Coopers 9673 User manual

Car Camera 9673
PARTS
1. Micro USB/12V slot
2. AV out socket
3. SD/MMC card slot
4. Speaker
5. Mount hole
6. Microphone
7. Battery compartment cover
8. Lens
9. IR LED
10.ON/OFF switch/red charging indicator
11.Record/capture/enter button red working indicator
12.2.5in LCD screen
13.Menu button
14.Down
15.Up
16.Mode button
17.Li-ion battery
18.USB cable
19.Windscreen mount
20.12V car charger
ASSEMBLY
• Remove the battery compartment cover (7) and insert the Li-
ion battery (17) into the battery compartment,ensuring the metal
plates on the battery align with the metal connectors in the battery
compartment.
• Insert the SD card (not supplied) into the SD card slot ensuring it clicks into place.
To remove, press the SD card which will then partially eject,allowing it to be
removed by hand. If the SD card is not installed,the display screen will show“No
Card”. Always ensure the SC card is fitted correctly. Incorrect fitting may
damage the device and/or the SD card.We recommend using a class 4 SD card or
higher.
• Attach the camera to the windscreen mount (19) by screwing the camera into the
mount hole (5) and tighten by turning the wheel anti-clockwise.
• To adjust the angle of the windscreen mount,turn either of the knobs anti-
clockwise to loosen,adjust and turn clockwise to secure.The suction cup may
require light moistening to give improved suction to the windscreen.
CHARGING
• To recharge the battery, connect the Car Camera to a computer or laptop using
the USB cable or to the 12V socket in your vehicle using the 12V Car Charger.
• Charge fully for 12 hours the first three times the battery is charged. This will
maximise the capacity of the battery.
INSTALLATION
• It is vitally important that the Car Camera is installed in the correct position.The
Car Camera (including its mount & suction cup) should not intrude into the light
and dark shaded areas (showing the wiper clearance zones on the windscreen) in
the diagram opposite by more than 1cm (dark) or 4cm (light).This is a legal
requirement under the RoadTrafficAct 1988.Incorrectly positioned installation
may contravene this act and may constitute Dangerous Driving.
• Please note these shaded areas vary in size between vehicle types. If in any
doubt as to the legality of the use of this item in your particular vehicle,
please contact your vehicle manufacturer.
OPERATION
• The Car Camera can either be operated using the charged Li-ion battery
supplied or by connecting the in-car charger to the 12V socket in your
vehicle. Insert a 4-32GB SD/MMC card into the SD/MMC card slot (3).
• The Car Camera LCD screen must not be visible to the driver whilst the
vehicle is being driven.Always ensure the Car Camera LCD screen is folded
away when driving.
Please read carefully before use and retain for future reference.
Instructions
5
61
19
4
7
10
11
3
2
12
13
14
16
9
8
15
20
18
17

RECORDING
• The Car Camera digital video recorder is activated by pressing the ON/OFF switch (10) when the unit is running from the Li-ion battery. When the unit is running
from the 12V socket it will begin recording automatically when the car engine is started.
• Recording can be stopped at any time by pressing the record/capture/enter button (11) or by turning off the engine when running from the 12V socket.
• When recording with the motion detect function enabled, once motion has been detected the Car Camera will record for the recording time selected (see settings).
It will then stop recording automatically if no motion is detected at the end of the selected recording time period,or continue recording if motion is still being
detected.
RECORDING GUIDE
The number of photos or videos that can be taken varies according to the device settings, the subject and the SD card used. However, please refer to below guide for
an approximation:
Video length No. of Photos
Micro SD card 1920x1080 (FHD) 1280x720(HD) 848x480 (D1) 640x480 (640) 1280x1024 (1.3M) 1600x1200 (2M) 2048x1536 (3M) 2592x1944 (5M)
16GB 80mins 240mins 240mins 260mins 12160 11520 10960 9440
8GB 40mins 120mins 120mins 140mins 6080 5760 5530 4720
4GB 20mins 60mins 60mins 80mins 3040 2880 2760 2360
CAMERA MODE
• To select camera mode, switch the Car Camera on,fold down the LCD screen (12) and press the mode select button (16) once.
•To take a photo in this mode, press the record/capture/enter button (11).
VIEWING PHOTOS & RECORDINGS
• Turn on the Car Camera using the ON/OFF switch (10) and press the Mode select button (16) twice to enter Preview Mode.
• Photos & recordings are filed by date created.Cycle through the folders of recorded material by pressing the Up (15) and Down (14) buttons.
• To view photos & recordings made on the chosen date, press the record/capture/enter button (11) once to enter the folder and then select the chosen file using the
Up (15) and Down (14) buttons and press the record/capture/enter button (11) again to view/play.
• DO NOT VIEW RECORDINGS OR PHOTOSWHILST DRIVINGYOURVEHICLE. This contravenesThe RoadVehicles (Construction and Use) Regulations 1986.
UPLOADING PHOTOS & RECORDINGS
• Connect the USB cable (18) to your computer and to the USB slot (1) on the Car Camera.
•The computer should detect the Car Camera automatically.
• Photos & recordings are filed by date created in the DVR index.
• Upload and save the photos & recordings to your computer.
DELETING PHOTOS & RECORDINGS
• To delete a photo or recording,press the Menu button (13),select the file you wish to delete using the Up (15) and Down (14) buttons and then press the
record/capture/enter button (11) to delete.

