Craftsman 172.276700 User manual

Operator's Manual
2.4 Amp 1/4 Sheet
Finishing Sander
Model No. 172.276700
CAUTION: Read, understand and follow
all Safety Rules and Operating Instructions
in this manual before using this product.
Sears Brands Management Corporation,
Hoffman Estates, IL 60179
See the full line of Craftsman ® products
at craftsman.com Intertek 3025736
Double Insulated
*WARRANTY
* SAFETY
* UNPACKING
* DESCRIPTION
* ASSEMBLY
* OPERATION
* MAINTENANCE
6/28/12

Warranty .................................................................................... Page 2
Safety Symbols ........................................................................... Page 3
Safety instructions ....................................................................... Pages 4- 10
Unpacking .................................................................................. Page 10
Description .......................................................................................... Pages 11 - 12
Assembly. ............................................................................................ Pages 13- 17
Operation ............................................................................................ Pages 18 - 21
Maintenance ....................................................................................... Pages 22 - 23
Accessories ......................................................................................... Page 24
Parts List ............................................................................................. Pages 25 - 26
CRAFTSMAN PROFESSIONAL ONE YEAR LiMiTED WARRANTY
FOR ONE YEAR from the date of purchase, this product is warranted
against any defects in material or workmanship. With proof of purchase,
a defective product will be replaced free of charge.
For warranty coverage details to obtain free replacement, visit the web
site: www.craftsman.com
This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state.
Sears Brands Management Corporation, Hoffman Estates, IL 60179
SAVE THESE INSTRUCTIONS!
READ ALL INSTRUCTIONS!
I _WARNING: Some dust created by using power tools contains chemicals
known to the State of California to cause cancer and birth defects or other
reproductive harm.

Thepurposeofsafetysymbolsistoattractyourattentiontopossibledangers.
Thesafetysymbolsandtheexplanationswiththemdeserveyourcarefulattention
andunderstanding.Thesymbolwarningsdonot,bythemselves,eliminateany
danger.Theinstructionsandwarningstheygivearenosubstitutesforproper
accidentpreventionmeasures.
_,WARNING:Besuretoreadandunderstandallsafetyinstructionsinthis
manual,includingallsafetyalertsymbolssuchas"DANGER,""WARNING,"and
"CAUTION"beforeusingthisfinishingsander.Failuretofollowallinstructions
listedinthismanualmayresultinelectricshock,fireand/orseriouspersonalinjury.
SYMBOL SIGNAL MEANING
,_ SAFETY ALERT SYMBOL: Indicates DANGER, WARNING, OR CAUTION.
May be used in conjunction with other symbols or pictographs.
_i, DANGER: Indicates a hazardous situation which, if not avoided, will result
in death or serious injury.This signal word is to be limited to the most extreme
situations. Always follow the safety precautions to reduce the risk of fire, electric
shock, and personal injury.
,_ WARNING: Indicates a hazardous situation which, if not avoided, could result
in death or serious injury. Always follow the safety precautions to reduce the risk
of fire, electric shock, and personal injury.
,_ CAUTION: Indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury.
Damage Prevention and Information Messages
These inform the user of important information and/or instructions that could lead
to equipment or other property damage ifthey are not followed. Each message is
preceded by the word "NOTE;' as in the example below:
NOTE: Equipment and/or property damage may result if these instructions are not
followed.
WARNING: To ensure safety and reliability, all repairs
should be performed by a qualified service technician.
,_ WARNING: The operation of any power tools can result in
foreign objects being thrown into your eyes, which can result in
severe eye damage. Before beginning power tool operation,
always wear safety goggles or safety glasses with side shield
and a full face shield when needed. We recommend a Wide
Vision Safety Mask for use over eyeglasses or standard safety glasses with side
shields. Always use eye protection which is marked to comply with ANSI Z87.1
shields.

