Alcatel X220 User manual

1
User Manual
Table of Contents
Safety and Use...................................................................................................................... 2
Installation Guide................................................................................................................. 4
Main Interface Overview................................................................................................... 4
Entrance to Main Interface............................................................................................... 5
Connect to Internet............................................................................................................. 6
SMS Services (Text Message)............................................................................................. 7
Contacts................................................................................................................................. 9
Settings.................................................................................................................................. 10
Warranty............................................................................................................................... 13
FAQs....................................................................................................................................... 14
Installation Guide for Mac............................................................................................... 15

2
Safety and Use
We recommend that you read this chapter carefully before using your
modem. The manufacturer disclaims any liability for damage, which
may result as a consequence of improper use of the modem or of use
contrary to the instructions contained herein.
Traffic Safety
When driving, do not use the modem:
When switched on, the modem emits electromagnetic waves that
can interfere with the vehicle’s electronic systems such as ABS
anti-lock brakes or airbags. To ensure that there is no problem,
please do not place the modem on top of the dashboard or within
an airbag deployment area.
Check with your car dealer or the car manufacturer to make sure
that the dashboard is adequately shielded from modem RF energy.
Conditions of Use
1. Switch the modem off before boarding an aircraft.
2. Switch the modem off when you are in health care facilities, except
in designated areas. As with many other types of equipment now in
regular use, mobile telemodems can interfere with other electrical
or electronic devices, or equipment-using radio frequencies.
3. Switch the modem off when you are near gas or flammable liquids.
Strictly obey all signs and instructions posted in a fuel depot, petrol
station, chemical plant, or in any potentially explosive atmosphere.
4. When the modem is switched on, it should be kept at least 15 cm
from any medical device such as a pacemaker, a hearing aid or
insulin pump, etc.
5. Do not let children use the modem without supervision. The modem
may contain small parts that could become detached and create
a choking hazard.
6. When replacing the cover, please note that the modem may
contain substances that could create an allergic reaction.
7. Always handle the modem with care and keep it in a clean and
dust-free place.
8. Do not open, dismantle or attempt to repair the modem yourself.
9. Do not drop, throw or bend the modem.

3
10. Do not paint the modem.
Collection Point:
This symbol on the modem means that it must be taken to
collection points at the end of their life:
Municipal waste disposal centers with specific bins for these items of
equipment
Collection bins at points of sale.
They will then be recycled, preventing substances being disposed
of in the environment, so that their components can be reused.
In European Union countries:
These collection points are accessible free of charge.
All products with this symbol must be brought to these collection points.
In non European Union jurisdictions:
Items of equipment with this symbol are not to be thrown into ordinary
bins if your jurisdiction or your region has suitable recycling and
collection facilities; instead they are to be taken to collection points for
them to be recycled.
In the United States, please visit www.recyclewirelessphones.org for
more information on recycling wireless products.
Protection against theft
The modem is identified by an IMEI (modem serial number) shown on
the packaging label and in the modem’s dashboard. We recommend
that you note the number the first time you use the modem by opening
the dashboard “Settings” > “Diagnostics” to get it.
Disclaimer
There may be certain differences between the user manual description
and the modem’s operation, depending on the software release of the
modem or specific operator services.

4
Installation Guide
Installation procedures may vary based on the operating system
installed on your PC. The following instructions are based on the
Windows XP OS:
Turn on your PC and plug the modem into the USB interface slot to
begin software installation. Windows should automatically detect the
new device and will prompt you to begin installation.
After following the prompts of installation setup, upon completion, a
shortcut will be placed on your desktop for quick future access.
Note:
1. If installation “auto-run” does not begin, you will need to locate the
“autoRun.exe)” file in the driver path, and Double-Click on
AutoRun.exe to run the installation manually.
2. A Micro-SD card is an optional accessory.
3. Please do not remove the USIM/SIM card and or the Micro-SD card
when the modem is in use.
Upon successful installation of the HSPA management program, the
program will launch automatically. You may also double-click the short
cut icon on the desktop to launch the program.
Main Interface Overview
Following table are listed Short Cut Icons in PC Suite Interface.
Interface Icons Provided Services
Home Home Page (Click on <Connect> icon from the
main window to connect/disconnect from the
Internet)
Contacts Display The Phones Book Interface
SMS Display The Text Message Interface
Browser Open the Browser
Settings Display the Settings manual
Following table are listed the Icons of status bar information

