Corksport X-corder sz-1000 User manual

1

Drive Recorder SZ-1000

User's Manual

Version 1.001

[The information contained in this manual was correct at the time of publication. However, as our engineers are always

updating and improving our products & software, your device’s hardware & software may have a slightly different

appearance or modified functionality than presented in this manual.]

CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT

2

- TABLE OF CONTENTS -

• What’s in the Box · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3

• Description & Function · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4

• Key Features · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 5

• Installation Precautions · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 6

• Installation Procedure · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 7

• Installation Warnings · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 8

• LED Indicator and Button · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 9

• Product Upgrade · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 10

• PC Viewer: Setup · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 11

• PC Viewer: Main Screen · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 12

• PC Viewer: Information · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 12

• PC Viewer: Add File List · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 13

• PC Viewer: Delete File List · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 14

• PC Viewer: Data and File Download · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 14

• PC Viewer: Display Video Image · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 15

• PC Viewer: Speed & Acceleration Information · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 15

• PC Viewer: GPS Information · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 15

• PC Viewer: Driving History Mode · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 16

• PC Viewer: Map Information · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 16

• PC Viewer: Password Setup and Release · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 17

• PC Viewer: Setup Directly Folder · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 18

• PC Viewer: Setup User’s Information & Option · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 19

• PC Viewer: Event Log · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 20

• Product Specification · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 21

• Troubleshooting · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 22

• Limited Warranty · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 23

CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT

• What’s in the Box

※Before getting started, please check to see that your X-Corder package includes the following

items.

• X-Corder Unit

• SD Card

• 12 Volt Vehicle Power Cable

• Adhesive Tape

• Mount Clip

• User's Manual

If you are missing any parts, please contact your dealer immediately.

X-Corder Unit SD Card (2GB) 12V Vehicle Power

Cable

Mount Clip Adhesive Tape User's Manual

3

CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT

• Description & Function

1) Camera Lens: Capture video image.

Note: Please clean the camera lens before using to avoid foreign materials blocking the lens.

2) GPS Receiver: Built in GPS receiver receives real-time GPS satellite data.

3) Hinge button: Control viewing angle of the unit.

4) SD Memory Card Slot: Insert SD memory card into the slot before power on.

5) Power connector: Connect to vehicle 12V power source or other power source.

6) Power LED Indicator: Power on/off indicator.

7) SD Card LED Indicator: SD Card LED will blink while recording data.

8) GPS LED Indicator: GPS LED will light up when receiving GPS satellite data.

9) MUTE LED Indicator: sound recording on/off indicator.

10)Event Recording button: Toggle between full time recording and event recording by pressing

the button.

11)MUTE button: Selectable sound recording on/off.

12)Emergency button: Time lapse image recording. By holding the emergency button, it will

convert into Parking Surveillance Mode on/off.

13)Microphone: Record voice and sound inside and around vehicle.

14)Adhesive plate: Attach the plate to the windshield of vehicle

15)AV-Out: Video output connector to other display device (i.e. in-dash screen or navigation unit).

4

CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT

5

• Key Features

※Recording accident video image

When an accident occurs while driving, the device detects the shock automatically by way of a

3-axis accelerometer, and records the video 15 seconds before and 15 seconds after the event took

place.

※Manually recording video image

When the user press Emergency button, it records video image manually.

※Recording location information

Record & Save the location information, time, and speed by GPS sensor when an accident occurs.

※Recording driving condition information

Built-in 3-axis accelerometer detects and records the severity of a crash as well as acceleration,

braking and cornering gravitational forces.

※Digital Image Tachometer (DIT) Function

Save route, time and speed data together with images while driving. DIT data stored to SD Card

automatically. You can analyze the data on your computer by using the viewer software supplied

with the device.

※Data analysis & Playback of an accident or event

Playback an accident video image, which can show information on the speed, coordinates, gravity,

acceleration and sensor value at the time of the accident happened. Data can be collected from the

viewer program.

CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT

6

• Installation Precautions

※Please read the following content thoroughly before installation.

1. Be sure that all components were included in the packaging.

2. Make sure to power off the vehicle before proceeding with installation.

3. Do not break or damage power cable.

4. Do not install the device in an area that will affect the driver’s eyesight.

5. Make sure installation does not interfere with any other vehicle device or component.

6. Thoroughly clean area where device is to be installed to ensure the device adheres securely.

7. Please use enclosed SD card, power cable and accessories only. We do not guarantee the

compatibility of third party components.

CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT

• Installation Procedure

※The basic mounting location of the product is top or bottom of front windshield of vehicle.

Attach the product on the position where safe driving is not obstructed.

1. Locate the area in which you choose to install the device.

Remove one side of the tape and stick to device.

2. Remove the other side of the adhesive and attach device base to

windshield.

Note: Be sure to attach X-Corder to windshield firmly.

3. Adjust hinge button so the camera angle is to plumb in the surface

of earth.

