Coopers of Stortford 9274 User manual

Please read carefully before use and retain for future reference.
GETTING STARTED PARTS & ASSEMBLY
Remove the soup maker and
accessories from the box.
Remove any packaging from
the product.
Place the packaging inside
the box and either store or
dispose of safely.
Before using the soup maker
for the first time wipe down
the jug and lid with a damp
cloth using a mild detergent.
Dry thoroughly before use.
Do not immerse the unit or
the jug in water or any other
liquids.
Caution: the jug contains very
sharp blades and should be
handled with care at all
times.
The soup maker has two
programmed soup settings to create a chunky or smooth soup and also has a reheat function
enabling precooked soup to be reheated before serving.
The built-in blender blades can be used to allow the soup maker to be used solely as a
blender to make purees, dips and dressings.
The soup maker is fitted with several safety features including an interlocking lid cut-out, a
minimum liquid sensor, a hot liquid overflow sensor for safe use at all times and safety
micro-switch cut-off on the motor base.
BEFORE STARTING COOKING
Place the base unit of soup maker on a flat, heat-resistant, stable surface. Carefully position
the jug on the base unit aligning the connections in the base of the jug handle with those in
the base unit, ensuring the jug is secure.
Plug the soup maker to the mains power supply, fill with liquid to desired level (must be
above “WATER MIN.” marking on jug) and fit the lid to the soup maker by aligning the
“Close/Power on” symbol on the lid with the line on the top of the handle.
Once aligned, turn the lid in the direction of the arrows on the lid until the lid lock symbol
aligns with the line on the handle. Ensure the measuring cup stopper is fitted to the top of
the lid.
Press the START/STOP button to turn the soup maker on. The button will illuminate indicating
the soup maker is on. If at this point the alarm sounds, disconnect the soup maker from the
mains power supply and check that the lid is properly fitted and the fluid level is correct as
described on trouble shooting, then re-connect to the mains and power up.
Soup Maker 9274

INSTALLATION OF THE STAINLESS STEEL FILTER
The stainless steel filter divides the jug into 2 sections and fits around the raised ring in the base of
the jug. The inner section is used to make smoothies, soya milk, porridge or for mixing food, and the
outer section makes chunkier foods. For soya milk and smoothies, the fine blend section (marked
“Soya”) should be at the bottom of the jug. For soups and porridge, the coarser blend section
(marked “Soup”) should be at the bottom.
The outer section separates chunks from foods being blended so is essential for making chunky
soups. Make sure the total volume of ingredients added is above the minimum level required but not
more than 1700ml, ensuring the internal sensor near the base of the jug is covered with liquid.
Under-filling the soup maker jug will result in the alarm sounding and the unit failing to operate and
should the boiling action during cooking cause the hot contents to reach the lid, the upper sensor
will switch off the heating function to help prevent boiling over.
COOKING
To start the cooking process, choose the desired mode:
Option
Description
Time
Soup Chunky
Heats and coarsely blends non-soaked vegetables,
fruits, bean, etc. into chunks
30 mins
Soup Smooth
Heats and finely blends tender vegetables, fruits, etc.
25 mins
Boiling
Boil food
15 mins
Reheat/Keep Warm
Reheat leftovers or keep soup, milk, hot or melted
chocolate, etc. warm
12 mins
Smoothie
For smoothie making or super fine blending
2.6 mins
Blender/Mix
Blend, mix fruits and vegetables, etc.
1.3 mins
Pulse
Hand press to blend quickly
User defined
Start/Stop
Soup Maker START/STOP control
Note: Cooking times above are approximate and are for reference only.

Press the “START/STOP” button, the indicator flashes, load ingredients, choose the type of cooking
operation to confirm, the soup maker will beep 3 times which means the cooking process has already
started.
Making a smooth soup takes around 25 minutes while chunky soup, porridge or soya milk takes
around 30 minutes. When the cooking or blending is complete, the soup maker will beep for several
seconds and the indicators will blink.
During the cooking process, if the indicators blink and beep continuously it means an error has
occurred. Check the following:
1) Lid may not be properly locked.
2) There may be insufficient water inside the jug. The over-dry sensor may have activated.
3) Jug may not be properly placed in its main body which may have activated the safety micro-
switch.
4) Heating base and/or motor may have over-heated and the overloading safety switch may
have activated. Separate the jug from the base and allow to cool for 5 minutes.
5) Water or liquids may have exceeded the MAXIMUM level and the hot liquids overflow sensor
may have activated.
6) Water or liquid may be below the MINIMUM level and the Minimum liquid safety sensor
may have activated.
To completely stop the program at any time, simply press the START/STOP button.
Note: the programs rely on uninterrupted operation. Any interruption will result in the cancellation
of the program. Restarting a program will result in the cooking stages being repeated which may
affect the final recipe. Programs cannot be resumed once they have been stopped.
Any ingredients to be added during the cooking process can be added through the food chute in the
centre of the lid. Do not unlock or remove the lid as this will stop the program.
WARNING: heat/steam will be emitted from the lid. Care must be taken when removing the lid and
food chute.
Once the program has finished, the soup maker will sound an audible alarm and stop heating. Soup
can be poured straight from the jug. Be careful when removing the lid from the jug as it will be very
hot.
Pulse
After pressing “START/STOP” to put the machine on standby, press and hold the “Pulse” button to
blend. Release the button to stop.
Boiling
Fill water to between WATER MIN and BOIL MAX mark on the jug and add ingredients. Boil for
around 15 minutes.

