CountyLine TS30G-CL Guide

30 GALLON TRAILER SPRAYER
TSC SKU#: 1046832 •VENDOR#:TS30G-CL
ASSEMBLY & OPERATION INSTRUCTIONS MANUAL
SATISFACTION GUARANTEED
DISTRIBUTED BY: TRACTOR SUPPLY COMPANY •200 POWELL PLACE •BRENTWOOD, TN 37027 •WWW.TRACTORSUPPLY.COM •MADE IN U.S.A.

DISTRIBUTED BY: TRACTOR SUPPLY COMPANY •200 POWELL PLACE •BRENTWOOD, TN 37027 •WWW.TRACTORSUPPLY.COM •MADE IN U.S.A.
2
We have done our utmost to ensure that your CountyLine®sprayer will be one of the most
trouble-free and satisfying pieces of equipment that you have ever owned. Please let us know
of any questions you may have. We want to answer them as quickly as possible. When you do
call, please have your order number handy.
For technical assistance, visit our website @ www.FimcoIndustries.com or call TOLL FREE @
1-800-831-0027. Our Technical Support Representatives will be happy to help you. We also
hope to hear from you on how much you like your new helper.
And, please tell your friends about your new CountyLine®sprayer! Having CountyLine®owners
spread the word about our products and our way of doing business is the best advertising we
can have, and the best way to help us provide even better service in the years to come.
Thanks once again!
From all of us at
CONGRATULATIONS ON PURCHASING A
30 GALLON TRAILER SPRAYER!
Distributed By:
Tractor Supply Company
200 Powell Place
Brentwood, TN 37027
www.Tractorsupply.com
Made In U.S.A.

DISTRIBUTED BY: TRACTOR SUPPLY COMPANY •200 POWELL PLACE •BRENTWOOD, TN 37027 •WWW.TRACTORSUPPLY.COM •MADE IN U.S.A. 3
Congratulations! ....................................................................................................................... 2
Tools Needed............................................................................................................................ 4
What’s Inside The Box (Unpacking Your Sprayer) ................................................................... 4
General Information, Warranty & Safety Warnings................................................................... 5
Assembling Your Sprayer ...................................................................................................... 6-8
Testing, Operating & Calibration Instructions ...................................................................... 9-10
Maintenance & Storage...........................................................................................................11
Exploded Views & Parts List.............................................................................................. 12-15
Frequently Asked Questions................................................................................................... 16
Troubleshooting...................................................................................................................... 17
TABLE OF CONTENTS

DISTRIBUTED BY: TRACTOR SUPPLY COMPANY •200 POWELL PLACE •BRENTWOOD, TN 37027 •WWW.TRACTORSUPPLY.COM •MADE IN U.S.A.
4
ASSEMBLY & OPERATION INSTRUCTIONS MANUAL - 30 GALLON TRAILER SPRAYER #1046832
TOOLS NEEDED
• 1/2”Wrench • 9/16”Wrench • PipeSealant
WHAT’S INSIDE THE BOX (UNPACKING YOUR SPRAYER)
(1) Unit assembly, (2) wheels (5021102), (1) axle (5024105), (1) tank lid (5058188),
(1) boom offset tank mount (5095324), (1) hitch tube frame (5100758),
(1) drain plug cap (5274373), (1) 3 nozzle boom assembly (5277750), (1) parts bag (5277762).

