COP-USA ASH56NVIR-TVI30 User manual


TVI High Speed PTZ
Operation Manual
Prior to operation, please carefully read this manual！


Safety attentions:
Caution:
Electric shock,
Do not open
Caution:
For preventing electric shock, no removal
without authorization, no parts inside may be
repaired by the users themselves, which may
be only done by the qualified staff.
A flash of light in equilateral triangle is used for reminding user that “there are non-insulated dangerous voltage points nearby
this product”, endanger the personnel safety.
An exclamation mark in equilateral triangle is used for reminding user of referring to the literal description about its
operation and maintenance.
V2.0
！


CONTENTS
Attention ………………………………………………………………………………………………………………………………………………………………….5
Chapter I Functions and features ……………………………………………………………………………………………………………………………………7
1.1 PTZ Specifications………………………………………………………………………………………………………………………………………………..7
1.2 Auxiliary lighting…………………………………………………………………………………………………………………………………………………..8
1.3 PTZ functions………………………………………………………………………………………………………………………………………………………8
Chapter II Network menu Setting..………………………………………………………………………………………………………………………………………11
2.1 System connection diagram………………………………………………………………………………………………………………………………………11
2.2 ONVIF Discovery Tool configuration camera IP address………………………………………………………………………………………………………12
2.3 Log in the network………………………………………………………………………………………………………………………………………………….14
2.4 Video control install…………………………………………………………………………………………………………………………………………………15
2.5 Video preview……………………………………………………………………………………………………………………………………………………….18
2.6 Device parameters…………………………………………………………………………………………………………………………………………………..24
2.7 File management…………………………………………………………………………………………………………………………………………………….34
2.8 System information………………………………………………………………………………………………………………………………………………….34
Chapter III OSD menu setup………………………………………………………………………………………………………………………………………………36
3.1 Main menu……………………………………………………………………………………………………………………………………………………………36
3.2 System information………………………………………………………………………………………………………………………………………………….36
3.3 Camera setup…………………………………………………………………………………………………………………………………………………………36
3.4 PTZ setup……………………………………………………………………………………………………………………………………………………………..38
3.5 System setup……………………………………………………………………………………………………………………………………..44
Chapter IV PTZ Installation Description…………………………………………………………………………………………………………………47
4.1 Safety measures……………………………………………………………………………………………………………………………………47


4.2 Warning………………………………………………………………………………………………………………………………………………….47
4.3 Ambient requirements…………………………………………………………………………………………………………………………………….47
4.4 Cabling safety………………………………………………………………………………………………………………………………………………….48
4.5 Installation preparation………………………………………………………………………………………………………………………………………….48
4.6 Installation methods…………………………………………………………………………………………………………………………………………………..49
4.7 Installation description………………………………………………………………………………………………………………………………………………..50
4.8 Outgoing lines of PTZ…………………………………………………………………………………………………………………………………………………53
Annex I: Technical parameters for auxiliary lighting………………………………………………………………………………………………………………………56
Annex II:Troubleshooting……………………………………………………………………………………………………………………………………………………57
Annex III:24VAC line gauge and transmission distance relationship……………………………………………………………………………………………………58
Annex IV: Lightning and surge protection………………………………………………………………………………………………………………………………….60
Annex V: Maintenance of the terms of service…………………………………………………………………………………………………………………………….61