,4k WARNING: Read all safety warnings and instructions. Failure to follow ]
the warnings and instructions may result in electric shock, fire and/or J
serious injury.
Save all warnings and instructions for future reference.
The term power tool in the warnings refers to your electric (corded) power too! or
battery-operated (cordless) power tool.
WORK AREA SAFETY
1. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
2. Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the
dust or fumes.
3. Keep children and bystanders away while operating a power tool. Distractions can
cause you to lose control.
4. Make your workshop childproof with padlocks and master switches. Lock tools away
when not in use.
5. MAKE SURE the work area has ample lighting so you can see the work and that
there are no obstructions that will interfere with safe operation BEFORE using your
power tool.
PERSONAL SAFETY
1. Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use apower tool while you are tired or under the influence of
drugs, alcohol or medication. A moment of inattention while operating power tools
may result in serious personal injury.
2. Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal injuries.
3. Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energizing power tools that have
the switch on invites accidents.
4. Remove any adjusting key or wrench before turning the power tool on. A wrench
or a key left attached to a rotating part of the power tool may result in personal injury.
5. Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewelry or long hair can be caught in
moving parts.
7. if devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust collection
can reduce dust-related hazards.

TOOLUSEANDCARESAFETY
Z_ WARNING: BE SURE to read and understand all instructions before
operating this power tool. Failure to follow all instructions listed below may
result in electric shock, fire and/or serious personal injury.
1. Do not force the power tool. Use the correct power tool for your application. The
correct power tool will do the job better and safer at the rate for which it was designed.
2. Do not use the power tool if the switch does not turn it on and off. Any power tool
that cannot be controlled with the switch is dangerous and must be repaired.
3. Disconnect the plug from the power source and/or the battery pack from the power
tool before making any adjustments, changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of starting the power tool accidentally.
4. Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
5. Maintain power tools. Check for misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the power tools operation. If
damaged, have the power tool repaired before use. Many accidents are caused by
poorly maintained power tools.
6. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits etc., in accordance with these
instructions and in the manner intended for the particular type of power tool,
taking into account the working conditions and the work to be performed. Use of
the power tool for operations different from those intended could result in a hazardous
situation.
8. Use clamps or another practical way to secure and support the workpiece to a
stable platform.
9. Holding the work by hand or against your body leaves it unstable and may lead to
loss of control.
Z_ WARNING: Empty dust bag before storage to help prevent possible fire
hazard, especially when resin coating or linseed oil finishes have been sanded.
ELECTRICAL SAFETY
/_, WARNING: Do not permit fingers to touch
the terminals of plug when installing or removing
the plug from the outlet.
1. Double insulated tools are equipped with a polarized
plug (one blade is wider than the other). This plug
will fit in a polarized outlet only one way. Ifthe plug
does not fit fully in the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician to install a
polarized outlet. Do not change the plug in any way.
Or°o_er_e_d
Outlet Box --_

ELECTRICAL SAFETY
2Power tool plugs must match the outlet. Never modify the plug in any way. Do not
use any adapter plugs with grounded power tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
/_, WARNING: Double insulation DOES NOT take the place of normal safetyprecautions when operating this tool.
3. Avoid body contact with grounded surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is grounded.
4. Do not expose power tools to rain or wet conditions. Water entering a power tool
will increase the risk of electric shock.
5. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric shock.
6. When operating a power tool outdoors, use an extension cord suitable for outdoor
use marked "W-A" or "W". Use of a cord suitable for outdoor use reduces the risk of
electric shock.
7. If operating a power tool in a damp location is unavoidable, use a Ground Fault
Circuit Interupter (GFCI) protected supply. Use of aGFCI reduces the risk of
electric shock.
EXTENSION CORDS
USE PROPER EXTENSION CORD. Make sure your extension cord is in good
condition. When using an extension cord, be sure to use one heavy enough to
carry the current your product will draw. An undersized cord will cause a c]rop in
line voltage resulting in loss of power and overheating.Table 1 shows the correct
size to use depending on cord length and nameplate ampere rating. If in doubt,
use the next heavier gage. The smaller the gage number, the heavier the cord.
Table 1: Minimum Gage for Cord
Rating Volts I Total cord length (in feet)
Ampere
MoreThan Not More
Than
6
10
12
120vi 25i i leoI
AWG
0 18 16 16 I 14
6 18 16 14 ! 12
10 16 16 14 12
12 16 14 12 Not recommended
Z_ CAUTION: Keep the extension cord clear of the working area. ]
Position the cord so that it will not get caught on lumber, tools or other J
obstructions while you are working with a power tool.
Z_ WARNING: Check extension cords before each use. If damaged replace ]
immediately. Never use tool with a damaged cord since touching the damaged J
area could cause electrical shock, resulting in serious injury.
6

