Connect Tech Photon NVIDIA Jetson AI Camera Platform User manual

Photon NVIDIA® Jetson™ AI Camera
Platform
Connect Tech Inc. Tel: [phone]
42 Arrow Road Toll: 800-426-8979 (North America only)
Guelph, Ontario Fax: [phone]
N1K 1S6 Email: [e-mail]
www.connecttech.com [e-mail]
CTIM-00080 Revision 0.00 2019-09-19

Photon NVIDIA® Jetson™ AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.00
Page 2 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2020-01-16
Table of Contents
Table of Contents...................................................................................................................................2
Preface...................................................................................................................................................4
Disclaimer .......................................................................................................................................................4
Customer Support Overview...........................................................................................................................4
Contact Information ........................................................................................................................................4
Limited Product Warranty...............................................................................................................................5
Copyright Notice.............................................................................................................................................5
Trademark Acknowledgment..........................................................................................................................5
ESD Warning ..................................................................................................................................................6
Revision History ....................................................................................................................................6
Introduction...........................................................................................................................................7
Product Feature and Specifications .................................................................................................................7
Part Numbers / Ordering Information .............................................................................................................8
Product Overview..................................................................................................................................9
Block Diagram ................................................................................................................................................9
Connector Locations .....................................................................................................................................10
Connector Summary......................................................................................................................................12
Switch Summary ...........................................................................................................................................12
Detailed Feature Description................................................................................................................13
Jetson™ Nano/NX Module Connector..........................................................................................................13
Description .........................................................................................................................................13
HDMI Connector...........................................................................................................................................14
Description .........................................................................................................................................14
MIPI CSI-2 Connectors.................................................................................................................................15
Description .........................................................................................................................................15
USB 3.0 Type-C Connector ..........................................................................................................................16
Description .........................................................................................................................................16
10/100/1000 Ethernet Connector...................................................................................................................16
Description .........................................................................................................................................16
USB 2.0 OTG/Host Mode Connector ...........................................................................................................17
Description .........................................................................................................................................17
USB 2.0-FTDI Console Connector ...............................................................................................................17
Description .........................................................................................................................................17
M.2 B-Key Connector...................................................................................................................................18
Description .........................................................................................................................................18
M.2 E-Key Connector ...................................................................................................................................19
Description .........................................................................................................................................19
M.2 M-Key Connector..................................................................................................................................19
Description .........................................................................................................................................19
Dual microSD Card/Nano/NX SIM Card Connector....................................................................................20
Description .........................................................................................................................................20
+5V Fan Connector.......................................................................................................................................20
Description .........................................................................................................................................20
I2C/GPIO/Power Connector..........................................................................................................................21
Description .........................................................................................................................................21
Reset & Recovery Pushbutton.......................................................................................................................22

Photon NVIDIA® Jetson™ AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.00
Page 3 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2020-01-16
Description .........................................................................................................................................22
M.2 M-Key / M.2 E-Key DIP Switch Selection............................................................................................22
Description .........................................................................................................................................22
2.1mm Barrel Jack Connector.......................................................................................................................23
Description .........................................................................................................................................23
RGB LED......................................................................................................................................................23
Description .........................................................................................................................................23
Typical Installation..............................................................................................................................23
Thermal Details ...................................................................................................................................24
Connect Tech Custom Thermal Solutions ............................................................................................25
Current Consumption Details ..............................................................................................................26
Software / BSP Details .........................................................................................................................26