Photo Settings
To alter the photo settings,press the mode button to enter photo mode,then
press the menu button. The following settings can be amended:
Resolution 5M 2592x1944
3M 2048x1536
2M 1600x1200
1M 1024x768
Quality Super fine High quality photo
Fine Highest quality photo
Normal Standard quality photo
Exposure -2.0 – +2.0 Select the desired exposure:-2.0,-1.7,-1.3,
-1.0,-0.7,-0.3,0,+0.3,+0.7,+1.0, +1.3,
+1.7,+2.0
Driver Mode OFF The Car Camera will only take photos when
the capture button (11) is pressed.
Self-timer 2S The Car Camera will take photos with a 2
second delay from when the capture button
(11) is pressed.
Self-timer 10S The Car Camera will take photos with a 10
second delay from when the capture button
(11) is pressed.
Burst The Car Camera will take 3 consecutive
photos when the capture button (11) is
pressed.
Date Stamp OFF Neither the date nor time are displayed on
the photo.
D&T Both date & time are displayed on the
photo.
Playback Settings
To alter the playback settings, press the mode button three times to enter
playback mode,then press the menu button. Note:There must be files saved on
the SD Card to access these settings.
Lock Lock/Unlock one Protects/unprotects a single file.
Lock all Protects all files.
Unlock all Unprotects all files.
Delete One Deletes a single file.
All Deletes all files.
Slide Show Start Displays saved images in turn.
Voice Memo Add Adds a voice memo
Delete Deletes a voice memo
Start-up Set Sets a photo as the Start-up image.
Image Cancel Cancel a photo from being the Start-
up image.
SETTINGS
In all menu screens (except where otherwise detailed):
Press the enter button (11) to bring up the options. Use the up (15) or down
(14) keys to cycle between the options. Press the enter button (11) again to
confirm the desired option. Press the menu key (13) to go back to the previous
screen at any time.
Video Settings
To alter the video settings,turn the Car Camera on and press the MENU button.
The following settings can be amended:
Movie Size FHD 1920x1080
HD 1 720 280x
D1 720x480
640 640x480
Date &Time OFF Neither the date nor time are displayed on the
recording.
DATE The date only is displayed on the recording.
D&T Both date & time are displayed on the recording.
Motion detect ON The Car Camera will automatically start recording
when motion is detected and record for 2 minutes.
If no motion is detected after 2 minutes the Car
Camera will stop recording,but will continue for
another 2 minutes if motion is still being detected.
OFF The Car Camera will only record when the record
button is pressed.
Loop Rec ON The Car Camera will continue recording once the
pre-determined video duration has elapsed and the
recording has been stored.
OFF The Car Camera will record for the pre-determined
duration only.
LoopTime 2min The video will record for 2mins at a time before
saving each 2min clip.
5min The video will record for 5mins at a time before
saving each 5min clip.
10min The video will record for 10mins at a time before
saving each 10min clip.
15min The video will record for 20mins at a time before
saving each 20min clip.
Continue OFF Ensures the Car Camera will not turn off in video
mode when motion is not detected.
10min Turns off the Car Camera when motion is not
detected for 10mins.
20min Turns off the Car Camera when motion is not
detected for 20mins.
Video Sound ON The video will record with sound.
OFF The video will record without sound.
1960 280x
HD

System settings
To alter the playback settings, press the mode button three times to enter
playback mode,then press the menu button.
Sounds Shutter Toggle the shutter sound On or Off.
(use the mode Start-up Select the desired start-up sound:1,2 or
3 button to cycle or Off for no start-up sound.
between options for Beep Toggle the menu beep on or off.
each category) Volume Select the desired volume:1,2 or 3 or Off
Power frequency 50Hz Sets frequency to 50Hz.
60Hz Sets frequency to 60Hz.
Power Save 1min The Car Camera will automatically switch
off after 1min without use.
3min The Car Camera will automatically
switch off after 3mins without use.
5min The Car Camera will automatically switch
off after 5mins without use.
OFF The Car Camera will only switch off when
the On/Off button is switched off. .
Panel Protect 30s The screensaver will activate after
30 seconds.
1min The screensaver will activate after
1 minute.
2min The screensaver will activate after
2 minutes.
OFF The screensaver will not activate.
Date &Time 01 / 01 / 2011 Changes the date and time
settings and date format setting.
(press the mode 4 :33
button to cycle MM/DD/YYYY
between categories
and up or down
buttons to change
each category)
Language Multiple Select the desired menu language
options from 18 available languages.
TV Out NTSC Select the desiredTV format when
PAL using theAV Out socket.
Start-up Image Off No start-up image is displayed
System The default start-up image is
displayed.
My image The chosen user image is displayed.
Format Yes Formats the SD card.
No No formatting of the SD card.
IR LED Off Turns off the infra-red LED.
On Turns on the infra-red LED.
ResetAll Yes Reset to default settings.
No Maintain existing settings.
Version AS-2013-04-27c Version number
CLEANING
•Wipe clean with a soft dry cloth.
• Periodically wipe the lens clean with a soft dry cloth or lens cloth.
• Clean the screen usingTFT screen cleaner or equivalent wipes.
TECHNICALSPECIFICATION
Recording resolution 1920x1080/1280x960/1280x720/720x480/640x480
Video format AVI
Repeat storage by section 2/5/10/15mins
Power source Rechargeable Li-ion battery or 12V car
charger
Microphone Yes
Interface USB2.0
Screen 2.5”LCD,270° whirl
Day and Night vision Yes
Maxi mum di mensions ( when mou nted):
Length 17cm
Width 6cm
Depth 11cm
DISPOSAL
Dispose of all paper, cartons, batteries and plastic in accordance with your local
recycling regulations.At the end of the product’s lifespan please dispose of it at
an authorised household waste recycling centre.
