Contacta RF-PortableKit Setup guide

1
RF-PortableKit
Quickstart
User Guide
May 2023
Portable Radio Frequency System

2
Contents
Product Overview
Components
Quickstart
Safety
3
4
5-8
9
Contacta has a policy of continuous product development, therefore small specication changes
may not be reected in this manual. Images, labels, packaging, accessories and product colours
are subject to change without notice.

3
Product Overview
The Portable Radio Frequency System is an assistive listening solution.
It is designed for use by people with hearing devices which are
equipped with a telecoil function, along with people who have hearing
loss who do not use hearing devices.
The system includes a wireless lapel microphone for use by a
presenter addressing an audience. It also includes a wired boundary
microphone that can be placed in a room to provide audio feedback
from an audience or just to provide ambient sound.
An audio mixer is included with multiple spare inputs. This allows for
the connection of additional microphones and other sound sources
such as public address systems.
The system comes with three radio frequency receivers. These
are used by people with hearing loss to listen to an audio source
connected to the portable radio frequency system.
Neck hearing loops are provided for users who have a telecoil function
enabled hearing device. Standard headphones can be connected to
the receiver for users who do not have the telecoil facility.
The system has no limit on the number of receivers which can be
connected. Additional receivers are available for purchase separately.

4
Note: Plug type varies by country.
Components
1. Travel Case
2. Boundary Microphone
3. Stationary Radio Frequency Transmitter
4. Transmitter and Receiver Aerials
5. Handheld Microphone
6. Multi-Frequency Beltpack Microphone
7. 12 Channel Microphone Mixer
8. 1 Channel Microphone Receiver
9. 3 x Inductive Neck Hearing Loop
10. 3 x Portable Radio Frequency Receiver
Complete user guides are provided for individual components.

5
Quickstart
1. Place the Portable Radio Frequency System case on a at surface
near a power socket.
2. Unzip the rear of the case and pull out the mains power cord. Plug
it into a suitable wall power socket.
3. Remove the accessories bag from the back of the case.
4. Zip up the rear of the case, leaving the mains cable extended.
5. Unzip the front of the case and fold the ap underneath it as per
the below image:

6
6. Switch on the Radio Frequency Transmitter, 12 Channel Micro-
phone Mixer, and 1 Channel Microphone Receiver. Ensure the dials
for Channel 1 and Channel 2 are set to Level 2.
Refer to Step 3 in the Radio Frequency Transmitter User Guide
(Page 4) for further setup information.
Refer to Step Control Elements of the 12 Channel Microphone
Mixer User Guide (Page 4) for further setup information.
Refer to Step 2 of Operating Elements and Connections in the
IL-AC-WM-1C-LT Wireless Microphone System User Guide (Page 10)
for further setup information.
7. Ensure that the STS-M90 Boundary Microphone is switched on and
positioned appropriately for optimum audio pick-up.
Refer to Step 3 of the Operation in the Boundary Microphone User
Guide for further setup information.
8. Connect a neck hearing loop or headphones to a portable radio
frequency receiver. Switch on the receiver.
CAUTION: If you have a Pacemaker you may consider not using
the Inductive Neck Loop as this may cause interference with some
Pacemakers”.
9. Conrm that channel numbers on the displays of both the radio
frequency receiver and transmitter match.

7
Refer to Step 2.2 of the Portable Radio Frequency Receiver User
Guide (Page 5) for more information.
10. Place the neck loop around the neck of the hearing device user or
put on headphones if required.
11. Switch on the lapel microphone transmitter and conrm that its
number matches what is displayed on the receiver:
12. Attach the tie clip microphone to the person presenting. Either
place the transmitter in their pocket or clip it to a suitable place
around their waist.
13. If using the neck hearing loop, switch the relevant hearing device
to its ‘T’ setting and adjust the volume to the preferred level.
14. Once sound feedback is received at an appropriate volume, the
Portable Radio Frequency System is ready for use. Connect the
requred receivers.
15. After use, switch o Radio Frequency Transmitter, 12 Channel
Microphone Mixer, and 1 Channel Microphone Receiver.
16. Return all receivers to the top of the case. Then, return all remain-
ing accessories to the provided drawstring bag and position it into
the rear of the case.
17. Unplug the power supply from mains socket and store it in the rear

8
of the case. Zip up the front and rear of Portable Radio Frequency
System casing and place it in a safe location for next use.

9
Charging RF Receivers
Only use the provided wall plug charger and “USB-A to Micro-USB”
charging lead to charge your RF Receivers. Using a dierent charger or
third-party charging equipment may damage your device.
Replace Belt-Pack Microphone Batteries with Care
The Belt-Pack Microphone requires two AA batteries. To replace the bat-
teries, carefully unscrew the battery compartment and insert two new
AA batteries with the correct polarity.
Product Manuals
For more information on your RF Receivers or Belt-Pack Microphone,
please refer to the individual product manuals. These are provided in the
top compartment of the supplied case.
Safety

10
Local dealer:
UK & ROW
[phone]
[email protected].uk
US & Canada
[phone]
[email protected]
www.contacta.co.uk www.contactainc.com
