Craftsman 247.28902 User manual

Sears Brands Management Corporation, Hoffman Estates, IL 60179 U.S.A.
Visit our website: www.craftsman.com
Operator’s Manual
LAWN TRACTOR
19.5 HP, 42” Deck
Electric Start, 7 Speed
Model No. 247.28902
®
For answers to your questions about
this product, Call:
1-800-659-5917
Craftsman Tractor Help Line
7 am - 7 pm CT, Mon. - Sun.
This product has a low emission engine which operates differently
from previously built engines. Before you start the engine, read and
understand this Operator’s Manual.
• Espanol, P. 59
CAUTION
Before using this equipment,
read this manual and follow
all safety rules and operating
instructions.
Form No. 769-05571A
(February 15, 2010)

29
Labels
777I22455
777I22454
PA RK
BRAKE
PARK BRAKE OPER ATION:
1st.
Press
Brake
Pedal
2nd.
Move
Lever
To Park
Place Lever Fully To Run
Position To Operate Unit.
I23366 AC
7
6
5
4
3
2
1
777I22456
FAST
CHOKE
SLOW
F
FORWARD
NEUTRAL
REVERSE
N
R
777I22453
777S32491
1
2
3
4
5
PTO / BLADE ENGAGE
PTO OFF
PTO ON
ROTATING BLADES CAUSE
SERIOUS INJURY OR DEATH
• DO NOT MOW WHEN CHILDREN OR OTHERS ARE
AROUND
•
NEVER CARRY CHILDREN EVEN WITH BLADE(S) OFF.
• LOOK DOWN AND BEHIND BEFORE AND WHILE
BACKING.
• MOWING IN REVERSE IS NOT RECOMMENDED.
DANGER
TO AVOID SERIOUS INJURY OR DEAT H
• GO UP AND DOWNSLOP ES, NOT ACROSS.
• AVOID SUDDEN TURNS.
• DO NOT OPERATE THE UNIT WHERE IT COULD SLIP OR TIP.
• IF MACHINE STOPS GOING UPHILL, STOP BLADE(S)
AND BACK DOWNHILL SLOWLY.
• KEEP SAFETYDEVICE S (GUARDS, SHIELDS, AND
SWITCHES, ETC.) IN PLACE AND WORKING.
• REMOVE OBJECTS THAT COULD BE THROWN BY THE BLADE(S).
• KNOW LOCATIONAND FUNCTION OF ALL CONTROLS.
• BE SURE BLADE(S)AND ENGINE ARE STOPPED BEFORE
PLACING HANDS OR FEET NEAR BLADE(S).
• BEFORE LEAVING OPERATOR'S POSITION, DISENG AGE
BLADE(S), ENGAGE PARKING BRAKE, SHUT OFF A ND
REMOVE KEY.
READ OPERAT OR'S MANUAL
BRAKE / CLUTCH
PEDAL
P
Brake / Clutch Pedal On Drivers Left Side Of Rider
1. PLACESHIFT LEVER IN NEUTRAL.
2. RESTARTENGINE.
3. PLACESPEED CONTROL LEVER
INHIGH SPEED POSITION.
