CONTINENTAL EDISON CECP701FSA User manual

Manuel d’instructions de la
PLAQUE DE CUISSON INDUCTION
CECP701FSA

2
Cooking Hob
Cooking Zones 4 INDUCTION
Supply Voltage 220-240V 50/60 Hz
400 V 50/60 Hz
Installed Electric Power
(W) 7200
Product Size
D×W×H(mm) 590×520×55
560×490
Building-in Dimensions
A×B (mm)
Induction Hotplate
Appearance
CECP701FSA

3
Working Principle
The induction hotplate is mainly composed of an induced heating coil, hotplate
made of ferromagnetic materials and control system.
In principle, current generates a powerful magnetic field via the coil. Large
numbers of vortexes are produced in the way that the magnetic lines in the
field contact the bottom containing iron or stainless steel substances. The
tremendous energy generated by the vortexes can heat the food directly by
converting efficiency heat energy penetrating through the bottom.
Figure (1)
Product Introduction
The induction hotplate can meet various demands of cuisine by
electromagnetic heating, with micro-computerized control and multifunction,
really the optimal choice for modern families.
The induction hotplate centers on customers and adopts personalized design,
and which will make your life comfortable and enabling to fully enjoy the
pleasure of life.
We have designed this hob for private use in home.
Dear customer:
Thank you for purchasing the the induction hotplate our product can
serve you many years to your satisfaction.
Please read this instructions manual carefully before using and
installation, keep it cautiously after reading for future reference.
Thank you for your purchase of the induction hotplate again, and wish
you to enjoy the pleasure by it.

4
Over- Temperature Protection
A temperature sensor equipped can monitor the temperature inside the
hotplate. When an excessive temperature is monitored, the induction hotplate
will stop operation automatically.
Pot Detection
When an unsuitable size or non-magnetic pot (e.g. Aluminum), or some other
small item (e.g. knife, fork, key) has been left on the hob, or the pot has been
removed, the hob can stop heating immediately. If there is no suitable pan put
on the right hob in one minute, the hob will go automatically into the standby
state, and the buzzer will sound for warning at one time.
Heat Indication
When the hotplate is used for a long time, waste heat remains in the heating
zone in a few minutes. The code “H” appears, warning to be away from the
heating zone.
Protection of Shutting Down Automatic
Shutting down Automatic is a safety protection function for your induction
hotplate. It will shut down automatically if you forget to turn off your cooker.
The default working times for various power levels are shown in the
following table:
Power level The heating zone shut down automatically
after
1~5 8 hours
6~10 4 hours
11~14 2 hours
*Remind:
The patient with a heart pacemaker shall use this product under the guidance
of the doctor.
15 1 hours

5
Selection of installation equipment
Drill holes on the table surface according to the sizes shown in the drawing.
For the purpose of installation and use, a minimum of 50 mm space shall be
preserved around the hole.
Be sure the thickness of the table surface is at least 30mm. Please select
heat-resistant table material to avoid larger deformation caused by the heat
radiation from the hotplate.
As shown in Figure (2)
Under any circumstances, make sure the induction hotplate is well ventilated
and the air inlet and outlet are not blocked.
Ensure the induction hotplate is in good work state.
As shown in Figure (3)
Figure (3)
Figure (2)
5cm mini
5cm mini 5cm mini
56 cm
49
c
m
Air intake
mini 5 cm
mini 760mm
mini 2 cm
Air exit
mini 5 mm

6
Note: The safety distance between the hotplate and the cupboard above the
hotplate should be at least 760mm.
Fix the hob on the table by screw four brackets on the bottom of hob (as
shown in figure (4)) after installation. Adjust the bracket position to suit for
different table top thickness.
Figure (4)
Cautions:
1. The induction hotplate must be installed by qualified personnel or
technicians. We have professionals at your service. Please never conduct
the operation by yourself.
2. The induction hotplate shall not be mounted to cooling equipment,
dishwashers and rotary dryers.
3. The induction hotplate shall be installed such that better heat radiation can
be ensured to enhance its reliability.
4. The wall and induced heating zone above the table surface shall withstand
heat.
5. To avoid any damage, the sandwich layer and adhesive must be resistant to
heat.
ELECTRICAL CONNECTION
"The installation must conform to the standard directives."
The manufacturer declines all responsibility for any damage that may be
caused by unsuitable or unreasonable use.

