Corby Westminster User manual

COI0025_V14_180723
USE & CARE MANUAL
DIGITAL SAFE
This manual is for the following models:
Westminster Whitehall Mayfair
SFE0003 SFE0004 SFE0006
5323 2042A-1 CT-1340UZH
www.corbyofwindsor.com
www.firedupcorporation.com/manual
LANGUAGES
English 02-20
Français 21-40
Deutsch 41-60
Italiano 61-80
Español 81-100
Polski 101-120
Română121-140

These notes must be read before use
These instructions are for your safety. Please read through them thoroughly
before use and retain for future reference. Failure to follow them could cause
injury and/or property damage.
CONTENTS
SECTION 01
Important safety information 03
SECTION 02
Introduction 04
Parts supplied 04-06
SECTION 03
Installation 07 - 09
Setup & Use 10-12
Error codes 12
CEU User Guide 13
Guarantee & contact information 20
02
SECTION 01

IMPORTANT SAFETY INFORMATION
DO’S
• Read ALL the instructions before installing or using this safe.
• Only use this Safe for its intended use as described in this manual.
• Ensure the Safe is installed where there is sufficient load bearing capacity.
• Always install the Safe in accordance with this guide. If in doubt obtain expert
advice.
DON’TS
• Do not use or store the Safe outdoors.
• Do not attempt to modify or make repairs to the Safe.
• Do not attempt to power this product by the introduction of a separate
power supply other that supplied.
BATTERY CAUTION
• Use of rechargeable batteries is not recommended for this product.
• Do not attempt to recharge non-rechargeable batteries.
• Only use batteries of the same or equivalent type to those recommended.
• Take special care to ensure the batteries are inserted correctly, observing
polarity.
• Avoid short circuiting the contacts of the battery housing or the battery
terminals.
• Remove exhausted batteries from product.
• Remove the battery from the product if storing for long periods.
• Remove the battery if the product is to be scrapped.
• Dispose of exhausted batteries safely and never dispose of batteries in a fire.
SAVE THESE INSTRUCTIONS
03
SECTION 01

INTRODUCTION
Thank you for choosing this Corby Safe. The product has been designed to meet
the most stringent quality, performance, and safety requirements.
This Safe is perfectly suited to the requirements of a hotel guest-room.
HANDLING
Before continuing any further with the installation of this safe please read the
following:
• When lifting always keep your back straight. Bend your legs and not your back.
• Avoid twisting at the waist. It is better to reposition your feet.
• Avoid upper body / top heavy bending. Always bend from the knees rather
than the waist.
• Do not lean forward or sideways whilst handling the Safe.
• Always grip with the palm of the hand. Do not use the tips of fingers for
support.
• Always keep the product as close to the body as possible to prevent
unnecessary and undue strain on the body.
• Use gloves to provide additional grip.
• Always use assistance if required.
PARTS SUPPLIED
Whitehall / SFE0004 / 2042A-1
1x Safe
2x Fixing screws
4x AA batteries
1x Key
1x Carpet
04
SECTION 02
Internal
Battery pack
Fixing point

05
SECTION 02
PARTS SUPPLIED
Westminster / SFE0003 / 5323
Mayfair / SFE0006 / CT-1340UZH
1x Safe
1x External power supply
4x Fixing screws
4x AA batteries
2x Keys
1x Carpet
Front Opening Safe
Westminster / SFE0003 / 5323
Internal
Battery pack
Fixing point
USB In
External Power Supply
USB Out

06
SECTION 02
External Power Supply
USB Out
Top Opening Safe
Mayfair / SFE0006 / CT-1340UZH
Internal
USB In
Battery pack
Fixing point

07
SECTION 03
INSTALLATION
Always bolt your Safe down
(1) Choose a location for the Safe that is preferably concealed from view
(2) Take care that there is sufficient floor load bearing capacity.
(3) If installing the Safe in a cupboard or closet, make sure that its load bearing
capacity is sufficient and that a secure anchorage point can be made through
to the wall or floor.
(4) Make sure that there is no plumbing or wiring below or behind the chosen
location.
(5) Use more than one fixing point to secure the safe.
(6) When the Safe is to be anchored to a wood floor, ensure at least one of the
anchorage points is into a joist/support beam rather than just the floorboards.
A
Safe Door
A
B
Using the provided
fixings, fix the safe to
a wall (A) or the floor (B)
Safe Door
Top Opening Safe
Mayfair / SFE0006 / CT-1340UZH
Front Opening Safe
Westminster / SFE0003 / 5323
Whitehall / SFE0004 / 2042A-1