4. RELEASECLUTCH-BRAKE PEDAL
FULLY.
IF UNIT STALLSWITH SPEED CONTROL IN HIGH SPEED, OR IF UNIT
WILL NOT OPERATEWITH SPEED CONTROL LEVER IN A LOW SPEED
POSITION, PROCEED AS FOLLOWS:
5. DEPRESSCLUTCH-BRAKE PEDAL.
6. PLACESPEED CONTROL LEVER
INDESIRED POSITION.
7. PLACESHIFT LEVER IN EITHER
FORWARD OR REVERSE AND FOLLOW
NORMALOPERATING PROCEDURES.
Operation Of This Equipment May Create Sparks That Can Start
Fires Around Dry Vegetation. A Spark Arrestor May Be Required.
The Operator Should Contact Local Fire Agencies For Laws Or
Regulations To Fire Prevention Requirements.
For A List Of Optional Attachments,
Please Refer To Your OperatorsManual.
TO START
OPERATING MODES
1. DISENGAGE BLADES/PTO, (POWER TAKEOFF)
2. ENGAGE THE TRACTOR’S PARKINGBRAKE.
3. ACTIVATE THE CHOKE CONTROL.
4. TURN KEY TO STARTENGINE. AFTER STARTRELEASE KEY & DEACTIVATE CHOKE
BY PLACING THROTTLE TO
FAST“RABBIT”
POSITION.
REVERSECAUTION MODE
1. TURN KEY TO REVERSE CAUTION MODE POSITION.
2. DEPRESS REVERSE PUSHBUTTON.(RED INDICATOR LIGHT “ON”)
WHEN RED LIGHT IS “ON” MACHINE CAN BE OPERATED
IN REVERSE WITH MOWER BLADES ENGAGED.
IMPORTANT:MOWING IN REVERSE IS NOT RECOMMENDED.
3. AFTER RESUMING FORWARD OPERATION, RETURN
KEY TO “NORMAL MOWING” POSITION.
NOTE: IN BOTH MODES, WHEN OPERATOR LE AVES SEAT,
ENGINE WILL STOP UNLESS PARKING BRAKE IS SET AND
BLADES ARE DISENGAGED.
NORMAL MOWING
YOU MUST DISENGAGE BLADES/PTO, (POWERTA KEOFF)
BEFORE TRAVELING IN REVERSE.
777I22773
COLORS
FORMAT #
BLACK / MTD RED
NOTICE
STEERING WHEEL
MOUNTING HARDWARE
UNDER CAP, BEFORE
OPERAT ION SECURE
STEERING WHEEL TO
SHAFT ACCORDING
TO MANUAL
777X43688
T
O
A
V
O
I
D
E
N
G
I
N
E
D
A
M
A
G
E
DO NOT
USE E85 OR FUEL
CONTAINING MORE
THAN 10% ETHANOL
REF: 751B278856
777I23092
777S30018
DANGER
KEEP HANDS AND FEET AWAY.
DO NOT OPERATE MOWER
UNLESS CHUTE DEFLECTOR
OR ENTIRE GRASS CATCHER IS
IN ITS PROPER PLACE.
ASSEMBLE CHUTE DEFLECTOR TO THIS UNIT BEFORE OPERATING.
S30503
777S30503
777D14483
777D14482
(QTY 2) 777D14489
777X44381
Center Below Seat
777D14479
ENGINE
®
19.5 HP
REF. 777D14476 (QTY 3)

