Craftsman 7-IN. BUFFER / POLISHER 172.10721 User manual

Owner's Manual
7-in.
Buffer /Polisher
Model No.
172.10721
CAUTION: Read, understand and follow
all Safety Rules and Operating Instructions
in this manual before using this product.
• SAFETY
•OPERATION
•MAINTENANCE
•ESPANOL, PAGE 13
Seam, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.

Warranty ............................................................. Page 2
Safety Instructions ........................................... Page 3- 5
Description ......................................................... Page 6
Operation ....................................................... Pages 7-10
Maintenance ...................................................... Page 11
Accessories ....................................................... Page 11
FULL ONE YEAR WARRANTY ON CRAFTSMAN
BUFFER/POLISHER
If this CRAFTSMAN Buffer/Polisher fails to give complete satisfaction
within one years from the date of purchase, RETURN ITTOTHE
NEAREST SEARS STORE IN THE UNITED STATES, and Sears will
replace it, free of charge.
If this CRAFTSMAN Buffer/Polisher is used for commercial or rental
purposes, this warranty applies for only 90 days from the date
of purchase.
This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
Sears, Roebuck and Co., Dept. 817WA, Hoffman Estates, IL 60179
SAVETHESE INSTRUCTIONS!
READ ALL INSTRUCTIONS!
2

I/_ WARNING: BE SURE to read and understand all instructions. Failure I
to follow all instructions listed below may result in electric shock, fire and/or I
serious personal injury.
WORK AREA SAFETY
1. ALWAYS keep your work area clean and well lit. Cluttered and dark areas
invite accidents.
2. DO NOT operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust. Power tools create sparks
which may ignite the dust or fumes.
3. ALWAYS keep bystanders, children and visitors away while operating a
power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
1. Double insulated tools are equipped with a polarized plug (one blade is
wider than the other).This plug will fit in a polarized outlet only one way.
If the plug does not fit fully into the outlet reverse the plug. If it still
does not fit, contact a qualif ed electrician to install a polarized outlet.
DO NOT change or alter the plug in any way.
2. Double insulation [] eliminates the need for the three wire
grounded power cord and grounded power supply
system. Applicable only to Class II (double insulated) tools.
3. ALWAYS avoid body contact with grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is grounded.
4. DO NOT expose power tools to rain or wet conditions. Water entering a
power tool willincrease the risk of electric shock.
5. DO NOT abuse the cord. NEVER use the cord to carry the tools or pu
the plug from the outlet. Keep cord away from heat, oil, sharp edges or
moving parts. Replace damaged cords immediately. Damaged cords
increase the risk of electric shock.
6. When operating a power tool outside, ALWAYS use an outdoor
extension cord marked "W-A" or "W". These cords are rated for outdoor
use and reduce the risk of electric shock.
7. ALWAYS make sure that your extension cord is in good condition.When
using an exmnsion cord be sure to use one that is heavy enough to
carry the current that your tool will draw. A wire gauge (AWG) of at least
14 is recommended for an extension cord 25 feet or less in length. When
working outdoors ALWAYS use an extension cord that is suitable for outdoor
use.The cord's jacket will be marked WA, Smaller gauge wires have
greater capacity (16 gauge wlre has more capamty than 18 gauge wire).
An undersized cord will cause adrop in line voltage, resulting in loss of
power and overheating.
3

PERSONALSAFETY
1. ALWAYS stay alert, watch what you are doing and use common sense
when operating a power tool. DO NOT use tool while tired or under the
influence of drugs, alcohol or medication. A moment of inattention while
operating power tools may result in serious personal injury.
2. ALWAYS dress properly. DO NOT wear loose clothing or jewelry. Pull
back long hair. Keep your hair, clothing and gloves away from moving
parts. Loose clothing, jewelry or long hair can be caught in moving parts.
3. ALWAYS avoid accidental starting. BE SURE switch is in the "Off"
position before plugging in. Carrying tools with your finger on the switch or
plugging in tools that have the switch in the "On" position invites accidents.
4. DO NOT overreach. ALWAYS keep proper footing and balance at all
times. Proper footing and balance enables better control of the tool in
unexpected situations.
5. ALWAYS use safety equipment, Always wear eye protection.
WARNING: ALWAYS wear safety glasses or eye I
shields when operating power tools. I
4