5
Connection Statistics Icon Description
Network Signal Indicates the signal strength of the network
Network Status Indicates the network status. This will display the
operator name which the modem can find the
network. Or show the modem haven’t ready.< No
(U)SIM> or <NO Device>
Network Type Display in the status bar, to show you which network
you are using (GPRS / EDGE/ UMTS or HSPA)

Roaming Roaming Icon “ ”, when the network is under
roaming
New Message Display the SMS status including new SMS/SIM card
memory is full/Data Card memory is full
Network Connecting Connecting Icon “ “display in the status bar, when
the network is connected into internet network
Following table are listed the LED Indicates for each status.
LED Indicator Desctiption
Flashing Green & Red multicolour
circularly
Network Searching
Quickly Flashing Green & Red multicolour
circularly
Out of order
Green Light Slow Flashing Registering into HSPA or UMTS network
Constant Green Light Registered to HSPA or UMTS network
Red Light Slow Flashing Registering into GPRS or EDGE network
Constant Red Light Registered to GPRS or EDGE network

Entrance to Main Interface
The application runs automatically and the main window will pop up
when the modem will be connected. You can also access and run the
application from the <Start> menu.
If the PIN code is enabled, please enter the correct PIN code in the
entry field, and click on <OK>. You may try only 3 times to enter the
correct PIN code; after three incorrect attempts, the USIM or SIM card
will be blocked.

6
A PUK dialog box will then be displayed asking you to enter the right
PUK code, PIN Code and Confirmed PIN. Click on <OK> if you fail to
input the correct PUK code after 10 attempts, you will need to contact
your service provider.
If the PUK and PIN code is correct, the application will be launched and
all features are enabled
Connect to Internet

1. Connecting with the default logon profile
If you want to connect to the Internet without setting any user-defined
or predefined profiles, press icon of “connect”. The default connection
profile will be used in accordance with your USIM/SIM card.
Connecting
•Click on <Connect> from the home page;
•Wait several seconds until the connection is established;
•Once you are connected, Icon of <Connect> will change into
<Disconnect>.
Disconnecting
Click on Icon of <Disconnect> from the home page to disconnect from
the Internet.
2. Connecting with a user-defined logon profile
Click on settle icon and select the <Connection Profile…> menu to
open the profile setting window.
Adding a new connection profile
•Click on <Settings> and select the connect Profile to add a new
connection
•If <ADD> is selected, the new connection profile windows
will pop up.
•Please enter the info of requested;
•Account (Connection Naming), Number, APN, User Name, password

7
and final choice which Auth Type you are using by manually;
•Click <OK>
•Please select you preferred network and click on <Activate> to
default your connection setting.
Note：Users may obtain Number, APN Code, User Name, Password and
Auth type information from networks provider.
SMS Services (Text Message)
Click SMS icon from the main interface of the PC suite to access the SMS
service.
1. Displaying the received SMS
When a new message is received, a message box appears in the status
bar.
yClick the content of the chosen message. You may also display
the content on the message window.
Note: Received SMS will be saved the modem. If the modem Memory is
full, the message will saved on USIM/SIM
2. New SMS
yClick on <New> in the shortcut menu bar. An SMS creation window
will pop up;
yEnter the text.
3. Send
(1) You may enter a recipient’s number in 3 ways:
yEnter the number directly. If there are two or more recipients, use
“;” to separate each;
yEnter the name of a recipient saved in the phonebook;
yClick Icon of SMS in the pop up the window to access the
recipient’s selection window. Select one party, or more (using the
ctrl/shift key), and the click on <OK> to add the chosen party (ies)
to the recipient list.

8
(2) Click on <Send> to send the message. If the message is not sent, it
will be saved in the Outbox.
4. Reply
ySelect a message in the inbox and then click on <Reply> in the
shortcut menu bar;
yThe recipient’s / number will appear. It can now be modified;
yEnter the reply in input field, and then click on <Send>.
5. Forward
ySelect a message and then click on <Forward> in the shortcut menu
bar;
yThe content of the selected message will appear in the input field. It
can now be modified;
yEnter the recipient’s number and then click on <Send>.
6. Edit
yAccess the draft list to select a message, and open it by
double-clicking on it;
yClick on <Save> or <Send> when you have finished editing.
7. Delete
ySelect a message, or several messages (using the ctrl/shift key);
yClick on <Delete> in the tool bar. A dialog box will ask “Are you sure
to delete the message(s)”
yClick on <OK> and the SMS will be deleted. Once deleted, SMS
messages cannot be restored.
8. Resend
yAccess the Outbox to select a message or several messages (using
the ctrl/shift key);
yClick on <Resend> in the tool bar;
yThe application will resend the unsent/sent message(s).
9. Export
ySelect a message or several messages (using the ctrl/shift key) in the
current list;
yThen right click mouse, to export SMS to the chosen location and