7
Power line connection
The socket shall be connected according to the relevant standard or
connected to a single-pole breaker.
The method of connection is shown in Figure (5):
Figure (5)
blue
green-yellow
N2 N1 L2 L1
grey
brown
black
220-240V
220-240V
blue
green-yellow
N L2 L1
grey
brown
black
400V
220-240V
220-240V
PE
blue
green-yellow
N L
grey
brown
black
220-240V
PE
PE
connet to the main power supply connet to the main power supply connet to the main power supply
220-240V 2+2N~ 220-240V~
400V~ 2-N
If the cable is damaged or needed to be replaced, the operation must be
carried out by the after-sale agent with dedicated tools to avoid any accidents.
If the appliance is being connected directly to the mains an Omni-polar
circuit-breaker must be installed with a minimum opening of 3mm between
contacts.
The installer must ensure that the correct electrical connection has been made
and that it is compliant with safety regulations.
The cable must not be bent or compressed.
The cable must be checked regularly and replaced by authorized technicians
only.

8
Induction Hotplate Appearance
Figure (6)
Air entry
Air vent
Ceramic plate
Control panel
1 4
2 3

9
Schematic Diagram of The Control Panel
Figure (7)
Instructions For Use
Preparation Before Using:
After power on, the buzzer beep once, all the indicators light up for 1 second
and then go out, which indicates the induction hotplate enters the state of
standby.
Put the pot in the center of the heating zone.
Operation Instructions:
When the “ON / OFF” button is pressed, all the indicators show "-" or "---"
OR
According to the heating zone where the pot is placed, select a relevant zone
selection (e.g. select zone 1), with a corresponding power level indicator
flashing.
Heating zone selection key
Timer key
On/OFF
Lock
Regulating key
Boost
At the moment, press the "+" button, the indicator displays "8", or press the "-"
button, the indicator displays "1",then adjust the power u levels sing the "+", "-"
button or the slider
Function key
lide key
S

10
Boost function
To get a quicker heating speed, there is a function named “Boost” will satisfy
your requirement.
Directly press the “ Boost” button after selecting the heating zone, with the
power level indicator showing “P. ” , and the heating power can reach up to the
max. (e.g. select zone 1)
Note:1. The boost function only operates for 5 minutes, after which the cooking
zone returns to its orginal setting.
2. The boost function works on the all cooking zones.
Cancellation of “Boost” function
When in the "Boost" function, select the relevant heating zone with the “Boost”
function, and press the "Boost" button or the "-" button to cancel the Boost
function, then the cooking zone will revert to its original setting.
POWER UP
POWER DOWN
Or press the "+" and "-" buttons simultaneously, the power setting
immediately chang to 0, and the relevant cooking zone switches off.
See the attached table "the max power of each heating zone" for the power
specific to each heating zone.
Note: 1. After the "ON/OFF" button is pressed, the induction hotplate will restore
to its standby state if no any operation is carried out within one minute.
AND
3. As the boost function is activated ,the other cooking zone of the same side
is limited under level 2 automatically(for example, when the 2nd cooking
zone's boost function is activated, the 1st cooking zone which is of the same
left side will be limited under level 2 automatically).
OR

11
Or press the "+" and "-" buttons simultaneously when the relevant heating
zone has been selected, the “Boost” function will be cancelled automatically.
The power setting immediately chang to 0, and this heating zone switch off at
the same time.
AND
Timing function
Select the relevant cooking zone, and set the power level with the “+” or “-”
button. (e.g. the cooking zone 1 with power level 6)
Press the "Timing" button, the timing indicator flashes, and you can set the
timer at this point.
AND
Using the “+” and “-“buttons, you can realize the setting of timing from
0 to 9:59 minutes.
OR
Timing confirmation:
After selecting a set time, once the timing indicator flashes for 5 seconds, or
press the “Timing” button, the set time will be confirmed to be valid
automatically.
Timing cancellation:
If press the "+" and "-" simultaneously, the timing can be cancelled
automatically, with the timing indicator showing “0”.
~
Press the "+" key once increases the time by one minute ; hold down the "+" key
Press the "-" key once decreases the time by one minute ; hold down the "-" key
When the time exceeds 1 hour, hold down the
increases the time by 30 minutes .
When the time exceeds 2 hours, hold down the
decreases the time by 30 minutes .
increases the time by 10 minutes .
the "+" key
decreases the time by 10 minutes .
the "-" key

