PM612ob
60 Amp Busway Adapter
Catalog #
Type
Project
A machined aluminum track fixture for low voltage
MR16 lamps from 20 to 71 watts. For use with RSA
Profile Series 60 Amp Busway.
Front loading lamp with bayonet action lens /
accessory bezel. Optical accessories are captured
in the bezel with a threaded retainer ring preventing
accessory spill-out during relamping. Can accom-
modate up to three optical accessories.
Auto extending / retracting lamp holder. Lamps
extend for easy access and automatically retract
to optimum position. This is extremely helpful when
dealing with varying accessory combinations or dif-
fering manufacturer lamp dimensions.
Optical accessories include color filters, UV fil-
ters, screens, spread lenses, louvers, hex louvers,
snoots. Consult RSA for details.
Locking on both the horizontal and vertical
planes. 370º vertical rotation possible due to over-
center locking mechanism (60 amp busway only).
270º horizontal locking adjustment.
UL and CUL listed
Clear lens included.
Available in White, Black, Natural Aluminum or
custom finishes.
MR16 12V
Open Back Machined Fixture
PM612ob
Open Back Machined Fixture Lamp Wattage Finish
❑ PM612ob - MR16 for 60 Amp Busway ❑ 20 20 Watt 12V MR16 ❑ WH White
❑ 37 37 Watt 12V MR16 ❑ BK Black
❑ 42 42 Watt 12V MR16 ❑ AL Natural Aluminum
❑ 50 50 Watt 12V MR16 ❑ PT Custom Finish
❑ 71 71 Watt 12V MR16
Ordering Example: PM612ob-50-AL

PM35
®
0° Aiming Angle 30° Aiming Angle 30° Aiming Angle 45° Aiming Angle
Horizontal Footcandles Horizontal Footcandles Vertical Footcandles Vertical Footcandles
D FC L W D FC L W CB D FC L W CB D FC L W CB
FC FC
FC
CB
CB
L L
L
30° 30°
D
W
D
W
W
MR16 12V Halogen 2-Pin GX5.3
Q20 MR16 /C /VNSP7 GEL 6 215 0.7 0.7 6 140 0.8 0.7 3.5 2 243 0.9 0.5 3.5 3 304 0.7 0.4 3.
Beam Spread = 7° x 7
° 8 121 0.9 0.9 8 79 1.1 1.0 4.6 3 108 1.3 0.7 5.2 4 171 0.9 0.8 4.0
CBCP = 7,400 10 77 1.1 1.1 10 50 1.2 1.2 5.8 4 61 1.8 0.9 6.9 5 110 1.2 1.0 5.0
Rated Life = 3,000 Hrs. 12 54 1.3 1.3 12 35 1.4 1.4 6.9 5 39 2.2 1.2 8.7 6 76 1.4 1.2 6.0
Q20 MR16 /C /NSP15 GEL 4 237 0.9 0.9 4 154 1.2 1.1 2.3 1.5 263 1.1 0.6 2.6 4 374 0.8 0.6 2.0
Beam Spread = 15° x 15° 6 106 1.4 1.4 6 69 1.8 1.6 3.5 2.0 148 1.4 0.8 3.5 6 166 0.9 0.9 3.0