08
SECTION 03
308 61±1
195
430
95±2
308 61±1
186.5±2
430
370
FRONT OPENING SAFE
Westminster / SFE0003 / 5323
Whitehall / SFE0004 / 2042A-1
FRONT VIEW (A)
BOTTOM VIEW (B)

09
SECTION 03
TOP OPENING SAFE
Mayfair / SFE0006 / CT-1340UZH
95210
21070
FRONT
TOP VIEW

10
SECTION 03
SETUP
Whitehall / SFE0004 / 2042A-1
Install 4 x AA batteries into the battery pack.
USE
DEFAULT CODES
Guest code (3-6 digits): 123
Manager code(6 digits): 000000
Confirm
Clear
GUEST CODE
To Lock
(1) Close the door
(2) Enter your 3-6 digit code, press #
To Open
(1) Enter your 3-6 digit code
NOTE: If the wrong code is entered, the display will show ‘ERROR’. If the wrong code is
entered 4 times, the safe will shut down for 15 minutes.
USING MANAGER CODE
To Open
(1) Enter default Manager code, press #
CHANGING MANAGER CODE
When the safe is open:
(1) Press (‘PROG’ will display)
(2) Input Manager code (‘NEU’ will display)
(3) Input NEW 6 digit Manager code (‘AGAIN’ will display)
(4) Re-enter NEW 6 digit Manager code (‘DONE’ will display)
Manager code has been changed.
EMERGENCY OPEN/BATTERIES REQUIRE CHANGING:
(1) Remove the key cover (shown on page 4) by pulling it towards you
(2) Insert key and turn clockwise to open the door
(3) Remove the key and replace the key cover
(4) Replace batteries if necessary
IMPORTANT:Always keep the safe keys in a secure location.
#

11
SECTION 03
SETUP
Westminster / SFE0003 / 5323
Mayfair / SFE0006 / CT-1340UZH
Factory setting codes
Guest code (4-6 digits): 1234
Manager code(6 digits): 123456 (requires CEU)
First opening
• Install 4x AA batteries into the external power supply.
• Plug the external power supply into USB In port on the safe door.
• Input the factory setting guest code.
• The door will automatically open.
• Remove the batteries from the external power supply and place into the safe
door battery pack.
Changing manager code
Refer to CEU section at the end of this manual.
USE
To Close:
(1) Input your personal 4-6 digit code.
(2) Close the door, then press “lock”.
To Open:
(1) Input your own 4-6 digit code.
(2) The door will automatically open.
Emergency Open:
(1) Wait 15 minutes from the time the code has been incorrectly inputted 3
times. (This is a safety feature).
Key Hole

S
E
C
T
I
O
N
0
3
12
SECTION 03
(2) Carefully remove the “user’s instructions” section on the safe front to reveal a key
hole.
(3) Using the keys supplied open the safe.
(4) With the key still in the safe, type “1234lock”.
(5) Close the door and remove the key.
The safe is now reset to the original factory password of 1234.
IMPORTANT: Always keep the safe keys in a secure location.
ERROR CODES - Westminster / SFE0003 / 5323
Mayfair / SFE0006 / CT1340UZH
“o-ON”: Enable the password hidden function
“o-OFF”: Disable the password hidden function
“LO-BAT”: Low Battery
“CLOSE”: Closing
“CLOSED”: Closed
“OPEN”: Opening
“OPENED”: Opened
“NEW”: Need to input new password
“AGAIN”: Need to input the same password again
“DONE”: Done
“HOLD(1-15)”: The door is locked (1-15 minutes) wrong password inputted multiple times
“E-CODE”: Error password
“E-RUN” —— Can not open normally. The lock is stuck.
SOLUTION: Push the door to allow more space for the lock move.
“B-LOC” —— Can not close normally. The lock is stuck.
SOLUTION: Push the door to allow more space for the lock move.
ERROR CODES - Whitehall / SFE0004 / 2042A-1
“BA-HI”: Battery is OK
“BA-LO”: Low battery
“CLOLSE-”: The lock is closing
“CLOSED”: The lock is closed
“OPEN”: The lock is opening
“OPENED”: The lock is opened
“NEW”: Need to input a new password
“AGAIN”: Need to input the same password again
“DONE”: Done
“ERROR” -- Password is not correct
“ERROR1” -- Can not open normally. The lock is stuck.
SOLUTION: Push the door to allow more space for the lock to move.
“ERROR2” -- Can not close normally. The lock is stuck.
SOLUTION: Push the door to allow more space for the lock to move.