DISTRIBUTED BY: TRACTOR SUPPLY COMPANY •200 POWELL PLACE •BRENTWOOD, TN 37027 •WWW.TRACTORSUPPLY.COM •MADE IN U.S.A. 5
ASSEMBLY & OPERATION INSTRUCTIONS MANUAL - 30 GALLON TRAILER SPRAYER #1046832
GENERAL INFORMATION
The purpose of this manual is to assist you in operating and maintaining your lawn & garden trailer
sprayer. Please read it carefully, as it furnishes information which will help you achieve years of trouble-
free operation.
WARRANTY INFORMATION
SAFETY WARNINGS
• Readandunderstandallsafetyandoperating
instructions before using this product.
• Neverallowanyoneunfamiliarwiththesafety
or operating instructions to use this product.
• Becertainthenozzlesareorientedawayfrom
the tow vehicle and operator before activating
the spray.
• Keepchildrenoutofthesprayingareaand
under the watchful care of a responsible adult
• Keeppeopleandpetsatleast100feetaway
and upwind of material being sprayed.
• Usecarewhenapproachingblindcornersor
objects that can obscure your vision.
• Wearappropriateprotectivegearasspecied
in the MSDS information for the material being
sprayed.
• Cleanoutexcessmaterialfromthesprayer
and disconnect the sprayer from the battery
when not in use.
• Checktheareatobesprayedforobjects,
rocks, depressions or uneven terrain that
 couldupsetthesprayunitorcausesignicant
changes to the spray pattern.
• DONOTtamperwiththepressureregulator
switch. It is preset at the factory.
• Neveroperatethesprayerwhileunderthe
 inuenceofdrugs,alcoholormedication.
• Usethesprayeronlyduringdaylighthoursand
times of good visibility
• DONOT,underanyconditions,alterstandard
parts on your sprayer. This could cause
personal injury and will void your warranty.
• Nevertowyoursprayerunitonpublicroadsor
highways.
• Alwaystravelacrossslopes;neverupor
down. DO NOT operate on slopes greater than
15 degrees
• Neverattempttoliftormovethesprayerby
grasping the manifold.
Products are warranted for one year from date of
purchase against manufacturer or workmanship
defects. Commercial users have a 90 day warran-
ty. Your local Tractor Supply Company store is the
best source of replacement parts and service.
Toobtainprompt,efcientservice,alwaysremem-
ber to give the following information...
•CorrectPartDescriptionand/orpartnumber.
•Model#/Serial#ofyoursprayer.
Part descriptions and part numbers can be ob-
tained from the illustrated parts list section(s) of
this manual.
Whenever you need parts or repair service, contact
yourlocalTractorSupplyCompanystorerst.For
warranty work, always take your original sales slip,
or other evidence of purchase date, to your local
Tractor Supply Company store.

DISTRIBUTED BY: TRACTOR SUPPLY COMPANY •200 POWELL PLACE •BRENTWOOD, TN 37027 •WWW.TRACTORSUPPLY.COM •MADE IN U.S.A.
6
ASSEMBLY & OPERATION INSTRUCTIONS MANUAL - 30 GALLON TRAILER SPRAYER #1046832
ASSEMBLING YOUR SPRAYER
Your sprayer has been partially assembled at the factory. Follow the instructions below to
complete the assembly of this unit.
STEP 1
Starttheangescrewsbyhand
to attach the hitch tube frame,
axle supports and trailer frame
strap to the tank. Insert the axle
through the axle supports and
hitch tube, then tighten down all
7angescrews.Thiswillallow
alignment within each assembly
for proper axle installation.
Please note the directional
stickers on the axle supports
and hitch tube for proper
orientation. All three arrows will
be facing the back of the tank,
towards the tank drain.
STEP 2
Slide axle spacers on to
axle (Qty. 2).
STEP 3
Put tires on axle
(Qty. 2).
**1/2”Wrench
Required **

DISTRIBUTED BY: TRACTOR SUPPLY COMPANY •200 POWELL PLACE •BRENTWOOD, TN 37027 •WWW.TRACTORSUPPLY.COM •MADE IN U.S.A. 7
ASSEMBLY & OPERATION INSTRUCTIONS MANUAL - 30 GALLON TRAILER SPRAYER #1046832
STEP 4
Insert hair pins to axle
(Qty. 2). Connect hitch to
hitch tube frame.
STEP 5
Attach boom offset tank
mounttotankwithange
screws. Connect boom to
the boom bracket (Qty. 1)
using the two screws and
nuts from the parts bag.
STEP 6
Insert hose washer into
swivel nut. Connect feeder
hose from boom to the
manifold system (Qty. 1).
Screw the swivel nut onto
the valve.
ASSEMBLING YOUR SPRAYER CONTINUED
**1/2”Wrench
Required **

DISTRIBUTED BY: TRACTOR SUPPLY COMPANY •200 POWELL PLACE •BRENTWOOD, TN 37027 •WWW.TRACTORSUPPLY.COM •MADE IN U.S.A.
8
ASSEMBLY & OPERATION INSTRUCTIONS MANUAL - 30 GALLON TRAILER SPRAYER #1046832
ASSEMBLING YOUR SPRAYER CONTINUED
STEP 7
Thread the gauge onto
the manifold (Qty. 1)
using a good grade
pipe sealant. It is
recommended to use a
9/16”openendwrench.
Do not over tighten.
Screw on lid and hook
up lanyard.
STEP 8
Plug the lead wire assembly into the plug
on the wires to the pump.
Note: There is a switch on the leadwire
and a switch on the pump.
**9/16”Wrench
Required **