Photon NVIDIA® Jetson™ AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.00
Page 4 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2020-01-16
Preface
Disclaimer
The information contained within this user’s guide, including but not limited to any product specification, is
subject to change without notice.
Connect Tech assumes no liability for any damages incurred directly or indirectly from any technical or
typographical errors or omissions contained herein or for discrepancies between the product and the user’s
guide.
Customer Support Overview
If you experience difficulties after reading the manual and/or using the product, contact the Connect Tech
reseller from which you purchased the product. In most cases the reseller can help you with product installation
and difficulties.
In the event that the reseller is unable to resolve your problem, our highly qualified support staff can assist you.
Our support section is available 24 hours a day, 7 days a week on our website at:
http://connecttech.com/support/resource-center/.See the contact information section below for more
information on how to contact us directly. Our technical support is always free.
Contact Information
Mail/Courier
Connect Tech Inc.
Technical Support
42 Arrow Road
Guelph, Ontario
Canada N1K 1S6
Email/Internet
[e-mail]
[e-mail]
www.connecttech.com
Note:
Please go to the Connect Tech Resource Center for product manuals, installation guides, device drivers, BSPs
and technical tips. Submit your technical support questions to our support engineers.
Telephone/Facsimile
Technical Support representatives are ready to answer your call Monday through Friday, from 8:30 a.m. to
5:00 p.m. Eastern Standard Time. Our numbers for calls are:
Toll Free: 800-426-8979 (North America only)
Telephone: [phone] (Live assistance available 8:30 a.m. to 5:00 p.m. EST,
Monday to Friday)
Facsimile: 519-836-4878 (on-line 24 hours)

Photon NVIDIA® Jetson™ AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.00
Page 5 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2020-01-16
Limited Product Warranty
Connect Tech Inc. provides a one year Warranty for this product. Should this product, in Connect Tech Inc.'s
opinion, fail to be in good working order during the warranty period, Connect Tech Inc. will, at its option,
repair or replace this product at no charge, provided that the product has not been subjected to abuse, misuse,
accident, disaster or non-Connect Tech Inc. authorized modification or repair.
You may obtain warranty service by delivering this product to an authorized Connect Tech Inc. business
partner or to Connect Tech Inc. along with proof of purchase. Product returned to Connect Tech Inc. must be
pre-authorized by Connect Tech Inc. with an RMA (Return Material Authorization) number marked on the
outside of the package and sent prepaid, insured and packaged for safe shipment. Connect Tech Inc. will
return this product by prepaid ground shipment service.
The Connect Tech Inc. Limited Warranty is only valid over the serviceable life of the product. This is defined
as the period during which all components are available. Should the product prove to be irreparable, Connect
Tech Inc. reserves the right to substitute an equivalent product if available or to retract the Warranty if no
replacement is available.
The above warranty is the only warranty authorized by Connect Tech Inc. Under no circumstances will
Connect Tech Inc. be liable in any way for any damages, including any lost profits, lost savings or other
incidental or consequential damages arising out of the use of, or inability to use, such product.
Copyright Notice
The information contained in this document is subject to change without notice. Connect Tech Inc. shall not
be liable for errors contained herein or for incidental consequential damages in connection with the furnishing,
performance, or use of this material. This document contains proprietary information that is protected by
copyright. All rights are reserved. No part of this document may be photocopied, reproduced, or translated to
another language without the prior written consent of Connect Tech, Inc.
Copyright
©
2019 by Connect Tech, Inc.
Trademark Acknowledgment
Connect Tech, Inc. acknowledges all trademarks, registered trademarks and/or copyrights referred to in this
document as the property of their respective owners. Not listing all possible trademarks or copyright
acknowledgments does not constitute a lack of acknowledgment to the rightful owners of the trademarks and
copyrights mentioned in this document.

Photon NVIDIA® Jetson™ AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.00
Page 6 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2020-01-16
ESD Warning
Electronic components and circuits are sensitive to
ElectroStatic Discharge (ESD). When handling any circuit
board assemblies including Connect Tech COM Express
carrier assemblies, it is recommended that ESD safety
precautions be observed. ESD safe best practices include,
but are not limited to:
•Leaving circuit boards in their antistatic packaging
until they are ready to be installed.
•Using a grounded wrist strap when handling circuit
boards, at a minimum you should touch a grounded
metal object to dissipate any static charge that may be
present on you.
•Only handling circuit boards in ESD safe areas, which
may include ESD floor and table mats, wrist strap
stations and ESD safe lab coats.
•Avoiding handling circuit boards in carpeted areas.
•Try to handle the board by the edges, avoiding contact
with components.
Revision History
Revision
Date
Changes
0.00
2020-01-16
Preliminary Release