30
PARTS LIST
Craftsman Model 247.28902
A
A
8
12
15
5
21
22
22
33
34
4
29
37
30
32
3
18
30 30
25
17
45
36
35
38
39
2
13
16
20
4
28
26
24
2327
40
41
43
44
42
31
7
14
7
3
7
11
6
1
46
9
10
19

31
PARTS LIST
Craftsman Model 247.28902
Ref.
No. Part No. Description
1925-1649 Bulb Socket
2683-04619-4043 Hood Assembly
3710-04484 Screw, 5/16-18 x .750
4710-0599 Hex Washer Screw, 1/4-20 x .500
5712-0292 Tin Clip Nut, 1/4-20
6710-0751 Hex Screw, 1/4-20 x .620
7710-05108 Screw, 1/4 x .750
8712- 04064 Nut, Hex Flange Insert Lock, 1/4-20
9731-07668 Grill
10 731-07458 Headlight Lens, RH
11 731-07459 Headlight Lens, LH
12 731-07460 Dash Collar
13 731-07670 Hood Scoop, LH
14 731-07669 Hood Scoop, RH
15 735-0271A Bumper
16 738-04091A Shoulder Screw, 5/16-18
17 783-05327B-0637 Left Support Pivot Bracket
18 783-05328A-0637 Right Support Pivot Bracket
19 783-06598-4043 Lower Grill
20 783-06610-0637 Lower Grill Bracket
21 983-04226 Speed Selector, 7-Speed
22 710-04483 Self-Tap Screw, 1/4-20
23 710-3144 Hex Head Screw, 3/8-16
Ref.
No. Part No. Description
24 711- 07 36 Ferrule, 1/4-20 x 1.00
25 712- 04065 Nut, Hex Flange Insert Lock, 3/8-16
26 714-04040 Cotter Pin
27 936-0133 Flat Washer, .411 x 1.25 x .100
28 750-04465 Flange Spacer
29 783-04862 Speed latch
30 710-0604A Self-Tap Screw, 5/16-18
31 710-0895 Hex Screw, 1/4-15
32 712- 04063 Nut, Hex Flange Lock, 5/16-18
33 731-04945 Steering Support
34 783-04892B-0637 Dash
35 683-04448-0637 Battery Assembly Rod
36 726-0230 Cable Tie
37 747-04430 Speed Selector Control Rod
38 751-0555B 1.5 Gallon Fuel Tank
39 751-0603A Fuel Cap
40 783-04584A-0637 Gas Tank Support Bracket
41 731-05265 Choke Plug
42 746-04364 Throttle/Choke Assembly
43 725-04992 Key Switch Module
44 625-04124 Key (2 pack)
45 725-0157 Cable Tie
46 925-0963 Headlight Bulb

32
PARTS LIST
Craftsman Model 247.28902
1
6
2
7
11
13
18
25
26
19
3
5
10 9
4
8
16
17
12 20
46
14
21
26
26
22
23
2728 30
30
38
31
32
32
35
37
35
20
45
32
34
36
41
42
43
44
33
30
29
29
24
15
14
14
40
39

33
PARTS LIST
Craftsman Model 247.28902
Ref.
No. Part No. Description
1683-04155A-0637 Shaft, Lift
2712-04065 Nut,HexFlangeInsertLock,3/8-16
3714-04040 Bow-Tie Pin, 91, RH
4716-0106A E-ring, .625 Shaft
5720-0311 Grip, Handle
6732-04225 Spring, Lift Handle Torsion
7738-04130 Bolt, Shoulder, .625 x .175:3/8-16
8941-0225 Bearing, Hex Flange,
9747-05296 Handle, Lift
10 747-04393 Lift Rod, 13.68
11 783-04494C-0637 Arm, Deck Lift RH
783-04711C-0637 Arm, Deck Lift LH
12 647-04096-0637 PTO Handle Assembly
13 710-04608 Screw, Hx. Hd., 7/16-20 x 3.25
14 710-0599 Screw,Hd.Tapp,1/4-20x.5
15 714-04040 Click Pin
16 720-04049A Handle Grip
17 732-04276A PTO Spring, Extension
18 936-0171 Washer, Flat, 7/16
19 736-0322 Washer,Flat,.450x.250x.164
20 738-04237A Shoulder Screw, #10-32 x .500
21 741-04119A PTO Bearing
22 946-04173B Deck Engagement Cable
23 725-04439 12v. Solenoid
Ref.
No. Part No. Description
24 756-04196A Engagement Pulley
25 747-04857 Belt Keeper Rod Assembly
26 710-04484 Screw, Hd. Tapp, 5/16-18 x .75
27 683-04195-0637 Support Bracket Assembly
28 683-04601-0637 Rider Frame Assembly
29 710-0134 CarriageScrew,1/4-20x.62
30 710-3008 Screw, Hx. Hd., 5/16-18 x .75
31 712-04063 Nut,HexFlangeInsertLock,5/16-18
32 712-04064 Nut,HexFlangeInsertLock,1/4-20
33 912-0429 HexlockNut,5/16-18
34 732-04035 Spring, Compress., 1.28 x 3.125
35 736-0173 FlatWasher,.28x.74x.063
36 783-04548C-0637 Seat Bracket Frame
37 783-04637-0637 Running Board Bracket
38 783-04753-0637 Frame Support Bracket
39 783-04869A-0637 Battery Bracket
40 783-05389A-0637 Frame Brace Bracket
41 725-05090 Die Hard Battery
42 738-1132 Screw, Shoulder, .250 x .150
43 712-0271 Nut,Sems,1/4-20
44 683-04448-0637 Battery Rod
45 925-04039 Screw Mount Interlock Switch
46 725-04363 Interlock Switch

