Costar CR4000INT-UM User manual

Four-Channel Video Transmitter
i
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
COMPLIANCE NOTICE OF FCC:
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A
DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO
PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS
OPERATED IN A COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH THE
INSTRUCTION MANUAL, MAY CAUSE HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE HARMFUL
INTERFERENCE, IN WHICH CASE USERS WILL BE REQUIRED TO CORRECT THE INTERFERENCE AT
THEIR OWN EXPENSE.
WARNING: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE
FOR COMPLIANCE COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
THIS CLASS OF DIGITAL APPARATUS MEETS ALL REQUIREMENTS OF THE CANADIAN INTERFERENCE-
CAUSING EQUIPMENT REGULATIONS.
The information in this manual is believed to be accurate as of the date of publication. We are not responsible for
any problems resulting from the use thereof. The information contained herein is subject to change without notice.
Revisions or new editions to this publication may be issued to incorporate such changes.
The software included in this product contains some Open Sources. You may obtain the complete corresponding
source code from us. See the Open Source Guide on the software CD (OpenSourceGuide\OpenSourceGuide.pdf) or
as a printed document included along with the User's Manual.
WEEE (Waste Electrical & Electronic Equipment)
Correct Disposal of This Product
(Applicable in the European Union and other European countries with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed with other
household wastes at the end of its working life. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it
responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local
government office, for details of where and how they can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract.
This product should not be mixed with other commercial wastes for disposal.

User’s Manual
ii
Important Safeguards
1. Read Instructions
All the safety and operating instructions should be read before the
appliance is operated.
2. Retain Instructions
The safety and operating instructions should be retained for future
reference.
3. Cleaning
Unplug this equipment from the wall outlet before cleaning it. Do not
use liquid aerosol cleaners. Use a damp soft cloth for cleaning.
4. Attachments
Never add any attachments and/or equipment without the approval of
the manufacturer as such additions may result in the risk of fire,
electric shock or other personal injury.
5. Water and/or Moisture
Do not use this equipment near water or in contact with water.
6. Placing and Accessories
Do not place this equipment on an unstable cart, stand or table. The
equipment may fall, causing serious injury to a child or adult, and
serious damage to the equipment. Wall or shelf mounting should
follow the manufacturer's instructions, and should use a mounting kit
approved by the manufacturer.
13. Damage requiring Service
Unplug this equipment from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
A. When the power-supply cord or the plug has been damaged.
B. If liquid is spilled, or objects have fallen into the equipment.
C. If the equipment has been exposed to rain or water.
D. If the equipment does not operate normally by following the
operating instructions, adjust only those controls that are covered
by the operating instructions as an improper adjustment of other
controls may result in damage and will often require extensive
work by a qualified technician to restore the equipment to its
normal operation.
E. If the equipment has been dropped, or the cabinet damaged.
F. When the equipment exhibits a distinct change in performance —
this indicates a need for service.
14. Replacement Parts
When replacement parts are required, be sure the service technician
has used replacement parts specified by the manufacturer or that have
the same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock or other hazards.
15. Safety Check
Upon completion of any service or repairs to this equipment, ask the
service technician to perform safety checks to determine that the
equipment is in proper operating condition.
16. Field Installation
This installation should be made by a qualified service person and
should conform to all local codes.
17. Correct Batteries
Warning: Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
18. Tmra
A manufacturer’s maximum recommended ambient temperature
(Tmra) for the equipment must be specified so that the customer and
installer may determine a suitable maximum operating environment
for the equipment.
19. Elevated Operating Ambient Temperature
If installed in a closed or multi-unit rack assembly, the operating
ambient temperature of the rack environment may be greater than
room ambient. Therefore, consideration should be given to installing
the equipment in an environment compatible with the manufacturer’s
maximum rated ambient temperature (Tmra).
20. Reduced Air Flow
Installation of the equipment in the rack should be such that the
amount of airflow required for safe operation of the equipment is not
compromised.
21. Mechanical Loading
Mounting of the equipment in the rack should be such that a hazardous
condition is not caused by uneven mechanical loading.
22. Circuit Overloading
Consideration should be given to connection of the equipment to
supply circuit and the effect that overloading of circuits might have on
over current protection and supply wiring. Appropriate consideration
of equipment nameplate ratings should be used when addressing this
concern.
23. Reliable Earthing (Grounding)
Reliable grounding of rack mounted equipment should be maintained.
Particular attention should be given to supply connections other than
direct connections to the branch circuit (e.g., use of power strips).
This equipment and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause the
equipment and cart combination to overturn.
7. Power Sources
This equipment should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of
power, please consult your equipment dealer or local power company.
8. Power Cord
Operator or installer must remove power and TNT connections before
handling the equipment.
9. Lightning
For added protection for this equipment during a lightning storm, or
when it is left unattended and unused for long periods of time, unplug
it from the wall outlet and disconnect the antenna or cable system.
This will prevent damage to the equipment due to lightning and
power-line surges.
10. Overloading
Do not overload wall outlets and extension cords as this can result in
the risk of fire or electric shock.
11. Objects and Liquids
Never push objects of any kind through openings of this equipment as
they may touch dangerous voltage points or short out parts that could
result in a fire or electric shock. Never spill liquid of any kind on the
equipment.
12. Servicing
Do not attempt to service this equipment yourself. Refer all servicing
to qualified service personnel.