SAFETY SYMBOLS FOR YOUR TOOL
The label or= your tool may include the following symbols.
V....................................................................... Volta
A ...................................................................... Amps
Hz.................................................................... Hertz
W..................................................................... Watts
min .................................................................. Minutes
.................................................................... Alternating current
................................................................... Direct current
no .................................................................... No-load speed
[] .................................................................... Class II construction, Double Insulated
RPM .......................................................... Revolutions per minute
SPM ........................................................... Strokes per minute
OPM .......................................................... Orbits per minute
z_ .................................................................... Indicates danger, warning or caution
It means attention! Your safety is involved.
SERVICE SAFETY
1. If any part of this tool is missing or should break, bend, or fail in any way;
or should any electrical component fail to perform properly: SHUT OFF the
power switch and remove the tool's plug from the power source and have the
missing, damaged or failed parts replaced BEFORE resuming operation.
2. Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
3. If the replacement of the supply cord is necessary, this has to be done by the
manufacturer or his agent in order to avoid s safety hazard.
SAFETY RULES FOR POWER SANDERS
1. HOLD TOOL by insulated gripping surfaces when sanding where tool may contact
hidden wiring, such as walls, floors, or its own power cord. Contact with a "live" wire will
make exposed metals parts of the tool "live" and shock the operator.
2. INSPECT FOR AND REMOVE all nails, screws, staples or any embedded pieces
of metal from surface to be sanded. These protrusions could damage the sandpaper,
the cushion of the sander and cause loss of control. Following this rule will reduce the
risk of serious personal injury and damage to the sander.
3. NEVER use this or any power sander for wet sanding or liquid polishing.
Failure to follow this rule will increase the risk of electric shock.
4. ALWAYS clamp the workpiece securely so it will not move under the sander.
Unsecured work could be thrown towards the operator, causing injury.
5. DO NOT force the sander. The weight of the sander supplies adequate
pressure. Let the sander and the grit on the sandpaper do the work.
6. DO NOT sand in any one place for too long. The sander's rapid action may
remove too much material and make the surface uneven.

Z_ WARNING: Some dust crested by using power tools contains chemicals
known to the State of California to cause cancer and birth defects or other
reproductive harm. Some examples of these chemicals are:
°Lead from lead-based paints.
•Crystalline silica from bricks and cement and other masonry products.
, Arsenic and chromium, from chemically treated lumber.
Your risk from these exposures varies, depending upon how often you do
this type of work. To reduce your exposure to these chemicals:
•Work in a well-ventilated area.
, Work with approved safety equipment, such as those dust masks that
are specially designed to filter out microscopic particles.
Avoid prolonged contact with dust from power sanding, sawing, grinding,
drilling and other construction activities. Wear protective clothing and wash
exposed areas with soap and water. Allowing dust to get into your mouth,
eyes, or lay on the skin may promote absorption of harmful chemicals.
Z_ WARNING: Use of this tool can generate and/or disburse dust, which may
cause serious and permanent respiratory or other injury. Always use
NIOSH/OSHA approved respiratory protection appropriate for the dust exposure.
Direct particles away from face and body.
z_ WARNING: Collected sanding dust from sanding surface coatings
(polyurethane, linseed oil, etc.) can self-ignite in sander dust bag or elsewhere
and cause fire. To reduce risk, empty dust bag frequently and strictly follow
sander manual and coating manufacturer's instructions.
z_ CAUTION: When working on metal surfaces, DO NOT use the dust bag or
a vacuum cleaner because sparks are generated. Wear safety glasses and sdust
mask. Due to the danger of fire, do not use your sander to sand magnesium
surfaces. Do not use for wet sanding.
SANDING PAINTS
SANDING LEAD BASED PAINT is NOT RECOMMENDED due to the difficulty of
controlling the contaminated dust. The greatest danger of lead poisoning is to children
and pregnant women.
Since it is difficult to identify whether or not a paint contains lead without a chemical
analysis we recommend the following precautions when sanding any paint:
• NO children or pregnant women should enter the work area where the
paint sanding is being done until all clean up is completed.
A dust mask or respirator should be worn by all persons entering the work
area. The filter should be replaced daily, or whenever (if) the wearer has
difficulty breathing.

