Coopers 10496 User manual

Multi Music System 10496 Instructions for Use
Please read and retain these instructions for future reference v001: 28/09/16
Page No 1
PLEASE SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Power Details: Rated voltage (adaptor) 100 –240V; 50/60Hz, 0.65Amps
Adaptor output: DC 12V 1Amp
Power consumption 18W
Audio output: 4Wx2
Frequency details: AM: 522 - 1620KHz
FM: 87.5 - 108MHz
Accessories: AC/DC Adaptor, 45 RPM Adaptor
Please read this instruction manual thoroughly before starting and ensure you are familiar with the
operation of your new Multi Music System.

Multi Music System 10496 Instructions for Use
Please read and retain these instructions for future reference v001: 28/09/16
Page No 2
SAFETY INSTRUCTIONS:
WHEN USING ELECTRICAL APPLIANCES, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED:
READ ALL INSTRUCTIONS BEFORE USE.
TO PROTECT AGAINST ELECTRIC SHOCK, DO NOT IMMERSE CORD, PLUG OR APPLIANCE IN WATER OR
ANY OTHER LIQUID.
UNPLUG FROM OUTLET WHEN NOT IN USE AND BEFORE CLEANING.
DO NOT OPERATE ANY APPLIANCE WITH A DAMAGED CORD OR PLUG OR AFTER THE APPLIANCE
MALFUNCTIONS, OR HAS BEEN DAMAGED IN ANY MANNER. WE RECOMMEND THAT THE POWER
CORD IS NOT KINKED OR STORED IN A TWISTED MANNER, AND THAT YOU REGULARLY CHECK ITS
CONDITION.
THE USE OF ANY ACCESSORY ATTACHMENTS NOT RECOMMENDED BY COOPERS OF STORTFORD MAY
CAUSE INJURIES AND INVALIDATE ANY WARRANTY YOU MAY HAVE.
DO NOT USE OUTDOORS.
DO NOT LET CORD HANG OVER THE EDGE OF A TABLE OR COUNTER, OR TOUCH HOT SURFACES.
DO NOT PLACE ON OR NEAR HEAT SOURCES.
USE ON A LEVEL, STABLE SURFACE.
DO NOT COVER THE ITEM IN ANY WAY WHEN IN USE AS THIS MAY CAUSE OVERHEATING.
DO NOT USE THIS APPLIANCE FOR ANY OTHER USE THAN THE INTENDED USE IT IS DESIGNED FOR.
ENSURE THERE IS SUFFICIENT DISTANCE BETWEEN THIS APPLIANCE AND OTHER ITEMS OR SUFFICIENT
DISTANCE BETWEEN THE APPLIANCE AND THE CONFINES OF THE AREA IN WHICH IT IS SITUATED. WE
RECOMMEND A MINIMUM CLEARANCE AROUND ALL FACES OF AT LEAST 10CM.
BEFORE USE, CHECK THOROUGHLY FOR ANY DEFECTS AND DO NOT USE IF DEFECTS ARE FOUND. TAKE
CARE NOT TO DROP THE APPLIANCE AS HEAVY IMPACTS MAY CAUSE INTERNAL DAMAGE.

Multi Music System 10496 Instructions for Use
Please read and retain these instructions for future reference v001: 28/09/16
Page No 3
CONTENTS
LOCATION OF CONTROL ......................................................................................................................... 5
CONNECTION ..........................................................................................................................................6
SETTING THE CLOCK................................................................................................................................ 6
SETTING ALARM.................................................................................................................................. 7
SNOOZE FUNCTION............................................................................................................................. 7
TIMER FUNCTION................................................................................................................................8
LISTENING TO RADIO .............................................................................................................................. 8
RADIO TUNING.................................................................................................................................... 8
MANUAL PRESET RADIO STATIONS ....................................................................................................8
AUTO PRESET RADIO STATIONS.......................................................................................................... 8
FM & FM-STEREO RECEPTION ............................................................................................................9
HINTS FOR BETTER RECEPTION...........................................................................................................9
FM & FM-STEREO RADIO ENCODING.................................................................................................. 9
PHONO & ENCODING............................................................................... Error! Bookmark not defined.
PHONO ENCODING ...............................................................................................................................10
CASSETTE TAPE & ENCODING ...............................................................................................................10
CASSETTE TAPE ENCODING...................................................................................................................11
AUX IN JACK & ENCODING....................................................................................................................11
PLAYBACK OF MP3/WMA SONG VIA USB STORAGE MEDIA OR MEMORY CARD ................................ 12
CONNECTING ....................................................................................................................................12
TRACKS PROGRAMMING ..................................................................................................................13
COPYING OF MP3/WMA FILE............................................................................................................14
I) COPY 1 TRACK ................................................................................................................................ 14
II) COPY 1 FOLDER............................................................................................................................. 14
III) COPY ALL TRACK ..........................................................................................................................14
FILE DELETE FROM USB / SD CARD .......................................................................................................14
I) DELETE 1 TRACK .............................................................................................................................15
II) DELETE 1 FOLDER.......................................................................................................................... 15