AND
Interlock Function:
To ensure the safety of children, the induction hotplate is provided with the
function of interlock.
Interlock:
Press the “Interlock” button, then the induction hotplate enters the locking state,
with the timing indicator showing “Loc”.
Unlock:
Holding the “Interlock” button for about 3 seconds, the locking state will be
removed.
Note:
1. The rest buttons disabled except the “ON/OFF” and “Interlock” button when
the induction hotplate is in the locking state. Only unlocking the buttons or else
the induction hotplate won’t be operated.
2. If the induction hotplate enters the locking state in the off mode, the timing
indicator showing “Loc” for one minute. And it will be shown for one minute
again when the “ON/OFF” or “Interlock” button is pressed.
12
Note: 1. In the timing state, the power level of the relevant cooking zone can be
changed, and the time set is still valid.
2. Press the timing button without select one cooking zone when the induction
hotplate is working, the time-warning function will operate. And the warning time
can be set just like the timing function. The buzzer will be beeping for 30 seconds
when the time is reached. The function will be cancelled when the time is set to.
0.
3. the time-warning function will be cancelled when the induction hotplate is
switched off.
4.Timer can be set on all 4 cooking zones. When you set the time for several
cooking zones simultaneously, decimal dots of the relevant cooking zones
are on.
5. on the timer display will be shown the timer than will expire first. The dot of
the corresponding zone will be on but flashing. Once the countdown timer
expires the corresponding zone will be switch off. Then it will be shown the
new first expiring timer and the corresponding zone will have the dot flashing.

Warm Function:
This function is designed for keeping food warm automatically.
Select the relevant cooking zone, press the "Warm" button, the indicator
shows "A", then this relevant cooking zone starts warm function mode.
Note:
Warm function only works on the 2nd and 3rd cooking zone.
Fry Function:
This function is designed for frying food automatically.
Select the relevant cooking zone, press the "Fry" button, the indicator shows "F",
then this relevant cooking zone starts fry function mode
.
The max. power of each heating zone are as follows:
Max. Power(W)
Heating Zone
Normal Boost Dia. Of the Heating Zone
1 2200 2900 220mm
2 1500 2000 140mm
3 2000 2800 180mm
4 1500 2000 140mm
The above power may vary if the material or the size of pot is differet.
13

Selection of heating appliances
Iron oil frying pan Stainless steel pot
Iron pan Iron kettle
Enamel stainless
steel kettle Enamel cooking utensil Iron plate
You may have multiple appliances suitable for heating.
This induction hotplate is able to identify multiple heating appliances, and you
can test them according to one of the following methods:
1. Place the appliance in the heating zone. If the corresponding heating zone
displays a power level, it shows the suitability of the appliance; if “ ” flashes, it
shows the appliance does not fit in the induction cooking.
2. Have a magnet to contact the appliance. If there is attraction between them,
it shows the appliance also fits in the induction cooking.
●Requirement for pot material: the bottom contains materials of magnetic
conductivity.
●Requirement for shape: flat bottom.
14

Safety Reminding and Maintenance:
Please use a dedicated
power protection air
switch;
Indoor use only. Never directly wash the
induction hotplate with
water so as to avoid
dangers.
Never have the induction
hotplate to work without
food inside, otherwise its
operational performance
may be affected and
danger may happen.
For sealed food such as
canned goods, please
do not heat them before
opening their covers so
as to avoid any dangers
of explosion due to
heating expansion.
After being used for a
long time, the
corresponding heating
zone of the induction
hotplate is till hot. Never
touch the ceramic
surface to avoid
burning.
We suggest that you
should periodically check
that there are no object
(glass, paper, etc) that
could obstruct the inlet
under your induction
hotplate.
Metallic objects such as
knives, forks,spoons
and lids should not be
placed on the hotplate
since they can get hot.
Never use the induction
hotplate in high
temperature
environments such as
near a gas stove or
kerosene stove.
15

