Craftsman 172.11624 User manual

Owner'sManual
CORNER SANDER
Model No.
172.11624
CAUTION: Read understand and follow
all Safety Rules and Operating Instructions
in this manual before using th_s product.
• SAFETY
• OPERATION
•MAINTENANCE
•ESPANOL, PAGE17
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.

Warranty. ................................................................... Page 2
Safety Instructions .................................................... Pages 3-8
Safety Symbols ......................................................... Page 8
Description ................................................................ Page 9
Operation .................................................................. Pages 9-13
Maintenance ............................................................. Page 14
Accessories .............................................................. Page 15
ONE FULL YEAR WARRANTY ON CRAFTSMAN SANDER
If this product fails togive completesatisfactionwithinone year from the
date ofpumhase, RETURN ITTO THE NEAREST SEARS STORE INTHE
UNITED STATES, and Sears will replace it, free of charge.
Ifthis productisused for commercialor rentalpurposes,thiswarranty
applies for only90 days from the date ofpurchase.
This warrantygives you specific legal rights,and you may also haveother
rightswhichvaryfrom state to state.
Seam, Roebuck and Co., Dept. 817 WA, HoffmanEstates, IL 60179
SAVE THESE INSTRUCTIONS!
READ ALL INSTRUCTIONS!

I_WARNING: BE SURE to read and understand all instructions.
Failure to follow all instructions listed below may result in electric
shock, fire and/or serious personal Injury.
WORK AREA SAFETY
1. ALWAYS keep your work area clean and well lit. Cluttered benchesand
dark areas invite accidents.
2. DO NOT operate power tools in explosive atmospheres, such as in the
presence of flammable Itqulds, gases, or dust. Powertoolscreatesparks
whichmay ignitethe dustor fumes.
3. ALWAYS keep bystanders, children, and visitors away while operating
a power tool. Distractionscan causeyou to losecontrol.
ELECTRICAL SAFETY
1. Double insulated tools are equipped with a polarized plug (one blade
Is wider than the other.)This plug will fit in a polarized outlet only one
way. If the plug does not fit fully in the outlet, reverse the plug. if it still
does not fit, contact a qualified electrician to install a polarized outlet.
DO NOT change the plug in any way.
2. Doubleinsulation[] eliminates the need for the three wire grounded power
cordand groundedpowersupplysystem.Applicableonlyto Class II
(doubleinsulated)tools.
3. Beforeplugginginthe tool. BE SURE thatthe outletvoltagesuppliedis
withinthe voltagemarked on the toots data plate.DO NOT use"AC only"
ratedtoolswith aDC powersupply.
4. ALWAYS avoid body contact with grounded surfaces such as pipes,
radiators, ranges and refrigerators. There isan increased riskof electric
shockif yourbodyisgrounded.
5. If operating the power tool in damp locations is unavoidable, ALWAYS
use a Ground Fault Circuit Interrupter to supply power to your tool.
ALWAYS wear electrician's rubber gloves and footwear in damp
conditions.
6. DO NOT expose power tools to rain or wet conditions. Water enteringa
powertoolwillincrease the riskof electricshock.
7. DO NOT abuse the cord. NEVER use the cord to carry the tools or pull
the plug from the outlet. Keep cord away from heat, oil, sharp edges
or moving parts. Replace damaged cords immediately. Damaged cords
increasethe riskof electric shock.
8. When operating apower tool outside, ALWAYS use an outdoor
extension cord marked "W-A" or"W'. These cords ere rated for outdoor
use and reduce the risk of electric shock.
3