DISTRIBUTED BY: TRACTOR SUPPLY COMPANY •200 POWELL PLACE •BRENTWOOD, TN 37027 •WWW.TRACTORSUPPLY.COM •MADE IN U.S.A. 9
ASSEMBLY & OPERATION INSTRUCTIONS MANUAL - 30 GALLON TRAILER SPRAYER #1046832
TESTING YOUR SPRAYER
OPERATING INFORMATION
Your sprayer is equipped with (2) ON/OFF switches.
One is on the wire assembly that you hook up to your
battery, the other is on the pump itself, on the opposite
endofthepressureswitch.The“-”isthe“ON”position
andthe“o”isthe“OFF”positionfortheswitches.Make
surebothswitchesaredepressedinthe“-”positionfor
operation.
InadditiontotheON/OFFswitch,thepumpisequipped
with an electronic pressure switch that is factory pre-set
for it to shut off at 60 p.s.i.. This switch assembly is the
‘square box’ on the head portion of the pump.
Alwaysllthetankwithadesiredamountofwaterrst,
and then add the chemical slowly, mixing as you pour
the chemical into the tank. You may use the handgun to
spray into the solution in order to mix the chemical and
water.
The pumping system draws solution from the tank,
through the strainer/lter, and to the pump. The pump
forcesthesolutionunderpressuretothehandgunand/
or boom nozzles.
• Openthehandgunbysqueezingthehandlelever.
• Rotatingtheadjustablenozzletiponthehandgun
will change the tip pattern from a straight stream to
 aconepattern(nermist).
It is VERY important for you to test your sprayer with
plain water before actual spraying is attempted. This
will enable you to check the sprayer for leaks, with-
out the possibility of losing any expensive chemi-
cals.
Add water to the tank & drive to the starting place for
spraying. When you are ready to spray, turn the boom
valvetothe“on”position.Thiswillstartsolutionspraying
from the tips of the boom. The pressure will decrease
slightly when the boom is spraying. Adjust the pressure
byturningthe“ON/OFF”valveleveronthebypassline
valve.
Read the operating instructions. When everything tests
all right (no leaks, & good pressure), add the desired
chemicals to the mixture and water combination and
start your spraying operation. Adjust the pressure and
spray as you did in the testing procedure.
Conditions of weather and terrain must be considered
when setting the sprayer. Do not spray on windy days.
Protective clothing must be worn in some cases.
Be sure to read the chemical label(s) correctly!
WARNING: Some chemicals will damage the pump
valves if allowed to soak untreated for a length of
time! ALWAYS thoroughly ush the pump with water
after use. DO NOT allow chemicals to sit in the pump
for extended times of idleness. Follow the chemical
manufacturer’s instructions on disposal of all waste
water from the sprayer.

DISTRIBUTED BY: TRACTOR SUPPLY COMPANY •200 POWELL PLACE •BRENTWOOD, TN 37027 •WWW.TRACTORSUPPLY.COM •MADE IN U.S.A.
10
ASSEMBLY & OPERATION INSTRUCTIONS MANUAL - 30 GALLON TRAILER SPRAYER #1046832
CALIBRATING YOUR SPRAYER
Chemical labels may show application rates in gallons
per acre, gallons per 1000 square feet, or gallons per
100 square feet. You will note that the tip chart shows all
3 of these rating systems.
Once you know how much you are going to spray, then
determine (from the tip chart) the spraying pressure
(PSI), and the spraying speed (MPH).
Determining the proper speed of the pulling vehicle can
be done by marking off 100, 200, & 300 feet. The speed
chart indicates the number of seconds it takes to travel
the distances. Set the throttle and with a running start,
travel the distances. Adjust the throttle until you travel
the distances in the number of seconds indicated by the
speed chart. Once you have reached the throttle setting
needed, mark the throttle location so you can stop and
go again, returning to the same speed.
Add water and proper amount of chemical to the tank
and drive to the starting place for spraying.
Tip Chart
Speed in M.P.H. Time Required in Seconds to Travel a distance of;
(Miles Per Hour) 100 ft. 200 ft. 300 ft.
1.0 68.0 136 205
2.0 34.0 68 102
3.0 23.0 45 68
4.0 17.0 34 51
5.0 14.0 27 41
6.0 11.0 23 34
7.0 9.7 19 29
8.0 8.5 17 26
9.0 7.6 15 23
10.0 6.8 14 20
Speed Chart
Tip
Number
Spray
Height
Pressure
(psi)
Capacity
(GPM)
1
MPH
2
MPH
3
MPH
4
MPH
5
MPH
6
MPH
15 0.12 23.50 11.70 7.80 5.90 4.70 3.90
AIXR11002VP 18" 20 0.14 27.50 13.70 9.10 6.90 5.50 4.60
30 0.17 33.30 16.60 11.10 8.30 6.70 5.50
40 0.20 39.30 19.70 13.10 9.80 7.90 6.50
Tip
Number
Spray
Height
Pressure
(psi)
Capacity
(GPM)
1
MPH
2
MPH
3
MPH
4
MPH
5
MPH 
15 0.12 0.54 0.27 0.18 0.13 0.11
AIXR11002VP 18" 20 0.14 0.64 0.32 0.21 0.16 0.13
30 0.17 0.76 0.38 0.26 0.19 0.15
40 0.20 0.90 0.45 0.30 0.22 0.18
30"Spacing
30"spacing
GallonsPerAcreBasedonWater
GallonsPer1000Sq.Ft.BasedonWater

