Continuum 2424 User manual

Model2424
HowtouseyourNew
ContinuousFlow
WaterHeater
WARNING: If the information in these instructions is not followed exactly,
a fire or explosion may result causing property damage, personal injury or
death.
-Do not store or use gasoline or other flammable vapors and liquids in
the vicinity of this or any other appliance.
-WHAT TO DO IF YOU SMELL GAS
* Do not try to light any appliance.
* Do not touch any electrical switch; do not use any phone in your
building
* Immediately call your gas supplier from a neighbor’s phone. Follow
the gas supplier’s instructions.
* If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer,
service agency or the gas supplier.
(outdoor unit)

Model 2424www.rinnaiamerica.com 2
ecnailppafoepyT metsysretawtohsagwolfsuounitnocdellortnocerutarepmeT
noitarepO .cte,moorhtab,nehctiknide
tnuom,slortnocetomertuohtiw/htiW
metsystsuahxEnoitsubmocdecroF-tneVtceriD
rebmunledomianniRSU-W4242-UER
)s
'UTBtupnI(etarsagmuminiM/mumixaMs'UTB000,91-s'UTB000,081
)esirF°05(yticapacretawtoHMPG5.6ot6.0
)etomertuo
htiw(erutarepmeTtniopteSF°021
etomerhtiwegnarerutarepmeT
detcennocsdapyeK
F°041-69:rellortnocCM
F°021-69:rellortnocCSBdnaCB
epytsagdevorppA .nodellatsnigniebs'tiepytsagsehctamtinuerusnE-enaporProlarutaN
noitall
atsnIylnOroodtuO
snoisnemiD
"4/332thgieH
"4/331htdiW
htpeD"4/36
thgieW.sbL44
gnitarycneiciffE%28
levelesioN)A(Bd9
4
snoitcennoC
TPNM"4/3ylppussaG
TPNM"4/3telniretawdloC
TPNM"4/3teltuoretawtoH
metsysnoitingInoitingicinortc
eletceriD
noitpmusnoclacirtcelE
sttaw55lamroN
sttaw8ybdnatS
sttaw09noitcetorptsorf-itnA
lortnocerutarepmet
retaW .kcabdeefdnadrawrofdeefnoitalumiS
lortnocwolfretaW ecivedlortnocwolfretawlacinahcem-ortcelecitamot
uadnarosneswolfretaW
erusserpylppusretawmuminiM )ecnamrofrepmumixamrofISP08-06sdnemmocerianniR(ISP04
eru
sserpylppusretawmumixaMISP051
SPECIFICATIONS

Model 2424 800-621-94193
secivedytefaS
.zH06-stloV021CA-ecnailppA
)latigiD(stloV21CDlortnocetomeR
doremalF-eruliafemalF
F°302-noit
cetorpgnilioB
hctiwslatem-ibF°491)SHO(emalfgniniameR
F°972esuflamrehT
sretaehtsorf-itna&rosneslatemiB-no
itcetorptsorfcitamotuA
tiucricdetargetnI-kcehcmprnafnoitsubmoC
)pma3(esufssalG-tnerrucrevO
retawhtiwF°00
1otstluafedtinudetcennocsidsemocebrosliafetomerfI
.erutaefdlacs-itnanasisiht,gniwolf
lortnocetomeR
yrdnu
aL/nehctiKlortnocniaMSU3-54-CM
lortnocmoorhtaBSU3-54-CB
lortnocmoorhtabdnoceSSU3-54-CSB
elbaclortnocetom
eRelbacerocowtdeziralop-noN
selbitsubmocmorfsecnaraelC
"21retaehfopoT
"42retaehfotnorF
"6retaehfosediS
"0re
taehfokcaB
"21dnuorG
"63=sgnahrevo,sehcrop,sevaewoleB
erusserpylppussagmumixaMdnamuminiM .C.W"6muminiM*:s
aGlarutaN
.C.W"5.01mumixaM**).TAN(
.C.W"01muminiM*:saGenaporP
.C.W"41mumixaM**)GPL(
erusserPsaGdlofinaM er
ifwol.C.W"34.0erifhgih.C.W"3.5saGlarutaN
erifwol.C.W"95.0erifhgih.C.W"7.8:GPL
ytnarraW )sliatedrofytnarr
aws'tinuees(strapsraeyevif/regnahcxetaehsraeyneT:laitnediseR
)retaeHretaWCW4242esU-ytnarraWoN(:gnitaeHecapSrolaicremmoC
.stnemtsujdatupnifoesoprupehtrofsierusserptupnimuminiM*
.erusserpmumixamdeecxetonoD**
SPECIFICATIONS