Multi Music System 10496 Instructions for Use
Please read and retain these instructions for future reference v001: 28/09/16
Page No 4
II) DELETE ALL TRACK ........................................................................................................................15
REMOVING OF USB / MEMORY CARD .............................................................................................. 15
COMPACT DISC (CD) PLAYBACK & ENCODING...................................................................................... 15
TRACKS PROGRAMMING ..................................................................................................................16
COPYING OF CD.................................................................................................................................16
I) COPY 1 TRACK ................................................................................................................................ 16
II) COPY 1 FOLDER (FOR MP3/WMA DISC ONLY)..............................................................................17
III) COPY ALL TRACK ..........................................................................................................................17
SPLIT TRACK FUNCTION FOR USB/SD RECORDING FOR TURNTABLE/AUX IN ......................................17
1) MANUAL SPLIT OPERATION PROCEDURE: ...............................................................................17
Note for auto split:............................................................................................................................17
BLUETOOTH CONNECTION ...................................................................................................................18
EARPHONE JACK & LINE OUT SOCKET .................................................................................................. 18
REMOTE CONTROL................................................................................................................................18
BATTERY INSTALLATION....................................................................................................................18
TO CHANGE BATTERY:.......................................................................................................................18
BUTTONS DESCRIPTION ....................................................................................................................19
..........................................................................................................................................................19

Multi Music System 10496 Instructions for Use
Please read and retain these instructions for future reference v001: 28/09/16
Page No 5
LOCATION OF CONTROL
Figure 1
1) DUST COVER
2) SKIP DOWN BUTTON
3) STOP / BAND BUTTON
4) PLAY/PAUSE BUTTON
5) MODE / CLOCK
6) REC / DEL
7) SLEEP / TIMER
8) FUNCTION
9) CD DOOR
10) CD DOOR BUTTON
11) EARPHONE JACK
12) USB SOCKET
13) SKIP UP BUTTON
14) ALBUM / PRESET DOWN
15) STANDBY INDICATOR (15)
16) ALBUM / PRESET UP
17) LCD DISPLAY
18) POWER / VOLUME KNOB
19) REMOTE CONTROL RECEIVER
20) AUX IN JACK
21) SD/MMC CARD SLOT

Multi Music System 10496 Instructions for Use
Please read and retain these instructions for future reference v001: 28/09/16
Page No 6
Figure 2
22) CABINET
23) 45 RPM ADAPTOR
24) LIFT LEVER (FOR RECORD PLAY / PAUSE)
25) AUTO STOP ON/OFF BUTTON
26) 33/45/78 RPM SPEED SELECTOR
27) TONE ARM
Figure 3
28) LINE-OUT SOCKET
29) SPEAKER BOX CONNECTION RCA JACK
30) FM ANTENNA
31) DC ADAPTOR SLOT
32) CASSETTE PLAYER
CONNECTION (Fig. 1 and 3)
1. Connect external power adaptor to DC adaptor slot.
2. Connect external speaker box with the speaker box connection RCA jack of the unit back panel. (see Fig 3)
3. Push the POWER KNOB to switch on the unit, the STANDBY INDICATOR will be off. If the backlight on the
LCD display lights up, it means the power supply is normal, now your system is ready for use. (see Fig 1)
SETTING THE CLOCK (Fig. 1)
1. When the STANDBY INDICATOR lights up, unit is in the standby mode.
2. During standby mode, select between 12h or 24h mode: press and hold MODE button for 3-5 seconds,
12h / 24h will be flashing. Press SKIP UP or SKIP DOWN button to select 12h / 24h mode. Press MODE
button again to confirm.

