Control Products TC-110 Series User manual

Custom Design
TemperatureControllers
TC–110
TC–110H
TC–110RTD
General Description
SP-2 SP-1
N0 C NC NO C NC G S +5 –3 – +
The TC-110 series panel mount temperature controllers provide
temperature display, relay control, and feature programmable
setpoints, upper and lower setpoint limits, differentials and
calibration.
Applications
Applications include heating, cooling, refrigeration, HVAC,
food service, medical and industrial equipment.
Features
• Membrane touch-pad programming
• 0.56" high red LED display
• Programmable setpoint(s) and differential(s)
• Panel mount enclosure • Available with single or dual stages
• Temperature setpoint display
• LED relay status indicator(s)
• Tamper resistant programmable setpoint limits
Specifications
Ambient temperature range: 20° to 158°F,
– 6° to 70°C
Humidity: 90% non-condensing
Agency approvals: U.L. and C.U.L. recognized,
NSF listed depending on model (consult factory)
Weight: 3.6 oz. (1.64kg)
Power requirements: Available in 12 or 24 volt models -
Specify AC (2VA) or DC (100 mA) voltage supply
Accuracy: +1°F, +1°C
Relay status indicator: Lighted while relay is activated
Relay(s) contact rating: SPDT relay, 4 Amp
(24 VAC resistive).
Sensor , TC - 110
+5=factory
Factoryy
+ = volt (white)
– = ground (black)
Input
Power
–3=factory
SET
°F
ADJUST
>
>
Cutout Dimensions
2.533"
1.35"
relaystatusindicator 0.125"
hidden
button
3.1"
1.51"
3.22"
1.27"
Dimensions & Wiring
110RTD/111RTD –99° to 999°F / –72° to 538°C + 2°F/1°C 100 ohm platinum RTD (not included)
Series Temperature Range °F / °C Accuracy Sensor Type
110H/111H 32° to 572°F / 0° to 300°C + 2°F/1°C PTC, 0.188"OD x 4" stainless steel cap, 36" two conductor
24 AWG wire (included)
(over 300° span)
Sensor , TC - 110H
(polaritysensitive)
Sensor , TC - 110 RTD (no polarity)
(64 mm)
(38 mm)
(32 mm)
(3 mm)
(82 mm)
(38 mm)
(79 mm)
1.51" (34 mm)
S = signal (red)
S = signal (white)
G= ground (black)
G= ground (white)
1724 Lake Drive West • Minneapolis, MN 55317 • 612-448-2217 FAX [phone] • Made in USA
110/111 –67° to 302°F / –55° to 150°C +1°F/1°C PTC, 0.25"OD x 1.75" nickel plated copper cap, 36" two
conductor 24 AWG wire (included)
Innovative Technologies in Custom Electronic Design & Manufacturing

Programming Instructions
IMPORTANT: If the programming sequence is interrupted for more than 15 seconds or not completed to the blank
screen stage, the unit will automatically revert to the temperature display mode WITHOUT acknowledging any
new values (tamper resistant feature).
B. DIFFERENTIAL(S), HIGH/LOW SETPOINT LIMITS AND CALIBRATION – To program these parameters, press
the "hidden" button located behind the "°F" or "°C" symbol (instead of the SET button), and repeat the programming
procedure described in step A.
1. Differential "dIF" – setting a positive differential value will close the NO (normally open) relay(s)
on temperature fall (heating applications) and open the relay(s) on temperature rise. A negative differential
setting will close the NO relay(s) on temperature rise (cooling applications) and open the relay(s) on
temperature fall. Differential is programmable from –30° to +30°. DO NOT SET DIFFERENTIAL AT "0".
2. High and Low Setpoint Limits "HI" and "LO" – allow you to limit the range in which the setpoints can
be programmed. Also, by programming the high and low setpoint limit values to the same number, a
tamper-resistant fixed setpoint is established.
3. Calibration "CAL" – Controller calibration can be programmed +30 degrees. Unit is factory calibrated to a
certified standard.
A. SETPOINT(S) 1. To start the programming sequence, press the SET button once. Unit displays "SP1" (setpoint 1).
2. Press the SET button again to display SP1 value.
3. To program an increase or decrease in SP1, press the appropriate ADJUST arrow.
4. Repeat steps 1 thru 3 for SP2 (setpoint 2, dual stage model only).
5. To complete the programming sequence, press the SET button until the screen
goes blank. After five seconds, the unit will automatically display sensor temperature.
Please use the following example when ordering:
TC – 110 H – S – 24
Ordering Information
Rev. 4-95
Control Products, Inc. warrants its products to be free from defects in material and workmanship under normal use for
one year and is not responsible for consequential damages or installation costs of any nature. Exposure to contaminants
and extreme environmental conditions such as moisture, temperature, chemicals, etc. may cause the unit to degrade or
fail. Control Products accepts no liability for product applications or customer application testing.
Warranty
Custom Design & Modifications
In addition to standard models, Control Products specializes in complete custom design of electronic controls.
Modifications of our standard controls are also available. Please consult factory for more information.
TC = Temperature Controller 110 or 111 series
110 = °F
111 = °C
S or D
S = single stage
D = dual stage
Sensor Type
Blank = PTC
H = extended
range PTC
RTD = RTD
Supply Voltage Options
24 = VAC
24VDC = 24 VDC
12 = VAC
12VDC = 12 VDC