NOTE:Onlythosedustmaskssuitableforworkingwithleadpaintdustandfumesshould
beused.Ordinarypaintingmasksdonotofferthisprotection.Seeyourlocalhardware
dealerfortheproper(NIOSHapproved)mask.
•NOEATING,DRINKINGORSMOKINGshouldbedoneintheworkareato
preventingestingcontaminatedpaintparticles.Workersshouldwashand
cleanupBEFOREeatingdrinkingorsmoking.Articlesoffood,drink,or
smokingshouldNOTbeleftintheworkareawherecontaminateddustwould
settleonthem.
•Paintshouldberemovedinsuchamannerastominimizetheamountofdust
generated.
•Areaswherepaintremovalisoccurringshouldbesealedwithplasticsheeting
of4milsthickness.
•Sandingshouldbedoneinamannertoreducetrackingofpaintdustoutside
theworkarea.
•Allsurfacesintheworkareashouldbevacuumedandthoroughlycleaneddaily
forthedurationofthesandingproject.Vacuumfilterbagsshouldbechanged
frequently.
•Plasticdropclothsshouldbegatheredupanddisposedofalongwithanydust
chipsorotherremovaldebris.Theyshouldbeplacedinsealedrefusereceptacles
anddisposedofthroughregulartrashpick-upprocedures.Duringcleanup,children
andpregnantwomenshouldbeKEPTAWAYfromtheimmediateworkarea.
•Alltoys,washablefurnitureandutensilsusedbychildrenshouldbewashed
thoroughlybeforebeingusedagain.
ADDITIONALRULESFORSAFE OPERATION
I _ WARNING: BE SURE to read and understand all instructions. Failure to
follow all instructions listed below may result in electric shock, fire and/or
serious personal injury.
1. Harmful/toxic dusts will arise from sanding e.g. lead painted surfaces, woods and
metals. Contact with or inhalation of these dusts can endanger the health of operator
and bystanders. Always use eye glasses and dust mask.
2. Hearing protection should be worn when using the sander.
3. Always wear safety glasses or eye shields when using the sander. Everyday
eyeglasses have only impact-resistant lenses; they are not safety glasses.
Following this rule will reduce the risk of serious personal injury.
4. Remove the plug from the socket before carrying out any adjustment, servicing or
maintenance.
5. Fully unwind cable drum extensions to avoid potential overheating.
6. When an extension cable is required you must ensure it has the correct ampere rating
for your power tool and is in a safe electrical condition.
7. Ensure your mains supply voltage is same as indicated on the rating plate.
8. Your tool is double insulated for additional protection against a possible electrical
insulation failure within the tool.
9. Always check walls, floors and ceilings to avoid hidden power cables and pipes.
10. After long working periods external metal parts and accessories could be hot
11. If possible, ensure the work-piece is firmly clamped to prevent movement
12, Your sander is a hand held tool. do not clamp your sander.
13. Before sanding check the area is free of nails screws etc.
14 Never stop the sander by applying a force to the base plate.
9