ELECTRICALSAFETYcont.
NOTE:TheextensioncordmusthaveadequatewiresizeAWG (American
Wire Gauge) for safe, efficientuse. Smaller gaugewires have greater
capacity (16 gauge wire has more capacity than 18 gauge wire).
PERSONAL SAFETY
I. ALWAYS stay alert, watch what you are doing and use common sense
when operating a power tool. DO NOT use tool while tired or under the
Influence of drugs, alcohol or medlcetlon. A momentofinattentionwhile
operatingpowertoolsmay result in seriouspersonalinjury.
2. ALWAYS dress properly. DO NOT wear loose clothing or jewelry. Pull
back long hair. Keep your hair, clothing and gloves away from moving
parts. Loose clothing,jewelryor long haircan be caughtin movingparts.
3. ALWAYS avoid accidental starting. BE SURE switch is in the "Off"
position before plugging in. DO NOT carry toolswith yourfinger on the
switch.Carryingtoolswithyourfinger on the switchorpluggingin toolsthat
havethe switchin the"On" positioninvitesaccidents.
4. ALWAYS remove adjusting keys or wrenches before turning the tool
on, A wrenchor a key that isleftattached to a rotatingpart ofthe toolmay
resultin personalinjury.
5. DO NOT overreach. ALWAYS keep proper footing and balance at all
times. Properfootingand balance enables better control of the tool in
unexpected situations.
6. ALWAYS use safety equipment. ALWAYS wear eye protection. Dust
mask,non-skidsafety shoes, hard hat, or hearingprotectionmust be used
for appropriate conditions
TOOL USE AND CARE SAFETY
1. ALWAYS use clamps or other practical ways to secure and support th_
workpiece to a stable platform. Holdingthework byhand or againstyour
body isunstableand may lead to loss ofcontrol.
2. DO NOT force the tool. Use the correct tool for your application. The
correcttoolwilldo thejobbetterand saferatthe rateforwhichitisdesigned.
3. DO NOT use the tool if the switch does not turn it"On" or "Off".
Any tool that cannotbe controlled withthe switch isdangerousand must be
repaired.
4. ALWAYS disconnect the plug from the power source before making
any adjustments, changing accessories or storing the tool. Such
preventive safety measures reduce the risk of starting thetool accidentally.
4

TOOLUSEANDCARESAFETYcont.
5.ALWAYSstoreidletoolsoutofthereachofchildrenandother
untrainedpersons.Toolsare dangerousin thehands ofuntrainedusers.
6, ALWAYS maintain tools with care. Keep cuffing tools sharp and clean.
Properlymaintainedtoolswith sharpcuttingedges are lesslikelyto bind
and are easier to control.
7. ALWAYS check for mlsallgnment or binding of moving parts, breakage
of parts, and any other condition that may affect the tool's operation.
If damaged, have the tool serviced before using. Many accidentsare
caused by poody maintainedtools.
Z_WARNING: USE OFACCESSORIESTHAT ARE NOT RECOMMENDED I
FOR USEWlTHTHISTOOL MAY CREATE A HAZARDOUS CONDITION. |
I
8. ALWAYS use only accessories that are recommended for this tool.
Accessories that may besuitable for one tool can become hazardous when
used on another tool.
SERVICE SAFETY
1.if any part of this sander is missing or should break, bend, or fail in any
way; or should any electrical component fail to perform properly:
ALWAYS shut offthe powerswitchand removethe sanderplug fromthe
power source and have the missing, damaged or failed parts replaced
BEFORE resumingoperation.
2. Tool service must be performed only at a Sears Service Center. Service
or maintenance performed by unqualified personnel could result in a risk of
injury.
SAFETY RULES FOR SANDERS
1. NEVER use this or any power sander for wet sanding or liquid
polishing. Failureto followthisrulewillincreasethe riskofelectrical shock.

ADDITIONALRULESFORSAFEOPERATION
IZ_WARNING: BE SURE to read and understand all instructions. I
Failure to follow all Instructions listed below may result In I
electric shock, fire and/or serious personal injury.
1. Know your power tool. Read operator's manual carefully. Learn the
applications and limitations, as well as the specific potential hazards
related to this tool. Followingthis rulewillreducethe riskof electricshock,
fire or seriousinjury.
2. ALWAYS wear safety glasses or eye shields when using this sander.
Everyday eyeglasses have only impact-resistant lenses; they are NOT
safety glasses. Followingthis rulewillreducethe riskofseriouspersonal
injury.
3. ALWAYS protect your lungs. Wear a face mask or dust mask if the
operation is dusty. Followingthis rulewillreduce the riskof serious
personalinjury.
4. ALWAYS protect your hearing.Wear hearing protection during extended
periods of operation. Followingthis rulewillreducethe riskofserious
personalinjury.
5. ALWAYS Inspect the tool cords periodically and If damaged have them
repaired at your nearest Sears Service Center or other qualified Service
Facility. ALWAYS be aware of the cord location. Followingthis rulewill
reducethe riskof electricshockor fire.
6. ALWAYS check for damaged parts. Before further use of the tool, a
guard or other part that is damaged should be carefully checked to
determine If itwill operate properly and perform its intended function.
Check for mlsalignment or binding of moving parts, breakage of parts,
and any other condition that may affect the tool's operation. A guard
or other part that is damaged, should be properly repaired or replaced
at an qualified Service Center. Followingthis rule willreducethe risk of
electric shock, fire or serious injury,
7. DO NOT abuse the cord. NEVER use the cord to carry the tools or pull
the plug from the outlet. Keep cord away from heat, oil, sharp edges or
moving parts. Replace damaged cords immediately. Damaged cords
increasethe risk of electricshock. Following this rule willreduce the riskof
electric shock or fire.
6