5
Attention
Don’t look straight at the laser window lest your eyes or skin might be exposed under direct and scattering laser. Keep the illuminated
object more than 8m from the laser window.
Electrical safety
The installation and use of this product must strictly comply with national and local electrical standards. It has self-provided power supply. Power
is supplied to the product in two modes: DC12V (on-board) and AC24V (ordinary PTZ) (refer to product identification or connecting line
identification). When you use, must be comply with all kinds of electric safety stardard,use products self dedicated power adaptor.
Transport safety
During transport, storage and installation, damage of the product caused by heavy load, violent vibration and soaking shall be prevented. This
product is transported in form of integral packaging. Any damage of the product caused by transport not in the packaging form adopted during
delivery will not be under the coverage of warranty whether it is shipped by the supplier or returned to the factory for repair.
Installing safety
During installation, please refer to the user installation manual, handle the PTZ with care and do not squeeze any structural component lest
mechanical failure might be caused. The camera glass is a high-grade optical product and may not be touched with a naked hand as it may
scratch the glass, impairing image quality.
Qualification of maintenance workers
All installation and maintenance work about this device shall be completed by qualified maintenance technicians or system installation personnel.
In case of a failure, please find the reason in reference to the manual before repair. If the reason cannot be found, please ask professionals for repair.
All related maintenance work must be done by the maintenance personnel authorized by us.
No removal of camera without authorization
Do not remove the screws or protective cover of the PTZ. There are no parts repairable by users in the PTZ. The repair shall be done by qualified

6
maintenance personnel.
Environmental requirements
Temperature: -35~+55 Humidity: 90% Air pressure: 86-106kpa
Installation request
Install the device at a location with sufficient bearing capacity.
Do no store, install or use the product in an inflammable, explosive and dangerous area.
Do not install the product beyond the specified temperature, humidity or power specification.
Do no remove any internal component of the PTZ lest it might affect the use. There are no parts repairable by users inside it.
Whether the PTZ is powered on or not, please do not aim the camera at the sun or a very bright object and do not aim it at or have it monitor a bright
and still object in a long time.

7
Chapter I Functions and features
1.1 PTZ Specifications
Power supply AC24V 50/60Hz 2.50A
Power consumption 50W
Preset position 255pcs
Cruising 8gorup, each group contain 255 presets
Pattern 8pcs, each pcs can record 1024pcs PTZ order
Alarm 1channel alarm input, 1channel alarm output
Privacy mask 8 area
Focus limiting PTZ according to current zoom to change manual control
speed automaticly
Auto flip After camera tilt,pan will autorotation180°
Horizontal scan 8pcs limit scan\360°scan, scan speed adjustable
Pan speed 0.1°～160°/s
Pan range 360°endless
Tilt range -90°～90°
Tilt speed 0.1°～90°/s
Baud rate 2400/4800/9600/19200 bps
Fan/Heater Auto control
Relative humidity 10-75%（under no agglomeration）
Environment
tem
p
erature -35～+55

8
1.2 Auxiliary lighting
Optional accessories
Accessory 1 Ordinary Infrared
Accessory 2 Synchronous Infrared
Accessory 3 Synchronous Laser
Note: The detailed parameters of the accessories are shown in Annex I: Technical parameters for auxiliary lighting.
1.3 PTZ functions
The network PTZ camera is an embedded digital surveillance product integrating a megapixel high-definition camera, a universal speed-variable PTZ and a
network video server. It is a real HD IP camera, supporting a resolution of above 720p(1280*720),contain 11920*1080P resolution. It adopts an embedded
LINUX operating system and has high efficiency in system dispatching and high stability and reliability. Moreover, it also has such advantages as easy
installation and maintenance, high-definition image quality, scheduled surveillance and remote control.
1.3.1Main functions and application
Max. Resolution up to 1080P（1920（H）×1080（V）/30fps
New type of ultra-thin precision stepper motor drive, stable running, accurate positioning
Coding standard, h. 264 High Profile compression
Tilt range -90-+90°，auto-flip
Progressive scan CMOS, capture images without sawtooth.
CVT, humanized zoom speed automatic matching technology, telephoto automatic speed limit
Support local TF storage
Storage up to 255 presets.Power-interruption data memory
8 groups curise, ecah group contain MAX.32 preset,each preset stop time and cruise speed can adjust respectively
8 self-learning tracks，each group can sotrage 1024 pcs PTZ action.