Model 2424www.rinnaiamerica.com 4
Rinnai warrants the continuous Hot Water Heater Model 2424W, including any parts and compo-
nents thereof, to be free from any defects in materials and workmanship for the period specified below, subject to
the terms specified in this warranty. This warranty gives you specific legal rights and you may also have other
rights which vary from state to state.
This Warranty shall apply to the Continuum 2424W Continuous Hot Water Heater as follows:
CONDITION AND EXCEPTIONS Domestic Use Commercial or Space Heat
Item Type of Failure Covered Period of Coverage Period of Coverage
Heat Exchanger Defective Materials or 10 Years from Date of No Coverage
Workmanship Purchase (Use 2424WC water heater)
All other parts Defective Materials or 5 Years from Date of No Coverage
and components Workmanship Purchase (Use 2424WC water heater)
In the event of a malfunction, operational difficulty or failure of the product, or any part or any component thereof,
during the warranty term, resulting from defects in materials or workmanship, Rinnai will remedy the malfunction,
operational difficulty, or failure without charge to the owner of the water heater. The remedy will consist of repair
or replacement of the product at the option of Rinnai.
Rinnai will only provide those remedies listed above. The owner shall be responsible for all other costs, including
but not limited to shipping and delivery charges, labor associated with the removal and reinstallation of the
product or its components, and any other incidental costs such as other materials or permits that may be re-
quired for installation.
This warranty DOES NOT cover any failures, operational difficulty or malfunction due to accident, abuse, misuse, alter-
ation, Acts of God, misapplications, improper installation or improper maintenance or service, lime damage, or from any
other cause other than defects in materials or workmanship. Warranty does not cover use as a pool or spa heater.
PROCEDURE FOR MAKING ACLAIM
In order to obtain the benefits of the warranty, contact your selling dealer or Rinnai at 800-621-9419 for the
location of the servicing dealer nearest you.
Proof of Purchase is required to institute a claim under this warranty. This document does not constitute proof-of
purchase.
LIMITATION ON IMPLIED WARRANTIES
Any implied warranties of merchantability and fitness applicable to the equipment arising under state law are
limited in duration to the period of coverage provided by this limited warranty, unless the period provided by state
law is less. Some States do not allow limitations on how long an implied warranty lasts, so the above limitation
may not apply to you.
DISCLAIMERS
Rinnai is not liable for any special, indirect or consequential damages, such as water damage, loss of use,
inconvenience, damage to person or property, whether arising in contract or tort.
Rinnai does not authorize any person or company to assume for it any other obligation or liability in connection
with the sale, application, engineering, installation, use, removal, return or replacement of its product, and no
such representations are binding on Rinnai.
Please DETACH the enclosed warranty registration card, fill it out, and drop it in the mail. Receipt of this
completed card by Rinnai will constitute proof-of purchase for your Rinnai Continuum 2424W.
WARRANTY

Model 2424 800-621-94195
Specifications..............................................................2,3
Warranty ........................................................................ 4
Owner's Installation Information................................... 6
Features of your new Continuum ................................ 7
Safety Issues..............................................................8,9
Basic Operation........................................................... 10
About Hot Water ......................................................... 11
Scalds-First Aid ........................................................... 11
Remote Control Operation ......................................... 12
Error Messages........................................................... 13
Maintenance & Service Information......................14,15
Trouble Shooting and Common Questions............... 16
Operating Instructions............................................17,18
Care & Lime Condition Warning................................ 18
CONTENTS

Model 2424www.rinnaiamerica.com 6
This product must be installed by a Rinnai certified installer. Failure to
have the product installed by a Rinnai certified installer may result in a
voiding of the product’s warranty.
Detailed instructions on the proper installation practices to follow for
the installation of your new continuous hot water heater are included
at the back of this manual.
This appliance must be installed in accordance with local codes, or in
the absence of local codes, the National Fuel Gas Code, ANSI Z223.1
and/or the CAN/CGA-B149, Installation Codes.
Install this product outdoors, DO NOT install indoors.
Do Not use this appliance if any part has been underwater. Immedi-
ately call a qualified service technician to inspect the appliance and to
replace any part of the control system and any gas control which has
been underwater.
For the Rinnai Certified Installer nearest
you call:
1-800-621-9419.
OWNER’S INSTALLATION INFORMATION