Do not put any
detergents or flammable
materials in the
equipment installed
under the induction
hotplate.
If the surface is
cracked, swith off the
appliance to avoid the
possibility of electric
shock.
Do not place rough or
uneven appliances,
which may damage the
ceramic surface.
Clean the induction
hotplate on a regular
basis to prevent foreign
matters from entering the
fan thus influencing the
normal operation.
Keep electrical
appliance out of reach
from children or inform
person. Do not let them
use the appliances
without supervision.
If the supply cord is
damaged , it must be
replaced by the
manufacturer, its
service agent or
similarly qualified
persons in order to
avoid a hazard.
16

DISPOSAL: Do not
dispose this product
as unsorted municipal
waste. Collection of
such waste separately
for special treatment is
necessary.
This appliance is labeled in compliance with European
directive 2002/96/EC for Waste Electrical and Electronic
Equipment (WEEE). By ensuring that this appliance is
disposed of correctly, you will help prevent any possible
damage to the environment and to human health, which
might otherwise be caused if it were disposed of in the
wrong way.
The symbol on the product indicates that it may not be
treated as normal household waste. It should be taken to a
collection point for the recycling of electrical and electronic
goods.
This appliance requires specialist waste disposal. For
further information regarding the treatment, recover and
recycling of this product please contact your local council,
your household waste disposal service, or the shop where
you purchased it.
For more detailed information about treatment, recovery
and recycling of this product, please contact your local city
office, your household waste disposal service or the shop
where you purchased the product.
Cleanness and Maintenance
You can easily clean the surface of the induction hotplate if following
the methods given in the table.
Type of
contamination Method of cleaning Articles used
forcleaning
Light Immerse in hot water then wipe it
dry Cleaning sponge
Accumulation of
dirt Immerse in hot water then wipe it dry with abrasive sponge
Special cleaning
sponge for ceramic
glass
Rings and lime
crumbles
Apply white vinegar to the
polluted zone, then wipe it dry
with soft cloth or a special article
available in local markets
Special adhesive for
ceramic glass
17

Sweetmeat, melt
aluminum or
plastics
Use a scraper suitable for
ceramic glass (to protect glass, a
silicon product is preferred) to
remove residuals
Special adhesive for
ceramic glass
Hint: please disconnect power before the cleaning.
Failure Display and Inspection
If an abnormality comes up, the induction hotplate will enter the protective
state automatically and display corresponding protective codes:
Troubles Possible reasons Solutions
F0-F2 Fan failure. Please contact the supplier
Power on, and then restart after the
temperature around returns to be
normal.
F3-F8 Thermistor component
failure. Please contact the supplier.
Power on, and then restart after the
temperature around returns to be
normal.
F9-FE Temperature sensor of
the IGBT failure. Please contact the supplier.
Please inspect whether power
supply is normal.E1-E2 Abnormal supply voltage.
Please contact the supplier.
Please inspect the pot.
Please restart after the hotplate
cools down.
E3-E4 Abnormal temperature.
Please contact the supplier.
Please restart after the hotplate
cools down.E5-E6 Bad hotplate heat
radiation. Please contact the supplier.
The above are the judgment and inspection of common failures.
Please do not disassemble the unit by yourself to avoid any dangers and
damages to the induction hotplate.
18

Customer Care Service
Before calling the After Sales Service
In case the appliance should not work correctly we suggest to:
-verify if the plug is correctly inserted in the socket
-read the Failure and Display table above
In case it is not possible to establish the reason for the bad functioning of the
appliance, switch it off, do not try to manumit it and call the After Sales Service.
Special DecIaration
All the contents in this material have been subjected to careful check. For any
mistake and omission in printing or misunderstanding of the contents,the
company keeps the right of interpretation.
With a view to constantly improving our products, we reserve the right to make
any changes to the technical, program or aesthetic features connected with
the technical evolution.
Addition:any technical improvement will be placed in the revised manual
without notice;for product appearance and color is according to the actual one.
19

20
Cooking Hob CECP701FSA
Cooking Zones Plaque de cuisson induction 4 zones et 4 booster
Supply Voltage 220-240V 50/60 Hz
400 V 50/60 Hz
Installed Electric Power
(W) 7200
Product Size
D×W×H(mm) 590×520×55
560×490
Building-in Dimensions
A×B (mm)
Induction Hotplate
Appearance
