CORNING PC-400D User manual

Catalog Number
Model Product Top Plate 230 Volt 230 Volt
Number Type Size 120 Volt 100 Volt (Non-Europe) (Europe)
PC-400D Hot Plate 5" x 7" 6795-400D 6797-400D 6798-400D 6796-400D
(12.7 x 17.8 cm)
PC-410D Stirrer 5" x 7" 6795-410D 6797-410D 6798-410D 6796-410D
(12.7 x 17.8 cm)
PC-420D Stirrer/ 5" x 7" 6795-420D 6797-420D 6798-420D 6796-420D
Hot Plate (12.7 x 17.8 cm)
PC-600D Hot Plate 10" x 10" 6795-600D 6797-600D 6798-600D 6796-600D
(25.4 x 25.4 cm)
PC-610D Stirrer 10" x 10" 6795-610D 6797-610D 6798-610D 6796-610D
(25.4 x 25.4 cm)
PC-620D Stirrer/ 10" x 10" 6795-620D 6797-620D 6798-620D 6796-620D
Hot Plate (25.4 x 25.4 cm)
6795PR Temperature All 6795PR
Controller
Instruct on Manual
For All Hot Plates, St rrers, and St rrer/Hot Plates w th
D g tal D splays and for the 6795PR Temperature Controller

Acerca de este Manual
Este manual está diseñado para ayudarlo a optimizar el uso desu nueva parrilla de
calentamiento, agitador, parrilla de calentamiento/agitador ó contolador de temperatura.
El manual está disponi le en Inglés, Francés, Alemán, Japonés, Coreano, Mandarín
Chino y Español y en la sección de literatura de productos de la página We de
Corning http://www.corning.com/lifesciences.
Vo taje de os productos
Parrillas de calentamiento, agitadores, parrillas de calentamiento/agitador están
disponi les en diferentes voltajes. Antes de usarla, revise que la unidad reci ida tiene
el voltaje correcto para su locación.
Registro de garantía
Llene y envie por correo la tarjeta de registroo envie esta information a través de nuestra
página we http://www.corning.com/lifesciences/warranty para validar por dos años la
garantía de Parrillas de calentamiento, agitadores, parrillas de calentamiento/agitador.
About This Manual
This manual is designed to assist you in optimal usage of your new hot plate, stirrer,
stirrer/hot plate or temperature controller. The manual is availa le in English, French,
German, Japanese, Korean, Mandarin Chinese and Spanish in the product literature
section of Corning’s we site http://www.corning.com/lifesciences.
Product Vo tages
Hot plates, stirrers, and stirrer/hot plates are availa le in different voltages. Before
initial use, check that the unit you received is the correct voltage for your location.
Warranty Registration
Filling out and mailing the attached Warranty Registration Card or su mitting this
information online at http://www.corning.com/lifesciences/warranty will validate the
hot plate, stirrer or stirrer/hot plate’s two year warranty.
Mode d’emploi
Ce mode d’emploi a pour ut de vous aidez à utiliser votre nouvelle plaque chauffante,
agitateur, agitateur chauffant ou contrôleur de température, de manière optimale. Il est
disponi le en français, anglais, allemand, espagnol, japonais et chinois. Vous pouvez
également le consulter et le télécharger sur notre site dans la section «product literature».
http://www.corning.com/lifesciences
Vo tage des apparei s
Les plaques chauffantes, agitateurs et agitateurs chauffants sont disponi les en différents
voltages. Vérifiez avant la première utilisation que l’appareil fourni possède le voltage
adéquat.
Garantie
Remplissez et envoyez la carte de garantie incluse ou remplissez ces renseignements en
ligne sur notre site http://www.corning.com/lifesciences/warranty.
Votre garantie de deux ans sera alors activée.
Zu dieser Gebrauchsanleitung
Diese Ge rauchsanleitung wurde erstellt, um Ihnen da ei zu helfen, Ihre neu erwor enen
Geräte wie Heizplatte, Rührer, Rührer/Heizplatte oder Temperaturregler optimal zu
ge rauchen. Diese Ge rauchsanleitung ist in Englisch, Französisch, Deutsch, Japanisch,
Koreanisch, Mandarin Chinesisch und Spanisch sowie im A schnitt zur Produktliteratur
der Corning Internetseite unter http://www.corning.com/lifesciences erhältlich.