13
DIGITAL SAFE
COMPUTERISED EMERGENCY UNIT
(CEU)
This manual is for the following models:
SFE0007
5324
CONTENTS
SECTION 01 Page
Parts Supplied 17
Battery Caution 17
SECTION 02
Use
Turn on the CEU 18
Turn off the CEU 18
Menu on the CEU
18
Set Clock 18
Reading Safe Records 18
Set Safe Admin Code 19
Set CEU Admin Code 19
Open Safe 19
Set Lamp 19
Set Communication Mode 20
Communication with PC
Reading Data 20
Save Records 22
Print Records 22
SECTION 03
Guarantee & contact information 24

14
SECTION 01
PARTS SUPPLIED
1x CEU
1x Micro USB cable
1x USB to USB cable
4x AAA Batteries
BATTERY CAUTION
• Use of rechargeable batteries is not recommended for this product.
• Do not attempt to recharge non-rechargeable batteries.
• Only use batteries of the same or equivalent type to those recommended.
• Take special care to ensure the batteries are inserted correctly, observing
polarity.
• Avoid short circuiting the contacts of the battery housing or the battery
terminals.
• Remove exhausted batteries from product.
• Remove the battery from the product if storing for long periods.
• Remove the battery if the product is to be scrapped.
• Dispose of exhausted batteries safely and never dispose of batteries in a fire.
123
456
789
0#
OK
CEU
USB Out
Micro USB Cables
USB to USB Cable

15
SECTION 02
USE
TURN ON THE CEU
Put 4x AAA batteries in the CEU.
Press and hold for 2 seconds.
TURN OFF THE CEU
Press and hold for 2 seconds.
MENU ON THE CEU
1. Records
1. ReadRecord
2. CheckRecord
3. DeleteRecord
2. SetClock
1. SetClock
2. SynClock
3. SetAdminCode
1. ModifyCasePin
2. ModifyCeuPin
4. OpenSafe
5. SetLamp
6. PrintRecords*
7. CommMode
1. IO-A
2. IO-B
3. USART
4. PC
SET CLOCK
Important: To ensure accurate data records the clock on CEU must be set and
synchronised with the safe box when installed.
(1) Press ▼or ▲on CEU to choose 7.CommMode, and press OK to enter
submenu. Then press ▼or ▲and choose 1. IO-A, and press OK.
(2) Connect CEU to safe using Micro USB Cable. After CEU turns on, Press ▼or ▲
to choose 2.Setclock, and press OK to enter into submenu.
(3) Press ▼or ▲to choose 1.SetClock and press OK to set time.
A. Input number to set date and time
B. Press OK to save setting and return back to main menu
(4) Press ▼or ▲to choose 2.SynClock, and press OK to synchronize time
between CEU and safe.
(5) Press return back to main menu.
READING SAFE RECORDS
(1) Press ▼or ▲on CEU to choose 7.CommMode, and press OK to enter
submenu. Then press ▼or ▲and choose 1. IO-A, and press OK.
(2) Connect CEU with safe using Micro USB Cable. After CEU turns on, press ▼or
▲to choose 1.Records, and press OK to enter into submenu.
* Direct printing from CEU not available on
this model. To print records see page 8.

16
SECTION 02
(3) Press ▼or ▲on CEU to choose 1.ReadRecord, and press OK. This will copy the
safes records to the CEU. Note: Only one safes data can be stored on the CEU at a
time.
(4) The CEU can now be disconected from the safe.
(5) To view the records stored on the CEU enter the 1.Records menu, then press ▼
or ▲to choose 2.CheckRecord, and press OK to view the records stored on the
CEU. Use ▼or ▲to scroll through the records. Press to return back to previous
menu.
(6) To view the view the records on a PC follow the instructions on Page 6
Communication With PC.
(7) To delete the records stored on the CEU enter the 1.Records menu, then press
▼or ▲to choose 3.DeleteRecord, press OK to delete the data.
SET SAFE ADMIN CODE
IMPORTANT:It is not necessary to change administration
code. The code is used for communication between the CEU
and safe. The safe and CEU admin codes must be the same,
otherwise the CEU will not be able to read the records from
the safe. If changing the administration code, keep a record
of the new code and the old code.
(1) Press ▼or ▲on CEU to choose 7.CommMode, and press OK to enter submenu.
Then press ▼or ▲and choose 1. IO-A, and press OK.
(2) Connect CEU with safe using Micro USB Cable. After CEU turns on, press ▼or ▲
to choose 3.SetAdminCode, and press OK to enter into submenu.
(3) Choose 1. ModifyCasePin and press OK to modify case pin.
(4) Input 6 digit factory setting manager code (123456)and press OK.
(5) Input new 6 digit code and press OK.
(6) Input the new 6 digit code again. The screen will show success or failure.
SET CEU ADMIN CODE
(1) Turn on CEU, press ▼or ▲to choose 3.SetAdminCode, and press OK to enter
into submenu.
(2) Press ▼or ▲to choose 2. ModifyCeuPin, press OK to modify CEU pin.
(3) Input 6 digit code, and press OK. Please make sure the CEU pin is the same as
the safe admin code.
OPEN SAFE
(1) Connect CEU with safe using Micro USB Cable.
(2) Choose 4. OpenSafe and press OK. The safe door will open.