DISTRIBUTED BY: TRACTOR SUPPLY COMPANY •200 POWELL PLACE •BRENTWOOD, TN 37027 •WWW.TRACTORSUPPLY.COM •MADE IN U.S.A. 11
ASSEMBLY & OPERATION INSTRUCTIONS MANUAL - 30 GALLON TRAILER SPRAYER #1046832
MAINTENANCE (AFTER SPRAYING)
Afteruse,llthesprayertankpartwaywithwater.Start
the sprayer, and allow the clear water to be pumped
through the plumbing system and out through the spray
nozzles.
Rellthetankabouthalffullwithplainwaterandusea
chemical neutralizer, such as ‘Nutra-Sol’, or equivalent,
and repeat cleaning instructions above. A mix of water
and some good quality dish detergent would be a suf-
cientalternative.
Flush the entire sprayer with the neutralizing/cleaning
agent, then ush out one more time with plain water.
Follow the chemical manufacturer’s disposal instruc-
tions of all wash or rinsing water.
For the boom, if applicable, remove the tips and screens
from the nozzle assemblies. Wash these components
thoroughly with water or cleaning solution appropriate
forthechemicalbeingused.Blowouttheoriceclean,
anddry. Iforiceremainsclogged,cleanitwithane
bristle (NOT WIRE) brush, or with a toothpick. Do not
damagetheorice.Waterrinseanddrytipsbeforestor-
ing.
WINTER STORAGE
Drain all water out of your sprayer, paying special atten-
tion to the pump, handgun, and valve(s). These items
are especially prone to damage from chemicals and
freezing weather.
The sprayer should be winterized before storage by
pumping a solution of RV antifreeze through the entire
plumbing system. This antifreeze solution should remain
in the plumbing system during the winter months. When
spring time comes and you are preparing your sprayer
for the spray season, rinse the entire plumbing system
out, clearing the lines of the antifreeze solution. Proper
care and maintenance will prolong the life of your spray-
er.

DISTRIBUTED BY: TRACTOR SUPPLY COMPANY •200 POWELL PLACE •BRENTWOOD, TN 37027 •WWW.TRACTORSUPPLY.COM •MADE IN U.S.A.
12
ASSEMBLY & OPERATION INSTRUCTIONS MANUAL - 30 GALLON TRAILER SPRAYER #1046832
EXPLODED VIEWS & PARTS LISTS
TRAILER ASSEMBLY

DISTRIBUTED BY: TRACTOR SUPPLY COMPANY •200 POWELL PLACE •BRENTWOOD, TN 37027 •WWW.TRACTORSUPPLY.COM •MADE IN U.S.A. 13
ASSEMBLY & OPERATION INSTRUCTIONS MANUAL - 30 GALLON TRAILER SPRAYER #1046832
EXPLODED VIEWS & PARTS LISTS CONTINUED
BOOM ASSEMBLY

DISTRIBUTED BY: TRACTOR SUPPLY COMPANY •200 POWELL PLACE •BRENTWOOD, TN 37027 •WWW.TRACTORSUPPLY.COM •MADE IN U.S.A.
14
ASSEMBLY & OPERATION INSTRUCTIONS MANUAL - 30 GALLON TRAILER SPRAYER #1046832
EXPLODED VIEWS & PARTS LISTS CONTINUED
GENERAL TANK ASSEMBLY

DISTRIBUTED BY: TRACTOR SUPPLY COMPANY •200 POWELL PLACE •BRENTWOOD, TN 37027 •WWW.TRACTORSUPPLY.COM •MADE IN U.S.A. 15
ASSEMBLY & OPERATION INSTRUCTIONS MANUAL - 30 GALLON TRAILER SPRAYER #1046832
EXPLODED VIEWS & PARTS LISTS CONTINUED
PUMP ASSEMBLY (5275703)
MANIFOLD ASSEMBLY (5277551)