ADDITIONALRULESFORSAFEOPERATIONCONT.
8.ALWAYSmakesurethatyourextensioncordIsIngoodcondition.
Whenusingan extension cord be sure to use one that is heavy
enough to carry the current that your tool will draw. A wire gauge
(AWG) of at least14 is recommendedfor an extensioncord25 feet or less
in length.When workingoutdoorsALWAYS use an extensioncordthatis
suitable foroutdooruse.The cord'sjacketwillbe markedWA_Smaller
gauge wires, have greater capacity (16 gauge wire has more capacity
than 18 gauge wire). An undersizedcordwillcausea drop in linevoltage.
resultingin lossofpowerand overheating.
9. ALWAYS inspect and remove all nails from lumber before sanding.
Followingthis rulewillreducethe riskof seriouspersonalinjury.
10.DO NOT use the tool while tired or under the influence of drugs,
alcohol or any medication. Followingthis rulewillreducethe riskof
electric shock, fire or serious personal injury.
11.SAVETHESE INSTRUCTIONS. Refer to them frequently and use them
to instruct others who may use this tool. If someone borrows this tool,
make sure they have these instructions also.
/_WARNING: Some dust particles created by power sanding,
sawing, grinding, drilling and other construction jobs contain
chemicals known to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
•Lead from lead-based paints.
•Crystalline silica from bricks and cement and other masonry products.
•Arsenic and chromium from chemically treated lumber.
Your risk from these exposures varies, depending upon how often you do
this type of work.To reduce your exposure to these chemicals:
•Work in a well-ventilated area.
•Work with approved safety equipment, such as those dust masks that
are specially designed to filter out microscopic particles.
7

ADDITIONALRULESFORSAFEOPERATIONCONT.
Z_ WARNING: The operation of any sander can I
resultin foreign objects being thrown intoyour eyes, I
which san result in severe eye damage. Before
beginning power tool operation, ALWAYS wear
safety goggles or safety glasses with side shield
and a fullface shield when needed. We recommend
a Wide Vision Safety Mask for use over eyeglasses
or standard safety glasses with side shield, available
at Sears Retail Stores.
The label of your tool may include the following symbols:
V ........................................................... VOltS
A........................................................... Amps
Hz......................................................... Hertz
W.......................................................... Watts
rain ....................................................... Minutes
....................................................... .Alternating current
......................................................... Direct current
Hz......................................................... Frequency
no ........................................................ No-load speed
[] ......................................................... Class II Construction
..Jmin ................................................... Revolutions or Strokes per minute
OPM ...................................................... JObitsPer Minute
Z_ ......................................................... Indicates Danger, Warning or
Caution+It means attentiont
Your safety is involved.
IMPORTANT! READ ALL INSTRUCTIONS!