9
Support auto iris and auto electronic shutter and adapt to various surveillance environments
Long-focus speed restriction: The PTZ may automatically adjust its manual control speed based on the current focus of the camera. The larger the
magnification of the camera is, the lower the manual control speed will be, to ensure fast and accurate object search.
Alarm: The PTZ has 1 alarm inputs and 1 alarm output,support alarm auto record video
Recording function: Support Manul,alarm,timing recording,support recording in advance, reserved space, auto delete function
Built-in WEB server, support through WEB to proceed real-time video, equipment management and control,video playback
The integral high speed pan/tilt is a high-tech monitoring product with high definition color camera, variable speed pan/tilt, multi-functional decoder,
CPU,and storage chip. It minimizes the interconnections among system components, improves the system reliability. Meanwhile, it is also easy for
installation and maintenance, good appearance, easy operation etc.
HD-SDI(High definition-Serial Digital Input) is a broadcast quality HD digital input and output port. HD serial digital port, it used for transmit no
compressed digital video signal;HD representation is HD signal.
HD-SDI is according to SMPTE292M, interface standard under 1.485Gb/s or 1.485/1.001Gb/s signal rate to transmit. Ineterface use coaxial-cable,
use BNC interface as line standard. Effective range is 100M.
1.3.2 Synchronous infrared - applicable to infrared synchronous PTZ
Adopt world’s most advanced high-power infrared lamp technology.
The infrared lamp features high photoelectric conversion efficiency, small heat, long life and low power (<5W). Its unique encapsulation process
ensures the 10000h lumens depreciation is less than 5%, overcoming the deadly defect of conventional infrared lamps – fast lumens depreciation.
By applying single-point high power and visibility - a feature of a point light source, an infrared lamp with a changeable angle is developed. Its angle is
changed with the visual angle of the integrated machine synchronously, ensuring the infrared lamp is not wasted and does not have an effect of a
flashlight. It maximally uses infrared light and overthrows the conventional practice of tens of watts and large volume.
Its intelligent synchronization and automatic identification method is original in the world. It can automatically identify Sony, Hitachi and CNB
integrated machines. So far it is the most user-friendly product.
1.3.3 Laser synchronous – applicable to laser synchronous PTZ
Continuous motor-driven focusing of the laser light source: The motor-driven focus control technology dedicated to a semiconductor laser unit is
adopted. The light spot may be adjusted according to the range and distance of surveillance,laser angle can change from 1 degree to 18

10
degree.During focusing, the laser light spot does not bounce. After special treatment, the laser transmittance of the optical lens may exceed 98%.
Homogenization of laser light spot: As the light source adopts a semiconductor laser unit with optical output, after the laser light source is incorporated
into the optical fiber and transmitted, a unique homogenization technology will be adopted to make the lighting effect more uniform and clearer.
Unique all-directional fine tuning device: A high-accuracy vertical and horizontal fine tuning device, which may easily adjust laser beam and camera to
a same axle.
Long-life laser unit: Adopt German laser chip, Au/Sn eutectic soldering encapsulation, perfect aging testing technology and advanced optical fiber
coupling technology, making the life of the laser unit is more than 10000h.
Laser control is in an automatic state in general. The laser acts automatically with the enabling/disabling of low illumination level of the camera. During
zooming, laser will act along with the camera to minimize its loss.

11
Chapter II Network menu Setting
2.1 System connection diagram

12
2.2 ONVIF Discovery Tool
configuration camera IP address
In system CD,we support ONVIF Discovery Tool for user, it can used for device management test:
Search IP camera or Video server device which in the network
View IP,Hardware...etc information
Modify IP, subnet mask and gateway
Run ONVIF Discovery Tool management tool,auto searching avaliable IP camera in current network. List IP address,UUID、Hardware..etc.information.
Due to each camera from factory, all the ID address are the same,so if before install Ip camera, you can use ONVIF Discovery Tool to configurate IP
address. Use mouse to choose the device,input the device ONVIF protocol’s username and password, double-click will popup current device’s information

13
dialog box, can configurate IP adrress..etc.After modity, click”SAVE”, it will show you a tip to tell you are sucess, then click”Reboot” to re-start the device.
Test whether connected
After setup IP address, click left bottom of PC: Start--all program--attachment”,open”Command Prompt”,use PING command to test whether PC has
connected with IP camera.
Command as: Ping 192.168.1.8
If screen show“Request timed out.”or” destination host unreachable”,it means install not OK.Pleae check below:
Hardware connect correct or not
PC’s TCP/IP set Full-Mesh as IP camera or not.
Whether network forbit PING command or not,please ask network manager.

