Coppernic ID Platform FAP30 User manual

ID Platform FAP30
Quick Start and Regulatory Guide
QSG 200054 A10
| Non-Contractual Picture |

•The items supplied with the device and any available accessories may vary depending on the region.
•The supplied items are designed only for this device and may not be compatible with other devices.
•Appearances and specifications are subject to change without prior notice.
•Additional accessories can be purchased from your local COPPERNIC retailer.
•Using unapproved accessories may cause performance issues and malfunctions that are not covered by the
warranty.
AVAILABILITY OF ALL ACCESSORIES IS SUBJECT TO CHANGE.
SAFETY PRECAUTIONS
Page 02 | 14
ID Platform FAP30
Quick Start and Regulatory Guide
QSG 200054 A10

WHAT'S IN THE BOX ?
DEVICE
NOTICE
BOX
1
2
3
PLUGS : EU | UK | US
CABLE MICRO USB C | USB A
POWER JACK CABLE
4
5
6
TEST REPORT
7
1 2 3
4
765
Page 03 | 14
ID Platform FAP30
Quick Start and Regulatory Guide
QSG 200054 A10

PRODUCT OVERVIEW
front camera
fingerprint sensor
FAP30
NFC
antenna area
light sensor
charge indicator
| Non-Contractual Pictures |
LED flash
loudspeaker
LED flash
rear camera
IR led IR led
iris scanner
Page 04 | 14
battery cover
Product label
ID Platform FAP30
Quick Start and Regulatory Guide
QSG 200054 A10

PRODUCT OVERVIEW
USB-C service port
volume keys +/-
function key
configurable
USB-A host port
12V/2,5A power jack cable
micro sim card slot
micro sd card slot
micro sam slot
audio jack
SIDE VIEW #01
SIDE VIEW #02
SIDE VIEW #03
power key
Page 05 | 14
| Non-Contractual Pictures |
ID Platform FAP30
Quick Start and Regulatory Guide
QSG 200054 A10

TOUCHSCREEN RECOMMENDATIONS
Page 06 | 14
ID PLATFORM IS EQUIPPED WITH A 5 POINTS MULTITOUCH GFF SENSOR TYPE.
•Do not allow the touchscreen to come into contact with other electrical devices.
•Electrostatic discharges can cause the touchscreen to malfunction.
•To avoid damaging the touchscreen, do not tap it with anything sharp or apply excessive pressure to it with your
fingertips.
•The device may not recognize touch inputs close to the edges of the screen, which are outside of the touch input area.
•It is recommended to use fingers or dedicated touch stylus when using the touchscreen.
ID Platform FAP30
Quick Start and Regulatory Guide
QSG 200054 A10

Setting up your device
CAUTION
ID Platform FAP30 can accommodate only one type of removable battery.
Charge the BATTERY
1. 12.600 mAh battery should be charged ONLY with the charger provided.Damage occurring when using another
charger will not be covered by the warranty.
2. Charge the battery using the COPPERNIC charger:
§Insert the DC Power Jack plug into the ID Platform tablet as shown into the connector with the flat part facing up:
Page 07 | 14
NOTE
•Battery charge is using QUALCOMM patented Quick charge algorithm.
•Charging current can be up to 5A but will depend on battery state of charge and device temperature.Hot
environment or extensive operation may slow down the charge.
§Put the suitable country power adapter into plug.
Charge (%)
0 -75% 75 -100%
Time (h)
2h + 2-3h
Charging time
Charge LED indicators
Power On Mode Power Off Mode
Charging Charging
Error Error
Battery level > 90% N/A
Battery level 100%
N/A charge indicator
ID Platform FAP30
Quick Start and Regulatory Guide
QSG 200054 A10

Setting up your device
MICRO SD card installation
NOTE
Micro SD cards up to 256GB can be used with the ID Platform (not included)
•To insert the Micro SD card, open the side door.
•Insert carefully the Micro SD card into the slot as shown with the gold contacts facing up.
•Insert the memory card all the way until you hear a locking sound.
•To remove the Micro SD card, push against the edge of the memory card and release it softly.
Micro SD card
Page 08 | 14
ID Platform FAP30
Quick Start and Regulatory Guide
QSG 200054 A10

Setting up your device
MICRO SIM card installation
•Switch off the tablet.
•To insert the Micro SIM card (SIM1), open the side door.
•Insert carefully the Micro SIM card into the slot as shown with the gold contacts facing up.
•Insert the Micro SIM card all the way until you hear a locking sound.
•To remove the Micro SIM card, push against the edge of the card and release it softly.
NOTE
The SAM slot could be used for a second SIM card (SIM2)
Micro SIM card
(SIM1)
Page 09 | 14
Micro SIM card
(SIM2)
ID Platform FAP30
Quick Start and Regulatory Guide
QSG 200054 A10

Setting up your device
MICRO SAM installation
•To insert the Micro SAM, open the side door.
•Insert carefully the Micro SAM into the slot as shown with the gold contacts facing up.
•Insert the Micro SAM all the way until you hear a locking sound.
•To remove the Micro SAM, push against the edge of the card and release it softly.
•Then, install the dedicated applications to use this Secure Element.
Micro SAM card
Page 10 | 14