Produkt Netzspannungen
Heizplatten, Rührer und Rührer/Heizplatten sind für verschiedene Netzspannungen
erhältlich. Kontrollieren Sie itte vor dem ersten Ge rauch, o das Gerät, das Sie
erhalten ha en, ü er die korrekte Netzspannung für Ihren Standort verfügt.
Garantie-Registrierung
Das Ausfüllen und Zusenden der eigefügten Karte für Garantie-Registrierung oder das
Einreichen dieser Information online unter http://www.corning.com/lifesciences/warranty
estätigt die zwei Jahre Garantie für Heizplatte, Rührer oder Rührer/Heizplatte.

1
Table of Contents
SafetyInformation ......................2
Operating Conditions . . . . . . . . . . . . . . . . . . . 3
Product Controls and Indicators . . . . . . . . . . .
Product Connections . . . . . . . . . . . . . . . . . . . .
Stirring Instructions . . . . . . . . . . . . . . . . . . . . . 5
Heating Instructions (without the External
Temperature Controller) . . . . . . . . . . . . . . . . . 6
Heating Instructions (with the External
Temperature Controller, Cat. No. 6795PR) . . 6
Heating Operation Principles . . . . . . . . . . . . . 7
Heating Operation Safety . . . . . . . . . . . . . . . . 9
ProductRepair .........................9
Product Maintenance . . . . . . . . . . . . . . . . . . . . 9
Optional Accessories . . . . . . . . . . . . . . . . . . . 11
ReplacementParts .....................12
Technical Specifications . . . . . . . . . . . . . . . . 12
Product Size and Dimensions . . . . . . . . . . . . 13
Frequently Asked Questions . . . . . . . . . . . . . 13
CE,WEEE ..........................1
WarrantyStatement....................15

32
Safety Information
This instruction manual contains important operating and maintenance
instructions which must e read, understood, and followed y the prod-
uct user. Failure to use this product according to this instruction manual
may degrade or defeat the protection normally provided y this product.
Read this instruction manual prior to product use and keep this instruc-
tion manual for future reference.
Product Symbols
Caution - Risk of danger: Cautions that there is materi-
al in the instruction manual which must e read, under-
stood, and followed in order to preserve product safety
features.
Caution – Hot Surface: Cautions that the top plate is
too hot to touch.
Indicates that the unit is plugged into power supply.
Indicates that the accessory external temperature con-
troller is properly plugged into the unit.
Warnings
Persona Injury
◗Do not use this product in a manner other than as stated in the
Operating Conditions section of this manual as the protection provided
y the equipment may e impaired.
◗This product is designed for use in la oratory environments y persons
knowledgea le in safe la oratory practices.
◗Always wear safety glasses and other appropriate protective equipment
when operating this product.
E ectric Shock
◗This product must e connected to a grounded power outlet for safe
functioning.
◗Use only the power cord supplied with the product.
◗The power cord is the device availa le for full disconnect from mains
input.
◗Position the product for use so that the power cord can e easily dis-
connected without having to move the product.
◗Disconnect the power cord efore moving or cleaning the unit.
Product Damage
◗Keep the product dry and clean.
◗Do not immerse the product for cleaning.
◗The ceramic top may reak if impacted.
◗The maximum gross weight placed on the top surface must not exceed
11Kg (25 l s.)
◗These units are not explosion or spark proof.
◗Do not heat or stir volatile or flamma le materials.
◗Do not operate this product near volatile or flamma le materials.
◗Do not use this product with a metal vessel.
Operating Conditions
Corning hot plates, stirrers, and stirrer/hot plates are designed to
provide safe functioning under the following conditions:
◗Indoor use
◗Altitude up to 2000 meters (6,500 feet)
◗Am ient temperatures of 0°C to 30°C
◗Product should e placed on a flat surface at least 30.5 cm (12") from
walls, 122 cm (48") from ceilings, and 30.5 cm (12") from other hot
plates if using multiple units.
◗Maximum relative humidity of 80% for temperatures up to 31°C,
decreasing linearly to 50% relative humidity at 40°C.
◗Pollution Degree 2: Any foreign matter that may accumulate on or
within the product during normal use is not electrically conductive.
◗Installation Category II: Product is designed for connection to an
electrical ranch circuit inside a uilding with main supply voltage
fluctuations not exceeding ±10% of the nominal voltage.