Model 2424 800-621-94197
)The Continuum 2424 is one of the most advanced water heaters available. It supplies
hot water continuously at the temperature preset in the unit or at the temperature set
on the optional remote control(s). Remote controls are recommended for optimum per-
formance.
)The Continuum 2424 never runs out of hot water. While electricity, water and gas sup-
plies are connected, hot water is available whenever the hot tap is open.
)The gas burner lights automatically when the hot water tap is opened, and goes out
when the tap is closed. Ignition is electronic, there is no pilot light. When the hot water
tap is off, no gas is used. You save energy and money with the Continuum 2424.
)The temperature of the outgoing hot water is constantly monitored by a built in sensor.
If the temperature of the outgoing water rises to more than 6 degrees above the se-
lected temperature (shown on the optional digital remote control) the gas burner will
automatically go out. The gas burner will re-ignite once the outgoing hot water tempera-
ture falls below the selected temperature.
)Built into the microprocessor of the Continuum 2424 is the ability to LIMIT THE MAXI-
MUM TEMPERATURE of the hot water supplied by the Continuum 2424. Without the
connection of an optional remote control, the Continuum 2424 is preset to deliver 120
degree water.
)With the optional remote the water temperature is adjustable from 96 to 140 with the
main controller and from 96 to 120 with the bath controller. The water temperature can
be preset at 108, 120, 130, or 140 by a certified Rinnai technician. If you require a
temperature other than 120 or what the remotes will give you, please contact your
Rinnai certified technician.
)Error messages are displayed on the optional remote controls, simplifying service calls.
)The Continuum 2424 incorporates a device to prevent the temperature from varying
when the water is off, then on again. It also incorporates a rapid response device for
fast heating.
)The sound (noise) level from the Continuum 2424 is very low.
)The Continuum 2424 is a very compact power vented device. It saves valuable floor
and wall space.
FEATURES OF YOUR NEW CONTINUUM

Model 2424www.rinnaiamerica.com 8
Always check water temperature by hand
before entering the shower or bath. The
temperature may have been changed.
The water temperature can only be ad-
justed between 96°F and 110°F when the
hot water tap is open, and hot water is
flowing.
Do not clean Remote Controls with
solvents. Use a soft damp cloth. Do not touch the cover or insert objects
into the flue outlet of the Continuum 2424.
On cold days steam may be discharged
from the flue outlet, this is normal with a
high efficiency appliance and does not
indicate a fault.
SAFETY ISSUES

Model 2424 800-621-94199
Keep flammable materials, trees, shrubs etc.
away from the Continuum 2424
Do not spray water directly into the flue
terminal.
If the external Continuum 2424 is discon-
nected from the power supply and freez-
ing conditions are expected, turn off
water and gas, and drain all water from
the appliance.
Water Off
Gas Off DRAIN
Drain Water FILTER
Depending on the weather conditions and the
length of the pipe between the Continuum
2424 and the tap in use, there may be a
variation between the temperatures displayed
at the Remote Control and the temperature of
the water at the tap.
106°F
The Continuum 2424 controls the water
temperature automatically. To do this it
sometimes needs to change the water
flow accordingly. The water flow from the
hot water tap may vary after the selected
temperature at the Remote Control is
altered. The water flow may also vary
from summer to winter, as incoming water
temperatures differ.
100°F 140°F
108
SAFETY ISSUES
If power and the automatic frost protection are
connected, freezing will be prevented in conditions
as cold as -30°F.
WATERGAS

Model 2424www.rinnaiamerica.com 10
To operate the Continuum 2424 simply turn
any hot water tap on. This will automatically
light the burner providing hot water at the
preset temperature. If the optional remote
controls have been installed, the green IN USE
indicator will glow on all remote controls.
AdjustingTemperature
1
To take control of the Continuum 2424 all
hot water taps must be closed. Press the
“Priority button” on the control you want to
set the temperature with and the yellow
“Priority” indicator will glow on the Control
which you have pressed the “Priority
button” on. This indicates that the Con-
tinuum 2424 is ready to supply hot water
at the set temperature as soon as a tap is
opened.
The temperature can only be adjusted
on the Remote Control where the Priority
indicator is glowing, and the same tem-
perature will be displayed
on all Controls.
98F 110F
3 Simply press the or button
until the required temperature is dis-
played on the Digital Monitor.
4
110°F
2
TEMPERATURE CANNOT BE
ADJUSTED EXCEPT BE-
TWEEN 96°F AND 110°F
WHEN ANY HOT WATER
TAP IS OPEN.
CHECK WATER TEMPERA-
TURE BEFORE ENTERING
SHOWER OR BATH.
Always test the water temperature
in bath before a child gets in.
This is best done by the parent
placing their elbow in the water.
BASIC OPERATION
Priority

