CoolKiller CK 98 User manual

132.00 mm
90.00 mm
Manufacturer: Dieyun Innovation Technology Co., LTD., No. 20,
Sanjiang Industrial Zone, Hengli Town, Dongguan city
INSTAGRAM: https://www.instagram.com/coolkiller_keyboard/
TWITTER: https://twitter.com/coolkillerkbd
YouTube: https://www.youtube.com/@coolkillerkeyboard
Email: [e-mail]
Website: www.coolkiller2023.com
Aliexpress Store: https://www.aliexpress.com/store/1102642321

内容清单:
机械键盘 ×1
航插弹簧数据线 x 1
说明书 x 1
CK 98透明机械键盘
双头拔键器×1
军火箱 x 1
1

CK 98 键盘规格
按键数：97键
连接端口：USB Type-C
模式：三模
PCB：支持热插拔
产品名称：CK 98机械键盘
产品重量：1300g
产品尺寸：390*145*44mm
灯光：RGB灯效
静音棉：两张硅胶静音棉+轴下垫
2

快速上手指南
如果你是MAC用户，请拨动系统转换开关换成MAC系统
（转换成功后默认界面下屏幕左下角为MAC）
如果你是WIN用户，请拨动系统转换开关换成WIN系统
（转换成功后默认界面下屏幕左下角为WIN）
WIN
MAC
12
1电源开关（内置锂电池）
2系统转换开关
3

1.连接蓝牙
先短按fn+1/2/3后长按fn+1/2/3
使键盘进入配对模式，
键盘的配对名为：CK98 5.0/CK98 3.0
长按后1/2/3键白灯快闪，
配对成功后1/2/3键常亮2秒，恢复背光
(默认界面下屏幕右下角为蓝牙标识）
MAC
2.连接有线
长按fn+5使键盘进入有线模式
长按后5键白灯快闪，
配对成功后5键常亮2秒，恢复背光
默认界面下屏幕右下角为
WIN
4

先短按fn+4后长按fn+4
使键盘进入2.4G配对模式
3.2.4G模式
长按后4键白灯快闪，
配对成功后4键常亮2秒，恢复背光
(默认界面下屏幕右下角为2.4G标识）
WIN
4.变换灯效
fn+INS 使键盘调节灯光模式
fn+DEL 切换单色颜色
fn+PGUP 关闭/打开背光
5

5.充电
充电状态 默认界面下右上角出现充电指示动画
*1,灯亮工作电流250MA 可持续时间15小时左右(一直工作)
*2,灯灭工作电流40MA 可持续时间80小时左右(一直工作）
*3,待机电流0.5MA 待机时间180天左右
*4,键盘无动作2分钟进入待机模式 按任何键启动键盘进入工作模式.
6.回连
1.键盘开机默认上次连接的设备
2.fn+1（fn+2，fn+3)白灯慢闪回连
*键盘必须曾经配对过该装置才可实现此功能
WIN
6

7.储存、使用环境
1.储存温度：-20℃~+70℃
2.工作温度：-20℃~+60℃
3.储存湿度：非凝结状态下相对湿度30%RH~95%RH
8.兼容系统:
支持操作系统：ANDROID/ISO/Win XP/Win7/Win8/Win10/MAC(默认WIN系统)
7

Fn组合功能键(MAC系统）
F1
F2
F3
F4
F5
F6
F7
F8
F9
F10
F11
F12
短按蓝牙1回连，
长按蓝牙1配对
短按蓝牙2回连，
长按蓝牙2配对
短按蓝牙3回连，
长按蓝牙3配对
短按2.4G回连，
长按2.4G配对
有线模式
查询电量
主背光灯效切换
长按3s,恢复出厂设置
8

Fn组合功能键(MAC系统）
END
背光亮度+
背光亮度-
背光速度-
背光速度+
关闭背光
查询显示屏信息
屏主界面转自定义界面
HOME
PAUSE
9

Fn组合功能键(WIN系统）
长按3s,恢复出厂设置
多媒体
音量减
音量加
静音
上一曲
下一曲
暂停播放
停止
邮件
网页
电脑
计算器
短按蓝牙1回连，
长按蓝牙1配对
短按蓝牙2回连，
长按蓝牙2配对
短按蓝牙3回连，
长按蓝牙3配对
短按2.4G回连，
长按2.4G配对
有线模式
查询电量
主背光灯效切换
10

