COOL Spot Pop Up Canopy With Netting User manual

11 Ft x 11 Ft Pop Up Canopy With Netting
INSTRUCTION MANUAL
Do not return your canopy to the place of purchase.
For warranty service, repair parts, or product questions please
email: [email protected]
Thank you for choosing Coolspot !

WARRANTY
Please read and save these instructions before attempting to set up this canopy.
1 year limited warranty
Please email ser[email protected]om before returning the product to our shop.
Cool Spot Shelters warrants for a period of 1 year from the original date of purchase, this product against any
defects in materials or workmanship. At its discretion, Cool Spot Shelters may provide replacement parts to
original purchaser. Original receipt or proof of purchase as well as proof of defect is required. Cool Spot Shelters
will not be responsible for shipping costs incurred outside the continental USA. Warranty is valid for the original
purchaser for 1 year from the date of purchase and is not transferable. This warranty does not cover any product
purchased through non authorized dealers and/or on-line auction websites."
This Warranty Does Not Cover
This 1 Year Limited Warranty does not cover normal wear and tear, abuse or misuse of this product including
damage from inclement weather conditions, such as wind, rain, or hail. In case of inclement weather, take down
and store the canopy, remove and store valuables, and seek appropriate shelter.
Under no circumstances will Cool Spot Shelters be liable or responsible for any incidental or
consequential damages.
This product is designed and intended for commercial and recreational usage. Pro-longed exposure to UV rays
will cause any fabric to fade and deteriorate and is NOT covered by this 1 Year Limited Warranty.
All replacement products or parts will assume the remaining warranty of the original product. This warranty gives
you specific legal rights. You may also have other rights, which vary from state to state.
It is your responsibility to read and save these instructions before attempting to set up your
commercial canopy. We would also like to suggest that you follow these safety precautions, care
and maintenance tips when using your canopy.
1. Never set up or continue to use in any rain, wind or storm conditions, especially lightning storms. Damage can
occur to your canopy and put you and others in potential danger.
2. We suggest that you take your time in order to avoid bending the frame or pinching your fingers or hands
while opening and closing the frame.
3. Avoid setting up your canopy on steep inclines.
4. Do not use your canopy for permanent shelter. It is designed for temporary use only.
5. Keep your canopy away from heat and flames at all times. Do not barbecue or build fires under your canopy.
6. Never leave your canopy unattended.
7. Hand wash the canopy using only mild soap and water. Never use harsh detergents, abrasives or bleach. Do
not machine wash fabric components.
8. Never fold or store your canopy when it is wet or damp. Let it dry completely to avoid mildew.
9. The frame MUST be staked or properly weighted down at all times.
10. For best results in keeping your top clean and avoid small rips and tears, it is recommended that the top be
removed from the frame and stored in the carry bag after each use.
1

2
PACKING INCLUDES
Hardware
A - Canopy Frame (1pc)
E - Mosquito Netting (1pc) F - Carry Bag (1pc)
B - Connector (4pcs) C - Small Top (1pc)
D - Big Top (1pc)
EE - Ring (32pcs)
AA - Stake (8pcs) BB - Big Stake (4pcs) CC - Rope (4pcs)
DD - Netting Rope (2pcs)
Part List

3
ATTACH THE BIG TOP
Step 1

4
ATTACH TNE SMALL TOP & UNFOLD THE CANOPY
Step 2

5
LOCK THE FRAME & ADJUST THE CANOPY HEIGHT
Step 3
Click
Click

6
ATTACH THE NETTING ROPES
Step 4
2X

7
ATTACH THE MOSQUITO NETTING
Step 5
32X

8
SECURE THE CANOPY IN PLACE
Step 6

9
SECURE THE CANOPY IN PLACE
Step 7

10
TAKE DOWN THE CANOPY
2
4
6
3
1
5
Pull up all stakes from the
ground.
Press the push pin on each
leg and retract the legs to
their original height.
Push the push button on each slider
to unlock the frame.
Push inward until the frame
is fully closed.
Slide the carry bag over the
closed frame and close the
zipper on carry bag.
Remove the mosquito
netting if attached.
Push

REPLACEMENT PARTS
Spare Parts
To inquire about replacement parts, please email to [email protected]
1
1
8
10 9
6
2
3
4
5
7
Part Description
1Central Cap
8Middle Bolt Kit
2Top Cap
9Side Bolt Kit
3Slider
10 Eave Assembly
4Leg Assembly
5Plastic Foot
6Ceiling Assembly
7Connector
12
13
Big Top
11
15
17
18
19
16
Mosquito Netting
Stake
Big Stake
Rope
Netting Rope
Ring
14 Carry Bag
Small Top
5
6
7
98
10
11
15 16 17 18 19
14
12 13
2 3 4