Four-Channel Video Transmitter
iii
Table of Contents
Chapter 1 — Introduction.......................................................................................... 1
1.1 In This Manual ............................................................................................... 1
1.2 Features......................................................................................................... 1
1.3 Typical Applications ....................................................................................... 2
Chapter 2 — Installation ........................................................................................... 5
2.1 Package Contents ......................................................................................... 5
2.2 Front Panel .................................................................................................... 5
Factory Reset ................................................................................................ 5
2.3 Rear Panel ..................................................................................................... 6
Chapter 3 — Remote Setup ..................................................................................... 8
3.1 Quick Setup ................................................................................................... 8
3.2 System ........................................................................................................... 9
General.......................................................................................................... 9
Date/Time .................................................................................................... 10
User/Group .................................................................................................. 10
3.3 Network........................................................................................................ 11
IP Address ................................................................................................... 11
DVRNS ........................................................................................................ 11
Port .............................................................................................................. 12
Bandwidth Control .......................................................................................13
Security........................................................................................................ 13
3.4 Video............................................................................................................ 14
Camera ........................................................................................................ 14
Live Monitoring ............................................................................................ 15
Webcasting.................................................................................................. 16
Output OSD ................................................................................................. 16
MAT ............................................................................................................. 16
3.5 Audio............................................................................................................ 17
Input/Output................................................................................................. 17
3.6 Event............................................................................................................ 17
Alarm In ....................................................................................................... 18
Motion Detection.......................................................................................... 18
Video Loss................................................................................................... 19
Video Blind ..................................................................................................19
System Event .............................................................................................. 20
Event Action ................................................................................................ 20
Chapter 4 — Web Monitoring ................................................................................. 22
Appendix ................................................................................................................. 25
LED Indicators ................................................................................................... 25
Troubleshooting ................................................................................................. 25
Connector Pin Outs ........................................................................................... 25
Map of Screens (Remote Setup) ....................................................................... 26
Specifications..................................................................................................... 27