14
2.3 Log in the network
This chapter introduce how to access IP camera through web browser. This manual’s interface are under Windows XP and IE8.
When through IE brower to preview IP camrea’s image,
need install VLC.EXE software firstly, after install, open IE,
input IP address (Default: 192.168.1.8),Enter into login
interface. In login interface,input IP camera’s
username(Default: admin),Password(Default:
888888) ,you can choose remember username and
PW,then click” login”,when going into user interface, will
popup below dialog box, click”OK” , after a series install
operate, and install video Activex, re-start brower, you can
view video.

15
2.4 Video Activex install
Log into user interface, you can click top right”Player download”
Interface will popup player download dialog box,shown as right
Picture,choose”Run”, will popup below dialog box:
Click’Run”,install video Activex.

16
Click “Next” ,continue install
Choose a disk to install this software, then click”Install”,
Continue install.

17
After install,as right picture,Click”Close”,finish
Install, close IE. Then Login PTZ IP address, can view video.
Ps: If your Activex in your PC is old version,
IE will popup information, to ask you install newest
Activex version.

18
2.5 Video preview
Note：It always has delay if transmission by IP, it depends on user’s PC CPU and qualities of switcher and router.Normally, MP IP
video has <500ms delay.
1
2
3
4

19
Area 1: Toolbar: Click into corresponding function
ICON Explan
Enter the image code stream, PTZ, camera control interface
Into network parameters and speed dome function Settings
Enter the picture management or local video playback and
download
System information display
Player Activex download
Exit user interface, back to Login interface
Area 2: Support Main stream,sub-stream 2kinds stream preveiw, at the righ area 3 open corresponding preview images. Support VLC player and
RTSP(TCP)、RTSP(UDP) protocol，support WMP player and MKSP protocol. Support real-time and fluency 2 kinds cache policy, IP camera can catch image
and record to TF card at same time.
Area 3: Preview interface:
Top left OSD show PTZ’s protocol,ID,Year,date,time,PTZ direction and specific coordinates,camera’s zoom,PTZ current
movemen.
Area 4: PTZ control, camera specification,Peripherals management function.

20
4
5
2.5.1 PTZ control
After open preview image, each key in the right of interface means:
 Speed key Setup PTZ totate speed.
 Direction
key Control PTZ”up,top left,top right,down,left bottom,right bottom,right,left. Click
icon,can call OSD menu
 Zoom Change lens zoom(invalid for auto Zoom camer)
 Focal Change lens’ focus (invalid for auto focus camer)
 IRIS Change Lens’s IRIS (invalid for auto IRIS camer)
 Preset
1. In preset box choose preset No. Trough[2nd key]to adjust camera position,click“ ”
will save current preview point. If need customize other reset,pleaes re-done Setp 1.
2.Call back preset:In prset box choose preset No.Click“ ” can access seted preset
⑦Scan
Scan means PTZ constant speed in a clockwise from left limit point to the right limit
point,setup step as below:
1. Through adjust camera to desired point,click “ ” can set left limit point. Pan move
PTZ to 2nd position, click“ ” can set right limit point&scan speed
2. After operate,click“ ” can call back scaning line.
⑧Patrol
Patrol is a path for camera, through multiple serial number cruise points,patrol setup as
below:
1. Setup patrol point 1,in display box, choose patrol No.click“ ”,go into patrol point
editcontain: title,preset,stop time,and patrol speed.
Re-operate 1st step,to setup other patrol point. After operate, click“ ” can callback
patrol line.
 Pattern
Pattern used to recode camera running line.Pattern setup as below:
1. Click“ ”,start into pattern setup
2. Operate PTZ kinds of control。
3. After operate, re-click“ ” can finish setup.
Search pattern: Click“ ” start run pattern.
1
2
3
6
7
8
9