Model 2424 800-621-941911
ABOUT HOT WATER
Hot Water Is Dangerous, especially for the young and the elderly or the
infirm. The Continuum 2424 allows you to precisely control the tempera-
ture of your hot water, ensuring safe hot water temperatures.
Water Temperatures over 125°F can cause
severe burns instantly or death from scalds.
Hot Water can cause first degree burns with
exposure for as little as:
3 seconds at 140 °F
20 seconds at 130 °F
8 minutes at 120 °F
Test the temperature of the water with your
elbow before placing a child in the bath or
shower.
Do not leave a child or an infirm person in
the bath unsupervised.
Scalds - First Aid
1) Remove clothing; Remove all wet clothing, quickly. Wet clothing retains the heat.
2) Apply cold water for 30 minutes; Immediately submerge the burnt area in cold
water for 30 minutes to reduce the heat in the skin, preventing deeper burning.
Never use butter, oils or ointment to cover the burn. They may retain the heat.
3) Keep the scalded person warm; Place a blanket around the person.
4) Seek Medical Advice; Call your medical advice hotline and describe the scald,
follow their directions.
BURN

Model 2424www.rinnaiamerica.com 12
In Use Indicator
Indicates that a hot water
tap is open and that control
of the temperature is taken
at another controller.
Digital Monitor
Indicates the selected
water temperature. Error
messages flash in the
event of a failure.
Priority Indicator
Indicates whether this
controller has priority
control over the water
temperature.
Priority Button
Pressing takes control of
the water temperature by
this controller.
Thermostat
Increase or decrease
the desired water
temperature.
°F
Set Temperature In Use
Priority
Bath Controller
BC - 45 - 3US HC
The Main Controller MC-45-3US is intended to be used in the kitchen,
laundry room or utility area, the Bath Controller BC-45-3US and the
Second Bath Controller BSC-45-3US are intended for installation in the
bathroom.
endless hot water system
CAUTION: Hotter water increases the risk
of scald injury. Before changing tempera-
ture setting, see instruction manual
REMOTE CONTROL OPERATION

Model 2424 800-621-941913
Code
Displayed Fault Remedy
Air Supply or Exhaust Blockage
No Ignition
Flame Failure
Earthing Failure
Remaining Flame Safety Device
Over Temperature Warning
Heat Exchanger Incoming Water
Temperature Sensor Faulty
Outgoing Water Temperature Sensor Faulty
Mod. Solenoid Valve Answer Abnormal
Combustion Fan Failure
Solenoid Valve Driving Circuit Faulty
Flame Sensing Device Faulty
Scale build-up in Heat Exchanger
Check that nothing is block-
ing the air intake or exhaust.
Check that the gas is turned
on at the water heater, gas
meter or cylinder.
Check that the gas is turned
on at the water heater and gas
meter. Check for obstructions
in flue outlet.
Service Call
Service Call
Service Call
Service Call
Service Call
Service Call
Service Call
Service Call
10
11
12
14
16
31
32
52
61
71
72
LC Service Call
ERROR MESSAGES
The Continuum 2424 has the ability to check its own operation continuously. If a fault occurs,
an Error Message will flash on the Digital Monitor of the Remote Controls. This assists with
diagnosing the fault, and may enable you to overcome a problem without a service call.
Please quote the code displayed when inquiring about service.
NOTE: Failure to remedy faults may result in severe burns, scalds, and/or death.

Model 2424www.rinnaiamerica.com 14
In the case of any fault or error message from the Continuum 2424, first turn
all hot water taps off. Wait for 5 seconds. Turn the hot water tap back on. If this
does not correct the fault or eliminate the error message from the remote control,
press the priority button on and off twice to reset the system. If the error mes-
sage still remains, call your Rinnai Authorized Service Representative or Rinnai
at 800-621-9419.
DO NOT ATTEMPT TO SERVICE YOUR Continuum 2424 YOURSELF.
Call a Rinnai Authorized Service Technician or call Rinnai at 800-621-9419.
Should overheating occur or the gas supply fail to shutoff, turn off the
manual gas control valve to the appliance.
Warning: Always turn off the electrical power supply, the manual gas valve
and the manual water control valve whenever servicing the unit.
The Continuum 2424 should be checked by a Rinnai Certified
Technician once a year. A Rinnai Certified Technician should
perform any repairs that may be necessary.
The following items should be checked each inspection:
1) The area around the Continuum 2424 unit should be free from combustible
materials such as cloth, vegetation and building materials. (see page 9)
2) Check burners for presence of foreign debris.
3) Remove and clean the inlet water filter.
4) Keep the appliance area clear and free from combustible materials, gasoline, and other
flammable vapors and liquids.
5) Do not obstruct flow of combustion and ventilation air.
MAINTENANCE & SERVICE INFORMATION