17
SECTION 02
SET LAMP
The LED lamp will automatically turn on when the safe door is opened. To dissable
or enable the LED lamp follow the procedure below;
(1) Connect CEU with safe using Micro USB Cable. After the CEU starts work, press
▼or ▲to choose 5.SetLamp, and press OK.
(2) Follow the above to reverse the setting.
SET COMMUNICATION MODE
(1) Connect CEU with safe using Micro USB Cable. After CEU turns on, press ▼or
▲to choose 7.CommMode, and press OK to enter into submenu.
(2) Choose the desired communication mode, and press OK (modes explained
below).
IO-A is for communication between the CEU and the safe.
IO-B is not used on this safe.
PC is for communication between the CEU and a computer.
COMMUNICATION WITH PC
IMPORTANT: Digital Safe Software and Drivers must be
downloaded and installed from
https://www.corbyofwindsor.com/software/hotel-safe-softwar
e.zip for the CEU to be able to communicate with a PC.
READING DATA
(1) Go to https://www.corbyofwindsor.com/software/hotel-safe-software.zip
The hotel safe software will automatically begin downloading.
(2) The following warning may appear;
If so, click on the arrow and select Keep.
(3) Click on the download file to open.

18
SECTION 02
(4) Open the folder Hotel Safe.
(5) Double click on Driver.exe.
(6) Click Install.
(7) Once intallation is complete click OK.

19
SECTION 02
(8) On the CEU Select CommMode PC. The CEU will now be able to
communicate with the PC.
(9) Plug the CEU into the PC using the USB to USB cable.
(10) Double click on HotelSafe.exe. The software will then open.
(11) Ensure the CEU is plugged into the PC and the communication mode is set
to PC. Select Yes to search for the CEU.
SAVE RECORDS
(1) Follow Reading Data stages 1-14 (pages 6-8).
(2) Select Save As. The data will be saved as a .csv file which can be opened in
Microsoft Excel.
PRINT RECORDS
(1) Follow Reading Data stages 1-14 (pages 6-8).
(2) Select Print.Now follow the instructions on the print dialogue.
(12) Select OK.(14) A message will show how
many data entries are stored.
Select Yes to download the data.
(13) Select Read.

20
SECTION 03
www.firedupcorporation.com
Fired Up Corporation Ltd
Fired Up Buildings
HD1 3LF, UK
Fired Up Corporation
(Ireland) Ltd
71, D02 P593, Dublin
GUARANTEE
For your convenience, you are not required to complete a form and return it to
us in order to validate your guarantee. However, please ensure that you retain
your receipt which will act as both proof of purchase and a guarantee
validation document. We recommend that you attach your receipt to this
documentation.
Your product carries a 12 month guarantee from the date that the original
purchaser receives it. If your product fails to operate to its specification due to
faulty workmanship or materials during the guarantee period, we will either repair
or replace the product. We will use our discretion to determine whether to offer
a repair or provide a replacement. The product will not be covered by the
guarantee if it has been misused, transformed, modified or altered in any way.
If your product fails within the guarantee period, please ensure that you have all
necessary documentation available including proof or purchase (receipt or
invoice with serial number, location and date of purchase) in addition to all
original undamaged packaging and leaflets etc. It is strongly recommended
that you inspect your product carefully before it is used or installed. For full
details of your product you should refer to the instruction manual which
accompanies the product. You are strongly advised to read this manual
carefully in its entirety and to retain it for future reference.
This product guarantee does not affect your statutory rights.
AFFIX RECEIPT OR PROOF
OF PURCHASE HERE