User’s Manual
iv

Four-Channel Video Transmitter
1
Chapter 1 — Introduction
1.1 In This Manual
This manual is intended for users of the four-channel network video transmitter (network video encoder)
and includes instructions for using and managing the transmitter on the network.
1.2 Features
This network video transmitter compresses live video from analog cameras and transmits the video over
Ethernet connections. The transmitter can be accessed, configured and managed by using the INIT
(Integrated Network Installation Tool) program. It has a built-in web server allowing you to monitor live
video remotely using a web browser. The remote programs (RASplus and iNEX Basic) provided
with the transmitter also allows remote management, monitoring and recording. This transmitter
offers the following features:
4 composite video input connectors
1 analog video output for quad display
Auto detection for NTSC and PAL
Dual streaming for monitoring and recording
H.264, MPEG-4 and M-JPEG compression algorithm
Four levels of video compression and various video compression resolutions
Two-way audio communication
Pre- and post-event buffering and video stream buffering to enhance reliability of network recording
Remote monitoring via web browser or remote software
Compatibility with Genetec Omnicast software using Genetec Protocol (RTSP Port: 554)
Automatic HTML code generation for webcasting on a user’s website
Up to 20 simultaneous connections to the transmitter
Enhanced security using IP address filtering, HTTPS and SSL functions and password protected
multiple user levels
Network bandwidth limit and MAT functions to use network bandwidth efficiently
Convenient firmware upgrades via either the USB port or the network
Firmware duplication and autorecovery functions to enhance system stability
Management of multiple transmitters via Ethernet connections
Event detection functions: alarm-in, motion, video loss, video blind
Power sources: 12 VDC, 24 VAC, PoE (Power over Ethernet)
RS485 interface for controlling a PTZ camera
4-channel alarm in and 1-channel alarm out
1-channel audio in and out
NOTES:
Remote monitoring and recording through dual streaming are available by using the RASplus and
iNEX Basic programs provided with the transmitter.
In this manual, a “remote system” refers to a PC that the remote program or WebGuard program is
running, and a network video receiver.

User’s Manual
2
1.3 Typical Applications
Remote Monitoring (I)
Remote Monitoring (II)

Four-Channel Video Transmitter
3
Remote Recording
Webcasting

User’s Manual
4
Control Center

Four-Channel Video Transmitter
5
Chapter 2 — Installation
2.1 Package Contents
Network Video Transmitter
DC Adapter (12V)
Power Cord
Installation CD (INIT, RASplus and iNEX Basic software, iNEX Basic User’s Manual)
User’s Manuals (Transmitter, INIT, RASplus)
Wall-mount Kits
2.2 Front Panel
No. Designation Details
1 USB Port
Connect a USB flash drive to upgrade the software. Disconnect power from
the transmitter and connect a USB flash drive containing the upgrade package
file (.rui and autorun.txt) to the transmitter. Connect power to the transmitter,
and the software will be upgraded automatically. You can upgrade the software
remotely by running the INIT program. Refer to the INIT User’s Manual
for details on remote software upgrade.
2 Factory Reset
Switch Use to return all settings to the original factory settings. See below for details.
3 Network LED
Displays network connection status. Refer to Appendix A – LED Indicators for
details.
4 Power LED
Displays system operating status. Refer to Appendix A – LED Indicators for
details.
Factory Reset
This switch will only be used on the rare occasions that you want to return all the settings to the original
factory settings.
CAUTION: When performing a Factory Reset, you will lose any settings you have saved.
Disconnect the power adapter from the transmitter. →Poke a straightened paperclip into the factory
reset switch hole. →Connect the power while holding the reset switch →Release the switch when
the Network and Power LEDs blink together. →The transmitter resets to factory defaults and restarts
after completing the factory reset.

User’s Manual
6
You can perform a factory reset while the transmitter is turned on by poking a straightened paperclip
into the factory reset switch hole and releasing the reset switch. A factory reset also can be performed
remotely by running the INIT program. The transmitter restarts after completing the factory reset.
Refer to the INIT User’s Manual for details on remote factory resetting.
2.3 Rear Panel
No. Designation Details
1 Network Port
Connect a Cat5 cable with an RJ-45 jack. Refer to the INIT User’s Manual
for details on network connection setup.
When using a PoE switch, the transmitter can be supplied with power over
Ethernet. (Refer to the PoE switch manufacturer’s manual for details.)
2 Audio Out
Connect to an amplifier (Line-out). The transmitter does not have amplified
audio output, so you will need a speaker with an amplifier.
3 Audio In
Connect to an audio source. (Line-in or Microphone)
4 Video In Connect coaxial cables from the video sources (NTSC or PAL).
5 Video Out Connect to a monitor (NTSC or PAL).
6 RS485 Port
Connect to a PTZ camera. Connect TX+/RX+ and TX-/RX- of the PTZ camera
to the + and – (respectively) of the transmitter. Refer to the PTZ camera
manufacturer’s manual for configuring the RS485 connection. When the
transmitter receives RS485 data via a video receiver, other RS485 communication
devices can be connected. Refer to the video receiver’s User’s Manual for
details for receiving RS485 data via a video receiver.
7 Alarm Output
Connect an alarm-out device to the NO (Normally Open) and C(Common)
connectors. NO is a relay output which sinks 0.3A @ 125 VAC and 1A @
30 VDC.
8 GND
Connect to the ground side of the alarm inputs.
9 Alarm Input
Connect alarm-in devices. Mechanical or electrical switches can be wired to
the AI (Alarm-In) and GND (Ground) connectors. The voltage range is from
0V to 3.3V. When the electrical switch is wired, the threshold voltage for
NC (Normally Closed) is above 2.4V and for NO (Normally Open) is below
0.3V, and it should be stable at least 0.5 seconds to be detected.
10 Power In
Connect two wires from the power adapter (12 VDC or 24 VAC). You do not
need to distinguish power polarity when connecting the wires. The transmitter
starts booting as soon as power is applied.

