Connects2Vision CAM-RT2.2 User manual

Image Sensor: 1/3” CMOS
Resolution: 510 x 492 (NTSC), 500 x 582 (PAL)
TV Lines: 700
Signal System: NTSC/PAL
Minimum Illumination: 0 Lux (LED’s on)
Infra-Red LED’s: Yes
Built-in Lens: f-2.8mm
Waterproof Rating: IP69K
Viewing Angle: 120° (Diagonal) x 95° (Horizontal) x 75° (Vertical)
Electronic Shutter: 1/60 (NTSC) 1/50 (PAL) - 1/100,00 second
Operating Voltage: 12V DC (Negative Ground)
Current Consumption: 69-117mA @ 13.8V
Operating Temperature: -30 Degrees C to +70 Degrees C
Certications: FCC, CE, E-mark, ISO9001, TS16949, RoHs
User Manual
Prior to Installation
Read the manual prior to installation. Technical knowledge is necessary for installation.
Please ensure you use the correct tools to avoid damage to the vehicle or product.
Connects2 can not be held responsible for the installation of this product.
Technical Support
Connects2 want to provide a fast and suitable resolution should you encounter any
technical issues. With this in mind, when contacting Connects2, try to provide as
much Information as possible. This will speed up the process and help us to help you.
Please use our dedicated online technical support centre: support.connects2.com
Renault Brake Light Reverse Camera
Renault Trac (X82) 2014 >
PRODUCT FEATURES:
DISCLAIMER:
CAM-RT2.2

www.connects2.com
2
Connects2Vision
CONTENTS
• Camera with 65cm cable to Male 4pin camera connector
• 10m Male to Female 4pin extension cable
• Instructions
INSTALLATION
1. Remove the third brake light from the vehicle and unplug the connection
cable.
2. Remove the bulb and ret it into the CAM-RT2.2
3. Connect the connection cable to the CAM-RT2.2 and ret to the vehicle
taking care not to trap any cables.
4. Check for normal function of the third brake light.
5. Connect the camera cable to the 4pin extension cable.
6. Connect the Black wire to a suitable ground and connect the Red wire to
the reversing light circuit or an interface which provides a reverse signal.
7. Connect the 4pin extension cable to the camera connection cable and
connect the Yellow RCA connector to the display monitor using the supplied
RCA splice and ensure that the image is displayed correctly.
Subscribe to our YouTube Channel for installation
guides and tips... www.youtube.com/connects2
PAL / NTSC SELECTION
To select PAL - leave the green wires separated
To Select NTSC - Connect the Green wires together