CBCP = 3,750 8 59 1.8 1.8 8 39 2.4 2.2 4.6 2.5 95 1.8 0.9 4.3 8 94 1.2 1.2 4.0
Rated Life = 5,000 Hrs. 10 38 2.3 2.3 10 25 3.0 2.7 5.8 3.0 66 2.1 1.1 5.2 10 60 1.5 1.5 5.0
Q20 MR16 /C /FL40 GEL 1.5 222 1.0 1.0 1.5 163 1.1 1.1 0.9 1.0 135 0.9 0.9 1.7 1.0 254 0.8 1.0 1.0
Beam Spread = 40° x 40° 2.0 125 1.3 1.3 2.0 92 1.4 1.4 1.2 1.5 60 1.4 1.3 2.6 1.5 113 1.1 1.5 1
CBCP = 525 2.5 80 1.6 1.6 2.5 59 1.8 1.8 1.4 2.0 34 1.8 1.8 3.5 2.0 63 1.5 2.0 2.0
Rated Life = 5,000 Hrs. 3.0 56 2.0 2.0 3.0 41 2.1 2.1 1.7 2.5 22 2.3 2.3 4.3 2.5 41 1.9 2.5 2.5
Q35 MR16 /C /SP20 GEL 3 356 1.0 1.0 3 231 1.3 1.1 1.7 1.5 223 1.4 0.9 2.6 2 305 1.2 0.9 2.0
Beam Spread = 20° x 20° 4 200 1.3 1.3 4 130 1.7 1.5 2.3 2.0 126 1.9 1.1 3.5 3 136 1.7 1.3 3.0
CBCP = 3,200 5 128 1.6 1.6 5 83 2.1 1.9 2.9 2.5 80 2.4 1.4 4.3 4 76 2.3 1.8 4.0
Rated Life = 5,000 Hrs. 6 89 1.9 1.9 6 58 2.6 2.2 3.5 3.0 56 2.8 1.7 5.2 5 49 2.9 2.2 5.0
Q35 MR16 /C /FL40 GEL 2 262 1.2 1.2 2 204 1.3 1.2 1.2 1.0 253 0.9 0.8 1.7 1.5 235 1.2 1.0 1.5
Beam Spread = 40
° x 40° 3 116 1.8 1.8 3 91 2.0 1.8 1.7 1.5 112 1.4 1.2 2.6 2.0 132 1.5 1.3 2.0
CBCP = 1,000 4 65 2.3 2.3 4 51 2.6 2.4 2.3 2.0 63 1.8 1.7 3.5 2.5 85 1.9 1.7 2.5
Rated Life = 5,000 Hrs. 5 42 2.9 2.9 5 33 3.3 3.0 2.9 2.5 40 2.3 2.1 4.3 3.0 59 2.3 2.0 3.0
Q42 MR16 /C /VNSP9 GEL 6 347 0.8 0.8 6 226 1.0 0.9 3.5 2 415 1.0 0.6 3.5 4 276 1.1 0.7 4.0
Beam Spread = 9° x 9° 8 195 1.0 1.0 8 127 1.4 1.2 4.6 3 185 1.5 0.8 5.2 5 177 1.4 0.9 5.0
CBCP = 12,500 10 125 1.3 1.3 10 81 1.7 1.4 5.8 4 104 2.0 1.1 6.9 6 123 1.7 1.1 6.0
Rated Life = 3,500 Hrs. 12 87 1.5 1.5 12 56 2.1 1.7 6.9 5 66 2.6 1.4 8.7 7 90 2.0 1.3 7.0
Q50 MR16 /C /NSP15 GEL 6 264 1.5 1.5 6 171 1.9 1.7 3.5 2 361 1.5 1.5 3.5 4 229 1.7 1.2 4.
Beam Spread = 15° x 15° 8 148 1.9 1.9 8 96 2.5 2.2 4.6 3 160 2.3 2.3 5.2 5 147 2.1 1.6 5.0
CBCP = 9,500 10 95 2.4 2.4 10 62 3.1 2.8 5.8 4 90 3.0 3.0 6.9 6 102 2.5 1.9 6.0
Rated Life = 6,000 Hrs. 12 66 2.9 2.9 12 43 3.7 3.3 6.9 5 58 3.8 3.8 8.7 7 75 3.0 2.2 7.0
Q50 MR16 /C /NFL25 GEL 3 322 1.2 1.2 3 212 1.6 1.4 1.7 1.5 220 1.7 1.1 2.6 2 282 1.4 1.1 2.0
Beam Spread = 25° x 25° 4 181 1.7 1.7 4 119 2.1 1.9 2.3 2.0 124 2.2 1.4 3.5 3 125 2.2 1.7 3.0
CBCP = 3,000 5 116 2.1 2.1 5 76 2.7 2.4 2.9 2.5 79 2.8 1.8 4.3 4 70 2.9 2.3 4.