9
saved as a text file.
Contacts
Click contacts from the main interface of PC suite to access the
contacts management.
The contacts list column contains: (U) SIM /Modem /Computer. You can
use contacts stored either on the (U) SIM, modem or on computer in the
corresponding window.
1. New
ySelect <New> from the tool bar to access the contacts editor;
yEnter the relevant information, and press <OK>; the new contact will
appear in the current contact list.
2. Edit
ySelect a contact and access the contact editor by selecting <Edit>
from the tool bar or by double-clicking on the contact;
yModify the relevant contact information, and select <OK> to save
the changes.
3. Delete
ySelect one contact, or more (using the ctrl/shift key);
yClick on <Delete> from the tool bar. A dialog box will ask “Are you
sure to delete the contacts”
yClick on <OK> and the contact(s) will be deleted; deleted contacts
will not be restored.
4. Send SMS
ySelect one contact or more (using ctrl/shift key);
yClick on <Send SMS> in the tool bar;
yWhen the message is completed, you may send it by clicking on
<Send>.
5. Copy to (U) SIM card/Modem/Computer
ySelect one contact, or more (using ctrl/shift key) stored in the same

10
memory.
yRight-Click your mouse pointer, if selected <Copy to> in the manual
and select a target memory different from the memory being used;
yContact(s) will be copied to the target memory.
Settings
Click on settings icon from the main interface of PC Suite. A menu with
various settings will appear.
1. Network select
ySelect <Network selection> in the Settings menu. The default setting
is<Auto>;
yClick on<Manual…> to activate the network list window;
yA list of networks appears when the search is complete;
yClick <Search> an available network from the list of available
operators and click on <Select>. It will register the selected network.
2. Network mode
ySelect <Network mode> in Settings menu. The default setting is
<Auto>;
yClick on the mode which you prefer, it will search and register the
network mode which was chosen at next time of device
connection.
3. Network Band (This function is depend on product)
ySelect <Network band> in Settings menu. The default setting is
<Auto>;
yClick on the band which you prefer, it will search and register the
network band which was chosen at next time of device
connection.
4. SMS settings
Choose <SMS settings> in the Settings menu to access the SMS settings
window.
yService Center: The default number is found in the (U)SIM card. You
may change it.

11
yValidity period: You can choose between: 6 hours/1 day/1 week.
yMessage Alert: Click to validate the message alert sound.
5. Connection profile settings
Select<Connection profile…> in the Settings menu to access the
connection profile setting window.
<ADD>
Adding a new connection profile
Click on <Settings> and select the connect Profile to add a new
connection
•If <ADD> is selected, the new connection profile windows will pop
up;
•Please enter the info of requested;
•Account (Connection Naming), Number, APN, User Name, password
and final choice which Auth Type you are using by manually;
•Click <OK>;
•Please select you preferred network and click on <Activate> to
default your connection setting.
<Delete>
ySelect an item in the connection profile list;
yClick on <Delete> on the keyboard. You will be asked if you “Are
sure you delete”.
yChoose <OK> to delete the profile from the list.
<Modify>
ySelect an item in the connection profile list;
yClick on <Modify> to access the profile edit window;
yModify the parameters and click on <OK> to save the modification.
<Deactivate>
ySelect an item in the connection profile list;
yClick on <Deactivate> to release default setting.
6. System settings
Click to validate the sound prompt when the Internet will be

12
connected/ disconnected.
7. Request PIN
yClick on the <Request PIN> menu and select <Enable/Disable PIN>.
Activate the PIN input dialog box;
ySelect <Enable PIN> and enter the correct PIN code;
yClick on <OK>.
8. Change PIN
yClick on <Change PIN>, and activate the PIN modify dialog box;
yInput the old PIN and the new PIN, then confirm;
yClick on <OK> to confirm the new PIN code.
Note: You can only access the modify menu if the PIN is enabled.
9. Unlock (U) SIM Card
Click on <(U)SIM Unlock>, and activate the code which is requested in
dialog box to unlock this function, Then click on <OK> to confirm;
Note: All about code is supplied by your network provider (except PIN
Code).
10.Diagnostics Statistic
This menu is used to display the diagnostic information, including:
yModel Information: Modem Name/ Firmware version/IMEI/IMSI
yOperator Information: PIN code status/Network code/Network
selection mode/ Network mode/Signal strength.
yNetwork Status: CS network registration/PS network
registration/PS network attachment
11. About
You can get information on the version in the <About> menu.
12.Help
When the application is open, you can read the instructions about the
modem