Four-Channel Video Transmitter
7
NOTES:
To make connections on the Alarm Connector Strip, press and hold the button and insert the wire in
the hole below the button. After releasing the button, tug gently on the wire to make certain it is
connected. To disconnect a wire, press and hold the button above the wire and pull out the wire.
Camera and audio surveillance may be prohibited by laws that vary by region. Check the laws in
your area before using this product for surveillance purposes.
CAUTIONS:
The transmitter restarts after the power adaptor is disconnected from the transmitter when
switching the power source from 12 VDC or 24 VAC to PoE.
The network connector is not designed to be connected directly with cable or wire intended
for outdoor use.
Do NOT stack transmitters or put anything on top of the transmitter. Stacking transmitters
or placing items on top of them restricts ventilation which can cause improper operation or
the risk of fire.
WARNING: ROUTE POWER CORDS SO THAT THEY ARE NOT A TRIPPING HAZARD. MAKE
CERTAIN THE POWER CORD WILL NOT BE PINCHED OR ABRADED BY FURNITURE. DO NOT
INSTALL POWER CORDS UNDER RUGS OR CARPET. THE POWER CORD HAS A GROUNDING
PIN. IF YOUR POWER OUTLET DOES NOT HAVE A GROUNDING PIN RECEPTACLE, DO NOT
MODIFY THE PLUG. DO NOT OVERLOAD THE CIRCUIT BY PLUGGING TOO MANY DEVICES
INTO ONE CIRCUIT.

User’s Manual
8
Chapter 3 — Remote Setup
Remote Setup allows you to change all settings of the transmitter. Run the INIT program, select a
transmitter and click the Setup icon on the Main screen. Select Remote Setup from the Setup menu
and the Remote Setup screen appears. You can also display the Remote Setup screen by selecting
a transmitter, clicking the right mouse button and selecting Remote Setup on the Main screen.
NOTE: You can also change the settings by using remote programs (RASplus or iNEX Basic) or a web
browser.
Clicking a menu in the left of the Remote Setup screen displays the current settings for that menu on
the right side of the screen. Clicking submenus under each menu allows you to change the settings.
Clicking the OK button closes the Remote Setup screen and applies the changes.
3.1 Quick Setup
The Quick Setup allows you to change a transmitter’s basic system, network,
video and audio settings.

Four-Channel Video Transmitter
9
3.2 System
You can change a transmitter’s system information, import or export all settings,
and add users or groups.
General
Language: Choose the language to be used during
remote setup.
Name: Enter the transmitter’s name (up to 31 characters
including spaces).
Note: Enter additional information about the transmitter.
HW Version, SW Version: These fields display the
transmitter’s hardware and software versions.
Setup
−Load Default Setup…: Click to return all to the original
factory settings. You can select whether or not network
settings will be included when the default setup is applied.
Refer to the Network menu for details of the network
settings.
−Import Setup…: Click to apply the settings saved as a .dat file format to the transmitter. A setup screen
appears allowing you to select the setup file. You can select whether or not network settings (except
the DVRNS setting) will be included when the setup is applied. Refer to the Network menu for details
of the network settings.
−Export Setup…: Click to save the current transmitter settings as a .dat file format. A setup screen
appears allowing you to name the setup file.
NOTES:
The Load Default Setup and Import Setup functions are permitted only to the users in the Administrator
group.
Do NOT check the Include Network Setup box when the network settings of the setup file are used
in another transmitter. Otherwise, the connection to the transmitter might not be made properly.