54
Product Controls and Indicators
1Power Indicator: Illuminates at all times when the product is properly
connected to input power.
2Stir Contro Knob: Turn it all the way counterclockwise to turn off
stirring function. Turn it clockwise to set desired stirring speed.
3Stirring Speed Disp ay: Shows the speed set for stirring
Heat Contro Knob: Turn it all the way counterclockwise to turn off
heating function. Turn it clockwise to set desired heating temperature.
5Heating Temperature Disp ay: Shows the temperature set for heating.
6Hot Top Indicator: Illuminates when the temperature of the top is too
hot to touch (greater than ~60°C).
7Temperature Probe In Use Indicator: Illuminates when the external
temperature pro e is connected to the unit.
Product Connections
1Power Cord Input: Connect the supplied power cord into this
connector.
2Externa Temperature Contro er Input: Connect the optional External
Temperature Controller (Corning Cat. No. 6795PR) into this connector.
To Connect the External Temperature Controller
1Turn the Stir Control Kno and Heat Control Kno to the OFF
position.
2Disconnect power cord.
3Insert temperature controller connector into the input connector.
Reconnect power cord.
5Product is now ready for use with External Temperature Controller.
Repeat the a ove process when disconnecting the temperature controller.
Stirring Instructions
PC- 10D, PC- 20D, PC-610D, PC-620D
1Fill vessel with solution to e stirred.
2Place stir ar into vessel.
3Place vessel in the center of the top surface.
Turn Stir Control Kno until the Stirring Speed Display shows the
desired speed. The speed setting can e adjusted according to the
ta le elow.
Operating Range (RPM) Adjustable Increment, (RPM)
60-100 5
100-200 10
200-400 20
400-1150 50
- Flashing Display: The num er will FLASH when actual stirring
speed is not at set speed.
- Constant Display: The num er will not flash when actual stirring
speed is at the set speed. The num er will remain constantly ON
when the actual stirring speed is at the set speed.
5When desired stirring is complete, turn the Stir Control Kno to the
OFF position. Allow stir ar to cease rotation efore removing the
vessel from the unit.
6Heating and stirring can e performed simultaneously with PC-420D
and PC-620D models which offer oth heating and stirring functions.
Please note that the viscosity of the stirred material will affect the a ility
of the stir ar to remain coupled to the rotating ring magnet. Materials
of high viscosity must e stirred at slower speed settings.
1
2
1
76
4
5
2
3

76
Heating Instructions
(without External Temperature Controller)
PC- 00D, PC- 20D, PC-600D, and PC-620D
1Fill vessel with solution to e heated.
2If using a PC-420D or PC-620D and the stirring function, place stir
ar into vessel.
3Place vessel in the center of the top surface.
Turn Heat Control Kno until the Heating Temperature Display
shows the desired temperature. The temperature setting can e
adjusted in 5°C increments.
- F ashing Disp ay: The num er shown on the Heating Temperature
Display will FFLLAASSHHwhen actual heating temperature is not at the set
temperature.
- Constant Disp ay: The num er shown on the Heating Temperature
Display will remain constantly ON when the actual heating
temperature is at the set temperature.
- Hot Top Indicator: The Hot Top Indicator will e OONNat all times
when the temperature of the top surface is too hot to touch (greater
than approximately 60°C).
-The Hot Top Indicator will FFLLAASSHHwhen the Heat Control Kno is
turned OFF, ut the top surface is still too hot to touch.
-The Hot Top Indicator will e OFF when the temperature of the
top is less than approximately 60°C.
Caution: The Hot Top Indicator will turn OFF when the power cord is
disconnected from the product even if the temperature of the top surface
is still too hot to touch.
Heating Instructions
(with External Temperature Controller, Corning Catalog No. 6795PR)
PC- 00D, PC- 20D, PC-600D, PC-620D, and 6795PR
1Connect the External Temperature Controller to the connector on
the ack of the unit.
- Temperature Pro e in Use Indicator: This will illuminate when
External Temperature Controller is properly connected.
2Fill vessel with solution to e heated.
3If using a PC-420D or PC-620D and the stirring function, place stir
ar into vessel.
Place vessel in the center of the top surface.
5Insert the tip of the External Temperature Pro e into the solution.
- The tip should e located in the center of the vessel and at approxi-
mately one-half of the depth of the solution.
6Secure the position of the External Temperature Controller y using a
ring stand/support rod and clamp.
