CRAFTSMAN 3/8 in.
19.2 VOLT CORDLESS DRILL-DRIVER
MODEL NO. 315.116890
REPAIR SHEET

19.2V 3/8 in. CORDLESS DRILL-DRIVER – MODEL NUMBER 315.116890
2
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your DRILL-DRIVER or when ordering repair parts.
?
Charging
(15 min.)
Ecaluating
2
14
3
KEY PART
NO. NUMBER DESCRIPTION QTY.
PARTS LIST
1 6612001 SCREW (SPECIAL)..........................................................................................1
2 670743001 CHUCK............................................................................................................1
3 940045280 DATA LABEL....................................................................................................1
4 940114217 LOGO LABEL ..................................................................................................1
5 130279005 BATTERY PACK (Item No. 911375) .................................................................1
6 140107001 CHARGER .......................................................................................................1
7 6782045 DOUBLE ENDED BIT (#2 PHILLIPS HEAD & #6 SLOTTED) ...........................1
5
6
7

FIGURE A
19.2V 3/8 in. CORDLESS DRILL-DRIVER – MODEL NUMBER 315.116890
3
1
2
3
4
7
8
9
18
16
11
10
12
13
14
15
17
5
2
20
6
19

1 660208052 SCREW (M4 x 16 mm).............................................................. 8
2 200858001 HOUSING ASSEMBLY ............................................................. 1
3 6320601 BIT CLIP ................................................................................... 1
4 340136001 FORWARD/REVERSE SELECTOR ........................................... 1
5 660203054 SCREW (M3 x 18 mm).............................................................. 4
6 6375301 CLUTCH RETAINER ................................................................. 1
7 6392201 SPRING PLATE......................................................................... 2
8 5434609 SPRING HOLDER..................................................................... 1
9 3801103 CLUTCH CAP ........................................................................... 1
10 5501403 SLEEVE..................................................................................... 1
11 6872401 TORQUE CONTROL SPRING .................................................. 1
12 6710501 CLUTCH WASHER (0.8 mm) .................................................... 1
13 6843505 CLUTCH PIN ............................................................................ 8
14 6722001 BALL (4.0 mm).......................................................................... 8
15 220089001 GEAR BOX ASSEMBLY............................................................ 1
16 270001452 SWITCH ASSEMBLY ................................................................ 1
17 6621106 SCREW (M3 x 6 mm)................................................................ 2
18 6702801 SPRING WASHER (5.5 mm) ..................................................... 2
29 230040011 MOTOR ASSEMBLY................................................................. 1
20 300480006 REAR LEVEL ASSEMBLY ......................................................... 1
987000433 OPERATOR’S MANUAL (960931339)
1-4-11
(REV:03)
19.2V 3/8 in. CORDLESS DRILL-DRIVER – MODEL NUMBER 315.116890
4
PARTS LIST FOR FIGURE A
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your DRILL-DRIVER or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION QTY.

SWITCH
MOTOR
BLACK LEAD
BLACK LEAD
WIRING DIAGRAM
RED LEAD
YELLOW LEAD
BLUE LEAD
BLACK LEAD RED LEAD
19.2V 3/8 in. CORDLESS DRILL-DRIVER – MODEL NUMBER 315.116890
5
