Contera®Outdoor Dome
Installation Manual
1080p
5MP
AV02CLD-100
AV05CLD-100

2
Contera Outdoor Dome | Installation Manual
Table of Contents
About Our Warranty ................................................................................................................................... 3
Global (3 Year) Limited Warranty ............................................................................................................ 3
Camera Overview....................................................................................................................................... 4
Package Contents...................................................................................................................................... 5
Installation .................................................................................................................................................. 6
Surface Mount...................................................................................................................................... 10
Wall Mount ........................................................................................................................................... 12
Pendant Mount .................................................................................................................................... 14
Pole Mount........................................................................................................................................... 16
Corner Mount....................................................................................................................................... 18
Electrical Box Adapter .......................................................................................................................... 20
SD Card ............................................................................................................................................... 20
Adjusting the Pan, Tilt and Focus ......................................................................................................... 21
Camera Power Up.................................................................................................................................... 23
Alarm I/O Functions.................................................................................................................................. 24
Audio Kit AV-1AK Installation Instructions................................................................................................. 25
Reset to Factory Default........................................................................................................................... 26
Camera Discovery, Setup, and Configuration ........................................................................................... 27
Camera Discovery ................................................................................................................................ 27
Web Interface Navigation ..................................................................................................................... 28
Zoom and Focus .................................................................................................................................. 30
Image ................................................................................................................................................... 31
Video & Audio ...................................................................................................................................... 36
Network ............................................................................................................................................... 39
Privacy Mask........................................................................................................................................ 44
Event.................................................................................................................................................... 45
System Options.................................................................................................................................... 50
Administration ...................................................................................................................................... 51
About ................................................................................................................................................... 53

3
Contera Outdoor Dome | Installation Manual
About Our Warranty
Global (3 Year) Limited Warranty
ARECONT VISION warrants to Purchaser (and only Purchaser) (the “Limited Warranty”), that: (a) each
Product shall be free from material defects in material and workmanship for a period of thirty-six (36) months
from the date of shipment (the “Warranty Period”); (b) during the Warranty Period, the Products will materially
conform with the specification in the applicable documentation; (c) all licensed programs accompanying the
Product (the “Licensed Programs”) will materially conform with applicable specifications. ARECONT VISION
warrants to Purchaser (and only Purchaser) (the “Limited Warranty”), that: (a) each Product shall be free from
material defects in material and workmanship for a period of thirty-six (36) months from the date of shipment
(the “Warranty Period”); (b) during the Warranty Period, the Products will materially conform with the
specification in the applicable documentation; (c) all licensed programs accompanying the Product (the
“Licensed Programs”) will materially conform with applicable specifications.
ARECONT VISION warrants to Purchaser (and only Purchaser) (the “Limited Warranty”), that: (a) each
Product shall be free from material defects in material and workmanship for a period of thirty-six (36) months
from the date of shipment (the “Warranty Period”); (b) during the Warranty Period, the Products will materially
conform with the specification in the applicable documentation; (c) all licensed programs accompanying the
Product (the “Licensed Programs”) will materially conform with applicable specifications.
During the Warranty Period, the Products will materially conform with the specification in the applicable
documentation; (c) all licensed programs accompanying the Product (the “Licensed Programs”) will materially
conform with applicable specifications.

4
Contera Outdoor Dome | Installation Manual
Contera Outdoor Dome IP Megapixel Cameras
Camera Overview
The Contera®Outdoor Dome megapixel camera features 1080p and 5-megapixel (MP) resolution for
optimum performance. The Contera Outdoor Dome combines a day/night mechanical IR cut filter with an
integrated motorized remote focus and zoom precision iris (P-iris) lens for excellent, optimal image quality.
Regardless of the time of day, the Contera Outdoor Dome is prepared for any lighting condition. For
applications with poor lighting conditions, Enhanced WDR™ (wide dynamic range) at 120dB provides the
best visual balance to shaded and bright light conditions.
For clear color images in low-light, NightView™ offers strong low-light sensitivity for capturing details in
extremely poor-lit scenes. Built-in Smart IR LED illumination automatically adjusts output in response to the
distance of an object in view to prevent over-exposure when the object is very close to the camera. Arecont
Vision® was the first to bring H.264 to the mainstream market and recently developed SNAPstream™
(Smart Noise Adaptation and Processing) technology for reducing bandwidth without impacting image
quality. Today we are proud to offer our next generation H.265 with SNAPstream+™ smart codec capable of
delivering high quality video while saving over 50% of the data rate to reduce or prevent strain on the
network.
The SD card slot supports up to 256GB of storage capacity for convenient onboard storage. The camera’s
power can be supplied via a Power-over- Ethernet (PoE - IEEE 802.3af) compliant network cable connection.
The Contera Outdoor Dome is IP66 rated for both indoor and outdoor applications. All models feature an
impact resistant cast-aluminum housing capable of withstanding the equivalent of 55 kg (120 lbs) of force.
The Contera Outdoor Dome is ONVIF (Open Network Video Interface Forum) Profile S and G compliant,
providing interoperability between network video products regardless of manufacturer.

