CORNING PC-200 Series User manual

Corning®
PC-200/210/220 Series
Analog Hot Plates
and Stirrers
Instruction Manual
Catalog Numbers:
Hot Plates: Model PC-200
6795-200
6796-200
6797-200
Stirrers: Model PC-210
6795-210
6796-210
6797-210
Stirrer/Hot Plates: Model PC-220
6795-220
6796-220
6797-220

1
Table of Contents
1.0 International Symbols ....................................................2
2.0 Product Description ......................................................2
3.0 Operating Conditions .....................................................3
4.0 Warnings ................................................................ 3
5.0 Heating Operation and Controls........................................... 4
6.0 Stirring Operation and Controls ........................................... 4
7.0 Inspection Procedure ..................................................... 5
8.0 Preventative Maintenance ................................................ 5
9.0 Technical Specifications...................................................6
10.0 Limited Warranty .........................................................7
11.0 Equipment Disposal ......................................................8

2
1.0 International Symbols
The following chart is an illustrated glossary of the symbols that may be used in this
manual or on the product.
Power – Indicates unit is plugged into power supply
Hot top – Top plate is too hot to touch (>60°C)
Heat – Indicates heat knob
Stir – Indicates stir knob
Indicates disposal instruction. DO NOT throw this unit into a municipal trash
bin when this unit has reached the end of its lifetime. To protect the global
environment and minimize pollution, please recycle this unit.
2.0 Product Description
Corning® Hot Plates and Stirrers have been a laboratory standard for over 50 years. Our
products have been engineered with customer input to be reliable, precise, safe, and easy to
use. This product features:
◗ A microprocessor that provides linear control for both heating and stirring to ensure
consistent performance.
◗ Enclosed control electronics that protect sensitive components from harsh environments
and reduce maintenance time and costs.
◗ The Pyroceram® top plate is easy to clean and highly resistant to scratches, corrosion, and
chemical attack. It is also flatter to provide faster, more uniform heating, and is whiter to
provide better contrast during applications which require monitoring of color changes.
◗ Rigorous testing standards for electrical safety, EMI (Electro Magnetic Interference),
and regulatory approvals. Corning Hot Plates and Stirrers meet UL (USA), CSA (Canada),
IEC61010 CE (Europe), GS (Germany), FCC regulations and others where appropriate.
◗ International symbols for power, heat, stir, and hot top.

3
3.0 Operating Conditions
Corning® PC-200 series Hot Plates and Stirrers are designed to be safe under the
following conditions:
◗ Indoor use
◗ Altitude up to 2,000 meters
◗ Temperature of 0°C to 40°C
◗ Maximum relative humidity 80% for temperatures up to 31°C
◗ Main supply voltage fluctuations not to exceed ±10% of the nominal voltage
◗ Installation Category II
◗ Pollution Degree 2
◗ Position at least 30 cm from walls, 1.2 meters from ceilings, and 30 cm between hot plates
if using multiple units.
4.0 Warnings
◗ Always wear safety glasses and other appropriate protection when operating this
equipment.
◗ Keep the Pyroceram® top plate clean. Use non-abrasive cleaner. Spills may damage the
top and lead to thermal failure. Unplug the unit and remove spills promptly. Should the
top plate become damaged by etching, scratching, or chipping, replace the top plate
and element assembly immediately using the manufacturer’s complete assembly and
instructions.
◗ Do not immerse the unit for cleaning.
◗ Do not heat or stir volatile materials.
◗ Do not use foil, fiberglass pads, or other insulating materials on the top of the unit when
heating. Heat settings above 5 are not recommended for sand bath applications.
◗ Do not modify or substitute the earthed power plug. Use only power cords supplied by the
manufacturer. Use only properly earthed outlets to avoid shock hazard.
◗ Do not modify the unit electrically or mechanically as personal injury or product damage
may occur.
◗ Do not use ring stand to support unit on lattice or for support of heavy loads. Gross
weight on top of any unit should not exceed 11 kg.
◗ Not explosion- or spark-proof.
◗ Not for industrial use. These units are designed for use in laboratory environments by
persons knowledgeable in safe laboratory practices.
◗ Do not use equipment in a manner other than stated in the Operating Conditions section
since the protection provided by the equipment may be impaired.
◗ Do not use metal containers or large heavy wall glass containers on top of the unit
when heating.

