Cordex UT5000 Quick guide

INSTRUCTIONS
FOR SAFE
OPERATIONS
UT5000
INTRINSICALLY
SAFE ULTRASONIC
THICKNESS GAUGE
RUGGED AUTHORITY www.cord-ex.com

CONTENTS READ THIS FIRST
Read This First
Safety Information
Faults and Damage
Safety Regulations
Batteries
Calibration
3
3
3
3
3
3
Exchanging Batteries 4
Operational Cautions
Maintenance
5
5
Certification
EC Declaration of Conformity
ATEX Certificate
IECEx Certificate
6
7
8
10
The CorDEX UT5000 thickness gauge is a
gauge for measuring the wall thickness of
pipes or tanks.
Read and understand all Warnings and
Cautions before using this product.
Safety Information
This instruction manual contains information
and warnings that must be observed for safe
operation under the conditions described.
Faults and Damage
If there are any grounds for believing the unit
is no longer safe to use, it must be taken out
of service and measures taken to prevent its
further unintentional use. The safety of the unit
may be impaired if, for example:
• External damage to the housing is visible
• The unit has not been stored correctly
• The unit has suffered transport damage
Safety Regulations
When using the UT5000, the appropriate
regulations must be observed to avoid
incorrect operation of the unit.
ATTENTION! Please make sure that the case
is securely fastened when using the unit. The
unit must not be opened in the hazardous
area. Only probes intended for this instrument
must be used.
Batteries
If you change the battery, make sure that the
replacement is suitable for the purpose.
The use of different batteries is strictly
forbidden.
Calibration
Calibration must be carried out by the
manufacturer since the protective circuits
must be checked after calibration for safety
reasons.
RUGGED AUTHORITY
UT5000 – Intrinsically Safe Ultrasonic Thickness Gauge
3

Focus Ring 135˚ Swivel Lens
EXCHANGING
BATTERIES
OPERATIONAL
CAUTIONS
The cautions contained in this section do not
relate specifically to safe use in hazardous
area applications but should be followed
to help prevent damage to the device or
personnel.
• Keep out of reach of children
• The UT5000 is a precision instruction. Do not
drop it, strike it or use excessive force when
handling
Maintenance
For safety critical maintenance, please refer
to EN60079:17
Batteries are inserted into the compartment in
the bottom side of the instrument.
To change the battery:
• Half turn the screws on the compartment
cover and then carfully life the cover.
• Make sure that the rubber sealing of the
cover will not be damaged or removed from
the guiding notch.
• Insert the new battery.
WARNING! Ensure correct orientation
according to the sketch on the battery cover
to avoid internal damage to the tester.
When exchanging batteries, the memorized
parameter and calibration values are deleted.
Therefore you need to execute a new
calibration and enter the relevant parameters
again after exchange of the batteries.
After battery replacement, switch the
instrument on/off twice to reset it to a
predefined operating status. All previous
settings will be restored to the tester after
connecting to the CorDEX CONNECT™
software, or the UT5000 Mini app.
ATTENTION! Only use a 3.6V Lithium Thionyl
Chloride Cell. The use of different batteries is
strictly forbidden.
RUGGED AUTHORITY
UT5000 – Intrinsically Safe Ultrasonic Thickness Gauge
5

CERTIFICATION
Model UT5000
ATEX Certificate No. Baseefa 11ATEX0114
IECEx Certificate No. IECEx BAS 11.0094
Certificate Type
II 2G Ex ib IIC T4 Gb
USB Terminal parameter Um253V
Ambient Temperature Tamb -10 to +50°C
Power Supply 1x CorDEX Instruments Battery
Part Number: CDX5000-327
EC DECLARATION
OF CONFORMITY
Better:Better_Work:CorDEX:03_CorDEX_Products:CorDEX_Products_UT5000:CorDEX_Products_UT5000_ECDeclaration:EC
Declaration of Conformity (UT5000) Rev 2.docx
Cordex Instruments Limited
1 Owens Road
Skippers Lane Industrial
Estate
Middlesbrough
TS6 6HE
Declaration No. SO/8 Rev 2
EC Declaration of Conformity
in accordance with EEC ATEX Directive 94/9/EC
We,
CorDEX Instruments Ltd.
Hereby declare that the products described below
Product: Ultrasonic Thickness Gauge
Model:
UT5000
are in conformity with the essential health and safety requirements of Council Directive
94/9/EC relating to equipment intended for use in potentially explosive atmospheres
(ATEX Directive) Ex II 2GD, Ex ib IIC T4 Gb Ex ibD IIIB T200°C Db Tamb (-10°C to
+50°C) equipment, by the application of the following Standards:-
EN 60079-0:2009 Explosive atmospheres - Equipment: General requirements
EN 60079-11:2007 Explosive atmospheres. Equipment protection by intrinsic safety “i”
EN 61241-11:2005
Electrical apparatus for use in the presence of combustible dust.
Protection by intrinsic safety "iD"
as certified by Notified Body Number 1180 Baseefa Ltd, UK by EC-Type Examination
Certificate: Baseefa11ATEX0114 and are subject to the procedure set out in Annex VII of
Directive 94/9/EC and these procedures are in conformity with the requirements of EN
13980:2002 under the supervision of Notified Body Number 0518, SIRA Certification
Service Rake Lane, Eccleston, Chester, CH4 9JN.
It is ensured through internal measures that the products conform at all times to the
requirements of the current EEC Directives and relevant standards.
Signature: Authorised Person
Position: Director on behalf of CorDEX Instruments Ltd
Date: 07/10/2014
Product Serial number
RUGGED AUTHORITY
UT5000 – Intrinsically Safe Ultrasonic Thickness Gauge
7

ATEX
CERTIFICATION
ATEX
CERTIFICATION
RUGGED AUTHORITY
UT5000 – Intrinsically Safe Ultrasonic Thickness Gauge
9

IECEx
CERTIFICATION
IECEx
CERTIFICATION
RUGGED AUTHORITY
UT5000 – Intrinsically Safe Ultrasonic Thickness Gauge
11

IECEx
CERTIFICATION
IECEx
CERTIFICATION
RUGGED AUTHORITY
UT5000 – Intrinsically Safe Ultrasonic Thickness Gauge
13

Copyright © 2014, CorDEX Instruments Limited.
All other brand and product names are
trademarks of CorDEX Instruments Limited. Ref. ID 2310, Rev. A