KNOWYOUR SANDER (See Fig.l)
The compact,lightweightdesignofthis sanderallowsittofit intosmall areas
thatothersanders can_ reach.It is idealforsanding, polishing,detailing,
removingrustwithsandingpads,tips,polishingpads and scrubbingpads
(soldseparately). It has 2 interchangeablebasesfor extraversatilityin awide
varietyof largeand smallapplications.Italso features hook-and-loop
attachment forfast, easy sandingpads attachmentor removal.
Fig I Handle
Rocker
Triangular
Base
No-load Speed
Rating
Input
Orbit Diameter
12,000 OPM (Orbits Per Minute)
120 Volts, 60 Hz AC
1.5 Amps
5/16-in. (0.31-in,)
Before attempting to use any tool, be sure to familiarize yourself with all
the operating features and safety instructions.
I
/-'_WARNING: IF ANY PARTS ARE MISSING, DO NOT OPERATE I
YOUR SANDER UNTILTHE MISSING PARTS ARE REPLACED. I
FAILURE TO FOLLOW THIS RULE COULD RESULT IN SERIOUS
PERSONAL INJURY.

CAUTION: DO NOT let familiarity with your sander make you
careless. Remember that a careless fraction of a second issufficient
to cause severe injury.
_1 L_ WARNING: ALWAYSwser safety goggles
or safety glasses with side shield and a full face
shield when operating your sander. Failure to do so
could result in foreign objects being thrown intoyour
eyes, resulting in possible serious injury.Ifthe sanding
operation is dusty, also wear a face or dust mask.
Electrical Connection
Yoursander hasa precision-builtelectricmotor and itshouldonlybeconnected
to a 120-volt, 60-Hz. power supply (normal household current). DO NOT
operateon direct current(DC).This large voltagedrop willcausea lossofpower
thatwilloverheatthe motor.If yoursanderdoes not operatewhen pluggedinto
an outlet, havea professionalelectriciancheckthepowersupply.
Z_ WARNING: Your sander should NEVER be connected to the
power source when you are assembling parts, making adjustments,
installing or removing sandpaper, cleaning or when it isnot in use.
Disconnecting the sander will prevent accidental starting, that could
cause serious personal injury.
JZ_ CAUTION: DO NOT use this sander near water. I
2 INTERCHANGEABLE BASES (See Figs. 2, 3, 4)
This sander (Fig.2) has2 interchangeable basesfor extraversatility.The large
triangularbase (Fig. 3) is for sandinglargersurfaces. The detailfinger base
(Fig.4) isidealfor sendingcorners and small, intricate hard-to-reachareas.
Fig. 3
Triangular Base
g.4
Detail Finger Base_
10

CHANGINGTHEBASES(SeeFigs.5,6)
IfyourjobrequiresusingtheDetail Finger Base, followthese simplestepsfor
removingthe attached base.
1. Unplugthe sander. I
/I_WAHNINL_: Failure to unplug the sander could result in accidental I
starting causing possible serious personar injury, I
2. Remove the 5 Phillips iz
head screws holding the Fig. 5 \
Triangular Base.
3. Lift Triangular Base off of sander.
4. Place Detail Finger Base
onto sander and line up holes
in base with holes in sander
5. Re-insert the 5 screws
and tighten securely.
Fig. 6
Delail Finger
Base
ROCKER SWITCH (See Fig. 7)
To turn the sander "ON",
simply pushthe rockerswitch.
Toturnthe sander "OFF",
push the rocker switch again.
Fig. 7
On/Off
Switch
11

ATTACHINGSANDINGSHEETSANDPADS(SeeFigs.8,9)
Thissanderfeatures an easy hook and loop accessoryfasteningsystemfor
quickchangingwithoutclamps,
1. Unplugthesander.
L WARNING: Failure to unplug the sander could result in accidental I
starting causing possible serious personal injury. I
2. Carefully center the sanding
sheet or pad over the base to be
used.Une up thetip of the
sandingsheet or pad withthe tip
ofthe base.
3, Press thesheet or pad firmly in
place.
4. To remove sheet or pad, simply
pull itoff.
Fig. 9 Base
Tip of
SANDING WITH EITHER BASE
(See Fig. 10)
1. Alwayshold the sander as shown
infigure 10.
2. Movethe sanderin long,
sweepingstrokesacross the
sandingsurface.
3. Light pressure is all that is
needed for sanding, polishing
and scrubbing.
Let the sander do the work.
Fig. 10
IMPORTANT: Applying excessive pressure will slow the sander and produce
unsatisfactory results,
4. Check your work often. This sander removes material quickly.
12