34
PARTS LIST
Craftsman Model 247.28902
20
7
19
5
610
11
18
8
4
2
30
34
34 29
33
35
36
26
27
31
34
24
29
34
23 28
8
21
1
1
6
17
8
8
14
37
3
38
15
13
11
22
25
40
41
42
12
43
32
28
39
39
9

35
PARTS LIST
Craftsman Model 247.28902
Ref.
No. Part No. Description
1617- 04024 Gear Assembly, Steering
2710-0376 Screw, 5/16-18, 1.00, Gr5
3710-0643 Screw, 5/16-18, 1.00, Gr5, Lock
4710-1309 Screw, Mach, 5/16-18, 0.750
5710-3180 Screw, 5/16-18, 1.75, Gr5
6912-0240 Nut, Jam, 7/16-20, Gr2
7912-0214 Nut, Jam Lock, 3/8-24
8712- 04063 Nut, Flange Lock, 5/16-18, Grf
9931-0484A Hub Cap
10 923-0448A Ball Joint, 7/16-20, Lock
11 736-0242 Washer, Bell, .340 x .872 x .060
12 934-0255 Valve Stem
13 738-04141 Shoulder Screw, 5/16-18
14 738-0919A Steering Shaft, 5/8 Spline x 21.86
15 941-04124 Bearing, Flange, Hex 5/8
16 941-04454 Plastic Bushing .375 ID x .05 OD
17 747-04298 Drag Link, Steering
18 948-0389 Cap, 1.25 x .16
19 748-04065-0637 Steering, Block
20 748-04068 Spacer, .710 ID x .125 OD x .56
21 750-04418 Spacer, .322 ID x .625 OD x .21
22 783-04644 Stabilizer Plate, Gear Segment
Ref.
No. Part No. Description
23 938-04007A-0637 Axle Assembly LH
24 638-04008P Axle Assembly RH
25 683-0128B-0637 Pivot Bar Axle Assembly
26 710-04484 Screw, 5/16-18, 0.750
27 712- 04065 Nut, Flange Lock, 3/8-16, GrF
28 714-04039 Pin, Cotter, 5/32, 1.25
29 914-0474 Pin, Cotter, 1/8 x 0.75
30 736-0341 Push Cap, 3/4
31 731-04057A Axle Cap
32 736-04228A Washer, Flat, .781 x 1.59
33 738-04128 Screw, Shlder, .500 x 2.380, 3/8-16
34 741-0660A Flange Bearing
35 747-04299A Tie Rod
36 783-05326B-0637 Pivot Bar Bracket
37 631-04028 Steering Wheel, Standard Grip
38 731-06825 Cap, Steering Wheel (Crafts. logo)
39 634-04086-0961 Wheel Assembly
40 934-04081-4042 Rim
41 734-1731-0901 Tire, 15 x 6 x 6 Sq. Shoulder
42 741-0990B Flange Bearing
43 741-0516B Flange Bearing

36
PARTS LIST
Craftsman Model 247.28902
27
26
1
16
4
713
21
22
28
25
23
36
29
24
15
11
8
5
10
6
20
12
14
3
9
17
18
19
2
30
31
31 32
34
35
33