Multi Music System 10496 Instructions for Use
Please read and retain these instructions for future reference v001: 28/09/16
Page No 7
3. Setting hour: Press SKIP UP or SKIP DOWN button to select the correct hour, then press MODE button
again to confirm.
4. Setting minute: After step 3 is completed, press SKIP UP or SKIP DOWN button to select the correct minute,
then press MODE button again to confirm.
SETTING ALARM (Fig. 1)
1. During standby mode, hold the TIMER button for 3-5 seconds. Setting alarm sequence is “ALARM ON TIME
> ALARM OFF TIME > ALARM MODE > ALARM VOLUME”.
2. Setting alarm on time: “ON” is lighting on the display
a) Setting hour: Press the SKIP UP or SKIP DOWN (2) button to select the correct hour, then
press the TIMER button again to confirm.
b) Setting minute: Press the SKIP UPor SKIP DOWN button to select the correct minute, then
press the TIMER button again to confirm.
3. Setting alarm off time: “OFF” is lighting on the display:
a) Setting hour: Press the SKIP UP or SKIP DOWN button to select the correct hour, then press
the TIMER button again to confirm.
b) Setting minute: Press the SKIP UP or SKIP DOWN button to select the correct minute, then
press the TIMER button again to confirm.
4. Setting alarm mode: “TUNE” is lighting up on the display:
a) Press the SKIP UP or SKIP DOWN button to select the alarm mode.
b) Sequence is TUNE > CD > USB > SD, press the TIMER button again to confirm.
5. Setting alarm volume: “V - ” is lighting up on the display:
a) Press the SKIP UP or SKIP DOWN button to select the alarm volume, press the TIMER button
again to confirm.
6. Setting alarm is completed, the display will show the setting again for user’s checking
7. “CLOCK” icon is flashing when alarm is activated. “CLOCK” icon lights up when alarm setting is stored but
not yet activated.
8. Cancel alarm: during standby mode, when “CLOCK” icon is on, press the TIMER button, “CLOCK” icon will
be off.
SNOOZE FUNCTION (Fig. 1)
Press the “SNOOZE” button on the remote control when alarm is activated, alarm will be silent for 9 minutes.
After 9 minutes snooze interval, alarm will be activated again. Snooze can be used repeatedly within the 1-
hour alarm active interval.

Multi Music System 10496 Instructions for Use
Please read and retain these instructions for future reference v001: 28/09/16
Page No 8
TIMER FUNCTION (automatic switch to standby) (Fig. 1)
1. Push the POWER KNOB till the STANDBY INDICATOR light is off. Unit is turning from standby mode to
operation mode.
2. When the unit is turned on, press the SLEEP button repeatedly to choose the sleep time minutes from
90>80>70…..>10 off.
3. Sleep time setting is stored when the “SLEEP” icon lights up on the display.
4. When the sleep time minutes are over, unit will be switched to standby mode automatically.
LISTENING TO RADIO
RADIO TUNING (Fig. 1)
1. Press the FUNCTION button to select “TUNE” mode.
2. Select the desired band by pressing the BAND button (AM or FM).
3. Tune to the selected station by pressing the SKIP UP or SKIP DOWN button for 1-2 seconds, and then
release.
4. The unit will start seeking automatically and stop when a radio station is found.
MANUAL PRESET RADIO STATIONS (Fig. 1)
1. When the desired radio station is found, press MODE button, program number will be flashing.
2. Press the PRESET UP or PRESET DOWN button to choose the program number for storing the desired radio
station.
3. Press the MODE button again to confirm, program number will stop flashing.
4. Repeat steps 2 & 3 until all desired radio stations have been found and stored.
5. Press the PRESET UP or PRESET DOWN button to choose the preset radio stations.
6. The number of stations that can be found and stored is dependent on the reception in different areas and
countries (FM: max 30 stations, AM: max 20 Stations)
AUTO PRESET RADIO STATIONS (Fig. 1)
1. During radio mode, press the PLAY/PAUSE button, the unit will automatically scan the radio frequency.
When the clear signal is found, it will automatically store the radio station, starting from program number
1.
2. The number of stations that can be found and stored is dependent on the reception in different areas and
countries. See Manual Preset Radio Stations point 6 above.