ADDITIONALRULESFORSAFEOPERATIONcont.
15.Onlyusepaperingoodcondition.Donotusetornorwornpaper.
16.Donotsandmaterialcontainingasbestosduetoahealthrisk.
17.Donotsandleadbasedpaintduetotheriskofleadpoisoning.
18.Donoteatordrinkintheworkingareaofthesander.
19.Donotallowpeopletoentertheworkingareawithoutwearingadustmask.
20.Wherepossible,sealofftheworkingareatocontainthedustforlaterremoval.
21.Yourtoolisdesignedfordrysandingonly,notwetsanding.
22.Yourtoolisdesignedforgeneralpurposelightpolishingofwoodandmetals.
23.Donotsandmagnesiummaterialduetotheriskoffire.
24.SAVETHESEINSTRUCTIONS.Refertothemfrequentlyandusethemtoinstruct
otherswhomayusethistool.Ifsomeoneborrowsthistool,makesuretheyhave
theseinstructionsalso.
Z_WARNING:ThispowertoolshouldNEVERbeconnectedtothepower
sourcewhenyouareassemblingparts,makingadjustments,installingor
removingsandpaper,cleaningorwhenitisnotinuse.Disconnectingthesander
willpreventaccidentalstarting,whichcouldcauseseriouspersonalinjury.
1.Removethesanderfromthestorage/carry case and inspect it carefully to make sure
that no breakage or damage has occurred during shipping.
2. Do not discard any of the packing materials until all parts are accounted for.
3. Included with your sander is a dust bag assembly, with vac adapter.
4. Also included is a paper punch template.
5. If any of the parts are damaged or missing (refer to PARTS LIST below), return the
sander to your nearest Sears store or Craftsman outlet to have the sander replaced.
I Z_ WARNING: ff any parts are missing, DO NOT operate this power tool until
the missing parts are replaced. Failure to do so could result in possible serious
personal injury.
PARTS LIST (Fig. 1)
1. Sander
t Bag Assembly
___i Adapter 4. Paper Punch Template
5. Storage /Carry Case
__ dust ports 6. Operator's Manual 10

KNOWYOURFINmSHINGSANDER (Fig. 2)
NOTE: Before attempting to use your sander, familiarize yourself with all of the /
operating features and safety requirements. J
Your Professional 1/4-sheet finishing sander has aprecision-built electric motor and it
should be connected to a120-volt, 00-Hz AC ONLY power supply (normal household
current). DO NOT operate on direct current (DC).The large voltage drop will cause a loss
of power and the motor will overheat. If the sander does not operate when plugged into
correct 120-volt, 60-Hz AC ONLY outlet, check the power supply. This sander has a 8-ft.,
2-wire power cord (no adapter needed).
This Finishing Sander has the following features:
1. Powerful 2.4 amp motor provides the torque, power and durability for a variety of
continuous sanding applications.
2. 14,000 Orbits per minute (no load speed). Match correct sandpaper grit for the
surface being sanded for either fast material removal or afine, smooth finish.
3. Random orbital action with 1/16-in. orbit diameter helps to provide a swirl free finish
4. Ergonomically designed Palm Grip Handle with Molded-in Comfort Grip for
maximum balance, control, gripping comfort and reduced operator fatigue.
5. Precision-tuned counterbalanced system reduces vibration for smooth operation
and less operator fatigue.
6. On/Off rocker is conveniently located for easy control. Sealed to keep out
dust for long life.
7. Heavy Duty Wire Form Sandpaper Clamps provides secure paper retention and
quick paper changes.
8. The Cushion located on the bottom of the sander accepts standard non-adhesive
sandpaper.
9. Uses 1/4-sheet sandpaper to provide a16-sq. in. sanding surface.
10. Paper Punch Template for accurately making holes in sandpaper for dust collection
system.
11. Built-in Dust Collection System. Dust bag assembly with dual dust ports collects
dust from work surface through holes in platen, cushion and sanding sheets. Use
either the dust bag, or attach a 1/4 or 2/2- nch vac hose and wet /dry vac (so d
separately) for dust collection. Helps keep work surface and area clean and extends
life of sanding sheets.
12. High impact-resistant housing helps protect tool from damage and reduces weight.
13. Permanently lubricated 100% ball bearings for smooth operation and long life.
14. Storage /Carrying Case for easy carrying and storage of sander and accessories.