37
PARTS LIST
Craftsman Model 247.28902
Ref.
No. Part No. Description
1710-1268 Screw, #10-16 x .375
2712- 04063 Flange Lock Nut, 5/16-18
3712- 04064 Flange Lock Nut, 1/4-20
4720-0309A Seat Adjustment Grip
5726-0201 Speed Nut
6731-04074 Seat Adjustment Spacer
7732-0499 Compression Spring, .41 x 1.50
8732-118 4 Extension Spring
9736-0204 Flat Washer, .344 x .62 x .033
10 736-0242 Flat Washer, .340 x .872 x .060
11 736-3019 Flat Washer, .531 x .062 x .134
12 938-0137A Shoulder Screw, .34 x .285: 1/4-20
13 938-0296 Shoulder Screw, 5/16-18 x .437 x .268
14 738-0966A Shoulder Bolt, .50 x .925: 3/8-16
15 783-0209D Lift Seat Bracket
16 78 3- 0 611 Seat Adjustment Stop Bracket
17 783-0738D-0637 Seat Pivot Bracket
18 783-0739A-0637 Seat Adjustment Lever
19 783-0753 Seat Adjustment Selector
20 757-04125 Low Back Seat
21 710-04483 Screw, 1/4-20 x .500
22 710-04484 Screw, 5/16-18 x .750
23 710-0599 Screw Pan Torx Head, 1/4-20 x .500
24 731-04591A Cup Holder
25 736-0607 Lock Washer, 5/16
26 783-04587C-4043 Fender
27 783-04843-0637 Lift Adjuster Bracket
28 783-1489C-0637 Seat Mounting Bracket
29 735-04047 Rubber Foot Pad, LH
735-04048 Rubber Foot Pad, RH
30 710-0227 Screw, 8-18 x .500
31 726-0279 Insulator Plate
32 925-1303 Outer Seat Spring
33 726-0278 Insulator Boss Plate
34 725-1439 Inner Seat Spring
35 710-0134 Carriage Screw, .62: 1/4-20
36 726-04072A Ratchet Clip, .250 x .500

38
PARTS LIST
Craftsman Model 247.28902
3
4
4
7
14
12
10
1
15
5
2
8
13
9
6
11

39
PARTS LIST
Craftsman Model 247.28902
Ref. Part No. Description
1683-04549-0637 Muer Shield Assembly
2710-0227 Screw, AB #8-18 0.500
3710-04683 Tap Screw, 3/8-16 1.000
4710-0642 Tap Screw, 1/4-20 0.750
5710-1314A Screw, Socket Head, 5/16-18 x .750
6712-0271 Sems Nut, 1/4-20
7BS-692236 Exhaust Gasket
8725-0157 Cable Tie, 3/16 X .05 X 7.4
9726-0205 Hose Clamp, .490 Dia.
10 728-04000 Pop Rivet, .188 Dia X .300 L
11 731-05628 Oil Drain Sleeve
12 751-0564B Muer Deector
13 751-10349 Low Permeation Fuel Hose, 1/4
14 751-10353 Long Muer Deector
15 751-10448B Briggs Single Muer

40
PARTS LIST
Craftsman Model 247.28902
B
B
A
A
33
38
18
46
45
48
49
49
47
50
52 27
43
51
56
54
13
10
12
4
42
54
55
52
44
55
1
14
23
22
39
8
30
62
61
63
45
36
2
7
57 58
59
12
3
17
5
35
34
24
26
25
21
19
29
20
41
31
37
41
6
40
16
53
28
9
60
60
11 15
32