Photon NVIDIA® Jetson™ AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.00
Page 7 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2020-01-16
Introduction
Connect Tech’s Photon Jetson™AI Camera Platform brings a low cost deployable Jetson solution to the
market. The Photon’s design includes Power over Ethernet (PoE) 802.3at (or a lower cost variant without
PoE), Gigabit Ethernet, HDMI video, 1 x USB 3.0 Type C, 2 x MIPI CSI-2, USB 2.0 (w/ OTG functionality),
1 x USB 2.0 (Debug functionality), M.2 (B-Key, M-Key, and E-Key functionality), Camera I2C Control, and
4-bit GPIO.
Product Feature and Specifications
Feature
Photon NVIDIA® Jetson™ AI Camera Platform
Module Compatibility
NVIDIA® Jetson™Nano (PRODUCTION MODULE ONLY)
NVIDIA® Jetson™Xavier NX
Mechanical Dimensions
145mm x 64.5mm
USB Camera
1x USB 3.0 (Connector: USB Type-C)
MIPI Cameras
2x 2-lane MIPI CSI-2
Connector: 1-1734248-5
•15-pin FPC 1mm Pitch Connector
•Same MIPI connector used on Nano Dev Kit
Camera Module Manufacturer A: Leopard Imaging
Camera Module Part Number A: LI-IMX219-MIPI-FF-NANO
Camera Module Manufacturer B: e-con Systems
Camera Module Part Number B: e-CAM30_CUNANO
Camera Module Manufacturer C: Raspberry Pi Camera Module v2
Camera Module Part Number C: 913-2664
Camera Misc Interface
1x I2C (Can be used for Lens Control)
4x GPIO (Can be used for Additional Camera Control)
1x Power Output (Can be used for IR LEDs)
•Please Contact Connect Tech for your specific voltage requirements
Internal Debug Ports
1x HDMI Display Output (Vertical Connector)
Storage
1x SD Card Slot
1x NVMe (M.2 2280 M-KEY)
Wireless Expansion
1x WiFi Module (M.2 2230 E-KEY)
1x LTE Module (M.2 3042 B-KEY) w/ SIM Card Slot
Rear IO –Ethernet
1x 10/100/1000BASE-T Uplink
PoE IEEE 802.3af-2003 (15.4W) PD
PoE+ IEEE 802.3at-2009 (25.5W) PD
Capable of operating on either network
Lower-cost PoE Bypass Option Available
Rear IO –USB OTG
1x USB 2.0 OTG for Flashing Capability (Micro USB)
Rear IO –USB UART
1x USB FTDI UART (Micro USB)
Rear IO –Power Input
1x 2mm DC Barrel Jack
+12V DC Input
Rear IO –User Feedback
1x RGB LED
Rear IO - Button
Dual RESET + FLASH Enable Functionality
Operating Temperature
-25°C to +85°C

Photon NVIDIA® Jetson™ AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.00
Page 8 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2020-01-16
Weight
76g (0.167lbs)
Warranty and Support
1 Year Warranty and Free Support
Part Numbers / Ordering Information
Part Number
Description
NGX002
Photon NVIDIA® Jetson™ AI Camera Platform w/ PoE PD
NGX003
Photon NVIDIA® Jetson™ AI Camera Platform w/ No-PoE PD

Photon NVIDIA® Jetson™ AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.00
Page 9 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2020-01-16
Product Overview
Block Diagram