Fig 2
On/Off
RockerSwitch Comfort Grip Handle
Dust
Bag Assembly
Lpter
with dual dust ports
Sandpaper
Platen Cushion
No-load Speed
Rating
Input
Orbit Diameter
Paper Size
Paper Type
14000 OPM (Orbits per Minute)
120 Volts, 60 Hz AC
2.4 Amps
1/16-in.
1/4 sheet
Non-Adhesive Sandpaper
12

[Z_ WARNING: Your sander should NEVER be connected to the power source
i
when you are assembling parts, making adjustments, installing or removing J
sandpaper, cleaning or when it is not in use. Disconnecting the sander will prevent
accidental starting, that could cause serious personal injury.
INSTALLING THE SANDPAPER (See Figs. 3, 3a, 3b on page 14 and Fig. 4 on page 15)
This sander has a cushion that allows you to use non-adhesive sandpaper. The
non-adhesive sandpaper clamps to the front and back of the platen and cushion.
This sander has a dust collection system that collects dust from the work surface through
holes located in the platen and cushion on the bottom of the sander. A paper punch
template is included for accurately punching holes into the 1/4-sheet sandpaper.
NOTE: Holes must be punched into the paper for the dust collection system to
3
work properly. See instructions on page 15 to punch holes. J
installing Non-Adhesive Sandpaper (See Figs. 3, 3a and 3b)
Fig 3 Paper
Clamp
Paper
Goes
Under
Clamp
Platen
Non-Adhesive
Sandpaper
Platen
Slot
Paper Clamp Lever
13

ALWAYSinspectthesandpaperbeforeinstalling.DONOTuseifbrokenordefective.
1.Unplugthesander.
I _ WARNING: Failure to unplug the sander could result in accidental startingcausing possible serious personal injury.
Installing Non-Adhesive Sandpaper (See Figs. 3,3a and 3b)
NOTE: Remove dust bag assembly when installing non-adhesive. ALWAYS
remember to reattach the dust bag assembly before beginning sanding operation
(see page 16, Fig. 5).
Paper Goes
Raise lever up Under Clamp
Fig 3b to clamp paper
2. If replacing sandpaper, remove old sandpaper.
3. Two paper clamp levers are located on each side of the sander and are locked into
a slot on top of the platen (see Fig. 3).
4. Raise these two levers "UP" and disengage them from the slots in the platen.
This will release the tension on the paper clamps located at the front and back of the sander
that hold the paper in position on the cushion (see Fig. 3a).
5. Remove old paper.
6. Insert front end of a new sheet of paper approximately 1/2-inch under the front paper clamp
(see Fig. 3b).
7. Lift up on the lever that controls the front paper clamp and lock it back into the slot on the
platen. This will securely clamp the paper to the front of the sander's cushion.
8. Smooth out the sheet of paper by pressing it tightly against the bottom of the cushion
(front to back).
g. Insert back end of paper into back paper clamp, fit sandpaper as tightly as possible, and lift
up on paper clamp lever to lock into place. This will securely clamp the paper to the back of
the sander's cushion. The sandpaper should now be positioned tightly against the cushion
from front to back, securely clamped in place.
NOTE: ALWAYS be sure that both paper clamp levers are in the locked position on ]
the platen and both paper clamps have the sandpaper securely clamped to the bottom 1
of the cushion before starting sanding operation.
14