41
PARTS LIST
Craftsman Model 247.28902
Ref.
No. Part No. Description
1918-04566 Transmission Drive Assembly
2647-04034C-0637 Pedal Assembly
3647-04035 Shaft Lever Assembly
4710-0227 Screw, 8-18:0.500
5710-04484 Screw, 5/16-18 x .750
6710-0599 Screw, 1/4-20 x 0.500
7710-0604A Screw, 5/16-18 x 0.625
8710-0809 Screw, 1/4-20 x 1.250
9710-1266 Hex Screw, 5/16-18 x .625
10 710-3008 Hex Screw, 5/16-18 x .75
11 911- 0 4075A Ferrule, 3/8-24 X .375 DIA.
12 712- 04063 Flangelock Nut, 5/16-18
13 712- 0700 Flange Nut, 9/16-18
14 914-0209 Cotter Pin INT- .125 DIA
15 714-04040 Bow-Tie Cotter Pin
16 718-04407 Pulley Hub, 5/8 SPLINE
17 720-04028 Shift Knob
18 725-0157 Cable Tie
19 725-1644 Short Spring Switch
20 726-0214 Push Cap, 5/8
21 926-0320 Plate Insulator Nut
22 731-04602 Sleeve, .758 x .821 x 3.3125
23 731-04604 Sleeve, .758 x .821 x 2.4375
24 731-06894 Shift Bearing Plate
25 732-04306 Spring Extension, .80 OD x 3.28 LG
26 732-04488 Spring Extension, .38 OD x 3.25 LG
27 732-0459C Spring Extension, .94 OD x 6.74 LG
28 732-0716D Spring Extension, .59 OD x 4.00 LG
29 735-0239 Foot Pad, 4.0 LONG
30 736-0242 Bell Washer, .340 x .872 x .060
31 747-04969 Belt Keeper Rod
32 747-05186 Variable Speed Control Rod
Ref.
No. Part No. Description
33 747-05188 Brake Rod
34 747-05243 Shift Rod, 46”
35 948-0334 Spacer, T-Axle
36 750-0566A Spacer, .260 x .375 x 1.030 LG
37 750-0802 Spacer, .640 ID x .76 OD x 2.63
38 954-04249 V Belt, 5L: 70.90 POLY
39 954-04265 V Belt, 5L: 33.8 POLY
40 756-04432 Trans. Pulley
41 783-04536B-0637 Pedal Support Bracket
42 783-04595A Shaft Adjust Bracket
43 956-04015A Variable Speed Pulley Assembly
44 683-04206 Bracket Assembly
45 710-0627 Hex Screw, 5/16-24 x .750
46 710-0778 Screw, 1/4-20 x 1.500
47 718-04261 Bearing Cup
48 736-0362 Flat Washer, .330 x 1.25 x .06:HT
49 941-0600 Ball Bearing, 17 x 40 x 12
50 683-04176A Transmission Bracket Assembly
51 753-05147 Idler Bracket Assembly
52 710-0347 Hex Screw, 3/8-16 x 1.75
53 710-1260A Screw, 5/16-18 x 0.750
54 712- 04065 Flange Lock Nut, 3/8-16
55 938-0347 Shoulder Spacer, .625 ID x .169
56 756-04325 Idler Pulley
57 725-04363 Switch Interlock
58 17962 Plate Switch
59 738-04237A Shoulder Screw, #10-32 x .500
60 634-04641-0961 Wheel Assembly, 18 x 9.5 x 8 Sq. Sh.
61 634-04369-4042 Rim Assembly
62 934-0255 Valve Stem
63 734 -1729 Tire, 18 x 9.5 x 8 Sq. Sh.
—925-04085 Wiring Harness (Not Shown)

42
PARTS LIST
Craftsman Model 247.28902
36
41
10
26
46
10
17
42
45
5
11
40
23
13
30
39
24
33
17
14
17
43
12
17
42
1
9
29
45
35
26
17
4
32
8
37
7
44
10
27
31
2
16
21
6
15
29
38
19
18
34
20
28
16
25 9
7
47
22
13
51
48 49
50
1
53
54
18
3
52
55
54
55