Photon NVIDIA® Jetson™ AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.00
Page 10 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2020-01-16
Connector Locations TOP VIEW
USB 3.0 TYPE-C (J2)
MIPI CSI-2 (P10B)
MIPI CSI-2 (P10A)
M.2 B-Key (P3) M.2 E-Key (P4)
Nano/NX Module Connector (P1)
HDMI (P12)
FAN (P8)
GIGABIT
ETHERNET/ PoE PD (P7)
RGB LED
RESET/RECOVERY PUSHBUTTON
USB 2.0 FTDI DEBUG (P6)
+12V DC 2.1mm
BARREL JACK (P2)

Photon NVIDIA® Jetson™ AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.00
Page 11 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2020-01-16
BOTTOM VIEW
USB 2.0 OTG (P13)
I2C/GPIO/POWER (P9)
M.2 M-Key (P5)
SDCARD/SIM CARD (P11)

Photon NVIDIA® Jetson™ AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.00
Page 12 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2020-01-16
Connector Summary
Designator
Connector
Description
P1
2309413-1
NVIDIA® Jetson™Nano
NVIDIA® Jetson™Xavier NX
Module Board-To-Board Connector
P2
PJ-002A
+12V DC 2.1mm Barrel Jack Connector
P3
SM3ZS067U310ABR1200
M.2 3042 B-Key 2G/3G/LTE Cellular Module Connector
P4
2199119-4
M.2 2230 E-Key WiFi/Bluetooth Module Connector
P5
SM3ZS067U410AMR1000
M.2 2280 M-Key NVMe SSD Connector
P6
1981568-1
USB 2.0 Micro-B FTDI Console Debug Connector
P7
JXK0-0190NL
RJ-45 Gigabit Ethernet Connector
P8
53047-0410
+5V 4-Position Molex 1.25mm PicoBlade Fan Connector
P9
SM09B-NSHSS-TB
I2C/GPIO/LED JST Connector
P10A
52610-1572
MIPI CSI-2 Camera Connector
P10B
52610-1572
MIPI CSI-2 Camera Connector
P11
1042391430
Dual microSD/SIM Connector
P12
0476591000
HDMI Video Connector
P13
47589-0001
USB 2.0 Micro-AB OTG Connector
J2
632723300011
USB 3.0 Type-C Connector
Switch Summary
Designator
Connector
Description
SW1
1571983-1
DIP Switch Select for Device M.2 WiFi/Bluetooth or M.2 NVMe
SW2
EVQ-P7A01P
Dual Function Reset/Recovery Pushbutton

Photon NVIDIA® Jetson™ AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.00
Page 13 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2020-01-16
Detailed Feature Description
Jetson™ Nano/NX Module Connector
Description
The NVIDIA Jetson™Nano/NVIDIA® Jetson™Xavier NX processor and chipset are implemented on the
Jetson™ Nano/Jetson™Xavier NX Module. This connects to the NVIDIA® Jetson™Nano/NVIDIA®
Jetson™Xavier NX AI Camera Platform via a TE Connectivity DDR4 SODIMM 260 Pin connector.
Function
Description
Location
P1
Type
TE Connectivity DDR4 SODIMM 260 Pin
Carrier
Connector
Part Number: 2309413-1
Manufacturer: TE Connectivity
Mating
Connector
Jetson™ Nano/NX Module
Pinout
Refer to NVIDIA’s Jetson™ Nano or
NVIDIA® Jetson™Xavier NX
System-On-Module datasheet for pinout
details
https://developer.nvidia.com/
embedded/downloads
Board-to-
Module
Standoff
Height
M2.5 x 6.57mm standoffs required
between
NVIDIA Jetson™ Nano
or
NVIDIA® Jetson™Xavier NX
Module and AI Camera Platform
(CTI P/N: 155-0746-000.A)

Photon NVIDIA® Jetson™ AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.00
Page 14 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2020-01-16
HDMI Connector
Description
The NVIDIA Jetson™Nano/NVIDIA® Jetson™Xavier NX module will output video via the AI Camera
Platform vertical HDMI connector.
Function
Description
Location
P12
Type
Molex HDMI Vertical Connector
Carrier Connector
Part Number: 0476591000
Manufacturer: Molex
Mating Connector
HDMI Cable
Pinout
Refer to HDMI Standard