Multi Music System 10496 Instructions for Use
Please read and retain these instructions for future reference v001: 28/09/16
Page No 9
FM & FM-STEREO RECEPTION (Fig. 1)
Press the “FM ST.” Button on the remote control to select FM mono or FM stereo mode. When stereo
signal is weak it is preferable to listen to the program in mono.
“ST” icon lights up on the display to show FM stereo mode is receiving.
HINTS FOR BETTER RECEPTION (Fig. 3)
1. AM: There is a built-in AM antenna. If AM reception is weak, slightly rotating or re-positioning of the unit
will usually improve the AM reception.
2. FM: The receiver has a built-in FM wire antenna hanging at the rear cabinet. This wire should be totally
unravelled and extended for best reception.
AM & FM-STEREO RADIO ENCODING (Fig. 1)
1. Press the FUNCTION button to select “TUNE” mode and select the desired band by pressing the BAND
button (AM or FM).
2. Insert memory device (USB drive, SD or MMC card)
3. Press the “REC” button, it will take 3-5 seconds to read memory device. Then USB icon will be flashing.
4. Press the SKIP UP button or SKIP DOWN button to select desired mode (USB or SD) for encoding.
Then press the “REC” button again to confirm. The system is starting the encoding mode after a few
seconds.
5. If only USB drive, SD or MMC card is inserted, step 4 can be skipped.
6. The USB or SD icon will be flashing on the display during encoding.
7. To finish encoding, press the STOP button and display will show “END” and return to “TUNER” mode.
REMARKS:
- The recording speed is 1:1 and according to the actual playing time of FM or FM-ST radio
- The recording format is preset at –MP3 bit rate : 128 kbps
- During FM & FM-STEREO radio encoding, radio frequency is fixed and cannot be tuned
RECORD PLAYER (Fig. 2)
-Remove the stylus protector.
-Make sure the tone arm is detached from the tone arm rest before operating and re-secured again
afterwards.
1. Press the FUNCTION button to select “PHON” on display.
2. Set the SPEED SELECTOR (26) to the proper position depending on the record to be played.

Multi Music System 10496 Instructions for Use
Please read and retain these instructions for future reference v001: 28/09/16
Page No 10
3. Place the record on the turn table; use the 45 rpm adaptor if required.
4. Push the LIFT LEVER upward to raise the tone arm from the arm rest, and then slowly move it to the
record side. The turn table will start to rotate.
5. Push down the LIFT LEVER to drop the tone arm and touch the record gently. Phono playing starts now.
6. Push the LIFT LEVER upward to raise the tone arm from the arm rest, the turntable will still be rotating but
phono playing will stop. To continue playing push down the LIFT LEVER.
7. Adjust the volume to the desired level.
8. At the end of the record, the turntable will automatically stop rotating. Push the LIFT LEVER upward to
raise the tone arm and manually move it to the arm rest, and then put down the LIFT LEVER.
9. To stop manually, lift the tone arm from the record and return it to the arm rest.
REMARK: If the record stops before the last track finishes, select the AUTO-STOP switch to “OFF“ position,
then it will run to the end of the record but will not stop automatically (turn off the unit by power button or
switch back the AUTO-STOP switch to “ ON “ position to stop the turntable rotate). Then put back the tone
arm to the arm rest.
PHONO ENCODING (Fig. 1)
1. Press the FUNCTION button to select “PHON” on display and then insert memory device (USB drive, SD or
MMC card).
2. Press the “REC” button, it will take 3-5 seconds to read the memory device. The USB icon will be flashing.
3. Press the SKIP UP button or SKIP DOWN button to select desired mode (USB or SD) for
encoding. Then press the “REC” button again to confirm. The system starts encoding mode after a few
seconds.
4. If only USB drive or SD/MMC card is inserted, step 3 can be skipped.
5. The USB or SD icon will flash on the display during encoding.
6. To finish encoding, press the STOP button and display will show “END” and return to phono mode.
REMARKS:
- The recording speed is 1:1 and according to the actual playing time of the record player.
- The recording format is preset at –MP3 bit rate : 128 kbps
CASSETTE TAPE & ENCODING (Fig. 1 and 3)
1. Press the FUNCTION button to select “TAPE” on display.
2. After inserting the cassette tape, the system will start playing automatically.
3. Adjust the volume to the desired level.
4. Press the “TAPE FAST FORWARD / EJECT” button” at cassette player half way during playing, the tape will
be advanced forward rapidly.