5
Contera Outdoor Dome | Installation Manual
CAUTION!
1. Do not attempt to service a damaged unit yourself. Refer all servicing to qualified service personnel.
2. Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and with all
local codes and authorities having jurisdiction. Wiring should be UL Listed and/or Recognized wire
suitable for the application.
3. Always use hardware e.g. screws, anchors, bolts, locking nuts etc. which are compatible with mounting
surface and of sufficient length and construction to insure a secure mount.
Package Contents
•AV02CLD-100/ AV05CLD-100
Description
QTY
AV02CLD-100/ AV05CLD-100 IP camera 1
Mounting Template 1
Accessory Pack 1

6
Contera Outdoor Dome | Installation Manual
Installation
1. Determine a secure location to mount the camera.
2. Use the supplied security L-key, to loosen the four (4) screws securing the dome cover.
3. Remove the dome cover and protective foam. Do not remove screws from the dome cover.
The Contera®Outdoor Dome camera has been designed to provide installers with flexible mounting
options such as ceilings, walls, poles or corners.
NOTE: When mounting the camera outdoors or in a wet environment, useof supplied
grommet is recommended. Ensure the grommet properly seated flush with the camera
housing.
NOTE: The camera issuggested tobe covered bya minimum 5.6” (14cm) overhang eave.

7
Contera Outdoor Dome | Installation Manual
Ensure you have the proper compatible mounting parts prior to starting your installation:
Pendant mount
Wall mount
Reference #
Pendant Mount Components Required
1 Pendant mount (AV-PMJB) with integrated junction box
2 Contera®Outdoor Dome camera
3 MD-CAP-W mounting cap

8
Contera Outdoor Dome | Installation Manual
Pole mount
Corner mount
Reference #
Wall Mount Components Required
1
Wall mount (AV-WMJB-W) with integrated junction box
2
Contera®Outdoor Dome camera
3
MD-CAP-W mounting cap
Reference #
Pole Mount Components Required
1 Wall mount (AV-WMJB-W) with integrated junction box
2 MD-CAP-W mounting cap
3 Contera®Outdoor Dome camera
4 AV-PMA corner mount adapter

9
Contera Outdoor Dome | Installation Manual
Reference #
Corner Mount Components Required
1 Wall mount (AV-WMJB-W) with integrated junction box
2 MD-CAP-W mounting cap
3 Contera®Outdoor Dome camera
4 AV-CRMA corner mount adapter

10
Contera Outdoor Dome | Installation Manual
Surface Mount
The Contera®Outdoor Dome camera can be directly attached onto hard ceilings or walls including wood,
plastic, metal and concrete.
1. Use the template, anchors, and screws provided to prepare the mounting provisions for the camera
installation.
2. Use the supplied security L-key, to loosen the four (4) tamper resistant screws securing the dome
cover. Do not remove screws from the dome cover.
3. Remove the protective foam and discard.
4. Install four supplied dry wall anchors using the supplied mounting template.
5. Align four supplied screws (4pcs #8-16 1¼” tapping screws) with the dry wall anchors and screw
mounting plate into place.
6. Prepare the network cable with the supplied grommet and insertion tool.

11
Contera Outdoor Dome | Installation Manual
NOTE: When mounting the camera outdoors or in a wet environment, use of supplied grommet is
recommended. Ensure the grommet is properly seated flush with the camera housing.
7. Align the hole on the camera with the hole on mounting plate, and install the grommet on camera
housing.
NOTE: If using the side connection of the NPT port, you need to install the supplied grommet
without a through hole on the camera housing, and remove the cap covering the side entrance,
otherwise; leave the cap in place. If using the NPT port, always use Teflon tape around the threads
to ensure proper sealing. The conduit fits ¾” NPT standard. Ensure NPT port is facing downward.
8. Fasten securely four captive screws.
9. Attach the Dome Cover to the Contera®Outdoor Dome camera and fasten securely four captive
screws.
10. To configure the camera, reference the camera discovery, set-up and configuration section.
CAUTION!
The captive screws must be used to properly secure the dome cover and camera housing. Failure to use the
captive fastener may result in serious injury. When mounting the dome cover to the camera housing, ensure
that the gasket is properly seated and not folded. Failure to do so may result in water and dust ingress.
Water damage from improper installation is not covered by the warranty!