4
5.0 Heating Operation and Controls
◗ The microprocessor ensures minimum heat-up times for samples by supplying maximum
power to the heating element until the set point is reached.
◗ Top quality insulation keeps the heat on the top, away from controls and the lab bench,
saving more energy than competitive units.
◗ The Hot Top Indicator light warns that the top plate is too hot to touch (>60°C).
◗ The Temperature sensor provides power cutoff in abnormal situations by limiting top plate
temperature to 550°C.
Heating Operation
Fill the vessel with solution. For stirrers and stirrer/hot plates only, place the provided stir
bar into the vessel, and set the vessel in the center of the top plate. Plug the line cord into
an earthed power outlet – the green power indicator light will illuminate. Turn the heat
knob clockwise to the desired setting. The amber heat light to the left of the heat knob will
illuminate. Hot top indicator light will illuminate and remain on when temperature of the
top plate reaches approximately 60°C.
Dial Setting Approx. Temp.
0 OFF
1 - 2 25°C
3 90°C
4 170°C
5 230°C
6 300°C
7 410°C
8 460°C
9 - 10 480°C
NOTE: Temperatures listed above are typical with no top load.
Actual temperatures will be governed by dial setting and top load.
6.0 Stirring Operation and Controls
◗ Exclusive closed-loop stirring control monitors and regulates the stirring speed – sensing
your requirements whether you’re stirring an aqueous, viscous, or semi-solid solution.
◗ Stirring control provides a “cushioned” reaction to large increases in speed to minimize
decoupling.
Stirring Operation
Fill the vessel with solution. For stirrers and stirrer/hot plates only, place the provided stir
bar into the vessel, and set the vessel in the center of the top plate. Plug the line cord into
an earthed power outlet. The green power indicator light will illuminate. Turn the stir
knob clockwise to the desired setting. The amber stir light to the left of the stir knob will
illuminate.

5
Approx.
Dial Setting Stir Range (rpm)
0 OFF
1 - 2 60 (1- to 2-second delay at low setting)
3 100
4 155
5 250
6 380
7 550
8 870
9 - 10 1,100
NOTE: Revolutions per minute (rpm) listed are typical and were taken with a top load of
400 mL of water in a 600 mL PYREX® beaker at room temperature. Actual speeds will be
governed by dial setting and top load.
7.0 Inspection Procedure
◗ Look for etching, scratching, or chipping on the top plate. If any of these conditions are
present, replace the complete top plate element assembly immediately.*
◗ Check if the power cord is damaged. If the cord is damaged, replace immediately.*
8.0 Preventative Maintenance
◗ Disconnect power by unplugging the unit before performing any maintenance or service.*
◗ Always use an earthed outlet.
◗ Keep the Pyroceram® top plate clean. Unplug the unit, and use non-abrasive cleaner.
◗ Clean spills promptly. Unplug the unit, and use a non-abrasive cleaner.
◗ Do not immerse the unit for cleaning.
*Service should always be performed by a qualified technician using Corning parts and instructions.
Please contact a Corning authorized repair facility for service and repair.

6
9.0 Technical Specifications
Model No. PC-200, PC-210, PC-220
Top Style Ceramic
Top Size 4 x 5 in.
(10.2 x 12.7 cm)
Dimensions (H x W x D) 4.5 x 5.8 x 7.3 in.
(11.43 x 14.7 x 18.5 cm)
Max. Temp. Stir Range Weight
Model No. Cat. No. Power Range (rpm) (kg)
PC-200 6795-200 120V/60Hz/253W/2.1A 25°C to 480°C – 1.8
PC-200 6796-200 230V/50Hz/253W/1.1A 25°C to 480°C – 1.8
PC-200 6797-200 100V/60Hz/253W/2.1A 25°C to 480°C – 1.8
PC-210 6795-210 120V/60Hz/33W/0.3A – 60 to 1,100 2.0
PC-210 6796-210 230V/50Hz/33W/0.17A – 60 to 1,100 2.0
PC-210 6797-210 100V/60Hz/30W/0.3A – 60 to 1,100 2.0
PC-220 6795-220 120V/60Hz/313W/2.4A 25°C to 480°C 60 to 1,100 2.3
PC-220 6796-220 230V/50Hz/313W/1.3A 25°C to 480°C 60 to 1,100 2.3
PC-220 6797-220 100V/60Hz/280W/2.8A 25°C to 480°C 60 to 1,100 2.3