13
Warranty
•The modem is warranted against any deviation from technical
specifications for a period of twelve (12) months from the date
specified on your original invoice1.
•Under the terms of this warranty, you must immediately inform your
vendor in case of a conformity defect on the modem, and present a
proof of purchase.
•The vendor or repair centre will decide whether to replace or repair,
as appropriate the modem.
•Repaired or replaced modems are warranted ONE (1) month unless
there are statutory provisions to the contrary.
•This warranty shall not apply to damage or defects to the modem
due to:
1) not following of the instructions for use or installation,
2) not being compliant with technical and safety standards
applicable in the geographical area where the modem is used,
3) improper maintenance of sources of energy, and of the overall
electric installation,
4) accidents or consequences of theft of the vehicle in which the
modem is transported, acts of vandalism, lightning, fire, humidity,
infiltration of liquids, inclement weather,
5) connecting to or integrating into the modem any equipment not
supplied or not recommended by the manufacturer,
6) any servicing, modification or repair performed by individuals not
authorised the manufacture, the vendor or the approved
maintenance centre,
7) use of the modem for a purpose other than that for which it was
designed,
8) normal wear,
9) malfunctions caused by external causes (e.g., radio interference
from other equipment, power voltage fluctuations),
10) faulty connections resulting from unsatisfactory radio transmission or
caused by the absence of radio relay coverage.
•Warranty is also excluded for the modems on which markings or
serial numbers have been removed or altered.

1The mandatory warranty period may vary if overriding statutory provisions are applicable in your jurisdiction.

14
•The modem is also warranted against hidden defects (defects
inherent in the design, manufacture, etc.).
•There are other express warranties than this printed limited warranty,
express or implied, of any nature whatsoever.
•In no event shall the manufacturer be liable for incidental or
consequential damages of any nature whatsoever, including but
not limited to trading loss, commercial loss, to the full extent those
damages can be disclaimed by law. Some countries/states do not
allow the exclusion or limitation of incidental or consequential
damages, or limitation of the duration of implied warranties, so the
preceding limitations or exclusions may not apply to you.
FAQs
1. Q: Which operation systems does the software support?
A: It supports Windows 2000, Windows XP, Windows Vista, Windows 7
and Mac OS (X 10.4.9 -10.6).
2. Q: I cannot install the driver
A: On some PCs, installation of the modem may take a long time
because of the PC configuration. So please wait and do not
cancel the process or you will have to uninstall and re-install
again.
3. Q: What should I do if the main interface continues to display
“Searching device”<”Initializing”>?
A: Please remove the modem and reinsert it.
4. Q: What should I do if the SIM/USUM card is unplugged during the
application?
A: Please disconnect the modem first, and then restart the
application.
5. Q: The SIM/USIM card does not register any networks
A: The reasons are shown below:
1. Unstable local signal;
2. The software is an old version;

15
3. Hardware problem.
Youmay:
1. Try to logon from another location;
2. Update the software;
3. Check the hardware or use another data card and retry.
6. Q: Why does the prompt “No available connection profile. Please set
an available default one in connection profile” appear?
A: Please add a connection profile manually.
7. Q: It failed to connect to the internet
A: Please make sure the connection profile and settings are correct.
8. Q: The connection speed and data transfer rates are too slow
A: Please check the local network signal strength.
9. Q: Sending an SMS failed
A: Please make sure the SMS center number is correct.
10.Q: I cannot receive an SMS
A: Please check whether your SIM/USIM card’s memory is full.
11.Q: Why can I only save part of the name when adding a new
contact?
A: The SIM/USIM card can only hold 12 SBC characters, and 6 DBC
characters.
12.Q: Does it support roaming?
A: This depends on the local operator. Please check with your local
operator or service provider.
Installation Guide for Mac
This manual describes the operations of the connect application.
This application requires MAC OS X10.4.9 or later.
1. To install the MODEM connect application on MAC OS X. Please

16
double-click the file HSPA USB MODEM.pkg
2. Click Continue
3. Select the MAC OS volume to install the application and click
“Continue Installation”

17
4. When the installation is finished, you will see the following window,
you need to restart your computer to use the modem.
5. Clicking Application>HSPA USB MODEM to start the connect
application. You may install this application in the Dock to access it
faster.