12
Contera Outdoor Dome | Installation Manual
Wall Mount
For a proper wall mount installation, the AV-WMJB-W wall mount and MD-CAP-W wall mount cap are
required (sold separately). A wall mount should only be attached onto hard ceilings including wood, plastic,
metal, and concrete.
1. Using the Mounting template, prepare the mounting provisions for the camera installation.
2. Connect wall mount cap and wall mount.
NOTE: The thread size for Top shield, pendant pole and mount is 1.5” NPT.
3. Attach the wall mount to the wall using the four drywall screws provided or any optional hardware
suitable for the mounting surface.
4. Run the Ethernet Cable and outside power cable (if necessary) through the supplied rubber gasket
and then through the wall mount. Ensure the gasket is seated properly.
5. Attach the mounting plate to the MD-CAP-W with the supplied screws.
6. Prepare the network cable with the supplied grommet and insertion tool.
NOTE: When mounting the camera outdoors or in a wet environment, use of supplied grommet is
recommended. Ensure the grommet is properly seated flush with the camera housing.

13
Contera Outdoor Dome | Installation Manual
7. Align the hole on the camera with the hole on mounting plate, and install the grommet on camera
housing.
8. Fasten securely four captive screws.
9. Attach the Dome Cover to the Contera®Outdoor Dome camera and fasten securely four captive
screws.
10. To configure the camera, reference the camera discovery, set-up and configuration section.
CAUTION!
The captive screws must be used to properly secure the dome cover and camera housing. Failure to use the
captive fastener may result in serious injury. When mounting the dome cover to the camera housing, ensure
that the gasket is properly seated and not folded. Failure to do so may result in water and dust ingress.
Water damage from improper installation is not covered by the warranty!

14
Contera Outdoor Dome | Installation Manual
Pendant Mount
For a proper pendant mount installation, the AV-PMJB pendant mount and MD-CAP-W mounting cap are
required (sold separately). A pendant mount should only be attached onto hard ceilings including wood,
plastic, metal, and concrete.
1. Using the Mounting template, prepare the mounting provisions for the camera installation.
2. Connect the cap, pendant pole and mount together.
NOTE: The thread size for Top shield, pendant pole and mount is 1.5” NPT.
3. Attach the pendant mount to the ceiling using the four wood screws provided or any optional
hardware suitable for the mounting surface.
4. Run the Ethernet Cable and outside power cable (if necessary) through the supplied rubber gasket
and then through the wall mount. Ensure the gasket is seated properly.
5. Attach the mounting plate to the MD-CAP-W with the supplied screws.
6. Prepare the network cable with the supplied grommet and insertion tool.
NOTE: When mounting the camera outdoors or in a wet environment, use of supplied grommet is
recommended. Ensure the grommet is properly seated flush with the camera housing.

15
Contera Outdoor Dome | Installation Manual
7. Align the hole on the camera with the hole on mounting plate, and install the grommet on camera
housing.
8. Fasten securely four captive screws.
9. Attach the Dome Cover to the Contera®Outdoor Dome camera and fasten securely four captive
screws.
10. To configure the camera, reference the camera discovery, set-up and configuration section.
CAUTION!
The captive screws must be used to properly secure the dome cover and camera housing. Failure to use the
captive fastener may result in serious injury. When mounting the dome cover to the camera housing, ensure
that the gasket is properly seated and not folded. Failure to do so may result in water and dust ingress.
Water damage from improper installation is not covered by the warranty!

