Cord DJ-U Pro User manual

Professional Direct Drive Turntable
with USB Recording
DJ-U Pro
Users Guide
TM

1
Thank you for purchasing the CORD™ DJ-U Pro, Direct Drive USB Recording Turntable. The DJ-U Pro is
just one of the many products in our range embracing our philosophy of ‘extraordinary audio visual gear.’
This product has been designed and engineered to give you many years of enjoyment. Please ensure
you carefully read this manual to gain the maximum performance and safety from your purchase.
We suggest you keep your original proof of purchase receipt, this manual and the original packaging for
future reference, in case you need to move your product, or in the unlikely event that you need to return
the product for service.
Product updates, technical info, warranty and service centre details are available on our web site at
www.cord-av.com.au
Introducon
*Design and specicaons contained within this manual are subject to change without noce.
TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE THE FRONT OR BACK COVER.
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
To prevent electric shock, do not use the polarized AC power plug with an extension
cord, receptacle or other outlet unless the blades can be fully inserted to prevent
blade exposure and the potenal risk of electric shock.
CONFORMS TO AUSTRALIAN AND NEW ZEALAND CERTIFICATION STANDARDS
AS/NZS: 60065
ELECTRICAL SAFETY PRODUCT
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN

Important Safety Messages
Before you power up your new CORD™ product, to ensure safe and ecient
operaon please take the me to read the following:
• Keep these instrucons in a safe place for future reference.
• Pay aenon to all warnings as these are important to ensure your safety and the opmum
operaon of this product.
• Always use this product in accordance with the instrucons.
• Do not use this product in or near water or in direct sunlight.
• Do not place items full of water on or near this product.
• Do not expose this product to rain or moisture of any kind.
• Do not use near any cooking, heang, cooling or venlaon appliances.
• Do not block any of the venlaon openings on this product.
• Turn this appliance o at the mains power switch during mes of electrical storms or when the
product will not be used for long periods of me.
• Only use the power cable and plug supplied with this product.
• Please consult a qualied electrician if the plug does not t your power outlet.
• To ensure your safety, protect the power plug and cable from being walked on, cut, pinched,
twisted or otherwise compromised.
• No user serviceable parts are used in this product. Refer all servicing to qualied and authorised
service personnel.
• If the product has been damaged in any way - for example if the power cable or plug is damaged,
liquid has been spilled or objects have fallen inside the product, the product has been exposed
to rain or moisture, does not operate normally or it has been dropped please refer the product
to your nearest authorised service centre which can be found on our website at
www.cord-av.com.au
2

Precauons
SAFETY PRECAUTIONS:
Power sources:
This product should be operated only from the type of power source indicated on the rear panel rang
label. If you are not sure of the type of power supply to your home, consult your product dealer or local
Power Company.
Venlaon holes:
If objects are placed on top of this unit, the heat generated inside may not be able to dissipate properly.
This will cause the internal temperature to rise and will adversely aect the performance of the product.
Remember that a great deal of heat can be generated when this product is used for long periods of me.
Installaon Locaon:
Do not install the unit in any of the following locaons as this may result in a deterioraon in perfor-
mance or malfuncon:
• Locaons exposed to direct sunlight or near objects radiang heat such as heang appliances.
• Locaons exposed to moisture or humidity.
• The stylus cartridge is very sensive and may pick up slight sound pressure or vibraons from your
loudspeakers which can travel along the oor or through the air resulng in feedback or howling
sound. Find a locaon which is very stable and vibraon free to reduce interference.
• The feet on the base of the unit funcon for both dampening and height adjustment. Adjust the feet
to stabilize the main body securely and horizontally level.
Operang Temperature:
This unit may not perform at its best in an extremely hot or cold environment. The opmum
ambient temperature range of operaon is between 5°C ~ 35°C.
GENERAL PRECAUTIONS:
• Always clean the stylus both before and aer playing a record with a so brush designed specically
for cleaning stylus. Also remember to clean the record with a suitable brush on both sides before
and aer each use.
• Be careful not to make the turntable vibrate while a record is playing as this can result in damage to
the stylus and the record.
• When changing over the headshell, clamp the tone arm to the arm rest so that the tone arm sha is
not strained in any way.
• Place only one record at a me on the plaer. If two or more records are stacked on the plaer, the
stylus will not make proper contact with the grooves, and this will impair the quality of audio repro-
ducon and cause damage to both the stylus and the record.
• Volale liquids must not be used to clean any part of this unit, such as solvents, alcohol, paint thin-
ners, etc. The use of such liquids may remove or damage the painted nish. Please avoid.
3