18
Radio Waves:
Proof of compliance with international standards (ICNIRP) or with European
Directive 1999/5/EC (R&TTE) is required of all Modem models before they can
be put on the market. The protection of the health and safety for the user and
any other person is an essential requirement of these standards or this
directive.
THIS MODEM COMPLIES WITH INTERNATIONAL AND EUROPEAN REQUIREMENTS
REGARDING EXPOSURE TO RADIO WAVES.
The Modem is a radio transmitter/receiver. It was designed and manufactured
to comply with the radiofrequency (RF) exposure thresholds recommended by
international requirements (ICNIRP)1and by the Council of the European
Union (Recommendation 1999/519/EC)2
These limits are part of a set of requirements and establish authorised
radiofrequency levels for the public. These limits were established by
independent groups of experts on the basis of regular and detailed scientific
assessments. They include a significant safety margin intended to ensure the
safety of all, regardless of age or state of health.
The exposure standard for modems is determined by a measurement unit
known as the Specific Absorption Rate or “SAR”. The SAR limit is set by
international requirements or by the Council of the European Union at 2
watts/kilogram (W/kg) averaged over 10 grams of body tissue.
The tests used to determine SAR levels were carried out on the basis of
standard usage modes with the phones transmitting at their maximum power
level over the entire range of frequency bands.
Although the SAR was established at the highest certified level, the actual SAR
level for the modem during use is generally much lower than the maximum
values. In fact, since modems are designed to operate at many different
power levels, they only use the minimum level of power required to provide a
connection to the network. In theory, the closer you are to a base station
antenna, the lower the power level required by the modem.
The highest tested SAR value for this modem compliance against the standard
is 1.703W/kg for use at the ear and 0.747W/kg for use closed to the body

1The ICNIRP requirements are applicable in the following regions: Central America (except Mexico), South
America, North and South Africa, Pacific Asia (except Korea), Australia.
2The European recommendation (1999/519/EC) is applicable in the following regions: Europe, Israel.

19
distance of 5mm. While there may be difference between the SAR levels on
various modems and at various positions, they all meet the relevant
International guidelines and EU requirement for RF (radio-waves) exposure.
For body-worn operation, the modem meets EU exposure guidelines provided
that it is used with a non-metallic accessory with the handset at least 1.5cm
from the body.
The World Health Organization (WHO) considers that present scientific
information does not indicate the need for any special precautions for use of
Modems. If individuals are concerned, they might choose to limit their own or
their children’s RF exposure by limiting the length of calls, or using “hands-free”
devices to keep modems away from the head and body (fact sheet n° 193).
Additional information about electromagnetic fields and public health are
available on the following site: http://www.who.int/peh-emf.
Although no danger relating to the use of modem was ever proved, the World
Health Organization advises as a precautionary measure to use your modem
with a good level of network reception as indicated on the software display (4
to 5 bars). It is also advised to keep the modem, during communications,
away from the belly of pregnant women and from the lower abdomen for
teenagers.
The modem is equipped with a built-in antenna. For optimal operation, you
should avoid touching it or degrading it.
General Information
* Internet address: www.alcatel-mobilephones.com
* Customer Support / Hot Line Number: see “TCT Mobile Services” leaflet or go
to our Internet site.
Do not allow the modem to be exposed to adverse weather or
environmental conditions (moisture, humidity, rain, infiltration of liquids,
dust, sea air, etc). The manufacturer’s recommended operating
temperature range is -10°C to +50°C.
As mobile devices offer a range of functions, they can be used in
positions other than against your ear. In such circumstances the device
will be compliant with the guidelines when used with HSPA Modem. If you
are not using HSPA Modem ensure that whatever product is used is free of
any metal and that it positions the phone at least 2cm away from the
body.

20

Alcatel is a trademark of Alcatel-Lucent used under license by TCT Mobile Limited.
All rights reserved © 2009-2010 TCT Mobile Limited.
TCT Mobile Limited reserves the right in the customer’s interest to alter material or technical
specifications without prior notice.
