1. Introduction
The Connected IO EMU CAT1 Modem is designed for applications leveraging Low Category LTE
technology. These LTE CAT1 modules will deliver data rates of 10Mbps downlink and 5 Mbps uplink in
an optimized network like Verizon or AT&T. The EMU CAT1 Modem is a compact module offering LTE
connectivity with 3G fallback across numerous carrier independent networks depending on the end
customers’ requirements.
This document provides instructions and basic operational guidelines for a Systems Administrator in the
use and monitoring for the EMU CAT1 Modem family of products.
2. Hardware Model
EMU Modem provides the following hardware configurations:
Model Name
4G LTE Band (MHz)
3G Bands (MHz)
Carriers
EM1000T-NA-CAT1
B2: 1900
B4: 1700 (UL)/2100 (DL)
B5: 850
B12: 700
B13: 700
B2: 1900
B5: 850
AT&T
T-Mobile
Rogers
Bell Canada
Telus
EM1000T-VZ-CAT1
B2: 1900
B4: 1700
B13: 700
N/A
•Verizon
Wireless
2.1. Hardware Features
The EMU Modem has the following hardware interfaces:
•Universal connectivity to host devices via a Micro-USB 2.0 connector
•Power input via a Mini-USB Type B connector
oOptional wall power adapter
▪Input: 100-240VAC, 50/60Hz, 0.2A
▪Output: 5VDC, 2.5A
•UICC internal Card Slot (2FF)
•Two standard SMA-F connectors provide accessibility for high performance, external antennas.
•Two external LED indicators one for Power Good, the other for 4G connection status
2.2. RF Features
The EMU Modem supports the following key RF features
•Data Only (no voice support)
•Rx Diversity
•4G LTE for all units, 3G fallback on specific products only
•SIM Access Profile for specific carrier support
•Standard and extended AT commend set for specific support
3. Activation

Connected IO Inc. C ONF I D E NT I A L
EMU CAT1 Modem User Manual Revision: V.05
P a g e | 6
The EMU Modem requires a data plan that has been activated by a specific carrier. The activation will
require a valid ICCID and IMEI numbers listed on the device before the activation can be completed.
3.1. Device Driver and Software Documentation
To locate the current device drivers, software updates, and documentation for a particular device requires
a user to register his device with Connected IO. This can be accomplished at:
https://www.connectedio.com/pages/software
4. Modem Usage in Windows
The following Sections, 4, 5, and 6 are excerpts directly from Telit Wireless to help the user manage
the EMU Modems, EM1000T-XX-CAT1. For a more detailed explanation than what is provided here
the user will need to register with Telit Wireless, http://www.telit.com/download-zone/.
4.1 TMB Tool
Telit provides the TMB tool that furnishes a simple interface to activate/deactivate the NCM, (Network
Control Module), protocol in Windows environment. Please check our “Software” page at
www.connectedio.com to download the tool. Before running the tool
1
, verify if the:
•current port configuration is #PORTCFG=0 (default);
•mode is #USBCFG=0 (default); USB3 port is available.
The Fig. 1 shows how the Telit Mobile Broadband tool appears on the display.
Fig. 1: TMB Tool
1
It is suggested to install NET Framework 4.5 or later.

Connected IO Inc. C ONF I D E NT I A L
EMU CAT1 Modem User Manual Revision: V.05
P a g e | 7
Push SIM Management button, and the following dialog box is displayed.
Push Metering button, the following dialog box is displayed.
Push Settings button, the following dialog box is displayed.
The APN is auto-connected to the CID 3. The Packet Data Protocol type is always set to "IP".
•See AT command AT#CGDCONT.

Connected IO Inc. C ONF I D E NT I A L
EMU CAT1 Modem User Manual Revision: V.05
P a g e | 8
Push Info button, the following information is displayed.
Push Connect button, the following dialog box is displayed and the NCM protocol activation was
successfully performed.
4.2 Windows Connection Manager
Another way to use the modem is with the Windows utilities.
After installing drivers for the modem, “Telit_Dialup” connection will appear under the Windows
Network Interfaces.
Please follow the steps below to connect the modem to the internet
1. Click on “Network Interfaces” Desktop icon.

Connected IO Inc. C ONF I D E NT I A L
EMU CAT1 Modem User Manual Revision: V.05
P a g e | 9
2. Click on “Telit_Dialup”. Settings menu will appear (see step 3)
3. Click ‘Telit_Dialup” again in the “Settings” menu.

Connected IO Inc. C ONF I D E NT I A L
EMU CAT1 Modem User Manual Revision: V.05
P a g e | 10
4. Click “Connect”.
5. Click “Dial”.