16
Contera Outdoor Dome | Installation Manual
Pole Mount
For a pole mount installation, the AV-WMJB-W wall mount, AV-PMA pole mount, and MD-CAP-W
mount cap are required (sold separately). A pole mount should only be attached onto hard ceilings
including wood, plastic, metal, and concrete.
1. Using the Mounting template, prepare the mounting provisions for the camera installation.
2. Connect the wall mount cap and wall mount.
3. Attach the Junction Box Adapter to the Pole Mount Adapter.
4. Remove the conduit plug on the junction box adapter and connect ¾” NPT conduit to the junction
box adapter.
NOTE: Use silicon or water pipe seal tape to make sure no water leakage between conduit
pipe and junction box adapter.
5. Run the Ethernet cable and outside power cable (if necessary) through the Junction Box Adapter.
Ensure the gasket is seated properly.
6. Attach the Wall Mount Adapter (AV-WMJB-W) to the Pole Mount Adapter (AV-PMA) .
Reference #
Description
1 Remove conduit plug
2 Connect ¾” NPT conduit to junction box adapter
(ensure use of water seal tape)

17
Contera Outdoor Dome | Installation Manual
7. Use the supplied two Steel Straps to attach the Pole Mount Adapter to the pole and tighten the
compression screws.
8. To attach the camera to the Wall Mount Adapter (AV-WMJB-W), reference the Installation and Wall
Mount section.
9. To configure the camera, reference the camera discovery, set-up and configuration section.
CAUTION!
The captive screws must be used to properly secure the dome cover and camera housing.
Failure to use the captive fastener may result in serious injury. When mounting the dome cover to the camera
housing, ensure that the gasket is properly seated and not folded. Failure to do so may result in water and
dust ingress. Water damage from improper installation is not covered by the warranty!
Reference #
Description
1 Steel straps with compression screws
2 AV-WMJB-W wall mount
3 MD-CAP-W mount cap
4 Conduit pipe
5 AV-PMA pole mount adapter
6 Apply Teflon water seal tape to the thread of ¾” NPT pipe to
avoid water leakage

18
Contera Outdoor Dome | Installation Manual
Corner Mount
For a corner mount installation, the AV-WMJB-W wall mount, AV-CRMA corner mount, and MD-CAP-W
mount cap are required (sold separately). A corner mount should only be attached onto hard corner surfaces
including wood, plastic, metal, and concrete.
1. Using the Mounting template, prepare the mounting provisions for the camera installation.
2. Connect the wall mount cap and wall mount.
3. Attach the Junction Box Adapter to the Corner Mount Adapter.
4. Remove the conduit plug on the junction box adapter and connect ¾” NPT conduit to the junction
box adapter.
NOTE: Use silicon or water pipe seal tape to make sure no water leakage between conduit
pipe and junction box adapter.
5. Run the Ethernet cable and outside power cable (if necessary) through the Junction Box Adapter.
Ensure the gasket is seated properly.
6. Attach the Wall Mount Adapter (AV-WMJB-W) to the Corner Mount Adapter (AV-CRMA).
Reference #
Description
1 Remove conduit plug
2 Connect ¾” NPT conduit to junction box adapter
(ensure use of water seal tape)

19
Contera Outdoor Dome | Installation Manual
7. Using the screws provided (or other hardware), attach the Corner Mount Adapter to an exterior 90
degree corner wall.
8. To attach the camera to the Wall Mount Adapter (AV-WMJB), reference the Installation and Wall
Mount section.
9. To configure the camera, reference the camera discovery, set-up and configuration section.
CAUTION!
The captive screws must be used to properly secure the dome cover and camera housing.
Failure to use the captive fastener may result in serious injury. When mounting the dome cover to the camera
housing, ensure that the gasket is properly seated and not folded. Failure to do so may result in water and
dust ingress. Water damage from improper installation is not covered by the warranty!
Reference #
Description
1 Attach corner mount adapter to exterior 90 corner wall
2 AV-WMJB wall mount
3 MD-CAP-W mount cap
4 Conduit pipe
5 AV-CRMA corner mount adapter
6 Apply Teflon water seal tape to the thread of ¾” NPT pipe to
avoid water leakage

20
Contera Outdoor Dome | Installation Manual
Electrical Box Adapter
The mounting plate is used to attach the camera to a common single, double or square electrical box.
1. Using the supplied machine screws, match the mounting holes on the electrical box adapter with the
threaded holes on the electrical box. Ensure every threaded hole is matched with a mounting hole.
2. Attach the electrical box adapter to the user supplied electrical box.
SD Card
Insert an SD card (user supplied) into the SD card slot until it locks in place. The location of the SD card slot
is located on the main board. The SD card can only be set-up via the Web Interface.
Note: Upon insertion or removal of an SD card, the camera must be rebooted.