Soup Making
Caution: it is not recommended to use uncooked meats in the soup maker. Any meat or fish must be
precooked. Do not add any frozen ingredients.
Making chunky soup
Install the stainless steel filter in the jug with the soup filter at the bottom. Chop all ingredients into
chunks and add the ingredients to remain as chunks to the outer section of the jug and the
ingredients to be blended into the inner section of the jug. Add your preferred liquid or stock to the
jug; all liquids and stocks used must be at room temperature rather than warm or hot.
Press the “Soup Chunky” button. The filter will protect the chunks from being blended with the rest
of the ingredients.
Making smooth soup
Chop all ingredients into chunks and add to the jug without the stainless steel filter fitted. Press the
“Soup Smooth” button.
Making smoothies
Add your preferred liquid to the jug with chopped ingredients and with the fine blend stainless steel
filter fitted. Press the “Smoothie” button.
Reheating
Cold soup can be reheated in the soup maker. Simply set up the soup maker as previously described
and add the cooked soup to the jug ensuring the volume is no less than the minimum and no more
than the maximum. Ensure the lid is correctly fitted and press the reheat button.
The reheat program will follow the sequence below:
Heating-Mixing-Heating-Mixing-Heating
This process will continue to follow the above cycle until the soup is heated and reaches the
optimum temperature of 65°C-75°C, ready to serve. The audible alarm will then sound.
The time taken to complete this process will depend on the temperature and volume of the soup
added but will be approximately 5-8 minutes.
WARNING: The reheating process is not a cooking function. All soups used in this process must be
precooked.
Blending
The soup maker can also be used as a blender; simply set up the soup maker as before and add moist
ingredients for blending. Make sure the lid is correctly fitted and press the blend button to start the
BLEND program.

Note: It is important that your ingredients reach a minimum depth of 3-4cm so that the safety cut-
out sensor does not activate and are no more than the MAXIMUM. It is NOT possible to blend dry
ingredients, as the sensor will not recognise them.
The blend cycle is a repeating 20-25 seconds high-speed blend with a slight rest. To stop the cycle
press the blend button again, or press START/STOP button.
WARNING
When using electrical appliances, basic safety precautions should always be followed.
Check that the voltage indicated on the rating label corresponds with that of the local
network before connection the appliance to the mains power supply.
This soup maker is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities or lack of experience and knowledge. They should be
given supervision and instruction in the use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do not play with the soup maker.
If the supply cord is damaged, a qualified engineer must replace it in order to avoid a hazard,
or send the unit to the authorized after-sales service centre for repair.
Take care to keep hands, long hair, loose clothing and other items away from the rotating
blades.
Do NOT use the soup maker if any part is damaged.
Do NOT use the soup maker without the lid being securely clipped in place.
Do NOT immerse the soup maker in water or any other liquids.
This appliance contains no user-serviceable parts. All repairs should only be carried out by a
qualified engineer. Improper repairs may place the user at risk of harm.
Do NOT leave the soup maker unattended whilst connected to the mains power supply.
This appliance must be unplugged from the power supply after use and whilst any cleaning
or maintenance is carried out.
Always use the soup maker on a flat, stable, heat-resistant surface.
Ensure there is sufficient ventilation around the soup maker to allow the escape of heat and
steam.
The jug body becomes hot during use; always hold the jug by the handle.
Do NOT use the soup maker for any purpose other than that for which it is intended.
Ensure that the supply cord is kept away from heat or sharp edges that could cause damage.
Do NOT allow the supply cord to hang over the edge of work surfaces or table-tops.
The soup maker is intended for domestic use only.
Do NOT use any accessories or attachments with this appliance other than those supplied or
recommended.
Wipe out any residue from around the jug including its filter properly after use.

