Cornell CVC-WD601P User manual

Marketed by:
CORNELL SALES & SERVICE SDN BHD (604369-P)
Lot 11A, Jalan 223, Section 51A,
46100 Petaling Jaya,
Selangor Darul Ehsan, Malaysia.
InfoLine: 1-800-881-770
www.cornell.com.my
3-in-1 Vacuum
Cleaner
User Manual
CVC-WD602S
CVC-WD601P
If a problem occurs always switch off the unit immediately
1. Motor does not operate
• Ensure unit is plugged in correctly and switched on.
2. Suction power is reduced or motor operate but weak suction power
• The maximum level of dust or water collection has reached the limit. Press the ON / OFF button, disconnect
the power cord from the power outlet and empty tank.
• Check and clear any blockages within the system or accessory.
• Ensure the filter is clean and not damaged in any away.
3. Heat from appliance
• Heat generated from appliance is normal.
TROUBLESHOOTING

OPERATING INSTRUCTIONS
DESCRIPTION & GENERAL ASSEMBLY OF WET/DRY VACUUM CLEANER
2 3
ATTENTION
TO ENSURE THE EFFICIENT PERFORMANCE OF
THE MACHINE, CLEAN THE POLYESTER FILTER AFTER EACH USE
THE VACUUM CLEANER IS DESIGNED FOR:
1. Dry vacuum suction of dust.
2. Wet vacuum suction of water based liquids.
3. Blow vacuuming can be useful for dusting out the garage
or workshop.
DRY VACUUMING
• Insert the cloth filter bag in the tank. (Fig. 1)
•Assemble the motor head on tank and lock it
manually. (Fig. 3)
• Connect the flexible hose to the suction inlet. (Fig. 4)
•Connect the wand and the extensions to the other side of
flexible hose. (Fig. 5)
• Select & connect the most suitable accessory. (Fig. 6)
• Connect the plug to power outlet and switch on the
power. (Fig. 7)
• Uses of the crevice tool. (Fig. 8)
•Uses of the Ellipse Brush. (Fig. 9)
•Uses of the Squeegee Nozzle for floor cleaning. (Fig. 10)
• Uses of the Master Nozzle for carpet tool. (Fig. 11)
WET VACUUMING
• Remove the cloth filter bag. (Fig. 2)
•Assemble the motor head on tank and lock it
manually. (Fig. 3)
• Connect the flexible hose to the suction inlet. (Fig. 4)
•Connect the wand and the extensions to the other side of
the flexible hose. (Fig. 5)
•Connect the Squeegee Nozzle. (Fig. 6)
•Connect the plug to power outlet and switch on the
power. (Fig. 7)
• Uses of the Squeegee Nozzle. (Fig. 12)
BLOW VACUUMING
•Empty and clean the tank.
•Fit the hose directly into the exhaust opening. (Fig.13)
PLEASE READ CAREFULLY BEFORE USE
1. This appliance is strictly for indoor use only and not for industrial use.
2. Ensure the voltage at the power outlet corresponds to the voltage indicated on the rating label.
3. If the power cord is damaged, switch off immediately and have it replaced by the manufacturer or authorized
service technician.
4. Never suck up asbestos or asbestos dust or anything that is burning or smouldering.
5. Never suck up water or any other liquid. Never suck up flammable substances and do not suck up ashes
unless they are cold. Do not use the appliance in rooms with explosive vapours (petrol, thinners, solvents).
6. Never suck up inflammable or corrosive liquids such as petrol or other volatile substances.
7. Avoid sucking up sharp objects or objects that can obstruct the hose.
8. Always use the vacuum cleaner horizontally positioned. Never operate it on a slanted surface or hang it
upside down. Otherwise the water may enter the motor to damage it.
9. Do not pull, lift or carry by the power cord. Do not use the cord as handle. Avoid closing the door on the cord
or yank the cord around or against sharp edges or corners.
10. Do not use the appliance without the filter in place.
11. Never leave refuse in the dust box for long periods of time.
12. Do not handle the plug, switch or the appliance with wet hands.
13. Always remove the plug from the power socket in case of any malfunction, and after use and before cleaning.
14. Do not position the appliance or power cord on or near hot surfaces or near open flames.
15. Keep the appliance out of children’s reach. This appliance should only be used by adults.
A. Motor head
B. Switch
C. Float, prevents water from entering
motor when is tank full.
D. Polyester filter, removable for liquid
suction.
E. Hand lock
F. Suction inlet.
G. Tank
H. Flexible hose
I. Extension Wands
J. Ellipse Brush
K. Crevice tool
L. Squeegee Nozzle (for wet)
M. Master Nozzle (for dry)
A
B
C
D
E
F
G
I
I
J
K
L
M
H
