CoolKiller CK 98 User manual

132.00 mm
90.00 mm
Manufacturer: Dieyun Innovation Technology Co., LTD., No. 20,
Sanjiang Industrial Zone, Hengli Town, Dongguan city

List of Contents:
Transparent mechanical keyboard ×1
Air spring data cable x 1
Instruction Manual x 1
CK 98 Transparent mechanical keyboard
Double head key extractor×1
Case of ammunition x 1
12

Quick Start Guide
If you are a MAC user, flip the switch to switch to a MAC system
（After the conversion is successful, the MAC is displayed
in the lower left corner of the default screen）
If you are a WIN user, please flip the system conversion switch to WIN
（After the conversion is successful, the lower left corner
of the screen is WIN by default）
WIN
MAC
12
1Power switch (built-in lithium battery)
2System transfer switch
13

1.Connect to Bluetooth
Press fn+1/2/3 and then hold down fn+1/2/3
Put the keyboard into pairing mode,
The keyboard pairing name is CK98 5.0/CK98 3.0
Long press 1/2/3 button and the white light
will flash.After the match is successful, the
1/2/3 button will keep on for 2 seconds and
restore the backlight(By default, the Bluetooth
identifier is at the lower right corner of the screen.)
MAC
2.Connecting wire
Long press fn+5 to put the keyboard into wired mode
Long press the back 5 button and the white light will flash.
After the pairing is successful, the 5 keys will be on for 2
seconds and the backlight will be restoredBy default, the
lower right corner of the screen is
WIN
14

4.Changing lamp effect
fn+INS Adjust the lighting mode
fn+DEL Switching monochrome colors
fn+PGUP Turn the backlight off/on
15

7.Storage and use environment
1.Storage temperature: -20℃~+70℃
2.Operating temperature: -20℃~+60℃
3.Storage humidity: The relative humidity in the non-condense state is 30%-95%RH
8.Compatible system:
Supported operating system: ANDROID/ISO/Win XP/Win7/Win8/Win10/MAC
(default WIN system)
16

5.Charging
Charging status The charging indicator animation is displayed in the
upper right corner of the default screen
*1,Lamp working current 250MA Sustainable time about 15 hours
(working all the time)
*2,Off working current 40MA Sustainable time about 80 hours
(always working)
*3,Standby current 0.5MA Standby time about 180 days
*4,Enter standby mode. Press any key to start the keyboard and enter working mode.
6.Back to the
1.Keyboard startup defaults to the last connected device
2.fn+1 (fn+2, fn+3) White slow flash connection
*To do this, the keyboard must have been paired with the device
WIN
17

Fn Combined Function Keys (MAC)
Reset function
F1
F2
F3
F4
F5
F6
F7
F8
F9
F10
F11
F12
Press Bluetooth 1 to connect back,
Long press Bluetooth 1 to pair
Short press Bluetooth 2 to connect
back ,Long press Bluetooth 2 to pair
Tap Bluetooth 3 to connect back,
Long press Bluetooth 3 to pair
Short press 2.4G to connect back,
Long press 2.4G to pair
Wired mode
Querying Electricity Quantity
Main backlight effect switch
18

Fn Combined Function Keys (MAC)
END
Backlight brightness +
Backlight brightness -
Backlight speed -
Backlight speed +
Backlight speed +
Querying the Display
Information
The home screen goes
to the Custom screen
HOME
PAUSE
19

Fn Combination key (WIN system)
Press and hold for 3s to
restore factory Settings
Multimedia
Reduction in volume
Volume plus
mute
The last song
Next song
Pause play
stop
mail
Web page
The computer
calculator
Press Bluetooth 1 to connect back,
Long press Bluetooth 1 to pair
Short press Bluetooth 2 to connect
back ,Long press Bluetooth 2 to pair
Tap Bluetooth 3 to connect back,
Long press Bluetooth 3 to pair
Short press 2.4G to connect back,
Long press 2.4G to pair
Wired mode
Querying Electricity Quantity
Main backlight effect switch
20

END
HOME
PAUSE
Backlight brightness +
Backlight brightness -
Backlight speed -
Backlight speed +
Backlight speed +
Querying the Display
Information
The home screen goes
to the Custom screen
Fn Combination key (WIN system)
21

FCC Warnning:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection againstharmful interference in a residential installation. This equipment generates,
uses and can radiateradio frequency energy and, if not installed and used in accordance with
the instructions, maycause harmful interference to radio communications. However, there
is no guarantee thatinterference will not occur in a particular installation. If this
equipment does cause harmfulinterference to radio or television reception, which can be
determined by turning the equipmentoff and on, the user is encouraged to try to correct the
interference by one or more of thefollowing measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer
could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1)This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 0cm
between the radiator and your body.
