Coral Box RN1 User manual

Reverse Nano Pump User’s Manual
Ⅰ. Introduction
CoralBox wave makers are specifically engineered as the perfect equipment to simulate the
natural sea environments.
RN-1 pump is a very compact propeller pump using innovation and high technology
solutions to provide natural environments for different sea inhabitants in aquariums,fish
tanks or in ponds.
The excellent design,including the compact housing and the magnet holder,permits 3D flow
directions and simple mounting at every point of aquarium walls.
Before assembling and operating correctly, please read the user manual carefully.
Ⅱ. Function Overview
1. Unique control system allows to operate with different types of wave and multiple
functions,which can generate different wave patterns according to different needs.
2. Wireless controllers allow to synchronize operation among wave makers.One main
controller can remotely control several sub-controllers.
3. Low voltage DC electronic pump with variable frequency provides a safe environment
for users.
4. Easy operation to achieve the multiple sea moving patterns.
5. Flow direction can be adjusted by different operative modes,as needed.
6. Large range of voltage input (AC100~240V 50/60Hz) allows to operate in various
power systems and prevent the impact on waves shapes.
Ⅲ.Package Content
Ⅳ.Assembly and installation Notes
Suitable for most sizes of fish tans and ponds,up to 15mm glass wall thickness.
Caution!Danger of injury!Pay attention to your fingers when locating the magnet due to the
strong attractive power.
1.Separate the external magnet from the pump package. Locate the pump in the selected
position inside the tank on the internal side of the glass wall. Locate the external magnet on
the external side of the same glass wall and slide it up to the pump position. Ensure that the
aquarium glass is free form algae inside and is dry and clean outside.
2.If the controller has to be stuck on the tank, peel-off the protection paper from one side of
the double sided tape and past it on the back side of the controller. Peel-off the second
protection paper and locate the controller in the selected position.
3.Connect the pump to the controller by means of the 3-pins connector. Insert the adapter
plug to the controller and connect the power unit to the power supply source.
4.Start controller programming.
Ⅴ.Operation and Function
1.Buttons and Functions of LED Display Controller
Mode/Night:Press the button to select different
modes:F1,F2,F3,F4,F5,F6 F7and enter to the Night
mode by long hold-down the button.
Freq/reverse:Press the button to adjust the
Frequency and long hold the button to enter in the
Reverse mode.
WI-LE/Reset:Press the button to select Master
control ”M”,"S" for Slave,”N” for Standalone unit. Hold
down the Reset key for 3 sec. to reset the controller unit.
Arrow keys :10Mins Feed / 20Mins Feed or move position.
*Attention:If the pump operates in Night Mode,any other mode/feeding is disabled until exit
from the Night Mode
Be careful: Make sure to switch off the main controller before plug it with DC power supply
or plug with powerhead block.
Coral Box wave maker pump
Wireless controller with connection cable
Power unit with power cable
Bi-adhesive
User manual
Name
RN1
Operating
Tension
24V
Flow Rate
1500~10000L
(396~2642gal/h)
Cable Length
1860mm (73inch)
Energy
Consumption
25W
Dimension
78*72* 52mm
(3.1*2.8*2 inch)
Voltage /
Frequency
110/240V 20/60Hz
Outlet Nozzle
diameter
70mm (2.8inch)

2.Introduction of each mode
F1:Stream Mode
One or more pumps
can operate at the
same time, in
constant flow.
F4:Nature Mode
The power level
changes between
30%~100%
making a more
natural flow pattern.
F2:Pulse Mode
One or more pumps
can operate at the
same time,in pulse
flow.
Pulse the wave by
time / flow frequency.
Nature Mode(LPS)
Reef Mode(SPS)
F5:Reef Mode
Power of flow is
changing in a
random mode in
volume and time.
This is the best
mode for corals.
F3:Asynchronous
Wave Mode
Shift flow in cycles,
Pump A run, Pump B
stop;Pump B run,
Pump A stop
Need have 2 Pump
with WIFI master and
slave to run.
F7: Reverse Mode
Clockwise
pump.The pump
uses the opposite
direction of the
water flow to
improve cleaning of
your tank.
F6:Timer Mode
Six different operative modes can be set in
this mode. For example, the first set of 9 a.m
to 10 a.m stream mode, the second set of
10 a.m to 1 p.m pulse mode.
F0: Stop Mode
It only works in the Timer Mode(F6). This
mode stops the Pump running in the
programmed time slot.
F1,F2,F3,F4,F5,F7 can press “Frequency/Reverse” button to adjust the
Frequency,Press “Up/Down”arrows to adjust the Flow.
3.How to Set the Timer?
First you need to press “MODE/NIGHT” button to select F6 Timer mode.
Enter in the programming mode by pressing “Timer switch” button.
Move the cursor in the position to be set by using Left/Right arrows.
Adjust Current Time/Schedule/Timer/mode by using Up/Down arrows.
4.Sequence Modes Setting:
Press “time switch” button to enter in the programming mode. Using left/right arrows, move
the cursor on the digit of the Schedule (T), and change it from 1 to 6 using up/down
arrows. Example if first time slot is to be programmed, digit shown in the display are: T1
Using left/right arrows, move the cursor on the Start Time digits. Move up/down arrows up
to achieve the desired figure. Example if start time is set to 09:00 than digit in the display
are: 09S
Using left/right arrows, move the cursor on the End Time digits. Move up/down arrows up to
achieve the desired figure. Example if end time is set to 11:00 than digit in the display are:
11E
Using left/right arrows, move the cursor on the Function digit. Move up/down arrows up to
achieve the desired function mode from 0 to 5. Example if mode is set to 1, then digit shown
in the display are: F1
Here is possible to set the Stop Mode (F0).
As a reference here below an example of daily program in multifunctional mode.
Display
Schedule
Timer ( Start ~ End )
Function
T1
09:00 Start ~ 11:00 End
F1
T2
11:00 Start ~ 13:00 End
F2
T3
13:00 Start ~ 15:00 End
F3
T4
15:00 Start ~ 18:00 End
F4
T5
18:00 Start ~ 22:00 End
F5
T6
22:00 Start ~ 09:00 End
F4
*Attention: To provides best motor impeller performance F7 reverse mode cannot
operation to timer to avoid Long time running.
Ⅵ.Warnings
Do not operate the pump outside water to ensure the performance.
Select a dry place to locate the controller to prevent water could be splashed on it.
Pay attention during magnets assembly. It is recommended to locate the magnetic pad
close to the outside wall of fish tank to prevent breaking the fish tank and then shift it in

