Covert Systems Wireless Air Purifier Camera User manual

The limited warranty stated herein is subject to all of the following terms and conditions.
TERMS AND CONDITIONS
1. NOTIFICATION OF CLAIMS: WARRANTY SERVICE: If Purchaser believes that the product is defective in
material or workmanship, then written notice with an explanation of the claim shall be given promptly by
Purchaser to the Manufacturer but all claims for warranty service must be made within the warranty period.
No repair or replacement of any product or part thereof shall extend the warranty period as to the entire
product. The specific warranty on the repaired part only shall be in effect for a period of ninety (90) days
following the repair or replacement of that part or the remaining period of the product parts warranty,
whichever is greater.
2. EXCLUSIVE REMEDY: ACCEPTANCE: Purchaser’s exclusive remedy and the Manufacture’s sole
obligation is to supply all labor necessary to repair any product found to be defective within the warranty
period. Purchaser’s failure to make a claim as provided in paragraph 1 above or continued use of the
product shall constitute an unqualified acceptance of such product and a waiver by Purchaser of all claims
thereto.
3. EXCEPTIONS TO LIMITED WARRANTY: The Manufacturer shall have no liability or obligation to Purchaser
with respect to any product requiring service during the warranty period which is subjected to any of the
following: abuse, improper use, negligence, accident, modification, failure of the end-user to follow the
operating procedures outlined in the user’s manual, failure of the end-user to follow the maintenance
procedures in the service manual for the product, attempted repair by non-qualified personnel, operation of
the product outside of the published environmental and electrical parameters, or if security seal has been
defaced, altered, or removed. The Manufacturer also excludes from warranty coverage products located
outside the United States, and consumable items such as fuses and batteries. Items not manufactured by
Backgrounds Unlimited, Inc but included in system bought by Purchaser are limited to original
manufacturer’s warranty and will be repaired by Backgrounds Unlimited, Inc. on cost of material basis.
4. PROOF OF PURCHASE: The purchaser’s dated invoice must be retained as evidence of the date
of purchase and to establish warranty eligibility.
DISCLAIMER OF WARRANTY
EXCEPT FOR THE FOREGOING WARRANTIES, THE MANUFACTURER HEREBY DISCLAIMS AND EXCLUDES ALL
OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO ANY AND/OR ALL IMPLIED
WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY WARRANTY WITH
REGARD TO ANY CLAIM OF INFRINGEMENT THAT MAY BE PROVIDED IN SECTION 2-312(3) OF THE UNIFORM
COMMERCIAL CODE AND/OR ANY OTHER COMPARABLE STATE STATUE. THE MANUFACTURER HEREBY
DISCLAIMS ANY REPRESENTATIONS OR WARRANTY THAT THE PRODUCT IS COMPATIBLE WITH ANY
COMBINATION OF NON-MANUFACTURER’S PRODUCTS PURCHASER MAY CHOOSE TO CONNECT TO THE
PRODUCT.
LIMITATION OF LIABILITY
THE LIABILITY OF THE MANUFACTURER, IF ANY, AND PURCHASER’S SOLE AND EXCLUSIVE REMEDY FOR
DAMAGES FOR ANY CLAIM OF ANY KIND WHATSOEVER, REGARDLESS OF THE LEGAL THEORY AND
WHETHER ARISING IN TORT OR CONTRACT, SHALL NOT BE GREATER THAN THE ACTUAL PURCHASE PRICE
OF THE PRODUCT WITH RESPECT TO WHICH SUCH CLAIM IS MADE. IN NO EVENT SHALL THE
MANUFACTURER BE LIABLE TO PURCHASER FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES OF ANY KIND INCLUDING, BUT NOT LIMITED TO, COMPENSATION,
REIMBURSEMENT OR DAMAGES ON ACCOUNT OF THE LOSS OF PRESENT OR PROSPECTIVE PROFITS OR
FOR ANY OTHER REASON WHATSOEVER.
5
Wireless Covert Systems
Wireless Air Purifier Camera
User’s Manual
FCC Part 15
2.4 GHz Wireless
Wireless Air Purifier Camera
FCC Part 15
“See what you’ve been missing!!”

INTRODUCTION
Congratulations, and thank you for purchasing the
Wireless Air Purifier Camera surveillance unit. This
totally contained surveillance system is designed and
manufactured using stringent standards and
customer input. Features Include:
•FCC-approved 2.4 GHz transmitter and receiver
•High resolution camera
•Easy installation
•User-friendly operation
As you read through this manual, please keep in mind
your system has been rigorously inspected for utmost
quality assurance prior to shipment.
About the Wireless Air Purifier Camera
The Wireless Air Purifier Camera
combines a tiny video camera and FCC-approved
video transmitter with an otherwise ordinary air
purifier. The result is an extremely powerful
surveillance tool. Whether you are gathering
evidence, furthering an investigation, or simply
seeking peace of mind, the Wireless Air Purifier
Camera will accomplish your goals.
NOTICE: Do not use this unit as your sole air
purifier. Although the unit is fully functional, is it
not guaranteed to perform to the standards of
an unaltered purifier unit.
i
Important Safety Precautions
•To prevent fire or shock hazard, do not expose this
product to rain or moisture. Do not use near a bath
tub, sink, washing machine, or swimming pool. Avoid
locations such as wet basements or any other area
where moisture may cause electric shock.
•To avoid electrical shock, do not attempt to open the
air purifier case.
•Operate the Wireless Air Purifier Camera using only
the included power supply.
•Do not overload electrical outlets or extension cords
as this can result in fire or electric shock.
•Refer servicing to qualified personnel.
Warranty Information
The manufacturer warrants their products to be free from
defects in material or workmanship for a period of ninety
(90) days from the date of original purchase.
Exceptions on selected products are as follows:
Product Warranty Coverage
Consumer products 1 year
Pro Consumer Products 2 years
Law Enforcement Grade Products 2 years
If a product has to be returned for repair, it should be re-
turned either in its original carton or similar packaging af-
fording an equal degree of protection. All freight costs
associated with replacement or repair of products are the
responsibility of the Purchaser. The Manufacturer is not
obligated to provide the Purchaser with a substitute unit
during the warranty period or at any time thereafter.
4