PAPER PUNCH (See Fig. 4)
A paper punch template is included with sander so you can punch properly aligned holes
into the sandpaper. This is done after the paper is installed onto the sander.
To punch holes, line up the front and side of the sander over the paper punch template as
shown in Fig. 4, then lower the sander onto the template while applying pressure. Make
sure the holes are punched all the way through the paper and clear the holes in the
sander's cushion and platen.
INOTE: Punching holes properly is a necessary step for the dust collection |
]
system to operate properly. J
Fig 4
f
DUST BAG /DUST COLLECTION
Z_ WARNING: Collected sanding dust from sanding surface coatings
(polyurethane, linseed oil, etc.) can self-ignite in sander dust bag or elsewhere
and cause fire. To reduce risk, empty dust bag frequently and strictly follow
sander manual and coating manufacturer's instructions.
z_ WARNING: When working on metal surfaces, DO NOT use the dust bag or
a vacuum cleaner because sparks are generated. Wear safety glasses and a dust
mask. Due to the danger of fire, do not use your sander to sand magnesium
surfaces. Do not use for wet sanding.
15

TOREMOVEANDEMPTYDUSTBAG(Fig.5,5aand5b)
1.Unplugthesander.
Z_ WARNING: Failureto unplug the sander could result in accidental starting 1
causing possible serious personal injury. l
2. Locate (2) tab connectors on either side of vac adapter/dust bag assembly and
squeeze. Pull assembly straight back and off of dust exhaust hole (see Fig. 5).
3. Turn dust bag assembly counterclockwise (embossed arrows show unlock and lock
rotation) and remove bag from vac adapter (see Fig. 5a, 5b).
Exhaust Hole Dual Dust Ports
/\_. I'_:( Fig. 5a Fig. 5b
_.\/ _"_-_>_X._. ,Countercbckwise
__for OFF DustBag
z(,/ _,> f _J \ Dust Bag
VacAdapter _ _ _',,"%/A h
for ON "_ _/ _ _ " VacAdapterwith Dual Dust
Ports
4. Empty bag by shaking aggressively until completely empty. Wipe dust and debris from
the vac adapter.
5. Reattach the bag assembly back onto the vac adapter, and reattach back onto the sander.
NOTE: Empty dust bag frequently so dust collection system works properly ]
Z_ WARNING: Empty dust bag before storage to help prevent possible fire 1
hazard, especially when resin coating or linseed oil finishes have been sanded. J
16

NOTE:Formoreefficientoperation,werecommendthatyouemptythedustbag
when it is no more than half full. This will allow the air to flow through the bag
better. ALWAYS empty and clean the dust bag thoroughly when you've finished
sanding and before you store the sander.
ATTACHING VAC HOSE TO THE DUST COLLECTION SYSTEM (See Fig. 6, 6a and 6b)
When sanding for extended periods of time, you can easily attach your sander to a vac
hose and wet/dry vac (sold separately).
• Unplug the sander•
Z_ WARNING: Failure to unplug }
the sander could result in accidental
starting causing possible serious
personal injury.
2. Remove dust bag assembly from the
vac adapter (see page 16, Fig. 5a and 5b).
3. Connect vac adapter with dual dust
ports to dust exhaust hole of sander
(see Fig. 6).
4• Attach either a 11/4 or 21/2-in vac hose
onto the vac adapter's dual dust ports
( see Fig. 6a and 6b).
Fig. 6
ig. 6a
(
5• Connect hose to wet /dry vac•Turn vac on while operating sander•
Z_ WARNING: When sander is not connected to vacuum, always install
dust bag back on sander. Failure to do so could cause sanding dust or foreign
objects to be thrown into the face or eyes which could result in possible
serious injury.
NOTE: A standard 11/4-in. vac hose connection fits inside the smaller diameter hole
inside the dust exhaust, while a standard 2r/2-in. vac hose connection fits inside the
larger hole of the dust exhaust.
17

