CORBERO E-CLAV71020T User manual
Washing Machine / User Manual
EN
E-CLAV71020T
Icon Type Meaning
WARNING Serious injury or death risk
RISK OF ELECTRIC SHOCK Dangerous voltage risk
FIRE Warning; Risk of fire / flammable materials
CAUTION Injury or property damage risk
IMPORTANT / NOTE Operating the system correctly
Thank you for choosing this product.
This User Manual contains important safety information and instructions on the operation
and maintenance of your appliance.
Please take the time to read this User Manual before using your appliance and keep this
book for future reference.
CONTENTS
1.SAFETY INSTRUCTIONS ................................................................................ ................1
1.1 General Safety Warnings ...............................................................................................2
1.2 During Use ....................................................................................................................6
1.3 Packaging and Environment...........................................................................................7
1.4 Savings Information........................................................................................................7
2.TECHNICAL SPECIFICATIONS....................................................................... ................9
2.1 General Appearance.......................................................................................................9
2.2 Technical Specifications .................................................................................................9
3.INSTALLATION............................................................................................... ................10
3.1 Removing the Transit Bolts...........................................................................................10
3.2 Adjusting the Feet / Adjusting Adjustable Stays............................................................10
3.3 Electrical Connection....................................................................................................10
3.4 Water Inlet Hose Connection........................................................................ ................11
3.5 Water Discharge Connection........................................................................................12
4.CONTROL PANEL OVERVIEW...................................................................... ................12
4.1 Detergent Drawer .........................................................................................................12
4.2 Sections ...................................................................................................................13
4.3 Program Dial.................................................................................................................13
4.4 Electronic Display.........................................................................................................13
5.USING YOUR WASHING MACHINE.............................................................. ................14
5.1 Preparing Your Laundry................................................................................................14
5.2 Putting Laundry in the Machine....................................................................................14
5.3 Adding Detergent to the Machine .................................................................................15
5.4 Operating Your Machine...............................................................................................15
5.5 Selecting a Programme................................................................................................15
5.6 Half-Load Detection System.........................................................................................16
5.7 Additional Functions ....................................................................................................16
5.8 Cancelling the Programme...........................................................................................19
5.9 Programme End ...........................................................................................................19
6.PROGRAMME TABLE.................................................................................... ................20
6.1 Important Informations..................................................................................................22
7.CLEANING AND MAINTENANCE ................................................................. ................23
7.1 Warning ...................................................................................................................23
7.2 Water Inlet Filters .........................................................................................................23
7.3 Pump Filter ...................................................................................................................24
7.4 Detergent Drawer .........................................................................................................24
8.FLUSH STOPPER / BODY / DRUM ............................................................... ................25
9.TROUBLESHOOTING.................................................................................... ................26
10.AUTOMATIC FAULT WARNINGS AND WHAT TO DO ............................... ................27
11.DESCRIBING THE ENERGY LABEL AND SAVING ENERGY.................... ................28
EN - 1
1.SAFETY INSTRUCTIONS
Operating voltage / frequency (V/Hz) (220-240)
V~/50Hz
Total current (A) 10
Water pressure (Mpa) Maximum 1 Mpa /
Minimum 0. 1Mpa
Total power (W) 2100
Maximum washing capacity
(dry laundry) (kg) 7.0
Do not install your machine on a carpet or such
grounds that would prevent the ventilation of its
base.
The appliance is not intended for use by people
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
Children of less than 3 years should be kept away
unless continuously supervised.
Call the nearest authorized service centre for a
replacement if the power cord malfunctions.
Use only the new water inlet hose coming with your
machine when making water inlet connections to
your machine. Never use old, used or damaged
water inlet hoses.
Children should not play with the appliance.
Cleaning and user maintenance should not be made
by children without supervision.
EN - 2
NOTE: For a softcopy of this user manual, please
contact the following address: “washingmachine@
standardtest. info”. In your e-mail, please provide the
model name and serial number (20 digits) which you
can find on the appliance door.
Read this user manual carefully.
Your machine is for domestic use only.
Using it for commercial purposes will cause
your warranty to be cancelled.
This manual has been prepared for more than
one model therefore your appliance may not have
some of the features described within. For this
reason, it is important to pay particular attention to
any figures whilst reading the operating manual.
1.1 General Safety Warnings
It is recommended that for your first wash,
you select the 90˚ Cotton programme without
laundry and half fill compartment II of the
detergent drawer with a suitable detergent.
of each wash.
EN - 3
programme you have chosen.
Make sure that the door of your Washing Machine is
not restricted and can be opened fully.
EN - 4
Install your machine in a location that can be
fully ventilated and preferably has constant air
circulation.