Setup & Assembly
Some assembly is required before you can begin to use your new unit. Please follow the assembly in-
strucons below before aempng to use your turntable.
Before you begin assembly be sure that all parts and accessories have arrived intact. Please unpack all
parts and use the check list below to idenfy parts and accessories:
• Instrucon Manual
• Headshell / Cartridge / Stylus Assembly
• RCA Cable
• AC Power Cable (Fixed)
• USB Cable
• Plaer
• Reversible Slipmat
• Counterweight
• 45-RPM Adaptor
• Acrylic Dust Cover / Lid
NOTES:
• Do not connect the AC power plug before assembly has been completed.
• Before turning the power on make sure once again all the connecons and power voltage sengs
are correct. Always turn o the power when connecng or disconnecng any cables or accessories.
TURNTABLE ASSEMBLY:
1. Removing From Carton:
Carefully remove the main unit with the packing material intact from the carton. Remove the packing
material once the unit has been removed from the carton.
IMPORTANT NOTE: Be sure to locate all of the accessories packaged within the polystyrene inner pack-
ing materials before discarding anything.
2. 45 Adapter:
Locate and remove the 45-rpm adapter from the packing material and place it in the 45 adapter cutout
on the top of the main unit as per the Parts Idencaon diagram on Page 6.
3. Turntable Plaer:
Remove the turntable plaer from the packing material and gently insert the plaer into the centre
spindle on the base of the turntable unit.
4. Slipmat:
Remove the black felt slipmat from the packaging and place it over the centre spindle and onto the plat-
ter.
5. Counterweight:
Slide the counterweight onto the rear sha of the tonearm. Turn the counterweight gently in a clock-
wise direcon (looking from the rear) and it will screw onto the rear sha of the tonearm.
TONEARM ASSEMBLY COUNTERWEIGHT
4

Setup & Assembly Cont’d
7. Headshell:
Make sure to leave the clear plasc pro-
tecve stylus cover in place.
Gently push the round connector end of
the Headshell into the front end of the
Tonearm making sure to align the locang
pin at the 12 O’clock posion.
HEADSHELL
HEADSHELL LOCKING NUT
TONEARM ASSEMBLY
6. Dust Cover:
Install the dust cover into the hinge pockets of the upper rear chassis of the main unit. Once properly
inserted, the tabs will securely click into place.
While holding the headshell, push gently into the front end of the tonearm. Simultaneously turn the
headshell locking nut counter-clockwise to rmly secure the headshell into the tonearm. The headshell
will slowly slide in as the nut turns. Tighten nger ght while carefully holding the headshell steadily
horizontal. *Do not over ghten or use any hand tools for this procedure.
5

Controls & Funcons
Direct Drive USB Turntable DJ-U Pro
TARGET LIGHT
OUTPUT
START / STOP
PITCH CONTROL
±10%
DIRECT DRIVE
USB TURNTABLE
SYSTEM
SPEED
33 45
-10
8
6
4
2
0
2
4
6
8
+10
USB
PHONO LINE
RL
50Hz
60Hz
33
45
33
45
21
1
2
3
4
5
6
8 9 10 11 12 13
14
15
16
17
19
20
18
22 23 24
7
1. 45-RPM Adapter:
This adapter allows you to play standard 7” 45-RPM EP vinyl records with large center holes.
2. Strobe Indicators:
The outer edge of the plaer is marked with four rows of circular indicators, or dots. These dots are used
to visually detail various stages of pitch or rotaon speed. The indicators are illuminated by the strobe
indicator pilot lamp. Each row should appear to stand sll at the correct pitch level.
3. Center Spindle:
The centre spindle holds both the turntable plaer and vinyl records stable and centered during opera-
on.
4. Strobe Indicator Pilot Lamp:
This lamp is specially designed to pulse a beam of light at the strobe indicators on the turntable plat-
ter to determine rotaon speed. NOTE: The use of uorescent lighng directly above the turntable can
defeat the strobe indicator pilot lamp and adversely aect the indicator accuracy.
5. Power Switch:
This is a rotary power switch. To turn main power on, turn the switch clockwise. To turn main power o,
turn the switch counter-clockwise.
6. Start/Stop:
This buon controls plaer moon. When the unit is turned on the plaer will not automacally begin
to spin. Pressing this buon once will engage the high torque motor and spin the plaer, pressing this
buon again will stop the plaer.
7. Plaer:
The plaer connects directly to the center spindle. The plaer and center spindle holds a vinyl record
perfectly at and centered.
8. Headshell:
The included headshell is used to connect your stylus & catridge to the tone arm.
6