Beforeattempting to use any tool, be sure to familiarize yourself with all the
operating features and safety instructions.
Z_ WARNING: IF ANY PARTS ARE MISSING, DO NOT OPERATEYOUR
SANDER UNTIL THE MISSING PARTS ABE REPLACED. FAILURE TO FOLLOW
THIS RULE COULD RESULT IN SERIOUS PERSONAL INJURY.
z_ WARNING: DO NOT let familiarity with your sander make you careless.
Remember that a careless fraction of a second is sufficient to cause severe injury. ]
ON/OFF ROCKER SWITCH (see Fig. 7)
This switch is sealed to help keep out dust
for a longer life and is conveniently located
near the front of the palm grip handle.
Start the sander by pushing in the part of the
switch with their. Let the motor build to its
maximum speed before starting sanding
operation. To turn sander off, push side of
switch with the [].
APPLICATIONS
Only use your sander for the applications listed below.
*Sanding wood surfaces with various grits of sandpaper.
*Removing rust from steel surfaces with special sandpaper.
[z_ WARNING: Due to the danger of fire, DO NOT use your sander to sand
magnesium surfaces. DO NOT use for wet sanding.
[ _WARN[NG: ALWAYS clamp the workpiece. An unsecured workpiece could
be thrown towards the operator, causing serious injury.
USING YOUR SANDER (See Fig. 8, on page 19)
1. ALWAYS clamp and secure the workpiece to prevent it from moving under sander.
2. ALWAYS hold your sander in front and away from you, keeping it clear of the workpiece.
3. Start the sander and let the motor build to its maximum speed.
4. Gradually lower the sander onto the workpiece with aslight forward movement.
5. Move the sander slowly, guiding it in aforward and backward motion.
6. ALWAYS remove the sander from the workpiece before turning it off.
18

[Z_ CAUTION: When gripping the sander during use, ALWAYS be careful not
"11
to cover the air vents with your hands (see Fig. 8). ]
Fig. 8 Air Vents
/
\
SANDING TIPS
1. DO NOT force the sander. The weight of the sander supplies adequate pressure on
the workpiece. Let the sander and the sandpaper's grit do the work.
• Applying additional pressure will only slow down the motor, wear the sandpaper
out faster and reduce the sander's orbital speed.
• Excessive pressure will overload the motor and cause possible damage to the
sander from the motor overheating.
.Excessive pressure will also result in a poor quality finish.
2. Any existing finish or resin on wood may soften from the heat of the friction and cause
the sandpaper to load-up faster.
3. Inspect sandpaper frequently and change paper when grit is worn and not able to
perform properly.
4. DO NOT sand in one spot for too long a time because the sander's rapid action may
remove too much material and make the surface uneven.
SELECTING THE RIGHT SANDPAPER
Selecting the correct grit and type of sandpaper is an extremely important decision that
will allow you to achieve the best quality sanding finish.
1. Aluminum oxide, silicon carbide and other synthetic abrasives are best for power
sanding.
2. Natural abrasives such as flint and garnet are too soft for economical use in power
sanding.
3. Coarse grit will remove the most material and finer grit will give you the best finish in all
sanding operations.
19

SELECTINGTHE RIGHT SANDPAPER cont.
4. The condition of the surface to be sanded will determine which grit will do the job.
5. If the surface is rough:
• Start with a coarse grit and sand until the surface is uniform.
. Then use medium to remove any scratches left by the coarse grit.
oThen use a finer grit for finishing the surface.
NOTE: ALWAYS continue sanding with each grit until the surface is uniform.
NOTE: DO NOT use the sander without sandpaper. This will damage the cushion.
Z_ WARNING: DO NOT wear loose clothing or jewelry when operating sander.
They could get caught in moving parts, causing serious injury. Keep head away from
sander and sanding area. Hair could be drawn into sander, causing serious injury.
lz_ WARNING:Empty dust bag before storage to help prevent possible firehazard, especially when resin coating or linseed oil finishes have been sanded.
lOTE: Empty dust bag frequently when sanding so dust collection systemworks properly.
ORBITAL MOTION (Fig. 9)
As shown in Figure 9 the orbit of the sander is 1/16-in in diameter so the sandpaper
moves in tiny circles at very high speed, allowing the sander to move easily.
This orbital action duplicates a "hand sanding" motion for more aggressive sanding as
you push the sander forward. This powerful orbital action is ideal for heavy-duty sanding
applications, such as:
1. Removin_i old finishes 3. Sanding stock down to required dimensions
2. Smoothin_ rough wood 4. Finishing surfaces that are to be painted
Fig. 9
20