Using a Recorder
If you wish to record the footage from your camera, you will need
to connect your receiver unit to a VCR or other video recorder as
follows:
1. Using the supplied RCA cable, connect one end to the video
output on the rear of the receiver unit. (See Figure 1.) Con-
nect the other end of the RCA cable to the video input jack
on your recorder according to the manufacturer’s instruc-
tions.
2. Change the video input for your recorder accordingly. (See
Figure 2.)
3. Use a monitor to assure that your video footage is reaching
the recorder. Connect the recorder to the monitor using the
recorder’s “video out” jack.
4. Your monitor should display the view from your camera.
Make any necessary adjustments to your receiver antenna
for best reception.
Locating the Video Input Button
Depending on the make and model of your monitor or recorder,
the video input button is usually located on the remote control or
on the front panel of the unit itself. However, some units require
you to select your video input within the on-screen menu. The
diagram below shows some examples of remote controls with a
video input button. For additional information, consult the
owner’s manual for your monitor or recorder.
Figure 2
3
General . . . . . . . . . . . . . 1
Pre-Operation . . . . . . . . . . 1
Deployment . . . . . . . . . . . 1
Options . . . . . . . . . . . . . 1
Operation . . . . . . . . . . . . 2
Using a Monitor . . . . . . . . . 2
Using a Recorder . . . . . . . . 3
Safety Precautions . . . . . . . 4
Warranty Information . . . . . . 4
Table of Contents
NOTE: In accordance with United States Codes, this unit
is not equipped with audio capabilities. It is illegal for
non-authorized persons to own, possess, or utilize surrep-
titious listening devices for the purpose of intercepting
and/or recording another person’s oral communications.
Any modifications made to this unit are unauthorized and
will immediately void the Manufacturer’s Warranty.
THIS EQUIPMENT HAS BEEN TESTED AND HAS BEEN FOUND TO BE IN COMPLI-
ANCE WITH THE LIMITS FOR A CLASS B DIGITAL DEVICE, PURSUANT TO PART 15 OF
THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PRO-
TECTIONS AGAINST HARMFUL INTERFERENCE IN A RESIDENTIAL INSTALLATION.
THIS EQUIPMENT USES, GENERATES AND CAN RADIATE RADIO FREQUENCY EN-
ERGY AND, IF NOT INSTALLED AND USED IN ACCORDANCE WITH INSTRUCTIONS,
MAY CAUSE HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS.
Part 15 Low Power:
ANY CHANGES OR MODIFICATIONS TO THIS EQUIPMENT WITHOUT THE
EXPRESS AUTHORIZATION OF THE MANUFACTURER COULD VOID THE
USER’S AUTHORITY TO OPERATE THIS EQUIPMENT. (RULE 15.21 OF THE
FCC)
FCC ID Number NH5FWVTXBD01A
ii

General
The transmitting antenna, also known as a “directional
antenna,” is located at the bottom of the unit facing up and
should be oriented with the receiver for optimal performance.
The 2.4 GHz antenna on the receiver is designed to pivot in vari-
ous directions for easier alignment. Although the unit will still
work properly without the units facing each other, the transmis-
sion range may be decreased.
Pre-Operation
1. Read this manual thoroughly!
2. Determine the best possible site selection based upon your
situation. Pay particular attention to lighting. It is always
best to have the lighting on or in front of your subject in-
stead of behind it.
Deployment
1. Place the Air Purifier unit on a flat surface or mount accord-
ing to the included Air Purifier manual. The camera is lo-
cated at the front of the unit and should face your target
area.
2. The AC/DC adapter for the air purifier unit is enclosed in the
box with the receiver and labeled accordingly. Using this
adapter, plug the unit into the nearest 110 ~ 115 Volt AC
outlet.
3. Determine the placement for your receiver unit and use the
supplied AC/DC power adapter to plug into the nearest
110~115 Volt AC outlet. Make sure the receiver switch is in
the “ON” position.
Options
If your unit was ordered with channel-select capability, you can
change the transmitting channel.
1. Find the channel select button on the bottom of the unit.
You must first press the tab and remove the bottom panel
1
from the unit. The small, black channel select button is
located on the internal white inlaid panel. The unit is ini-
tially set to channel 1. Push the button once for channel 2,
twice for channel 3, or three times for channel 4.
2. Locate the desired channel on the Receiver by pushing the
button located on the top of the receiver unit.
3. Once your receiver unit is properly connected to your moni-
tor or recorder, you will need to verify that an image is re-
ceived from the camera. This will indicate that the camera
and the receiving unit are properly set on the same chan-
nel.
Operation
Once your Wireless Air Purifier Camera is in place and aligned
with your receiving unit, you must connect your receiving unit
to a monitor and/or recorder to gain access to your video foot-
age.
Using a Monitor
If you wish only to view your video using a standard monitor or
television, you will need to connect your receiver directly to you
monitor as follows:
1. Using the supplied RCA cable, connect one end to the video
output on the rear of the receiver unit. (See Figure 1.) Con-
nect the other end of the RCA cable to the video input jack
on your monitor or television.
2. Change the video input for your monitor accordingly. (See
Figure 2.)
3. Your monitor should display the view from your camera.
Make any necessary adjustments to your receiver antenna
for best reception.
Video out to monitor or recorder
12 Volt DC power in
Figure 1
2