9. Target Light:
The Target Light is used to assist in cueing up the stylus more accurately in a dark environment.
10. Headshell Locking Nut:
The locking nut will securely hold the headshell to the tonearm.
11. S-Shaped Tone Arm:
The tonearm is the mechanism that holds the headshell and stylus allowing it to track across a record.
12. 33⅓ RPM Speed Selector:
Engaging this buon will rotate the plaer at 33⅓ RPM. A red LED will glow when this funcon is acvated.
13. 45 RPM Speed Selector:
Engaging this buon will rotate the plaer at 45 RPM. A red LED will glow when this funcon is acvated.
14. Pitch Adjust Slider:
This slider is used to adjust the playback pitch or plaer speed. This can be adjusted from minus 10% up to
plus 10%.
15. Tonearm Lever:
This lever is used to safely elevate the tone arm above, or to lower onto a record without endangering the
record surface.
16. Tonearm Rest and Clamp:
Safely holds the tonearm in a xed posion during periods of non-use and transportaon.
17. An-Skate Control:
Compensates for inward tracking forces when the stylus nears the centre of the record by applying an out-
ward force to the tonearm and stylus, which prevents the stylus skipping across the record.
18. Counterweight Scale:
This scale is used to properly balance the tonearm. NOTE: The counterweight scale must face toward the
user.
19. Counterweight:
The counterweight balances the tone arm and adjusts the stylus pressure.
20. Spare Stylus Holder:
This cutout has been designed to safely store a spare stylus & headshell assembly.
21. Dust Cover Hinges:
Hinges connect the dust cover to the main chassis, with a hold-up funcon to keep the dust cover open while
using the controls.
22. RCA Output Jacks:
These jacks send a low voltage Phono level output signal or high voltage Line level output signal to an ampli-
er, receiver or mixers Phono or Line input jacks.
23. Phono/Line Switch:
This switch is used to change the RCA audio output mode between Phono output or Line output.
24. USB Socket:
By connecng the Turntable to your computer via the USB cable (maximum 3.0m length). You can record
your vinyl to your hard disk using the free AUDACITY recording soware. You can download this free so-
ware at: hp://www.audacity.sourceforge.net/
*Instrucons for the use of this soware is also available from the Audacity website.
Controls & Funcons Cont’d
7

Connecons
TURNTABLE CONNECTIONS:
Before connecng the unit it is advised that you also consult your current equipments instrucon manu-
als to ensure product compability and to ensure proper use.
IMPORTANT: Be sure to turn o the equipment before you make changes to any connecons.
1. Phono / Line Switch:
This unit has the ability to output either a PHONO signal or a LINE signal via the RCA output on the rear
panel of the unit. The voltage and Impedance levels of the PHONO output and LINE output are very dif-
ferent. It is therefore extremely important to set this switch correctly.
If you connect this unit to a PHONO INPUT on your Receiver, Amplier or Mixer etc: Set the PHONO/
LINE Switch to ‘PHONO’.
If you are connecng this unit to a LINE INPUT on your Receiver, Amplier, Mixer, etc: Set the PHONO/
LINE Switch to ‘LINE’.
2. RCA Audio Cable Connecons:
Carefully connect the RCA cables from this turntable to either the PHONO or LINE input of your Ampli-
er, Receiver or Mixer as follows:
8
0
4
2
1
3
A
N
T
I
-
S
K
A
T
E
PC / MAC
0
4
2
1
3
A
N
T
I
-
S
K
A
T
E
Set the PHONO/LINE
Switch to ’LINE’
Set the PHONO/LINE
Switch to ’PHONO’
USB Cable
Receiver / Amplifier
LINE
GND
USB Cable to Computer

Connecons Cont’d
*Important Notes on Phono vs. Line Inputs & Outputs:
It is not suitable to use the PHONO output of this turntable with a LINE Input on your Amplier or
Receiver. If you do connect this unit to a LINE INPUT when the switch is set to the PHONO posion, the
resulng playback will be very low and almost inaudible.
It is even more important that you do not use the LINE output of this turntable with a PHONO Input on
ANY Amplier, Receiver, etc. If you do connect this unit to a Phono input when the switch is set to the
LINE posion, the resulng playback will be extremely loud and distorted and may easily cause serious
damage to your equipment, including your loudspeakers.
3. USB Cable Connecon:
Connect the USB output on the Turntable to any available USB input on your PC or Mac Computer. This
will enable you to record from your vinyl to an MP3 digital audio le using the free Audacity soware.
4. Power Cable Connecon:
Plug the mains power cable into your homes 240V mains power outlet and switch ON.
Adjusng the Tonearm & Stylus
TONEARM BALANCE ADJUSTMENT:
1. Set the ANTI-SKATE dial to ‘0’ posion.
2. Remove the Stylus cover.
3. Release the arm rest clamp and set the cueing lever to the up posion to li the tone arm up and o
the arm rest.
4. Move the tonearm over to the space between the arm rest and the plaer, taking care not to dam-
age the stylus.
5. Set the cueing lever to the down posion.
6. Support the headshell’s nger-li with one nger and aain level balance by turning the counter-
weight either clockwise or counter-clockwise. ‘Level balance’ means when the tonearm is parallel
to the plaer, and the tonearm therefore sits sll half way between the full up posion and the full
down posion of the tonearm movement range. The tonearm should not lt either toward the coun-
terweight side or the headshell side. Once the tonearm is hovering perfectly horizontal, the stylus
tracking weight is now set at zero.
7. Return the tonearm to the arm rest and fasten the arm rest clamp.
8. As the tracking force is zero when the tone arm is balanced level, turn only the tracking-force scale
ring in front of the counter-weight, and set the ‘0’ posion on the scale to the index line on the top
of the counterweight sha. Be sure to hold the counterweight with the other hand so that it does
not turn together with the scale ring.
9. Now turning the counterweight and scale ring together, set the correct tracking force opposite the
index line on the counterweight sha. The tracking-force scale ring has 0.1 gram steps and one full
turn of the counterweight will yield a tracking force of 4.0 grams.
9
