INDUSTRIALS
450 COOPER LIGHTING
• Specular enhanced
aluminum standard for
optical distribution. White
painted optics optional
• Great alternative to
traditional HID high bay
lighting
• Optional hanging devices
available when retrofitting
from HID (“TCB” Top
Connector Box)
• Superior lumen
maintenance exceeds that
of HID. 90-95% of initial
light output at end of life
• Instant strike and re-strike
ability
• Allows flexibility with use
of dimming, motion
sensors, and emergency
options.
• UL/CUL Listed. Suitable for
damp locations
DESCRIPTION
The HBO series is an outstanding
solution for high mounting
height industrial or retail
applications. The HBO optic
has been optimized to provide
maximum performance from
either the T5 or T8 lamps.
Optional uplight component is
provided to enable excellent
ceiling uniformity. HBO‘s high
lumen package allows the
benefits of fluorescent to be
applied at high mounting
heights that were traditionally
exclusive to H.I.D. The primary
benefits include exceptional
color rendering, high system
efficacy, 95% lumen
maintenance, long lamp life,
instant on/instant re-strike,
economical dimming, and
uniform brightness control.
Primary applications include
"big box" retail, shopping
malls, light industrial, etc.
F-BAY HBO,
HBOT SERIES
Nominal 1' x 4', 2' x 4'
or 3' x 4' High Bay
4, 6 or 8 Lamps
HIGH-BAY INDUSTRIAL
OPEN LUMINAIRE
ORDERING INFORMATION
SAMPLE NUMBER: 3HBO-832-120V-EB82
DIMENSIONS
Wattage (Length)
32=32W T8 (48") Lamps
28T5=28W T5 (48") Lamps
54T5=54W T5HO (48") Lamps
Distribution Optic
Blank=Aisle (Aluminum)
G=General (White Painted)
Series
HBO=High Bay
Open Version
HBOT=High Bay
Open Top Version
Width
Blank=15" wide
2=24" wide
3=32" wide
Voltage(1)
UNV=Universal 120/277 Voltage(2)
UNC=Universal 347/480 Voltage (T5 linear only)(2)
120V=120 Volt(3)
277V=277 Volt(3)
347V=347 Volt(3)
Options
GL=Single Element Fuse
GM=Double Element Fuse
Lamps - Lamps installed
Emergency - EM installed Packaging
U=Unit Pack
Ballast Type(1)
EB8 = T8 Electronic Instant Start.
Total Harmonic Distortion < 10%
EB8 /PLUS= T8 Electronic Instant Start.
High Ballast Factor >1.13. Total
Harmonic Distortion < 20%
ER8 = T8 Electronic Program Rapid Start.
Total Harmonic Distortion < 10%
EBT =T5 Linear Electronic Program Rapid
Start. Total Harmonic Distortion < 10%
DIM=Dimming
DLS=Digital Lighting System Dimming
(For complete details on generic or to specify
manufacturer’s ballast see pg. 469)
No. of Ballast
1, 2 or 3
No. of
Ballast
1, 2 or 3
No. of Ballast
1, 2 or 3
No. of Ballast
1 or 2
NOTES: (1)Products also available in non-US voltages and frequencies for international markets. (2)Not available when specifying emergencies, voltage must be
specific. (3)Voltage to be specified when using cord & plug.
For complete product data, reference the Fluorescent Specification binder. Specifications & dimensions subject to change without notice. Consult your Cooper Lighting
Representative for availability and ordering information.
No. of Lamps
4=4 Lamps
6=6 Lamps
8=8 Lamps
Options
(See Options &
Accessories Section)
COOPER LIGHTING - METALUX®
HBO
HBOT
X=4"
[102mm]
5-1/16"
[129mm]
XXX
16-5/16" [414mm]
X=4"
[102mm]
5-1/16
[129mm]
32-5/16" [820mm]
XXXXX
XX
HBO SERIES
4-LAMP T5/T8
8-LAMP T5/T8
X=4"
[102mm]
5-1/16"
[129mm]
XXX
24-5/16" [617mm]
XX
6-LAMP T5/T8
X=4"
[102mm]
5-3/16
[131mm]
32-11/16" [830mm]
XXXXX XX
HBOT SERIES
8-LAMP T5/T8
X=4"
[102mm]
5-3/16
[131mm]
24-9/16" [624mm]
XXXXX
6-LAMP T5/T8