correspondence of the pump location.
Never disassemble the controller and the adaptor without professional guidance.
Never repair a damaged cable without professional guidance. In case of main cable
damage, change the entire pump or power supply unit.
Ⅶ. FAQ & Maintenance
1.Why can't I change the mode?
Check if night mode is on, if it is set it to off. If Wireless is "S", the pump is controlled by the
master pump, change the wireless mode to N (Standalone)to allow for local settings.
Check the Timer if you change back to F6 Mode, after set the timer,you need to switch F6 to
running.Make sure all the timer program T1-T6 is set, remember check it not overlap corrupt
on the same time.Otherwise it will not function.
2.How Can I reset the controller?
Hold the Reset button 3 seconds, it will reset the controller programs to the factory status.
3.How many time periods can I program on each day?
Up to 6 time periods per days.
4.Why can’t i use F0 mode?
F0 Mode(Stop the pump),The function only works in Timer mode.
5.Why won’t my program run?
Check the timer, if you change back to F6 mode after you set the timer,you need to switch
F6 to running.
6.My pump produces some noise.What can I do?
New pumps could have temporary sound issue. Normally the noise will be naturally reduced
after one week of operation. You can also try to take-out the impeller and reinstall the
rubber bush.
7.How I can set for the Master and Slave Pump?
Set WIFI Button to “M” for A Pump,and set B Pump controller WIFI to “S”.
8.Which parts are consumables?
THE IMPELLER / THE RUBBER BUSH AND THE COVER ARE CONSUMABLE ITEM,
WE RECOMMEND TO CHECK REGULARLY THEIR STATUS AND TO CHANGE THEM
AFTER 1 YEAR TO PROVIDES BEST PERFORMANCES.
●This product is for indoor use only. Never submerge the controller, the power supply
unit or the connect or inside the water to avoid unnecessary loss.
●Regularly clean the controller to ensure good performance.
●Rub the controller surface with a dry cloth if it has been accidentally wetted to prevent
water from dripping into controller.
●Sweep the waste in the pump housing and on the propeller by opening the pump
housing. Rotate the basket in anti-clockwise direction to open the housing and lock it
by rotating in clockwise direction.
●Use soft cloth to rub the blade and clean the dirt in the pump
Ⅷ.WEEE - Waste Electrical and Electronic Equipment
In August of 2005, the European Union(EU) implemented the EU WEEE Directive
2002/96/EC and later the WEEE Recast Directive 2012/191EU requiring Producers of
electronic and electrical equipment(EEE) to manage and to finance the collection, reuse,
recycling and to appropriately treat WEEE that the Producer places on the EU market after
August 13,2005.
The objective of this directive is to minimize the volume of electrical and electronic waste
disposal and to encourage re-use and recycling at the end of life. Coral Box has met its
national obligations to the EU WEEE Directive by registering in those countries to which
Coral Box is an importer.
Coral Box has also elected to join WEEE Compliance Schemes in some countries to help
manage customer returns at end-of-life. If you have purchased Coral Box-branded electrical
or electronic products in the EU and are intending to discard these products at the end of
their useful life, please do no dispose of them with your other household or municipal waste.
Coral Box has labeled its branded electronic products with the WEEE Symbol (figure 1) to
alert our customers that products bearing this label should not be disposed of in a landfill or
with municipal or household waste in the EU.
Instead, please be aware that Coral Box is making a return and collection system available
to you, free of transportation and recycling costs, for discarding these products. Can only be
used by the Company if this document is publicly available.
For a copy of Coral Box’s Selective Treatment of Waste Electrical and Equipment outlined
under Articles 14 and 15 and Annex VII of the EU WEEE Directive 2012/19/EU, please click
here WEEE Selective Treatment List and the list of hazardous materials used in our product.
All right Reserved – No part or whole of this Manual can be reproduced without
written authorization by Coral Box
ITEM
CODE
Impeller
98443
Rubber Bush
98442
Cover
98441