Model 2424 800-621-941915
MAINTENANCE SUGGESTIONS
This water heater has been designed and constructed
for a long performance life when installed and operated
properly under normal conditions. Regular inspections,
as outlined in this section, are strongly recommended
as a means of keeping your heater operating efficiently.
1. Cleaning
The water heater must be cleaned annually.
Keep the water heater clear of dust and debris
especially in and around burner.
Cleaning procedures for the Continuum are as
follows:
1) Turn off and disconnect electrical power. Allow
to cool for one hour.
2) Remove the Front Panel by removing screws.
See parts breakdown on panels.
3) Use pressurized air to remove dust from around
main burner.
4) Use soft dry cloth to wipe cabinet.
DO NOT DAMAGE OR DISTORT ANY
PARTS OF HEATER.
DO NOT USE WET CLOTH OR
SPRAY CLEANERS ON BURNER.
2. Visual check of main burner flames.
The burner must flame evenly over the entire sur-
face when operating correctly. The flame must burn
with a clear, blue, stable flame. See the parts
breakdown of the burner for the location of view
ports. Any and all parts removed for inspection or
service must be replaced before operating the unit.
The flame pattern should be as shown in the fol-
lowing Figures.
* VENT MAINTENANCE
* VENT SYSTEM
Must be checked annually for
blockage or deterioration.
* MAINTENANCE-
ELECTRIC MOTORS
Motors are permanently lubri-
cated and need no lubrication.
Keep fan and motor free of
dust and dirt, clean annually.
MAINTENANCE & SERVICE INFORMATION

Model 2424www.rinnaiamerica.com 16
TROUBLE SHOOTING AND COMMON QUESTIONS
Q- I don't have any hot water when I open the tap!
A- Make sure there is gas and electricity to the Continuum 2424.
(the power is turned on and the gas is turned on)
Q- When I was using the hot water, the water got cold!
A- If you adjusted the flow from the tap to lessen it, you may have gone
below the minimum flow required. The Continuum 2424 requires .6
GPM to operate. If you mix the water with a tap and attempt to get a
temperature well below the temperature being controlled by the unit, it
may drop the flow below .6 GPM. Decrease the temperature supplied
by the Continuum 2424 at the remote control or increase your total
flow.
Q- White smoke comes out of the exhaust!
A- During colder weather when the exhaust temperature is hotter than
the air, the exhaust fumes condense producing white steam.
Q- When I open a hot tap. I do not immediately get hot water!
A- Hot water must travel through your plumbing from the Continuum
2424 to the faucet. This can take from 2 to 10 or more seconds de-
pending upon your plumbing system.
Q- After I turn off the hot water tap, the fan on the Continuum 2424
continues to run!
A- The fan is designed to be on for 65 seconds after the flow of water
stops.This is to ensure constant water temperatures during rapid start-
ing and stopping, as well as exhausting any residual gas flue prod-
ucts from the unit.

Model 2424 800-621-941917
Warning: If you do not follow these instructions exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.
A. This appliance is equipped with a direct igni-
tion device which automatically lights the
burner. Do not try to light the burner by hand.
B. BEFORE OPERATING: Smell all around
the appliance area for gas. Be sure to
smell below the unit because some gas is
heavier than air and will settle to the
ground.
WHAT TO DO IF YOU SMELL GAS
•Do not try to light any appliance.
•Do not touch any electric switch, do not
use any phone in your building.
•Immediately call your gas supplier from a
neighbor’s phone. Follow the gas
supplier’s instructions.
FOR YOUR SAFETY READ BEFORE OPERATING
•If you cannot reach your gas supplier, call
the fire department.
C. Use only your hand to operate remote con-
trol keypad. Do not use tools. Force or
attempted repair may result in a fire or ex-
plosion. If the remote keypad doesn’t work,
call a qualified service technician.
D. Do not use this appliance if any part has
been under water. Immediately call a quali-
fied service technician to inspect the appli-
ance and to replace any part of the control
system and any gas control which has been
under water.
6) Wait (5) minutes to clear out any gas. If
you then smell gas, STOP! Follow “B” in
the safety information above on this label.
If you don’t smell gas, go to next step.
Closed manual valve
(“OFF” position)
Open Manual valve
(“ON” position)
1) STOP! Read the safety information above
before proceeding.
2) Set the thermostat to lowest setting.
3) Turn off all electric power to the appliance.
4) This appliance is equipped with a direct igni-
tion device which automatically lights the
burner. Do not try to light the burner by hand.
5) Turn the manual valve located at gas
inlet of the appliance clockwise
to “OFF”.
OPERATING INSTRUCTIONS