- Assure that the ca le of the External Temperature Controller does
not come into contact with the heating surface.
7Turn Heat Control Kno until the Heating Temperature Display
shows the desired heating temperature.
- Flashing Display: The num er shown on the Heating Temperature
Display will FFLLAASSHHwhen the actual heating temperature is not at
the set temperature.
- Constant Display: The num er shown on the Heating Temperature
Display will remain constantly ON when the actual heating temper-
ature is at the set temperature.
- Hot Top Indicator: The Hot Top Indicator will e OONNat all times
when the temperature of the top surface is too hot to touch (greater
than ~60°C).
- The Hot Top Indicator will FFLLAASSHHwhen the Heat Control Kno is
turned OFF ut the top surface is still too hot to touch.
- The Hot Top Indicator will e OFF when the temperature of the
top is less than ~60°C.
Caution: The Hot Top Indicator will turn OFF when the power cord is
disconnected from the product even if the temperature of the top surface
is still too hot to touch.
Heating Operation Principles
The heating element and a temperature sensor are located just eneath
the ceramic top surface of the product. The microprocessor controlled
heat, generated y the heating element, is ased upon the sensor tem-
perature and the value set on the Heating Temperature Display. When
the sensor temperature is not within range of the value set on the dis-
play, the display will FFLLAASSHH. When the sensor temperature is within
range, the value displayed will remain constantly OONN.
The Heating Temperature Display does not indicate the actual tempera-
ture of materials placed on top of the product or the actual temperature
of the ceramic top surface.

98
The ta le elow shows a typical difference etween the temperature set
on the Heating Temperature Display and the actual temperature meas-
urement of the ceramic top surface:
Actual Actual
Temperature Set Top Surface Temperature Set Top Surface
on Display (°C) Temperature (°C) on Display (°C) Temperature (°C)
50 45 350 285
100 85 400 325
150 125 450 365
200 165 500 405
250 205 550 440
300 245
(The information a ove was taken using a 6795-420D with no top load
in 20°C am ient conditions)
Using the Externa Temperature Contro er, Corning Inc. Cat. No.6795PR
enab es precision temperature contro of materia s p aced in vesse s on top of
the product.
An External Temperature Controller is availa le for this product as an
accessory item. See page 11 for more details.
When the External Temperature Controller is connected to the product,
the closed loop control process descri ed previously is extended to
include temperature input from the External Temperature Controller.
The microprocessor controlled heat, generated y the heating element,
is ased upon the sensor temperature located in the tip of the External
Temperature Controller and the value set on the Heating Temperature
Display. When the sensor temperature is not within range of the value
set on the display, the display will FLASH. When the sensor temperature
is within range, the value displayed will remain constantly ON.
When the External Temperature Controller is connected to the product
and properly placed into a liquid on the top surface, then the Heating
Temperature Display does indicate and directly control the actual tem-
perature of the liquid on the top surface.
Caution: The top surface and the vessel used may e at su stantially
higher temperatures than indicated y the setting on the Heating Temp -
erature Display as the controller regulates the liquid temperature inside
the vessel.
Heating Operation Safety
The microprocessor controlled system has error routines uilt in to
detect product operation in some unfavora le conditions. The type of
error routines which may e active in a product varies depending upon
the functionality of the model and the operating software version.
If an error routine is engaged, the product will typically shut down.
Some error routines will display an error code num er in the left digital
location of the Heating Temperature Display when the product is shut
down. For more information on error codes, call Corning Technical
Service at 978.442.2200.
A product shut down y an error routine must e disconnected and
reconnected to mains input efore it can e used again. Please contact
Corning Inc. or a Corning Authorized Repair Facility if a product does
not reset from the error routine shut down or if it continues to shut
down after resetting.
Caution: Error routines uilt into these products do not su stitute the
need to use these products per the specified operating conditions and
according to safe la oratory practices. There are potential failure modes
in product functionality or in process of use that could result in uncon-
trolled or unexpected heating of the top surface. Reaction plans should
e developed and safety precautions put in place ased on the worse case
scenario that any materials placed on the top surface could e su jected
to a continuous supply of heat, raising the material temperature to levels
in excess of 550°C.
Product Repair
There are no direct user servicea le components inside this series of
products. A list of availa le replacement parts are listed on page 12.