SANDING TIPS
1. DO NOT forcethe sander.The weightofthe sander suppliesadequate
pressure.Letthe sanderand the sandpaperdo the work,
A. Applyingadditionalpressurewillonlyslow the motor,wear the
sandpaperout faster and reduce sanderspeed.
B. Excessivepressure willoverloadthe motorand cause possibledamage
tothesander from the motoroverheating.
C. Excessivepressurewillalso result in inferiorwork.
2. Any existingfinishor resin on woodmay softenfrom the heat ofthe friction.
3. DO NOT sand in one spotfor too longa time because the sander's
rapidactionmay remove too much materialand make the surfaceuneven.
SELECTING THE RIGHT SANDPAPER
Selecting the correct grit of sandpaper isan extremely important decision that
will allow you to achieve the best quality sanding finish,
1. Coarse grit will remove the most material and finer grit willgive you the best
finish in all sanding operations
2, The condition ofthe surface to be sanded will determine which grit will do
the job.
3. If the surface is rough:
A. Startwithacoarse grit (soldseparatly)and sand until thesurface is uniform.
B. Then use medium to remove any scratches left by the coarse grit.
C. Then use a finer grit (sold separatly) for finishing the surface.
NOTE: ALWAYS continuesandingwith each grit until the surface isuniform.
USING THE POLISHING AND SCRUBBING PADS
Thistoolis also idealforcleaning, polishingand removingrust withthe
polishingend scrubbingpads (soJdseparately),See AttachingSanding Sheets
and Pads on page 12.
13

SERVICE
IZ_WARNING: PreventaUve maintenance performed by unauthorized I
personnel may result in misplacing of internal wires and components,
which could cause s serious hazard,
• All servicethat requiresopeningthe sander MUST onlybe performedbya
Sears Service Center.Allmotor parts represantan importantpartof thedouble
insulationsystemand MUST onlybe servicedbyaSears Service Canter.
Service performedbyunqualifiedpersonnelcould resultina riskof injury.
•When servicingthistool, ALWAYS use onlyidenticalreplacementparts.
Followinstructionsinthe MaintenanceSection of thismanual. Useof
unauthorizedpartsor failuretofollowMaintenance instructionsmay create a
risk ofelectricalshockor injury.
• Avoidsolventswhen cleaningplasticparts.Most plasticsare susceptible to
damage from varioustypes of commercialsolventsand may be damaged by
their use.Use clean cloths to remove dirt, carbondust,etc.
Z_.WAR NING: To avoidaccidants,ALWAYS disconnectthetoolfromthe I
powersourceBEFORE cleaningor performingany maintanance.
All parts represent an important part of thedouble insulation system and should
be servicedonly at a Sears Service Center, I
/tkWARNING: DO NOT at any time let brake fluids, gasoline, petroleum- I
based products, penetrating oils, etc. to come incontact with plastic parts. I
They contain chemicals that can damage, weaken or destroy plastic.
Use clean cloths to remove dirt, carbon dust, etc.
14

EXTENSIONCORDS
Theuseofanyextensioncordwillcause some lossof power.To keepthe loss
at a minimumand to preventoverheating,usean extensioncord that is heavy
enough to carry the currentthat the tool willdraw.
A wire gauge (AWG) of at least 16 is recommended for an extensioncord
100 feet or less in length. When working outdoors ALWAYS use an extension
cord that is suitablefor outdoor use,The cord'sjacket willbe marked WA.
replace it immediately.NEVER use a toolwith a damaged cord because
touching the damaged area could cause electrical shock, resultingin
serious injury.
Extension cords that are suitablefor usewith yoursanderare available at your
nearest Sears Store.
The following recommended accessories are currently available at your local
Sears Store. They are available for both the triangular base and the detail
finger base,
Medium (120) Grit Sandpaper for paint, varnish, rust removal
and light stock removal
Fine (180) Grit Sandpaper for surface blending and sanding
Extra Fine (220) Grit Sandpaper for sanding between paint coats and
finish sanding
Detail SandingTips for use in corners and hard-to-reach areas
Light Gray Polishing /Stripping Pad for polishing metal, stripping varnish
and urethane
Dark Gray Fine Polishing Pad for fine polishing to a satin finish on paint,
metal, varnish and urethane
Gray Foam Padfor applying and removing polish
White Non-Woven Pad for light-duty scrubbing
Red Non-Woven Pad for heavy-duty scrubbing /rust removal
Z_WARNING: The use of attachments or accessories that are not J
recommended might be dangerous. I
15

NOTES
16

Manualdel Usuario
LIJADORA DE RINCONES
Modelo No.
172,11624
ATENCION: Antes de usar este producto,
lea comprenda y siga todas tas reglas de
seguridad y las instrucciones de funcionamiento
incluidas en este manual,
• SEGURIDAD
•FUNCtONAMIENTO
0MANTENIMIENTO
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.