Model 2424www.rinnaiamerica.com 18
FOR YOUR SAFETY READ BEFORE OPERATING
CARE & LIME CONDITION WARNING
7) Turn the manual valve located at the gas
inlet of appliance counterclockwise
to “ON”.
8) Turn on all electric power to the appliance.
9) Set thermostat to desired setting.
10) If the appliance will not operate,
Follow the instructions “To Turn Off
Gas To Appliance” and call your
service technician or gas supplier.
To Turn Off Gas To Appliance
1) Set the thermostat to lowest setting.
2) Turn off all electric power to the appliance if service is to be performed.
3) Turn the manual valve at gas inlet of appliance clockwise to “OFF”
Care of Unit’s Exterior:
Keep the exterior cabinet clean. Use a soft cloth and warm water when cleaning the cabinet.
Do Not use volatile substances such as benzene and thinners, as they may ignite, or cause
fading of the paint.
Lime Condition Warning Signal:
If you notice “LC” flashing on the remote key pad, this means the unit is beginning to lime up,
and MUST be flushed. Contact a qualified Rinnai service technician to flush the appliance.
Failure to flush the appliance when “LC” is flashing, will cause damage to the heat exchanger.
Damage caused by lime build up is not covered by the unit’s warranty.

Installer’sInstructions
www.rinnaiamerica.com
800-621-9419
Warnings....................................................20
Performance Data..........................................21
Locating the Unit.........................................22
Dimensions.................................................22
Recommended Piping for Installation........23,24
Power Failure Freeze Protection..................25
Gas Piping Sizing Charts.............................26
Gas Piping Notes.........................................27
Water Piping Notes......................................28
Pressure Relief Valve................................28
Electrical Connection Notes.........................29
Wiring Diagram........................................30,31
Lighting the Unit.........................................32
Remote Controls.....................................33,34
Testing........................................................35
Diagnostic Points.......................................36
Schematic Diagram.....................................37
Exploded View..................................38-41
Parts List..............................................42-46
Contents
of Installer’s
Manual
This section is for the Rinnai Certified
Installer only. If you are not certified
you are not authorized to install this
unit. The warranty may be voided due to
installation by a non-certified installer. For
information on becoming a Rinnai Certified
Installer, call1-800-621-9419.

Model 2424www.rinnaiamerica.com 20
This manual must be followed exactly.
1) Read the safety issues completely before installing the Continuum 2424.
2) This water heater is suitable for water (potable) heating or space heating.
- The piping connected to the Continuum 2424 must be approved for use in
potable water systems.
- Toxic chemicals such as those used for boiler water treatment are NOT to be
introduced to the Continuum 2424.
- The Continuum 2424, if it will be used as a potable water source, it must not
be connected to a system that was previously used with a nonpotable water
heating appliance.
3) The Continuum 2424 is not suitable for use as a pool or spa heater.
4) The dip switches on the computer board have been preset at the factory and
should not be readjusted without the express knowledge and involvement of
Rinnai.
5) Install the Continuum 2424 outdoors only.
6) Maintain proper space around the unit for proper servicing and operation.
Minimum clearances from combustible materials are listed below.
Top of Heater 12 inches
Back of Heater 0 inch
Front of Heater 24 inches
Sides of Heater 6 inches
Ground 12 inches
DO NOT install the Continuum 2424 under an overhang less than 3 feet from
the top of the unit. The area under any overhang greater than 3 feet must be
open on three sides.
7) Installer must install a Pressure relief valve. Pipe pressure relief discharge to a
drain or outside environment (see page 27).
INSTALLER’S INSTALLATION INSTRUCTIONS
-Warnings-
