinout
Pin
Description
Pin
Description
1
SIM_PWR
2
GND
3
SIM_RST
4
SIM_VPP
5
SIM_CLK
6
SIM_DATA
7
-
8
-
microSD Card Slot
Function
microSD Card Slot
Location
P12
Type
Molex microSD Memory Card Connector
P/N
502570-0893
Pinout
Pin
Description
Pin
Description
1
SDIO_DATA2
2
SDIO_DATA3
3
SDIO_CMD
4
SDIO_VCC
5
SDIO_CLK
6
GND
7
SDIO_DATA0
8
SDIO_DATA1
9
GND
10
SDIO_CD

Cogswell Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Document: CTIM-00484
Revision: 0.06
Page 19 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-03-20
USB 2.0 OTG and USB 2.0
The NVIDIA®Jetson™ Modules have a single USB 2.0 OTG Port that doubles as a regular USB 2.0 Port. On
the Cogswell, this Port is connected to a MUX to allow for both of these functions.
NOTE: Please note that you cannot use both the USB 2.0 OTG Micro-AB Connector and the USB 2.0 Type A
Connector at the same time.
Function
USB 2.0 OTG
Location
P13
Type
Molex Micro-AB USB Connector
P/N
47590-0001
Mating
Any Micro USB 2.0 Plug
Pinout
Pin
Description
1
VBUS
2
DATA-
3
DATA+
4
ID
5
GND
6
Shield
USB 2.0 OTG Client Mode and USB MUX
To put the Cogswell into Client Mode, the ID Pin on the Micro-AB Connector needs to be pulled high. Most
USB Micro-B Cables will do this internally. Once in Client Mode, the Cogswell will connect the OTG USB
2.0 Link to the Micro-AB Connector and disable the USB 2.0 Type A connector using the onboard USB MUX.
At this point the Cogswell can be connected to a Host PC for software image flashing. Please refer to the
Software / BSP section of the Manual for instructions on how to do this.
Function
USB 2.0
Location
P14
Type
Molex Type A USB 2.0 Right Angle Vertical Connector
P/N
67329-8000
Mating
Any Type A USB 2.0 Plug
Pinout
Pin
Description
1
VBUS
2
DATA-
3
DATA+
4
GND
5
Shield
6
Shield

Cogswell Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Document: CTIM-00484
Revision: 0.06
Page 20 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-03-20
USB 3.0/2.0
The maximum configuration for a NVIDIA®Jetson™ Module allows for one external USB 3.0 Port with an
integrated USB 2.0 Port. The USB 3.0 signals are sourced from different locations on the Jetson™ TX2, TX2i
or TX1 Modules. Use SW2A to select which Module is installed to correctly configure the on-board MUX
which will link the Module to the Cogswell USB 3.0 re-driver and connector.
Over current protection, power supply filtering and ESD protection is provided on-board.
NOTE: Please note that USB3.0 support is NOT natively supported by the stock L4T builds. For USB3.0
support users must deploy CTI-L4T BSP
Function
USB 3.0/2.0
Location
P15
Type
Molex Type A USB 3.0 Right Angle Vertical Connector
P/N
48404-0003
Mating
Any Type A USB 3.0/2.0 Plug
Pinout
Pin
Description
1
VBUS
2
USB2.0_DATA-
3
USB2.0_DATA+
4
GND
5
USB3.0_SSRX-
6
USB3.0_SSRX+
7
GND
8
USB3.0_SSTX-
9
USB3.0_SSTX+
10
Shield
CAN Bus
Function
CAN Bus
Location
P16
Type
Phoenix Contact Base Strip
P/N
1897102
Mating
1840379
Pinout
Pin
Description
1
CAN_P
2
CAN_N
3
CAN_GND