Note: You may want to adjust the angle based upon personal

preference as well.

4. Insert SD Memory CARD into the device.

5. Connect power cable to power connector of the device.

6. After routing cable in desired location, connect power cable to 12V

power supply.

7

CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT

8

• Installation Warnings

※Please read the following carefully to ensure proper installation and use.

• Do not disassemble, repair or alter the device. This will void the warranty.

• When cleaning the inside of a vehicle, do not spray water directly onto the device. It may cause damage, fire or

electric shock.

• Keep away from chemicals or detergents as they may change the surface of the device or ruin the interior of the

device.

• Avoid excessive impact and do not insert any foreign objects into the device. Severe impact, shock or foreign

materials may cause damage the device.

• When foreign materials block the lens, normal operation is impossible, so always clean the lens before use. Also,

when other objects are placed around camera they may reflect on the window and may be included in the image,

so please do not leave unnecessary objects around the device.

• Excessive road bumps and vibrations may cause the deviceto become misaligned. Simply correct the angle to

the desired position.

• Do not stare at or operate the device while driving.

• Keep the device away from excessive impact, humidity and salt.

• Be aware that the data from an accident under certain impact or acceleration may not be recorded in this device.

(Please refer to the function of black box) In this case, it is possible to record image manually with Emergency

button.

• Be aware that the image and additional data from the device may not be valid in the court of law.

• The time is set by using GPS satellite information.

• This device is designed to connect to an automobile 12 volt source only (DC12V ~24V).

• This device records real time video images onto an SD Card. If your SD card fails, a replacement SD card

may be used.

• This device meets requirements for EMI limits of Europe and USA. However, it may cause harmful

interference to other devices, so please try and locate the device away from other electronic devices as well as

antennas.

transmitted in any form or by any means including hardware and software, for any purpose without the express

prior written permission of manufacturer.

CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT

9

• LED Indicator & Button

1. LED Indicator Content

LED Status Description

OFF Power off or failure

ON Working by power supply or battery

POWER

Blink slowly Indicates Parking Surveillance Mode, synchronized with SD CARD LED

OFF Empty SD Card or recognition error

Blink slowly Indicates Parking Surveillance Mode, synchronized with POWER LED

Blink Data recording

SD CARD

ON Working properly

OFF GPS reception error

Blink Waiting to receive GPS information

GPS

ON Receiving GPS information (valid data)

OFF Mute Off. (Recording sound data)

MUTE ON Mute On. (Not recording sound data)

ALL Blink System error

2. Beep Sound & LED indicator according to operation

Button Operation Status Beep sound LED Indicator

- Power on Booting Beep-Beep-Beep

After all LEDs turn on for 2 sec.

and convert to current situation

mode.

- Upgrade

Upgrade the device through

SD Card Starting Beep~

Finishing Beep~ All LEDs turn on and turn off

sequentially

Press once from

OFF mode Full Time Recording ON

(Start full time recording)

Beep-Beep when event

situation occurs. Beep once

after recording Blinking SD CARD LED

Event Recording

button Press once from

ON mode Full Time Recording OFF

(switch to Event mode)

Beep-Beep when event

situation occurs. Beep once

after recording

SD CARD LED ON

Blinking when event occurs

Press EMERGENCY button Record video image manually Beep-Beep when starting

record. Beep after finishing

record

Blinking SD CARD LED during

recording data

Press EMERGENCY button

for 2sec.

from parking surveillance OFF

mode

Convert to Parking

Surveillance Mode Beep-Beep

(short 2 times) Blinking POWER LED & SD

CARD LED slowly

EMERGENCY

button

Press EMERGENCY button

for 2sec.

from packing surveillance ON

mode

Convert to previous mode Beep-Beep

(short 2 times) Indicate LED according to previous

mode

Press once in MUTE OFF Convert to MUTE ON Beep (shortly once) Turn On MUTE LED

Press once in MUTE ON Convert to MUTE OFF Beep (shortly once) Turn off MUTE LED

Press MUTE button

for 2sec. Convert to Buzzer Sound OFF Beep-Beep -

MUTE button

Press MUTE button

for 2sec. Convert to Buzzer Sound ON Beep-Beep -

CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT

10

• Product Upgrade

※The product may be changed or improved for content without obligation to notify any person or

organization of such changes or improvements.

Visit website or call the service center of dealer or manufacturer for current updates and

supplemental information concerning the use and operation of this device.

※How to upgrade.

1. Connect SD Card to PC.

2. Download update files to SD Card from website of dealer or manufacturer.

3. Insert SD Card to the device and turn on, it will then be automatically upgraded with LED

indicator blinking sequentially.

CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT

• PC Viewer Setup

※Follow these instructions to install PC Viewer program

1. Insert SD Card into the SD Card slot of the device. (The PC Viewer Program and Manual will be

copied to SD Card.)