Connected IO Inc. C ONF I D E NT I A L
EMU CAT1 Modem User Manual Revision: V.05
P a g e | 11
5. System Configuration –Windows-
5.1. AT Command
To send AT commands, download and install the Telit AT Controller software (TATC). See section 3.1 on
where TATC is located. Follow the steps below to access the AT terminal: NOTE: TCM and TATC use
the same DM- Port so turning off TCM prior to using the TATC will be required.
1. Start Telit AT Controller software. (Usually the connection manager installer will create an
icon on the desktop. If not, type “Telit AT Controller” in your Windows search field to locate)
2. Verify which serial port the device should be communicating on in the Windows Device
Manager.

Connected IO Inc. C ONF I D E NT I A L
EMU CAT1 Modem User Manual Revision: V.05
P a g e | 12
3. Click on the “Play” button it will connect the Telit AT Controller to the serial port so
communication can be established with the modem.
4. Click on “AT terminal” button.

Connected IO Inc. C ONF I D E NT I A L
EMU CAT1 Modem User Manual Revision: V.05
P a g e | 13
5. The previous step will open AT terminal as shown below:

Connected IO Inc. C ONF I D E NT I A L
EMU CAT1 Modem User Manual Revision: V.05
P a g e | 14
6. You can use the AT command to check the LTE status.
a. The AT command format is “AT+ Command”for example: AT+CSQ. Enter the AT
command and click “Execute”. Figure 1
7. AT command responses, will be displayed in the terminal window on the right side of the
Telit AT Controller software. Figure 1.
Figure 1: AT Command Example

Connected IO Inc. C ONF I D E NT I A L
EMU CAT1 Modem User Manual Revision: V.05
P a g e | 15
5.2. APN Change
Typically, the APN is auto-configured or auto-detected. The APN Change command allows you to
change the local telecommunication company. Enter AT command for changing APN in AT terminal as
follows: AT+CGDCONT=1,”IPV4V6”,”<your APN name>” and click the “Execute” button Figure 2.
Note: Use cid=1 for NA units and cid=3 for VZ units.
Examples:
•AT+CGDCONT=1,”IPV4V6”,”<your APN name>” for NA units
•AT+CGDCONT=3,”IPV4V6”,”<your APN name>” for VZ units
Figure 2: APN Change

Connected IO Inc. C ONF I D E NT I A L
EMU CAT1 Modem User Manual Revision: V.05
P a g e | 16
To verify the APN setting update was successful, enter AT command “AT+CGDCONT?” See Figure 3.
Figure 3: Check APN Function

Connected IO Inc. C ONF I D E NT I A L
EMU CAT1 Modem User Manual Revision: V.05
P a g e | 17
6. System Configuration –Linux-
6.1 Preliminary Check
First, the OS should detect the connected module as an NCM device. To force this check, create a file
named cdc_ncm.conf in the folder /etc/modprobe.d/ and insert the following line.
options cdc_ncm prefer_mbim=N
Assuming the module is using the default #PORTCFG=0 configuration and #USBCFG=0 mode.
Reboot the Ubuntu-PC, and plug the USB cable in. Use the dmesg command to check if the module is
recognized as a NCM device. The command response should contain something that looks like the
following:
dmesg<enter>
.
.
[ 510.764017] usb 1-3: new high-speed USB device number 7 using ehci-pci
[ 515.907764] usb 1-3: New USB device found, idVendor=1bc7, idProduct=0036
[ 515.907769] usb 1-3: New USB device strings: Mfr=1, Product=2, SerialNumber=3
[ 515.907772] usb 1-3: Product: FIH7160
[ 515.907775] usb 1-3: Manufacturer: Telit.
[ 515.907777] usb 1-3: SerialNumber: 351622079900102
[ 515.946172] cdc_acm 1-3:1.0: This device cannot do calls on its own. It is not a modem.
[ 515.946240] cdc_acm 1-3:1.0: ttyACM0: USB ACM device
[ 515.947784] cdc_acm 1-3:1.2: This device cannot do calls on its own. It is not a modem.
[ 515.947845] cdc_acm 1-3:1.2: ttyACM1: USB ACM device
[ 515.949159] cdc_acm 1-3:1.4: This device cannot do calls on its own. It is not a modem.
[ 515.949224] cdc_acm 1-3:1.4: ttyACM2: USB ACM device
[ 515.950912] cdc_acm 1-3:1.6: This device cannot do calls on its own. It is not a modem.
[ 515.950979] cdc_acm 1-3:1.6: ttyACM3: USB ACM device
[ 515.952409] cdc_acm 1-3:1.8: This device cannot do calls on its own. It is not a modem.
[ 515.952480] cdc_acm 1-3:1.8: ttyACM4: USB ACM device
[ 515.954035] cdc_acm 1-3:1.10: This device cannot do calls on its own. It is not a modem.
[ 515.954103] cdc_acm 1-3:1.10: ttyACM5: USB ACM device
[ 515.960140] cdc_ncm 1-3:1.12: MAC-Address: 00:00:11:12:13:14
[ 515.960144] cdc_ncm 1-3:1.12: setting rx_max = 16384
[ 515.960782] cdc_ncm 1-3:1.12 usb0: register 'cdc_ncm' at usb-0000:00:1a.7-3, CDC NCM, 00:00:11:12:13:14
The command response shows that Ubuntu, when connected to the module, maps automatically
ttyACMx into USBx as summarized in Table 2 below.