Photon NVIDIA® Jetson™ AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.00
Page 15 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2020-01-16
MIPI CSI-2 Connectors
Description
The NVIDIA Jetson™Nano/NVIDIA® Jetson™Xavier NX module will allow 2-Lane MIPI video input via
the vertical FPC connectors.
Function
Description
Location
P10A, P10B
MIPI Lane usage
P10A –CSI0
P10B –CSI2
Type
MOLEX FPC Vertical Connector
15 Pin
Carrier Connector
Part Number: 0526101572
Manufacturer: MOLEX
Mating Camera
Leopard Imaging
LI-IMX219-MIPI-FF-NANO/NX
E-Con Systems
e-CAM30_CUNANO/NX
Raspberry Pi Camera v2
913-2664
Pinout
Pin 1
GND
Pin 2
CAM_DN0
Pin 3
CAM_DP0
Pin 4
GND
Pin 5
CAM_DN1
Pin 6
CAM_DP1
Pin 7
GND
Pin 8
CAM_CLKN
Pin 9
CAM_CLKP
Pin 10
GND
Pin 11
CAM_PWDN
Pin 12
CAM_MCLK
Pin 13
I2C0_SCL
Pin 14
I2C0_SDA
Pin 15
3.3V

Photon NVIDIA® Jetson™ AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.00
Page 16 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2020-01-16
USB 3.0 Type-C Connector
Description
The NVIDIA Jetson™Nano/NVIDIA® Jetson™Xavier NX module will allow video input via the USB 3.0
Type-C connector.
Function
Description
Location
J2
Type
Wurth Electronics USB3.0 Type-C
Connector
Carrier Connector
Part Number: 632723300011
Manufacturer: Wurth Electronics
Mating Connector
USB Type-C Cable
Pinout
Refer to USB3.0 Type-C Pinout
Note 1: This port can also be used for host mode access to the NVIDIA® Jetson™Nano/NVIDIA® Jetson™
Xavier NX module at 5Gbps only.
Note 2: Display devices or devices requiring 20V power modes are not supported.
10/100/1000 Ethernet Connector
Description
The NVIDIA Jetson™Nano/NVIDIA® Jetson™Xavier NX module will allow internet communication via
the RJ-45 ethernet connector.
Function
Description
Location
P7
Type
Pulse Electronics RJ-45
Ethernet Connector
Carrier Connector
Part Number: JXK0-0190NL
Manufacturer: Pulse Electronics
Mating Connector
Ethernet (Cat5, Cat5e, Cat6, etc.)
Cable
Pinout
Refer to Ethernet Standard
Note 1: Power over Ethernet; PoE PD, (802.3af / 802.3at) can be delivered through this connector (CTI PN: NGX002).
Note 2: A lower cost Non-PoE PD (CTI PN: NGX003) version of the AI Camera platform is available.

Photon NVIDIA® Jetson™ AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.00
Page 17 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2020-01-16
USB 2.0 OTG/Host Mode Connector
Description
The NVIDIA® Jetson™Nano/NVIDIA® Jetson™Xavier NX AI Camera Platform implements a USB2.0
Micro-AB connector to allow host mode access to the module or OTG flashing of the module.
Function
Description
Location
P13
Type
Molex Micro-AB USB Connector
Carrier Connector
Part Number: 0475890001
Manufacturer: Molex
Mating Connector
USB 2.0 Micro-B or Micro-AB Cable
Pinout
Refer to USB Standard
Note 1: A USB Micro-B cable is required for OTG Flashing.
Note 2: A USB Micro-A cable is required for Host Mode.
USB 2.0-FTDI Console Connector
Description
The NVIDIA® Jetson™Nano/NVIDIA® Jetson™Xavier NX AI Camera Platform implements a USB2.0
Micro-B connector to allow users console access to the module through an FTDI interface bridge (USB-Serial)
to a desktop computer.
Function
Description
Location
P6
Type
TE Connectivity Micro-B USB
Connector
Carrier Connector
Part Number: 1981568-1
Manufacturer: TE Connectivity
Mating Connector
USB 2.0 Micro-B Cable
Pinout
Refer to USB Standard