Please contact Corning or a Corning authorized repair facility for
repair or maintenance issues.
Product Maintenance
Power
Caution: Disconnect power to the product y unplugging the power
cord efore performing any maintenance or inspection procedures.
◗Inspect the power cord regularly and replace if damaged. Use only
replacement power cords availa le from Corning and Corning
authorized product distri utors.

1110
Ceramic Top Plate
◗These products are supplied with Corning’s proprietary Pyroceram®
top that is easy to clean and highly resistant to scratches, corrosion,
and chemical attack.
◗The ceramic top may reak during use if not properly maintained.
◗Keep the ceramic top clean. A nona rasive cleaner may e used to
clean the ceramic top.
◗Inspect the ceramic top for damage during cleaning.
◗Discontinue product use if the ceramic top is chipped, etched, or
shows excessive scratching. A replacement top can e ordered. See
page 12 for details.
◗Contact Corning or a Corning authorized repair facility for top
replacement.
General
◗It is important to keep this product dry and clean.
◗Remove minor exterior liquid spills promptly.
◗Clean exterior surfaces with a nona rasive cleaner. Do not reconnect
product to power input until all cleaned surfaces have dried.
◗If liquid or wet solid material gets inside the product, immediately
disconnect power to the product and discontinue use. Contact
Corning for additional instructions regarding interior spills.
Optional Accessories
Corning
Catalog No. Description
6795PR External Temperature Controller for Digital Display Hotplate and
Hotplate/Stirrer – used for all PC-400D, 420D, 600D, and 620D models.
FEP coated stainless steel.
440129 Vertical Support Rod: Supplied as two 9" [22.86 cm] rods which can e
screwed together – can e used with all PC-XXXD series products. Stainless
steel.
440140 Boss Head Clamp – used for connecting the 440141 Holding Rod at a 90°
angle to the 440129 Support Rod. Aluminum.
440141 Holding Rod – used for holding the 6795PR External Temperature Controller
in position. Aluminum.
6795KIT Universal Accessories Kit includes: 6795PR, 6970SR, and 440129
6795-420KIT Kit includes: 6795-420D Stirrer/Hot Plate, 6795PR, 6970SR, and 440129
6795-620KIT Kit includes: 6795-620D Stirrer/Hot Plate, 6795PR, 6970SR, and 440129
400430 PTFE coated magnetic stir ar, 1 x 5.1 cm (.39" x 2") – recommended size for
all PC-610D and 620D models.
401435 PTFE coated magnetic stir ar, 1 x 2.5 cm (.39" x 1") – recommended size for
all PC-410D and 420D models.
6970SR Stir Bar Retriever, polypropylene
Accessories (Shown with 6795-420D)

13
Product Size and Dimensions
Top Plate Size Product Dimensions
Models Inches (Millimeters) Inches (Millimeters)
PC-400D/410D/420D 5" x 7" 4.25 x 7.75 x 11"
(12.7 x 17.8 cm) (10.8 x 19.7 x 28 cm)
PC-600D/610D/620D 10" x 10" 4.625 x 11 x 15.375"
(25.4 x 25.4 cm) (11.75 x 19.7 x 39.05 cm)
Frequently Asked uestions
◗I have a beaker of water on my hot plate and set the temperature
for 550°C. Why does the display setting blink and not remain
constant?
The display will link at any time when the temperature sensor is not
within range of the set temperature value. The temperature measured
y the sensor is a composite of the temperature of the heating element
located eneath the sensor, the ceramic top a ove the sensor, and the
very small air space around the sensor. Water requires a su stantial
amount of heat in order to oil yet remains at a constant temperature
of 100°C for the duration of the oiling process. Although the heating
element is producing maximum heat at the 550°C setting, the water
consumes this heat so quickly during the oiling process that the heat
is una le to raise the temperature measured y the sensor to within
range of the 550°C set value.
◗How long does it take to bring a beaker of water to boil?
Using a 600 mL PYREX®eaker with 400 mL of water at 25°C, it
takes approximately 15 minutes to ring the water to a full, rolling
oil.
◗Can I use a metal tray on top of my Corning®hot plate?
No. The metal will act as a heat sink, and have a high pro a ility of
creating an a normal heating condition. If an a normal condition is
detected, the product will shut down. A metal vessel will also scratch
the ceramic top plate.
◗The stir bar keeps decoupling. Why and what can I do to stop this?