Garantfa ............................................................... P_,gina 18
Instrucciones de Seguridad ................................. Pdginas 19-24
Sfmbolos de Seguridad ....................................... Pdgina 24
Descripci6n .......................................................... Pdgina 25
Funcionamiento ................................................... Pdginas 25-29
Mantenimiento ..................................................... Pdgina 30
Accesorios ........................................................... P_.gina 31
GARANTIA COMPLETA DE UN A_IO DE LA
LIJADORA CRAFTSMAN
Si este producto no le otorga completa satisfaccibn dentro de un afio de la
fecha de compra DEVUELVALO AL ALMACEN SEARS MAS CERCANO
EN LOS ESTADOS UNIDOS y Sears Io reemplazar._gratuitamente,
Si este productose usa para prop6sitos comercialeso de arriendo,esta
garantia es v_lida solamente durante 90 dfas desde la fecha de compra.
Esta garantia leotorga derechos legalesespecfficosy usted ademds
puede tener otrosderechos que varfan de un estado a otto.
Sears, Roebuck and Co,, Dept. 817 WA, Hoffman Estates, IL 60179
iCONSERVE ESTAS INSTRUCClONES!
iLEATODAS LAS INSTRUCClONES!
18

ADVERTENClA: ASEGURESE de leer ¥ comprender todas |as
I_lones. [] IncumplindefltodetodaslasInstrucciones sigulentespuede
producir un choque eldctrl¢o, Incendlo y/o leslones personales graves.
SEGURIDAD DEL AREA DETRABAJO
1. Slempre mantenga el lugar de traba|o llmp|o y b|en itumlnado. Los bancos
de trabajo desordenados y real iluminados favorecen los accidentes.
2. NO utilice las herramientas el_=ctricas en una atm6sfera explosiva, tal
como en presencla de Iiquldos infiamables, gases 0 polvo. Las
herramientas eldctricas crean chispas que pueden inflamar el polvo o los vapores.
3. Siempre msntenga a los espectadores, ni_os o v|sitantes a una distancia
prudente cuando est_ uUlizando una herramlenta el_ctrlca. Las
distracciones pueden hacede perder el control.
SEGURIDAD EL_CTRICA
1. Las herramlentas con alslamiento dob_ est_n equlpadas con un enchufe
polarizado (una hoja de contacto es mds ancha que la otra.) Este enchufe
puede colocarse en un tomacorrlente polarlzado en una s61a direccl6n.
Si el enchufe no calza blenen el tomacorriente, invlerta el enchufe.
Si todavl'a no calza, p6ngase en ¢ontacto con un electrlclsta callflcado
para que instale un tomacorriente adecuado. NO modifique el enchufe
de ninguna manera.
2. El aislamiento doble [] elimina la necesidad del cord6n el(§ctrico trifilar puesto
a tierra y de1sistema de atimentacibn de energia puesto a tierra. Esto se
aplica s51o a tas herramientas de Clase II (de doble aistamiento)
3. Antes de enchufar la herramienta,ASEGURESE que el interruptor de vollaje
corresponde al indicado en la placa de informacidn de la herramienta. NO USE
"CA solamente" en herramientas que dicen CC
4. SIEMPRE evite el contacto del cuerpo con |as superficies puestas a tierra
tales como tuberias, tad|adores, cocinas y refrigeradores. Existe mayor
riesgo de sufrir choque el_ctrico si su cuerpo esta a tierra.
5. SI no puede evitar usar su herramlenta en lugares hdmedos, SIEMPRE
use Interruptor de Circuito de Falla aTierra pars proporcionar energl'a a el
herramlenta, ten amblentes h_medoa use s|empre guantes de electrlclsta
ycatzado.
6. NO exponga las herramientas el_ctricas a la Iluvia ni a ambientes
hdmedos. Cuando entra agua a una herramienta electdca, se aumenta el
riesgo de sufrir un cheque el_ctrico.
7, NO abuse del cord6n ei_ctrico. Nunca transporte Is herramienta pot el
cordbn ni tire del cordbn para desenchufarla. Mantenga el cord6n alejado
del calor, del aceite, bordes afilados o piezas mdviles, Reemplace
inmediatamente los cordones el6ctricos que est_n dafiados. Los cordones
da_aclos aumentan el riesgo de sufrir un choque el_ctrico.
6. Cuando ut|lice una herramienta el_ctrica al sire libre, use un cordbn de
extensi6n marcado "W-A" o"W". Estos cordones estan aprobados pars
uso al aire libre y reducen el riesgo de choque electrico.
19