7
10.0 Limited Warranty
Corning Incorporated (Corning) warrants that this product will be free from defects in
material and workmanship for a period of two (2) years from date of purchase. CORNING
DISCLAIMS ALL OTHER WARRANTIES WHETHER EXPRESSED OR IMPLIED, INCLUDING ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR OF FITNESS FOR A PARTICULAR PURPOSE.
Corning’s sole obligation shall be to repair or replace, at its option, any product or part
thereof that proves defective in material or workmanship within the warranty period,
provided the purchaser notifies Corning of any such defect. Corning is not liable for any
incidental or consequential damages, commercial loss or any other damages from the use of
this product.
This warranty is valid only if the product is used for its intended purpose and within the
guidelines specified in the supplied instruction manual. This warranty does not cover
damage caused by accident, neglect, misuse, improper service, natural forces, or other
causes not arising from defects in original material or workmanship. This warranty does not
cover motor brushes, fuses, light bulbs, batteries, or damage to paint or finish. Claims for
transit damage should be filed with the transportation carrier.
In the event this product fails within the specified period of time because of a defect in
material or workmanship, contact Corning’s Customer Service at 800.492.1110. Outside the
United States, call +1.978.442.2200 or contact your local Corning sales office.
Corning’s Customer Service team will help arrange local service where available, coordinate
a return authorization number, or provide a return authorization number and shipping
instructions. Products received without proper authorization will be returned. All items
returned for service should be sent postage prepaid in the original packaging or other
suitable carton, padded to avoid damage. Corning will not be responsible for damage
incurred by improper packaging. Corning may elect for onsite service for larger equipment.
Some states do not allow limitation on the length of implied warranties or the exclusion
or limitation of incidental or consequential damages. This warranty gives you specific legal
rights. You may have other rights which vary from state to state.
No individual may accept for, or on behalf of Corning, any other obligation of liability, or
extend the period of this warranty.
For your reference, make a note of the model and serial number, date of purchase, and
supplier here.
Model No. ____________________ Serial No. _______________________________
Date Purchased ___________________________________________________________
Supplier _________________________________________________________________

8
11.0 Equipment Disposal
According to Directive 2012/19/EU of the European Parliament and Council
of 4th July 2012 on waste and electronic equipment (WEEE) as amended,
Corning® Analog Hot Plates, Stirrers, and Stirrer/Hot Plates are marked
with the crossed-out wheeled bin and must not be disposed of with
domestic waste.
Consequently, the buyer shall follow the instructions for reuse and recycling
of waste electronic and electrical equipment (WEEE) provided with the
products and available at the following link: www.corning.com/weee.

© 2016, 2020 Corning Incorporated. All rights reserved. 4/20 CLS-EQ-117DOC REV1
Register your product warranty online at
www.corning.com/lifesciences/warranty.
For more specific information on claims, visit the Certificates page at www.corning.com/lifesciences.
Warranty/Disclaimer: Unless otherwise specified, all products are for research use only. Not intended
for use in diagnostic or therapeutic procedures. Corning Life Sciences makes no claims regarding the
performance of these products for clinical or diagnostic applications.
For a listing of trademarks, visit www.corning.com/clstrademarks. All other trademarks are the property of their respective owners.
For additional product or technical information, visit www.corning.com/lifesciences or
call 800.492.1110. Outside the United States, call +1.978.442.2200 or contact your local
Corning sales office.
Corning Incorporated
Life Sciences
836 North St.
Building 300, Suite 3401
Tewksbury, MA 01876
t 800.492.1110
t 978.442.2200
f 978.442.2476
www.corning.com/lifesciences
ASIA/PACIFIC
Australia/New Zealand
t 61 427286832
Chinese Mainland
t 86 21 3338 4338
f 86 21 3338 4300
India
t 91 124 4604000
f 91 124 4604099
Japan
t 81 3-3586 1996
f 81 3-3586 1291
Korea
t 82 2-796-9500
f 82 2-796-9300
Singapore
t 65 6572-9740
f 65 6735-2913
Taiwan
t 886 2-2716-0338
f 886 2-2516-7500
EUROPE
[email protected]
France
t 0800 916 882
f 0800 918 636
Germany
t 0800 101 1153
f 0800 101 2427
The Netherlands
t 020 655 79 28
f 020 659 76 73
United Kingdom
t 0800 376 8660
f 0800 279 1117
All Other European
Countries
t [phone]
f [phone]
LATIN AMERICA
[email protected]
Brazil
t 55 (11) 3089-7400
Mexico
t (52-81) 8158-8400