Photon NVIDIA® Jetson™ AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.00
Page 18 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2020-01-16
M.2 B-Key Connector
Description
The NVIDIA® Jetson™Nano/NVIDIA® Jetson™Xavier NX AI Camera Platform implements a
M.2 3042 B-Key for a Cellular Module.
Function
Description
Location
P3
Type
JAE Electronics M.2 B-Key
Connector
Carrier Connector
Part Number:
SM3ZS067U310ABR1200
Manufacturer: JAE Electronics
Mating Connector
M.2 3042 Cellular Module
Pinout
Refer to M.2 NGFF Standard
Note: Only a USB 2.0 based M.2 3042 B-Key Cellular module can be used with this connector. PCIe is not connected to
the M.2 3042 B-Key.

Photon NVIDIA® Jetson™ AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.00
Page 19 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2020-01-16
M.2 E-Key Connector
Description
The NVIDIA® Jetson™Nano/NVIDIA® Jetson™Xavier NX AI Camera Platform implements a
M.2 2230 E-Key for a PCIe x1, USB 2.0 WiFi/Bluetooth Module.
Function
Description
Location
P4
Type
TE Connectivity M.2 E-Key
Connector
Carrier Connector
Part Number: 2199119-4
Manufacturer: TE Connectivity
Mating Connector
M.2 2230 WiFi/Bluetooth Module
Pinout
Refer to M.2 NGFF Standard
Note: Only a M.2 E-Key or M.2 M-Key can be operated at a time. This is a limitation in the amount of available PCIe
lanes from the Jetson™ Nano Module.
M.2 M-Key Connector
Description
The NVIDIA® Jetson™Nano/NVIDIA® Jetson™Xavier NX AI Camera Platform implements a
M.2 2280 M-Key for a PCIe x4 Gen 2 NVMe.
Function
Description
Location
P5
Type
JAE Electronics M.2 M-
Key Connector
Carrier
Connector
Part Number:
SM3ZS067U410AMR1000
Manufacturer: JAE
Electronics
Mating
Connector
M.2 2280 NVMe Module
Pinout
Refer to M.2 NGFF
Standard
Note 1: PCIe Gen 2 is the maximum speed of the Jetson™ Nano Module.
Note 2: Only a M.2 2280 M-Key or M.2 2230 E-Key can be operated at a time.
This is a limitation in the amount of available PCIe lanes from the Jetson™ Nano module.

Photon NVIDIA® Jetson™ AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.00
Page 20 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2020-01-16
Dual microSD Card/Nano/NX SIM Card Connector
Description
The NVIDIA® Jetson™Nano/NVIDIA® Jetson™Xavier NX AI Camera Platform implements a Dual
microSD Card/SIM Card connector.
Function
Description
Location
P11
Type
Molex Dual microSD/SIM Card
Connector
Carrier Connector
Part Number: 1042391430
Manufacturer: Molex
Mating Connector
microSD Card, Nano/NX SIM Card
Pinout
Refer to SD Card Standard and SIM
Card Standard
Note: microSD card is on the top, SIM card is on the bottom.
+5V Fan Connector
Description
The NVIDIA® Jetson™Nano/NVIDIA® Jetson™Xavier NX AI Camera Platform implements a 4 Position
Molex PicoBlade connector for active cooling capability.
Function
Description
Location
P8
Type
Molex 4 Position 1.25mm PicoBlade
Connector
Carrier Connector
Part Number: 53047-0410
Manufacturer: Molex
Mating Connector
Molex 0510210400 PicoBlade
Connector
Pinout
Pin 1
GND
Pin 2
+5V
Pin 3
FAN_TACH
Pin 4
FAN_PWM