User’s Manual
10
Date/Time
Date/Time: Change the system date/time, date/time
format and time zone and turn daylight saving time on
or off by checking the box. Clicking the Apply button
applies the changes immediately.
Time Sync
−Automatic Sync: Check the box to automatically
synchronize the time with a time server. Enter the IP
address or the domain name of the time server and set
the time interval for synchronization. If the time server
uses the DVRNS function, selecting the Use DVRNS
box allows you to enter the name instead of the IP address
or the domain name of the time server.
−Run as Server: Check the box to run the transmitter
as a time server.
NOTE: You can use the domain name instead of the IP address of the time server during the Time Sync
setting if you set up the DNS Server when setting up network.
User/Group
User/Group: Click the buttons to change the settings
for a group or a user allowed controlling the transmitter
remotely.
−Add Group: Click to add a group. Enter the desired
group name and set authority levels for the group to
control the transmitter remotely.
−Add User: Click to add a user. Enter the desired user
name and select the group that the user will belong to.
Enter a password to be assigned to the user.
−Change: Select a group and click the button to change
authority levels assigned to the group, or select a user
and click the button to change the user’s password.
−Delete: Select a group or user and click the button to
delete the group or user.
Allow Anonymous Login: Check the box to use the webcasting feature. Refer to 3.4 Video –
Webcasting for details.
Allow Anonymous PTZ Control: Check the box to allow remote control of a PTZ camera on a
website by using the webcasting feature.
NOTES:
The User/Group changes are permitted only to the users in the Administrator group.
There is no default password for the admin user in the Administrator group.
The authority levels that can be assigned are:
– Upgrade: The user can upgrade the software. (USB port upgrade is not
– Setup: The user can set up the system.
– Color Control: The user can control brightness, contrast, hue and saturation for cameras.
– PTZ Control: The user can control a PTZ camera.
– Alarm-Out Control: The user can reset the output during an alarm.
– Covert Camera View: The user can view video from cameras set as Covert 2.
– System Check: The user can view and check the remote system status.

Four-Channel Video Transmitter
11
3.3 Network
You can change the network settings, set up DVRNS and security functions
and control the network bandwidth.
IP Address
Type: Select the type of network configuration.
−Manual: Select when the transmitter is using a static IP
address for network connection, and set up LAN
parameters manually.
−DHCP: Select when the transmitter is networked via
DHCP (Dynamic Host Configuration Protocol). Click
the OK button, and a temporary IP address is automatically
assigned to the transmitter. The transmitter periodically
will be issued a new IP address automatically.
−ADSL: Select when the transmitter is networked via
ADSL. Enter the ID and password for ADSL connection,
and click the OK button. A temporary IP address is
automatically assigned to the transmitter. The transmitter
periodically will be issued a new IP address automatically.
DNS Server: Enter the IP address of the DNS server. If you set up the DNS server, the domain
name of the server can be used instead of the IP address during the DVRNS, time or SMTP server
setup. Ask your Internet service provider for the IP Address of the DNS Server.
NOTES:
Ask your network provider for details about the network connection type and connection information
for the transmitter.
If the transmitter is configured for a DHCP or ADSL network, it is best to use the DVRNS function
because the transmitter’s IP address might change frequently. Ask your Internet service provider for
information about the IP Address of the DNS Server.
DVRNS
Check the DVR Name Service box to use the DVR Name
Service function.
DVRNS Server: Enter the IP address or domain name
of the DVRNS server.
Port: Set up the port number of the DVRNS server.
Use NAT: Check the box when using NAT (Network
Address Translation).
DVR Name: Enter the transmitter’s name to be
registered on the DVRNS server. Check whether or
not the name is available by clicking the Check button.