Read these warnings. Follow the advice given
to protect yourself and others from risks and fatal
injuries.
RISK OF BURNS
Do not touch the drain hose or any discharged
water while your Washing Machine is running. The
high temperatures involved pose a burn risk.
RISK OF DEATH FROM ELECTRICAL
CURRENT
Never remove the plug from the socket by
hands or feet are wet.
Risk of flooding
Take necessary measures to prevent the hose from
EN - 5
block the plug hole.
Danger of Fire
Risk of fire and explosion
Risk of falling and injury
hazard.
detergent drawer.
The machine must be carried by at least 2
people.
Child safety
EN - 6
1.2 During Use
This appliance can be used by children aged
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be done
by children without supervision.
Before operating the washing machine, remove
the 4 transit bolts and rubber spacers from
the rear of the machine. If the bolts are not
removed they may cause heavy vibration, noise
and malfunction of the machine and cause the
guarantee to be void.
Your warranty does not cover damage caused by
EN - 7
sources of damage.
NOTE:
1.3 Packaging and Environment
Removal of packaging materials
1.4 Savings Information
EN - 8
CE Declaration of conformity
Disposal of your old machine
where you purchased the product.
EN - 9
2. TECHNICAL SPECIFICATIONS
123
4
5
6
7
8
9
10
2.1 General Appearance
1.
2.
3. Upper Tray
4. Detergent Drawer
5. Drum
6.
7. Water Inlet Valve
8. Power Cable
9.
10.
2.2 Technical Specifications
voltage /
frequency
(V/Hz)
(220-240)
V~/50Hz
Total current
(A) 10
Water
pressure
(Mpa)
1 Mpa
0. 1 Mpa
Total power
(W) 2100
dry laundry
7,0
1000
Programme
number 15
(mm)
Depth
845
597
527
EN - 10
3. INSTALLATION
3.1 Removing the Transit Bolts
X X4 4
X4
1
3
2
4
1.
If the bolts are not removed, they
warranty.
2.
spanner.
3.
pull.
4.
use.
NOTE:
the scope of the warranty.
3.2 Adjusting the Feet /
Adjusting Adjustable Stays
1
1.
(such as carpet) that would prevent
adjustable feet.
X4
2 3
2.
3.
3.3 Electrical Connection
EN - 11
amps.
damage that occurs due to the use of
NOTE:
3.4 Water Inlet Hose Connection
3/4”
10 mm
1
3
2
4
1.
and red capped hose to the hot water
that connect to the water supply.
2.
threaded tap.
and the red capped end of the hose to
opened tap).
3. Once you have made all of the
supply on and check for leaks.
4.
or crushed.
NOTE:
~ 95 cm ~ 140 cm
~ 145 cm ~ 95 cm
0 – max. 100 cm
˜˜
95 cm 150 cm
EN - 12
must only be connected to your water
hoses must not be reused.
3.5 Water Discharge Connection
hose.
bathtub.
not bent, buckled, crushed or extended.
ground.
4. CONTROL PANEL OVERVIEW
5.
1 2 3
1. Detergent Drawer
2.
3.
4.1 Detergent Drawer
1
2
3
4
5
6
1.
2.
3. Softener Compartment
4. Pre-Wash Detergent Compartment
5. Powder Detergent Levels
6. Powder Detergent Scoop (*)
EN - 13
4.2 Sections
Main wash detergent compartment:
Fabric conditioner, starch, detergent
compartment:
Pre-wash detergent compartment:
4.3 Program Dial
programme.
set exactly to the programme you want.
4.4 Electronic Display
10 9 8 7
1 2 3 4 5
6
1. Water Temperature Adjustment Button
2. RPM Speed Adjustment Button
3.
4.
5. Start/Pause Button
6.
7.
8.
9.
10.
The display panel shows the washing delay
timer (if set), temperature selection, any
additional functions you have selected and
the current stage of the programme you are
running on your machine ( prewash/
wash, rinsing, spinning).
EN - 14
The display panel shows “End” when the
selected programme is complete. The
display panel also indicates if a fault has
occurred with your machine.
5. USING YOUR
WASHING MACHINE
5.1 Preparing Your Laundry
1
3
5
7
2
4
6
1.
2.
together.
and should be washed separately
3.
CAUTION:
the warranty.
4.
eyes.
5.
or bag.
6.
7.
temperature
Can be dry
cleaned
pure alcohol
allowed
temperature
No dry
Hang to dry
Perchloroethylene
R11, R13,
Petroleum
Normal
Dry flat
Do not tumble
dry
R11, R113, Gas
Can be
bleached Do not bleach
F P A
5.2 Putting Laundry in the Machine
EN - 15
NOTE: Take care not to exceed
LAUNDRY TYPE WEIGHT (gr)
Towel 200
500
Bathrobe 1200
700
200
Underwear 100
Tablecloth 250
trapped between the rubber seal and
the door.