43
PARTS LIST
Craftsman Model 247.28902
Ref.
No. Part No. Description
1918-04822A Spindle Pulley Assembly
2683-0254B-0637 Deck Hanger Bracket Assembly
3956-1227 Spindle Pulley
4983 - 04511 Brake Assembly
5983-04525 Brake Assembly
6983-04572-0637 Deck
7710-04484 Screw, 5/16-18 x .750
8710-0514 Screw, 3/8-16 x 1.00
9710-0528 Hex Screw, 5/16-18 x 1.25
10 710-0599 Screw, 1/4-20 x .500
11 710-0778 Screw, 1/4-20 x 1.50
12 710-0809 Screw, 1/4-20 x 1.250
13 710-3144 Hex Head Screw, 3/8-16
14 710-3178 Carriage Bolt, 3/8-16 x .75
15 712- 0229 Push Nut, 3/8
16 712- 04063 Flangelock Nut, 5/16-18
17 712- 04065 Flangelock Nut, 3/8-16
18 712-0417A Flange Nut, 5/8-18
19 712- 04243 Flangelock Nut, 1/2-13
20 912-0641 Hex Nut, M16 - 1.5
21 714-04043 Cotter Pin, Bow-Tie
22 917-04074 Deck Adjuster Gear
23 932-0384 Extension Spring, .62 x 6.12
24 732-04727 Torsion Spring, 1.0 x 1.17
25 93 6 - 0119 Lock Washer, 5/16
26 936-0176 Flat Washer, .265 x 9.38 x .120
27 736-0187 Flat Washer, .64 x 1.24 x .06
28 736-0225 Flat Washer, .5/8 Int. Tth.
Ref.
No. Part No. Description
29 736-0262 Flat Washer, .385 x .870 x .092
30 736-0362 Flat Washer, .330 x 1.25 x .06
31 738-04146 Bolt Plug, M16 x 1.5
32 738-04162A Shoulder Spacer, .8840 x .190
33 738-04166 Shoulder Spacer, .5000 x .1475
34 942-04308 Cutting Blade, 21.23”: 2 in 1
35 747-04530 Belt Keeper Rod
36 747-04944B Deck Lift Rod
37 747-05105 Brake Control Rod
38 748-04069 Deck Lift Pivot Cup
39 750-0258 Spacer
40 750-0566A Spacer
41 954-04060B V-Type Belt, 96.5
42 756- 04129B Idler Pulley, 4.25 Diameter
43 783-05946 Idler Pivot Bracket
44 783-06243-0637 Deck Cable Engagement Bracket
45 783-06368-0637 Belt Pulley Guard
46 783-06424A-0637 Deck Belt Cover
47 783-06643-0637 Deck Support Bracket
48 631-04460 Chute Deector Assembly
49 711- 0 48 47A Hinge Pin
50 732-04372 Torsion Spring, .44 x 2.0
51 783-06074A Chute Bracket
52 936-0351 Flat Washer, .760 x 1.50
53 738-1186A Spindle Shaft
54 941-0919 Ball Bearing, .787 x 1.85 x .551
55 750-04936 Spacer, .792 x 1.060 x 1.860

44
PARTS LIST
Craftsman Model 247.28902 with Engine Model 31P677-1373-B2
29
32
307
306
718
3
22
15
1
2
24
691
552
43
1270
758
759
757
27
28
26
27
25
741
146
16
46
45
12
20
4
1044
562
505
227
1017
965
943
750
1024
847
523
842
525
524
684
11
584
585
1263
1264
850
616
404
614
1027

45
PARTS LIST
Craftsman Model 247.28902 with Engine Model 31P677-1373-B2
51
617
50
617
830
1034
1022
51
7
238 36
868
1029
33
534
192
35
337
635
1026
13
42
42
883
1022
1023
914
850
53
54
654
1026A
51A
45
415
186
306
51A

46
PARTS LIST
Craftsman Model 247.28902 with Engine Model 31P677-1373-B2
431
1266
240
187
601
104
105
51
634
987
95
130
98
133
94
117
141
131
127
108
118
276
1127
975
137
135A
137
125
947
1091
217
53
654
135
137
633

47
PARTS LIST
Craftsman Model 247.28902 with Engine Model 31P677-1373-B2
305
305A
1040
37
78
783
1051
23
1044
1005
415
1070
324
305B
304
445
968