Connected IO Inc. C ONF I D E NT I A L
EMU CAT1 Modem User Manual Revision: V.05
P a g e | 18
tty device on Ubuntu
USB ports on module
ttyACM0
USB0
ttyACM1
USB1
ttyACM2
USB2
ttyACM3
USB3
ttyACM4
USB4
ttyACM5
USB5
Table 2: ttyACMx  USBx
In addition, the command response shows:
•The name of NCM interface: usb0
•idProduct=0036, it identifies the #USBCFG=0 mode
Just to be sure to use the module to access the Network by means of the USB cable and the carriers, click
on button and disable the Networking connected to the Ethernet cable.
The following screenshot shows that the Networking is disabled.
Use the ifcongif command to display the status of the currently active network interfaces.

Connected IO Inc. C ONF I D E NT I A L
EMU CAT1 Modem User Manual Revision: V.05
P a g e | 19
Ifconfig<enter>
lo Link encap:Local Loopback
inet addr:127.0.0.1 Mask:255.0.0.0
inet6 addr: ::1/128 Scope:Host
UP LOOPBACK RUNNING MTU:65536 Metric:1
RX packets:281 errors:0 dropped:0 overruns:0 frame:0
TX packets:281 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:0
RX bytes:21279 (21.2 KB) TX bytes:21279 (21.2 KB)
This command response shows that only the loopback interface is active. It is used for diagnostics and
troubleshooting, and to connect to servers running on the local machine (local host).
Use ifconfig –acommand to display all interfaces, which are currently available, even if down.
ifconfig –a<enter>
eth1 Link encap:Ethernet HWaddr 00:1e:4f:db:2d:26
BROADCAST MULTICAST MTU:1500 Metric:1
RX packets:0 errors:0 dropped:0 overruns:0 frame:0
TX packets:0 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:1000
RX bytes:0 (0.0 B) TX bytes:0 (0.0 B)
Interrupt:21 Memory:fe9e0000-fea00000
lo Link encap:Local Loopback
inet addr:127.0.0.1 Mask:255.0.0.0
inet6 addr: ::1/128 Scope:Host
UP LOOPBACK RUNNING MTU:65536 Metric:1
RX packets:281 errors:0 dropped:0 overruns:0 frame:0
TX packets:281 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:0
RX bytes:21279 (21.2 KB) TX bytes:21279 (21.2 KB)
usb0 Link encap:Ethernet HWaddr 00:00:11:12:13:14
BROADCAST MULTICAST MTU:1500 Metric:1
RX packets:0 errors:0 dropped:0 overruns:0 frame:0
TX packets:0 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:1000
RX bytes:0 (0.0 B) TX bytes:0 (0.0 B)
This command response shows that usb0 is the name of NCM interface, as stated before.

Connected IO Inc. C ONF I D E NT I A L
EMU CAT1 Modem User Manual Revision: V.05
P a g e | 20
To send manually AT commands to the module, as shown in the next paragraph, you may use the serial
terminal emulation minicom. To install terminal emulation use the following command:
sudo apt-get install minicom<enter>
Assume that the module is using the default #PORTCFG=0 configuration. Enter one of the following
commands to use USB0 or USB3 port of the module, refer to Tab. 2.
sudo minicom –D /dev/ttyACM0<enter>
sudo minicom –D /dev/ttyACM3<enter>
6.2 NCM Activation on the Module
Assume that the module is using the default #PORTCFG=0 configuration, and the default #USBCFG=0
mode. Execute the following steps:
•USB cable is already plugged in, see previous chapter.
•Run the minicom serial terminal emulation connected to the USB0 port of the module
(/dev/ttyACM0 on Ubuntu side), see previous chapter.
•Enter the AT#PORTCFG=? Test command. If the entered command is not echoed, enter the ATE1
command to enable the echo.
Test command returns, for each Variant value, a short description on the logical connection regarding
physical serial ports/USBx ports and access points (AT parser instances, Trace), see below:
AT#PORTCFG=?
#PORTCFG: Variant=0: AT= USIF0 USB0 USB3; STT(Trace)= USB1
#PORTCFG: Variant=1: not supported by this product
#PORTCFG: Variant=2: not supported by this product
#PORTCFG: Variant=3: not supported by this product
#PORTCFG: Variant=4: not supported by this product
#PORTCFG: Variant=5: not supported by this product
#PORTCFG: Variant=6: not supported by this product
#PORTCFG: Variant=7: not supported by this product
#PORTCFG: Variant=8: AT= USB0 USB3 USB4; STT(Trace)= USB1