CLEANING & MAINTENANCE
NOT dishwasher safe.
Always disconnect the soup maker from the mains power supply before cleaning.
To clean the inside of the jug, rinse to remove any remaining soup or large food particles.
Wipe away any food remains using a soft cloth and mild detergent before rinsing again.
The blades inside the jug are not removable and are very sharp; extreme caution should be
taken when cleaning the inside of the jug.
Clean the surface of the base unit and the outer of the jug with a soft, damp cloth.
Rinse the lid in warm, soapy water.
Do not immerse the soup maker (jug, cord, motor housing) in water or any liquids.
WARNING: Food high in starch or sugar is easy to burn on the bottom.
Use the soup maker’s programs to aid the removal of stubborn stains.
Add 800ml of water and a small amount of mild detergent. Fit the lid and switch the soup maker on.
Press the BLENDER or PULSE and the blades will rotate to clean the jug. You can stop the cleaning
process at any time by switching off the appliance.
Alternatively, the soup making function can be used to loosen any stubborn stains. Add 800ml of
water and a small amount of detergent and fit the lid. Press the soup-making button to start the
program to clean the jug. You can stop the cleaning process at any time by switching off the
appliance.
ELECTRICAL INFORMATION

TROUBLESHOOTING
Problems
Potential Solutions
The unit is not working and beeping.
The jug is not fitted to the base correctly.
The lid is not fitted correctly.
There is not enough liquid in the jug.
The over-flow sensor has activated.
The unit has stopped mid-program
(during the operation).
The lid is loose.
Liquid level is too low due to evaporation
during cooking.
Liquid has exceeded the maximum.
The jug has lost connection with the base.
Chunks are still too large after the cycle is
complete (food is not well blended).
Chunks were possibly too large initially-use
the blend function after the cooking
program.
Incorrect function was selected.
Insufficient water added: add more water.
The ingredients are hard after the cooking
cycle (food not well cooked).
Chop the ingredients into smaller pieces
before adding.
The wrong soup cycle has been used for the
volume added.
Too much water or food added.
Filter is clogged.
Some foods require longer cooking times:
select a heating function until food fully
cooked.
The soup is not hot and the cooking cycle
appeared to finish early.
There was too much hot liquid in the jug-
movement of the soup during cooking
reached the upper overflow sensor.
Food is burnt, and stuck to the bottom
Food:Liquid ratio is too high.
Sugary or starchy foods have been used.
TECHNICAL INFORMATION
Voltage
220-240V AC
Frequency
50/60 Hz
Power (motor)
300W
Power (heater)
800-900W
Jug working capacity
1.7L
PACKAGING
Dispose of packaging at your local recycling centre.
Dispose of paper and carton separately from plastic bags at your local recycling centre.
Dispose of item at the end of its lifespan at your local authorised household waste recycling
centre.

EC DECLARATION OF CONFORMITY
In accordance with EN ISO 17050-1:2004
We The Enterprise Department Ltd.
Of 11 Bridge Street, Bishop’s Stortford, Hertfordshire, CM23 2JU, UK.
in accordance with the following Directive(s):
2006/95/EC The Low Voltage Directive
2006/42/EC The Machinery Directive
2004/108/EC The EMC Directive
hereby declare that:
Soup Maker
Model number: 9274
Batch Number: 16871
is in conformity with the applicable requirements of the following documents
Ref. No.
Title
Edition date
BS EN 55014-1+A1
Electromagnetic compatibility. Requirements for
household appliances, electric tools and similar
apparatus. Emission
2006
BS EN 55014-2+A1+A2
Electromagnetic compatibility. Requirements for
household appliances, electric tools and similar
apparatus. Immunity. Product family standard
1997
BS EN 61000-3-2
+A1+A2
Electromagnetic compatibility (EMC). Limits. Limits for
harmonic current emissions (equipment input current ≤
16 A per phase)
2006
BS EN 61000-3-3
Electromagnetic compatibility (EMC). Limits. Limitation
of voltage changes, voltage fluctuations and flicker in
public low-voltage supply systems, for equipment with
rated current ≤ 16 A per phase and not subject to
conditional connection
2008
BS EN 60335-2-14
+A1
Household and similar electrical appliances. Safety.
Particular requirements for kitchen machines
2006
BS EN 60335-2-15
+A1+A2
Household and similar electrical appliances. Safety.
Particular requirements for appliances for heating
liquids
2002
BS EN 60335-1
+A1+A2+A11+A12+
A13+A14+A15
Household and similar electrical appliances. Safety.
General requirements
2002
BS EN 62233
Measurement methods for electromagnetic fields of
household appliances and similar apparatus with regard
to human exposure
2008
The Low Voltage Directive
2008
I hereby declare that the equipment named above has been designed to comply with the relevant sections of
the above referenced specifications. The unit complies with all applicable Essential Requirements of the
Directives.
Mr. Stuart Fowler
Imports Director 27.06.2012