User’s Manual
12
Help Desk: Choosing the OK button registers the transmitter on the DVRNS server. Proper DVRNS
settings will display the help desk information of the DVRNS server.
NOTES:
The DVRNS (DVR Name Service) function allows the transmitter to use dynamic IP addresses for
remote connection. When using this function, you can access the transmitter remotely by using the
transmitter’s name instead of its IP address. For the DVRNS function to work properly, the
transmitter should be registered on the DVRNS server, and the DVRNS server settings in the INIT
program for the transmitter should match the settings registered on the DVRNS server. Any
changes on the DVRNS server might cause improper operation.
When LAN settings have been changed, set up the DVRNS settings after saving your LAN changes
by clicking the OK button.
You will need to get the IP address or domain name of the DVRNS server from your network administrator.
You can use the domain name instead of IP address if you set up the DNS server during the IP Address
setup.
When using a NAT (Network Address Translation) device, refer to the NAT manufacturer’s instructions
for the proper network settings.
The transmitter’s name you entered in the DVR Name field should be checked by clicking the Check
button, otherwise the DVRNS changes will not be saved. When entering no name or a name already
registered on the DVRNS server, an error message displays.
Port
Set up Admin, Watch, Record, Audio and WebGuard port
numbers for connections to the transmitter by using the
remote programs or web browser.
Check the Use HTTPS box to enhance the security of
WebGuard pages by using the HTTPS protocol when
running the WebGuard program.
NOTE: Do NOT use the same port number for more than
one function, or else, the transmitter cannot be connected
with the remote programs.
CAUTION: When changing the port settings, you must change the port settings on remote
programs too.

Four-Channel Video Transmitter
13
Bandwidth Control
You can control the network bandwidth by limiting the
network bandwidth depending on the network traffic.
Check the Network bandwidth limit box and set the
desired maximum bandwidth.
NOTE: When limiting the network bandwidth, the frame
rate might decrease to lower than the frame rate set
during the 3.4 Video – Live Monitoring setup.
Security
IP Filtering: Check the box to use the IP filtering
function. You can allow or block connections to the
transmitter by designating IP addresses.
−Add: Click the button to add IP addresses to the Allow
List or Deny List to allow or block connection to the
transmitter. Selecting the Host option allows you to add
one IP address at a time. Selecting the Group option
allows you to add continuous IP address numbers in one
action by designating a range of IP addresses to add.
−Remove, Remove All: Click the button to remove the
selected IP address or all IP addresses from Allow List
or Deny List.
SSL: Check the box to use the SSL function. You can enhance the security of data transmitted to
remote systems by using the SSL (Secure Sockets Layer) protocol. When using the SSL function,
the transmitter cannot be connected with a remote program or a network keyboard which does not
support the SSL function.
NOTES:
If you want to use the time synchronization, DVRNS and Email sending functions, the connection of
the IP addresses of the time server, DVRNS server and the SMTP server must be allowed when you
set up the IP filtering function. Any connection to the transmitter from the IP address in Deny List
will NOT be allowed.
Using the SSL function might cause system congestion in the remote system depending on the security
level.
This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit
(http://www.openssl.org/)

User’s Manual
14
3.4 Video
You can set camera features, image transmission parameters for both remote
monitoring and webcasting, and Output OSD (on-screen display).
Camera
Settings
−No.: Check the box to use the camera input.
−Title: Enter the camera name.
−Use: Select the way camera video is displayed on the
screen. Selecting Normal displays video and OSD
information on the screen. Selecting Covert 1 displays
only OSD on the screen but no video. Selecting Covert 2,
neither video nor OSD information displays, and the
camera input appears to be unused.
PTZ: Set up when a PTZ camera is connected to the
transmitter.
−Product: Choose a PTZ model.
−ID: Assign an ID number to the PTZ camera.
−Port Setup…: Click the button to set up the baud rate,
data bit, stop bit and parity by referring to the PTZ camera
manufacturer’s instructions.
NOTES:
When the user has the Covert Camera View authority and connects to the transmitter via the remote
programs, both video and OSD information are displayed on the screen regardless of the Settings –
Use setting. Refer to the 3.2 System – User/Group settings for details on the Covert Camera View
authority setup.
You will not be able to control a PTZ camera if it is not connected to the RS485 port properly. See
Chapter 2 – Installation; 2.3 Rear Panel Connectors, RS485 Port and the PTZ camera manufacturer’s
manual for configuring the RS485 connection.