2. Connect SD Card to computer by SD Card reader.

3. Open the program folder located on the SD Card.

4. Double-click “SZ1000.exe” in the program folder.

5. Click the “Next” button. The installation program will then begin.

6. Choose the folder in which to install Viewer program and then, Click “Install”.

7. Click “Finish” to complete setup program.

11

CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT

• PC Viewer Screen

1. Main screen: Displays video playback.

2. Speed & Acceleration: Displays speed and acceleration information.

3. Map: Displays the location of current playback video image.

4. GPS Information: Displays location information by text.

5. File list screen: Displays the file list being played back.

• PC Viewer Information

1. Click “Information” ( ) button.

2. You can see the PC Viewer Information.

12

CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT

PC Viewer: Add File List

※Adding file list by open file

1. Execute “PC Viewer” after connecting SD Card to computer.

2. Click file open button ( ) and Select files to playback from the SD Card

3. The selected files are listed in the file list screen

4. Double click the file to playback and the video image is shown in the main screen

5. Playback will occur one after the other for all selected files.

※Adding file list by file searching

1. Execute “PC Viewer” after connecting SD Card to computer.

2. Click file search button ( ) and open the file search screen.

3. Select folder or file to search.

4. The searched file will be listed in the file list screen.

5. Find the desired file and Click “OK”.

6. Double click the file to playback and the video image will be shown in the main screen.

7. Files will play back one after another until the selected files have all played.

13

CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT

• PC Viewer: Delete File List

1. Execute “PC Viewer” after connecting SD Card to computer.

2. Select the file to delete and Click the delete ( ) button.

3. To delete all file lists, Click the delete all ( ) button.

• PC Viewer: Data and File Download

1. Download the data or file stored in SD Memory Card to computer.

2. Connect SD Card to computer and click the download button, the following dialogue screen will

be opened.

3. Select the file or data that you want to download and click the “Download” button in the dialogue

screen. Then the selected file will be downloaded to the designated folder.

14

CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT

• PC Viewer: Playback Video Image

1. Double click the file to playback or Click the “Play”( ) button after selecting file

2. Click PAUSE ( ) button for pause

3. Click STOP ( ) button to end playback

4. Click the scroll bar to playback specific time.

5. Click SPEED UP/DOWN( ) button for playback speed

6. Click Volume UP/DOWN( ) button for volume control

7. To secure captured image from video image, Click image capture ( ) button.

The captured image is saved in a designated folder.

8. Click the print screen ( ) button to print image

• PC Viewer: Speed & Acceleration Information

9. Displays vehicle speed.

10. When clicking the speed( ) button, the speed graph is displayed and the icon

changes to the acceleration( ) icon.

• PC Viewer: GPS Information

1. Displays time information( )

2. Displays maximum impulse information( )

3. Displays Latitude( ) & Longitude information( )

15

CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT

• PC Viewer: Driving History Mode

1. Click Driving History Mode button ( ), then the main screen shows you the driving history.

2. Click the open file button ( ) and select the driving history file (*.dat)

3. To see driving route, select the specific area that you want to see, and click the “driving route”

( ) button. You will then be able to see the driving route on the separate pop-up screen.

• PC Viewer: MAP Information

1. Displays the location of current playback video image

2. Click the “+” & “-” buttons to Zoom In or Zoom Out. You can also click the mouse to move to a

specific location on the map.

3. Click the map capture ( ) button to secure map image. The captured map image is saved in the

designated folder (C:\Capture Data).

16

CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT

• PC Viewer: Password Setup and Release

1. Click the password setup ( ) button to create a password to protect from unauthorized use.

2. Select a folder on the SD Card to setup a password.

3. Type in your password and retype in the Confirm Password box. Click Save.

4. Click user setting( )button

5. Select “use” on the file password setting and click the “Save” button.

6.To release the password, select file and Click the password release ( ) button.

17

CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT

• PC Viewer Setting

1. Click the Setting ( ) button.

2. Select the folder to download the SD Card Data.

3. Select the folder to capture screen image.

4. Select the folder to save decrypted video image.

5. Select desired language (Korean / English / Japanese)

6. Select speed display options (mile/hour or km/hour)

7. Setup Mark Route and Display Interval in the Map Display Setup

8. Click "Save" to save current setting.

18

CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT

• PC Viewer: Setup User’s Information & Option

1. Click the settings ( ) button.

2. Type in the driver name

3. Enter the license plate number

4. Setup the impulse level with quick setting or manual setting.

5. Setup the frame rate of video image to be saved.

★Remarks: it can be changed to optimum frame rate according to circumstances when the video

image is being saved.

6. Setup File Encryption “On” & “Off”.

7. Setup Buzzer Sound "On" & "Off"

8. Setup Time Zone.

9. Click the “Save” button to save current setting.

19

CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT

• PC Viewer: Event Log

1. Click the Event Log ( ) button

2. Click the "Search" button and Select the folder where the event file is stored.

3. Veiw the event log.

4. To save event log, click "Save File As" button, then it will be saved as a text file in the designated

folder.

20

CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT CORKSPORT

Corksport X-Corder SZ-1000 User manual

Popular Dashcam manuals by other brands