These units are programmed to minimize decoupling. However, liquid
viscosity, stir ar magnetic strength, vessel used, and speed changes can
cause decoupling. High viscosity liquids must e stirred at slower speed
settings. The magnetic strength of stir ars can weaken over time and
may need to e replaced. Vessels used need to have thin, flat ottoms
to insure optimal performance. Rapid decreases in stir speed can cause
decoupling as the magnet slows down quicker than the stir ar and the
liquid.
◗What size vessel should I use?
Vessels used on the top of a hot plate must not e larger than the
top plate.
12
Replacement Parts
Corning
Catalog No. Description Usage
411007 Power Cord PC-400D/410D/420D, 120V
410956 Power Cord PC-600D/610D/620D, 120V
411021 Power Cord PC-400D/410D/420D and PC-600D/610D/620D,
100V
410942 Power Cord PC-400D/410D/420D and PC-600D/610D/620D,
230V (UK plug)
440124 Power Cord PC-400D/410D/420D and PC-600D/610D/620D,
230V (Euro Plug)
Contact Corning Ceramic top plate/ PC-400D/410D/420D, All Voltages
customer service element assem ly,
for part num er 5" x 7"
Contact Corning Ceramic top plate/ PC-600D/610D/620D, All Voltages
customer service element assem ly,
for part num er 10" x 10"
Contact Corning PC Control Board
customer service
for part num er
440135 Control Kno All models
Technical Specifications
Power (Volts/Hz/Watts/Amp)
120V 100V 230V 230V Temp. Stir Range
Model Type (6795 models) (6797 models) (6796 models) (6798 models)2Range1(RPM) Weight
PC-400D Hot 120V/60Hz/ 100V/60Hz/ 230V/50Hz/ 230V/50Hz/ 5°-550°C 2.7kg
Plate 628W/5.3A 548W/5.5A 628W/2.7A 628W/2.7A (41°-1022°F) (6.0 l s.)
PC-600D Hot 120V/60Hz/ 100V/60Hz/ 230V/50Hz/ 230V/50Hz/ 5°-550°C 4.5kg
Plate 1043W/8.7A 1043W/10.5A 1043W/4.5A 1043W/4.5A (41°-1022°F) (10.0 l s.)
PC-410D Stirrer 120V/60Hz/ 100V/60Hz/ 230V/50Hz/ 230V/50Hz/ 60-1150 3.2kg
73W/0.7A 78W/0.8A 73W/0.3A 73W/0.3A (7.0 l s.)
PC-610D Stirrer 120V/60Hz/ 100V/60Hz/ 230V/50Hz/ 230V/50Hz/ 60-1150 5.2kg
73W/0.7A 78W/0.8A 73W/0.3A 73W/0.3A (11.5 l s.)
PC-420D Stirrer/ 120V/60Hz/ 100V/60Hz/ 230V/50Hz/ 230V/50Hz/ 5°-550°C 60-1150 3.2kg
Hot 698W/5.9A 623W/6.3A 698W/3.0A 698W/3.0A (41°-1022°F) (7.0 l s.)
Plate
PC-620D Stirrer/ 120V/60Hz/ 100V/60Hz/ 230V/50Hz/ 230V/50Hz/ 5°-550°C 60-1150 5.2kg
Hot 1113W/9.3A 1113W/11.2A 1113W/4.8A 1113W/4.8A (41°-1022°F) (11.5 l s.)
Plate
1The Temperature Range using the External Temperature Controller is 5°-200°C (41°-392°F).
2Catalog num ers eginning with 6798 in 230V are non European configuration models.

15
Warranty Statement
Corning Incorporated warrants this product to e free from defects in
material and workmanship when used under normal la oratory conditions
for two (2) years. This warranty egins from the date of the purchase y
the end user.
This warranty is made in ieu of a other warranties expressed or imp ied
inc uding the warranties of merchantabi ity and fitness for a particu ar purpose.
Corning sha not be iab e for oss or damages arising from the use of these
products nor for consequentia damages of any kind.
In the event this product fails under normal la oratory conditions
with the specified period of time ecause of a defect in material or
workmanship, Corning will, at its option, repair or replace the product.
Contact the Corning Technical Information Center for return
authorization and shipping instructions at:
◗1.800.492.1110 (for toll-free calling within the U.S. and Canada)
◗1.978.442.2200 (outside the U.S.), or
◗contact your local Corning support office listed on the ack cover of
this manual.