SEGURIDAD ELECTRICA cont.
NOTA: El cord6nde extensk_ndebe tener el tama_ode alambreadecuado
AWG (AmericanWire Gauge) para usoeficientey seguro.Alambresde calibre
mdspeque_5otienenmayorcapacidad (alambre de calibre16 tiene rods
capacidadque el alambrade 18).
SEGURIDAD PERSONAL
1. SIEMPRE mant6ngase alerts, observe Io que es_ haclendoy use sentido
comdn cuando est6 cansado o bajo le Influencla de drogas, alcohol o
medlcamentos. Un momentode distracck_ncuando esld trabajandocon las
herramientaseldctricas,puedeocasionaruna lesi6npersonalgrave.
2. SIEMPRE use vestlmenta adecuada. NO use ropas sueltas o joyas.
Amdrrese el cabello largo. Mantenga su cabello, ropas y guantes
aleJadosde lee plezas m6viles. Las ropassuettas,lasjoyaso el cabello
largo pueden quedaratrapadosen las piezas m6viles.
3. SIEMPRE evite la puesta en marcha accidental. ASEGURESE de que el
interruptor est6 en la poslei6n "Off" (apagado) antes de enchufar la
herramlenta. NO transportelas herramientascon su dedo colocadoen el
interruptor.Se puede producirun acoidentesi transportala herrarnientacon
su dedo en elinterruptorosi enchufalaherramientacuandoel interruptor
esta en la posici6n "On"(encendido).
4. SlEMPRE saque las Ilaves de ajuste o Ilaves inglesas antes de poner en
marcha la herramienta, Sise deja una Ilaveinglesao una Ilavede ajuste en
una pieza m6vilo enuna piezagiratoriade la herramienta,se puede producir
una lesi6npersonal.
5. NO use la herramlenta a una dtstancla demasiado alejada. Mantenga
SIEMPRE un buen equllibrio y una posici6n firme. Elbuenequilibrioy
la posicibnfirme permiten un mejorcontrolde la herramientaen
situacionesimprevistas.
6. SIEMPRE use equipo de seguridad. Use SIEMPRE lentes protectores.
Se debe usarm_scarascontrael polvo,zapatosdeseguridadantirresbaladizos,
casco de seguridado protecci6nauditiva de acuerdo con las circunstancias.
USOY CUIDADO DE LAS HERRAMIENTAS DE SEGURIDAD
1. SIEMPRE use mordazas u otto mdtodo prdctico para asegurar y apoyar
la pleza de trabajo en una plataforma eatable. Si sujeta el trabajo con la mane
o contra su cuerpo queda inestable y puede conducir a la p6rdida de control.
2. NO fuerce la herramlenta. Use la herramienta aproplada para el trabajo.
La herramienta correcta hard el trabajo mejor y de manera rods segura, ala
velocidad para la cual rue dise_ada.
3. NO use la herramlenta si el Interrupter no funciona debldamente.
Es peligroso si la herramienta no puede ser controlada con el interruptor
y por Io tanto debe set reparada.
4. SIEMPRE desenchufe la herramienta antes de hacer algOn ajuste, cambiar
accesorios o guardarla. Estas medidas preventivas de seguridad reducen
el riesgo de que la herramienta se ponga en marcha accidentalmente.
20