Rated Life = 6,000 Hrs. 6 81 2.5 2.5 6 53 3.2 2.9 3.5 3.0 55 3.3 2.2 5.2 5 45 3.6 2.8 5.0
Q50 MR16 /C /FL40 GEL 3 213 2.0 2.0 3 181 2.1 2.0 1.7 1.5 259 1.1 1.3 2.6 2 274 1.3 1.5 2.0
Beam Spread = 40° x 40° 4 120 2.7 2.7 4 102 2.8 2.7 2.3 2.0 146 1.5 1.7 3.5 3 122 2.0 2.3 3.
CBCP = 1,700 5 77 3.4 3.4 5 65 3.5 3.4 2.9 2.5 93 1.9 2.2 4.3 4 68 2.6 3.0 4.0
Rated Life = 6,000 Hrs. 6 53 4.0 4.0 6 45 4.2 4.1 3.5 3.0 65 2.3 2.6 5.2 5 44 3.3 3.8 5.0
Q71 MR16 /C /NSP15 GEL 6 306 1.6 1.8 6 198 2.0 1.8 3.5 3 194 2.3 1.3 5.2 4 276 1.8 1.3 4.0
Beam Spread = 15° x 15° 8 172 2.2 2.4 8 112 2.6 2.4 4.6 4 109 3.1 1.8 6.9 6 123 2.7 1.9 6.0
CBCP = 11,000 10 110 2.7 3.0 10 71 3.3 3.0 5.8 5 70 3.9 2.2 8.7 8 69 3.6 2.6 8.0
Rated Life = 4,000 Hrs. 12 76 3.2 3.6 12 50 3.9 3.6 6.9 6 48 4.7 2.7 10.4 10 44 4.5 3.2 10.0
Q71 MR16 /C /NFL25 GEL 4 309 1.7 1.7 4 223 2.1 1.9 2.3 2 257 1.7 1.3 3.5 3 256 1.9 1.5 3.0
Beam Spread = 25° x 25° 6 137 2.5 2.5 6 99 3.1 2.8 3.5 3 114 2.5 1.9 5.2 4 144 2.6 2.1 4.0
CBCP = 4,950 8 77 3.4 3.4 8 56 4.1 3.7 4.6 4 64 3.4 2.6 6.9 5 92 3.2 2.6 5.0
Rated Life = 4,000 Hrs. 10 49 4.2 4.2 10 36 5.2 4.6 5.8 5 41 4.2 3.2 8.7 6 64 3.9 3.1 6.0
Q71 MR16 /C /FL40 GEL 3 236 2.1 2.1 3 200 2.2 2.1 1.7 1.5 286 1.2 1.3 2.6 2 301 1.4 1.5 2.0
Beam Spread = 40° x 40° 4 133 2.8 2.8 4 112 2.9 2.8 2.3 2.0 161 1.6 1.8 3.5 3 134 2.2 2.3 3.0
CBCP = 2,000 5 85 3.4 3.4 5 72 3.6 3.5 2.9 2.5 103 2.0 2.2 4.3 4 75 2.9 3.1 4.0
Rated Life = 4,000 Hrs. 6 59 4.1 4.1 6 50 4.4 4.2 3.5 3.0 71 2.5 2.6 5.2 5 48 3.6 3.8 5.0
Lamp Performance Data
D = Distance to the horizontal or vertical surface.
FC = Initial footcandles at the center of the beam.
L = Length of the beam where candlepower is reduced to 50%
of center beam candlepower.
W = Width of the beam where candlepower is reduced to 50%
of center beam candlepower.
CB = Distance to the center of the beam.
Lamp data given is typical and is based on bare lamp performance.
Contact lamp manufacturers for availability and specific performance.
Distance, length and width given in decimal feet.
Optivex UV
Filter
Red Color
Filter
Blue Color
Filter
Amber Color
Filter
Cosmetic Peach
2800K Filter
Milk White
Lens
Diffusion Spread
Lens
Linear Spread
Lens
LN25 LN26 LN27 LN29 CP16 LN24 LN21 LN23
Prismatic Spread
Lens
20% Reduction
Screen
30% Reduction
Screen
40% Reduction
Screen
Hex Cell
Louver
Cross
Baffle
Snoot
LN22 RS2016 RS3016 RS4016 LN20 CB16 SN16