DISTRIBUTED BY: TRACTOR SUPPLY COMPANY •200 POWELL PLACE •BRENTWOOD, TN 37027 •WWW.TRACTORSUPPLY.COM •MADE IN U.S.A.
16
ASSEMBLY & OPERATION INSTRUCTIONS MANUAL - 30 GALLON TRAILER SPRAYER #1046832
FREQUENTLY ASKED QUESTIONS
WHAT MATERIALS ARE NOT COMPATIBLE WITH MY SPRAYER?
• Thissprayerisdesignedtospraycommonliquidpesticidesmixedinwater.Itisnotcompatiblewith
 petroleumproductssuchasdieselfuel,kerosene,gasolineorotherammableliquids.
• Thissprayerisnotcompatiblewithbleachorothercausticcleaninguids.
• Whenusingwettablepowdersorotherdrysolublepesticides,makesuretollthetank1/2full,premixthe
 pesticideintoaslurryinasmallercontainer,addthistothesprayertankandthenllwithbalanceofthe
needed water. Dry materials should be sprayed as soon as possible and the sprayer should then be
rinsed immediately with clean water.
WHY DOES THE MOTOR NOT RUN?
• Checkforloosewiringconnection.
• Makesureon-offswitchesinboththeleadwireassemblyandonthepumpmotorareintheon
position. – is on, O is off.
• Checkfordefectivepressureswitch.
• Checkforlowvoltageatthepowersupply.
• Systemispressurizedandpressureswitchhasturnedthemotoroff.Squeezetheleveronthe
handgun or open the bypass valve .
WHY DOESN’T THE PUMP PRIME?
• Checkforairleakinsupply/suctionline.
• Checkfordebrisincheckvalveassembly
• Checkfordefectivecheckvalve.
• Checkforcloggedstrainer.
• Checkforcrackinpumphousing.
WHY IS THERE PULSATING FLOW (SURGING)?
• Checkforrestrictionindischargeline,ordebrisinnozzleorice.
• Dischargehoseistoolong.
• Adjustabletiponthehandgunissettotooneofamist.Adjusttipformoreoworslightlyopen
the bypass valve.
WHY DOES THE MOTOR CONTINUE TO RUN AFTER THE DISCHARGE IS SHUT OFF?
• Checkforleakindischargeline.
• Checkfordefectiveordirtycheckvalve
• Checkfordefectivepressureswitch.
WHAT IS THE RECOMMENDED PRESSURE FOR THE TRAILER TIRES?
• 30PSIisrecommended
HOW DO I ADJUST SPRAYING PRESSURE?
• Sprayingpressureisadjustedusingthebypassvalve.Withtheboomonandpumprunning,open
or close the bypass valve to get the desired pressure. With the bypass valve closed, you will get
maximum pressure.
WHY DOES THE FUSE ON MY PUMP BLOW?
• Excessivevoltage.Thepumpisdesignedforusewitha12voltsystemonly.
• Defectivepressureswitch.
• Motorisstuck.
• Defectivewireharness.

DISTRIBUTED BY: TRACTOR SUPPLY COMPANY •200 POWELL PLACE •BRENTWOOD, TN 37027 •WWW.TRACTORSUPPLY.COM •MADE IN U.S.A. 17
ASSEMBLY & OPERATION INSTRUCTIONS MANUAL - 30 GALLON TRAILER SPRAYER #1046832
TROUBLESHOOTING
PUMP WILL NOT START
Check:
• Correctvoltage(±10%)andelectricalconnections
• Fuseorbreaker
• Pressureswitchoperationandcorrectvoltage
at switch
• Rectierormotorforopenorgroundedcircuit
• Lockeddriveassembly
PUMP WILL NOT PRIME
(No discharge with motor running)
Check:
• Debrisinstrainer
• Restriction(kinks)ininlet/outlettubes
• Debrisorswellingininlet/outletvalves
PUMP WILL NOT SHUT OFF
(Output line closed and no leaks)
Check:
• Airtrappedinoutletlineorpumphead
• Correctvoltagetopump
• Debrisinpumpinlet/outletvalves
• Loosedriveassemblyorpumpheadscrews
• Pressureswitchoperations/adjustments
LEAKS FROM PUMP HEAD OR SWITCH
Check:
• Loosescrewsatswitchorpumphead
• Switchdiaphragmrupturedorpinched
• Punctureddiaphragmifuidispresent
PROBLEM / CAUSES AND REMEDIES:

18
30 GALLON TRAILER SPRAYER
TSC SKU#: 1046832 •VENDOR#:TS30G-CL
ASSEMBLY & OPERATION INSTRUCTIONS MANUAL
Distributed By:
Tractor Supply Company
200 Powell Place
Brentwood, TN 37027
www.Tractorsupply.com
Made In U.S.A.
Form 5008367
SATISFACTION GUARANTEED