5.3 Adding Detergent to the Machine
do not pre-wash. Put a small amount
detergent drawer.
compartment I of the detergent drawer
amount of detergent to use.
In areas of hard water, more detergent
of the detergent drawer. Do not exceed
the MAX level.
5.4 Operating Your Machine
1 2
1.
supply.
2. Turn on the water supply.
5.5 Selecting a Programme
Use the programme tables to select the
laundry.
EN - 16
5.6 Half-Load Detection System
system.
regardless of the programme you selected.
less water and energy.
(*) Model Dependant
5.7 Additional Functions
Press the button on the Control Panel
selected.
Reason for non-activation:
The additional function is not
compatible with the selected washing
programme.
Your machine has progressed too far
into the programme for the additional
function to be possible.
The additional function you have
chosen is not compatible with
another additional function you have
already selected.
1. Temperature Selection
Temp.
Use the washing water temperature
adjustment button to alter the automatically
programmed washing water temperature.
When you select a programme the
maximum temperature for that programme
is automatically selected. To adjust the
temperature, press the water temperature
adjustment button until the desired
temperature is displayed on the digital
display.
You can gradually decrease the washing
water temperature between the maximum
washing water temperature of the selected
programme and cold washing (--) selections
by pressing the temperature adjustment
button.
2. Spin Speed Selection
Speed
When you select a programme, the
maximum spin speed is automatically
selected.
To adjust the spin speed between the
EN - 17
maximum spin speed and the cancel
spinning option (--), press the Spin speed
button until the desired speed is displayed.
If you have skipped the spin speed you
want to set, keep pressing the spin speed
adjustment button until the desired spin
speed is displayed again.
3. Delay Timer
Delay
Press the Delay button once.
“1 h” will appear on the display.
The symbol will flash on the
electronic display.
Press the Delay button until the desired
delayed time appears on the display.
If you have skipped the delay time you
wanted to set, keep pressing the Delay
button until the desired delay time is
displayed again.
For the delay timer function to work, you
must press Start/Pause button.
To activate the time delay, press “Start/
Pause” button.
To cancel the time delay once it has
been set, press the Delay button once.
The symbol will no longer flash on
the electronic display.
In order to add/remove laundry while
delay timer function is working, you
must press Start/Pause button. After
adding/removing laundry, you must
press Start/Pause button again to
activate delay timer function.
4. Anti- Allergic(*)
You can add an additional rinse operation to
your laundry using this additional function.
Your machine will carry out all rinsing steps
with hot water. We recommend this setting
for laundry worn on delicate skin, baby
clothes and underwear.
To select this function, press the Antiallergic
button when the symbol is displayed.
5. Easy Ironing(*)
button 4 Easy
Table of contents
Other CORBERO Washer manuals
CORBERO
CORBERO E-CLAV81020T User manual
CORBERO
CORBERO CLAV22712 User manual
CORBERO
CORBERO CLA6005W User manual
CORBERO
CORBERO CLAM8419IN User manual
CORBERO
CORBERO E-CLAV91219BD User manual
CORBERO
CORBERO CSCEM8084W User manual
CORBERO
CORBERO CLAV221014VP User manual
CORBERO
CORBERO E-CLA5018W User manual
CORBERO
CORBERO E-CLAV61220T User manual
CORBERO
CORBERO CLAV22812VP User manual
CORBERO
CORBERO LF8500 User manual
CORBERO
CORBERO LC8821 User manual
CORBERO
CORBERO Lavadora Premium CLAV2284VPINVX User manual
CORBERO
CORBERO CLAV101422JETEXC User manual
CORBERO
CORBERO CLH1400VIAD User manual
CORBERO
CORBERO E-CLAV71220T User manual
CORBERO
CORBERO CLAV221012VP User manual
CORBERO
CORBERO LF 8521 User manual
CORBERO
CORBERO CLAV91422EXC User manual
CORBERO
CORBERO CLA1016W User manual
Popular Washer manuals by other brands
BENDIX
BENDIX BIW 103 W Operating and installation instructions
Speed Queen
Speed Queen AFNE9RSP113WH user guide
sangiorgio
sangiorgio EES510 Series user manual
Whirlpool
Whirlpool AWOD 6528 Programme chart
Kenmore
Kenmore 20842 & 20847 Information
Panasonic
Panasonic NA-106VC5 Operating instructions & installation instructions