Warranty Registration
Your purchase of this product must e registered with Corning in order
for your warranty to e in effect.
Register y mail y detaching the Warranty Registration card from this
instruction manual and mailing the completed card.
Or you can register online at http://www.corning.com/lifesciences/
warranty.
Your Purchase Record
Corning recommends that you record the details of your purchase in the
spaces elow for your future reference.
Model Num er _________________________________________________________________
Serial Num er __________________________________________________________________
Date Purchased/Received for use ___________________________________________________
Purchased From ________________________________________________________________
Purchase Reference Num er __________________________________________
14
◗Corning sells replacement parts. Can I do the repairs myself
instead of sending it in to Corning’s equipment repair department?
When repairs are completed y Corning or a Corning authorized repair
facility, the performance and safety of the product will e verified efore
eing returned to you. We do sell replacement parts so customers can
complete repairs themselves. It is recommended that only people know-
ledgea le in electronics complete those repairs. There is no warranty
or return on equipment replacement parts.
CE Declaration of Conformity
Corning Incorporated here y declares under its sole responsi ility that
the following products:
◗6796-400D, 6796-410D, 6796-420D, 6796-600D, 6796-610D,
6796-620D
Conform to the following EU Directives:
◗73/23/EEC: Low Voltage Directive, as amended y 93/68/EEC
◗89/336/EEC: Electromagnetic Compati ility Directive, as amended
y 92/31/EEC and 93/68/EEC
Presumption of compliance to these directives is supported through
successful evaluation to the requirements of the following standards:
◗IEC 61010-1: 2001 (Second Edition)
◗IEC 61010-2-010: 2003 (Second Edition)
◗IEC 61010-2-051: 2003 (Second Edition)
◗EN61326-1
◗EN61000-3-2, -3-3, -4-2, -4-3, -4-5, -4-6, -4-8, -4-11
Product Disposal
The “crossed-out wheelie in” sym ol, if present on the product, indi-
cates that the product was planned for use in a country complying with
the Waste Electrical and Electronic Equipment EU Directive,
2002/96/EC. This sym ol indicates that this equipment must not e dis-
posed of with unsorted municipal waste. It is the product user’s responsi-
ility to correctly dispose of waste equipment y handing it over to an
authorized facility for separate collection and recycling. It is the product
user’s responsi ility to decontaminate waste equipment from iological,
chemical, and/or radiological hazards prior to disposal.
Additional information pertaining to the disposal of Corning stirrer/hot plates
per the WEEE Directive can e o tained at www.corning.com/weee.

Corning, PYREX and Pyroceram are registered trademarks of Corning Incorporated, Corning, NY.
All other trademarks incl ded in this doc ment are the properties of their respective owners.
Corning Incorporated, One Riverfront Plaza, Corning, NY 14831-0001
© 2011 Corning Incorporated Printed in U.S.A. 12/11 POD CLS-EQ-091REV1
Please reg ster your warranty onl ne at
http://www.corning.com/lifesciences/warranty
Corning Incorporated
Life Sciences
Tower 2, 4th Floor
900 Chelmsford St.
Lowell, MA 01851
t 800.492.1110
t 978.442.2200
f 978.442.2476
www.corning.com/
lifesciences
Worldwide
Support Offices
A S I A / P AC I F I C
Australia/New Zealand
t 0402-794-347
China
t86 21 2215 2888
f 86 21 6215 2988
India
t 91 124 4604000
f 91 124 4604099
Japan
t 81 3-3586 1996
f 81 3-3586 1291
Korea
t 82 2-796-9500
f 82 2-796-9300
Singapore
t 65 6733-6511
f 65 6861-2913
Taiwan
t 886 2-2716-0338
f 886 2-2516-7500
E U R O P E
France
t 0800 916 882
f 0800 918 636
Germany
t 0800 101 1153
f 0800 101 2427
The Netherlands
t 31 20 655 79 28
f 31 20 659 76 73
United Kingdom
t 0800 376 8660
f 0800 279 1117
All Other European
Countries
t 31 (0) 20 659 60 51
f 31 (0) 20 659 76 73
L AT I N A M E R I C A
Brasil
t (55-11) 3089-7419
f (55-11) 3167-0700
Mexico
t (52-81) 8158-8400
f (52-81) 8313-8589