Fn组合功能键(WIN系统）
END
背光亮度+
背光亮度-
背光速度-
背光速度+
关闭背光
查询显示屏信息
屏主界面转自定义界面
HOME
PAUSE
11

List of Contents:
Transparent mechanical keyboard ×1
Air spring data cable x 1
Instruction Manual x 1
CK 98 Transparent mechanical keyboard
Double head key extractor×1
Case of ammunition x 1
12

CK 98 Keyboard specification
Number of keys: 97 keys
Connection port: USB Type-C
Mode: Three modes
PCB: Supports hot swap
Product Name: CK 98 Mechanical Keyboard
Product weight: 1300g
Product size: 390*145*44mm
Light: RGB light effect
Mute cotton: Two sheets of silicone mute cotton + shaft underpad
13

Quick Start Guide
If you are a MAC user, flip the switch to switch to a MAC system
（After the conversion is successful, the MAC is displayed
in the lower left corner of the default screen）
If you are a WIN user, please flip the system conversion switch to WIN
（After the conversion is successful, the lower left corner
of the screen is WIN by default）
WIN
MAC
12
1Power switch (built-in lithium battery)
2System transfer switch
14

1.Connect to Bluetooth
Press fn+1/2/3 and then hold down fn+1/2/3
Put the keyboard into pairing mode,
The keyboard pairing name is CK98 5.0/CK98 3.0
Long press 1/2/3 button and the white light
will flash.After the match is successful, the
1/2/3 button will keep on for 2 seconds and
restore the backlight(By default, the Bluetooth
identifier is at the lower right corner of the screen.)
MAC
2.Connecting wire
Long press fn+5 to put the keyboard into wired mode
Long press the back 5 button and the white light will flash.
After the pairing is successful, the 5 keys will be on for 2
seconds and the backlight will be restoredBy default, the
lower right corner of the screen is
WIN
15

Short press fn+4 and long press fn+4
Set the keyboard to 2.4G pairing mode
3.2.4G Mode
Long press the back 4 button and the white light will flash.
After the pairing is successful, the 4 keys will be on for 2
seconds and the backlight will be restored(2.4G logo is at the
lower right corner of the screen in the default interface)
WIN
4.Changing lamp effect
fn+INS Adjust the lighting mode
fn+DEL Switching monochrome colors
fn+PGUP Turn the backlight off/on
16

5.Charging
Charging status The charging indicator animation is displayed in the
upper right corner of the default screen
*1,Lamp working current 250MA Sustainable time about 15 hours
(working all the time)
*2,Off working current 40MA Sustainable time about 80 hours
(always working)
*3,Standby current 0.5MA Standby time about 180 days
*4,Enter standby mode. Press any key to start the keyboard and enter working mode.
6.Back to the
1.Keyboard startup defaults to the last connected device
2.fn+1 (fn+2, fn+3) White slow flash connection
*To do this, the keyboard must have been paired with the device
WIN
17

7.Storage and use environment
1.Storage temperature: -20℃~+70℃
2.Operating temperature: -20℃~+60℃
3.Storage humidity: The relative humidity in the non-condense state is 30%-95%RH
8.Compatible system:
Supported operating system: ANDROID/ISO/Win XP/Win7/Win8/Win10/MAC
(default WIN system)
18

Fn Combined Function Keys (MAC)
Reset function
F1
F2
F3
F4
F5
F6
F7
F8
F9
F10
F11
F12
Press Bluetooth 1 to connect back,
Long press Bluetooth 1 to pair
Short press Bluetooth 2 to connect
back,Long press Bluetooth 2 to pair
Tap Bluetooth 3 to connect back,
Long press Bluetooth 3 to pair
Short press 2.4G to connect back,
Long press 2.4G to pair
Wired mode
Querying Electricity Quantity
Main backlight effect switch
19