TOOL USE AND CARE SAFETY
1. DO NOT force the toot. Use the correct tool for your application.
The correct tool will do the job better and safer at the rate for which it is
designed.
2. DO NOT use the tool if the switch does not turn it "On" or "Off".
Any tool that cannot be controlled with the switch is dangerous and
must be repaired.
3. ALWAYS disconnect the plug from the power source before making
any adjustments, changing accessories or storing the tool. Such
preventive safety measures reduce the risk of starting the tool accidentally.
4. ALWAYS store idle tools out of the reach of children and other
untrained persons. Tools are dangerous in the hands of untrained users.
5. ALWAYS check for misalignment or binding of moving parts, breakage
of parts, and any other condition that may affect the tool's operation.
If damaged, have the tool serviced before using. Many accidents are
caused by poorly maintained tools.
I Z_WARNING: USE OF ACCESSORIESTHATARE NOT RECOMMENDED I
FOR USE WITH THIS TOOL MAY CREATE AHAZARDOUS CONDITION.
6, ALWAYS use only the Craftsman accessories that are recommended for
this tool, Accessories that may be suitable for one tool can become
hazardous when used on another tool.
SERVICE SAFETY
1. Toolservice MUST BE performed only by a Sears Parts and Repair Center.
Service or maintenance performed by unqualified personnel could result in a
riskof injury.
2. When servicing a tool, ALWAYS use only identical replacement parts.
Follow instructions in the maintenance section of this manual. Use of
unauthorized parts may create a risk of electric shock or injury.
IMPORTANT! READ ALL INSTRUCTIONS
5

Your Craftsman Buffer/Polisher has built-in features to make your job easier
and more efficient. The precision-tuned counterweight system matches with
the orbital motion for a "swir!-free shine. The perimeter handle system provides
maximum balance, control and gripping comfort on any horizontal or vertical
surface. It also includes a hook and _oop strip to help keep extension cord
securely plugged into buffer/polisher.
Pad Diameter
Motor OPM
Rating
Amps
7in.
3800
120 volts, 60 Hz AC
1.0
Disposable Wax Applicator Bonnet for applying waxes
Reusable Terry Cloth Bonnet for applying and removing waxes,
and for polishing
6

BEFORE YOU BEGIN TO WAX, BUFF AND POLISH YOUR CAR:
1. Wash, clean and dry your vehicle.
2. Remove all road tar, excess grease spots and bug stains with a
general-purpose cleaner.
3. Make sure the work area is dry.
ATTACHING THE WAX APPLICATOR BONNET TO THE FOAM PAD
(See Figure 2)
WARNING: When changing accessories, ._ j/
BE SURE that the switch is in the (OFF) Fig. -_
position and the cord is unplugged.
1. Place wax applicator bonnet on foam pad
as shown in Fig. 2.
2. ALWAYS make sure that the elastic strip
on the bottom of the bonnet is securely
tucked on the underside of the foam pad.
APPLYING WAXTO BONNET (See Figures 3 and 4)
IMPORTANT: DO NOT APPLY WAX
DIRECTLY ON CAR! Fig. 3 _
APPLYING PASTE WAX TO BONNET
(See Figure 3)
1. Spread a heaping teaspoon of wax
evenly over entire surface of applicator
bonnet using a putty knife or any other ____j/°
flat object (See Fig. 3).
APPLYING LIQUID WAXTO BONNET
(See Figure 4)
1. Apply three swirls of wax over applicator
bonnet (See Fig. 4).
2. This should be enough to cover 1/4 of
car surface.
3. Forthe second and third applications,
only use about one half as much as on
first application. The bonnet will not
absorb as much wax on these
applications.
Fig. 4
7

TO TURN BUFFER/POLISHER "ON" OR "OFF"
Slide switch forward to turn tool "On",
slide it backwards to shut tool "Off".
NOTE: After plugging tool into extension
cord, loop extension cord over tool's stub
length plug.Then wrap hook and loop strip
around extension cord to secure it in place.
IMPORTANT: Read, understand and follow
all safety and user instructions in this
manual and all directions and warnings on
polishes and waxes.
APPLYING WAX ONTO SURFACE TO
BE POLISHED (See Figures 5 to 8)
NOTE: To avoid splashing wax, ALWAYS
start and stop the buffer /polisher on or
against the surface to be polished.
1. Place extension cord over your shoulder
to keep it safely out of your way
(See Figure 5).
2. Turn buffer/polisher "On".
3. Apply wax in a straight line with either
a side-to-side or back-and-forth motion.
ALWAYS use broad, even strokes
when applying wax. (See Figure 6).
4. Start applying wax to the flat surfaces
(hood, trunk and roof) first, Wax one
section at a time (See Figure 7).
5. After flat surfaces are covered with wax,
do the sides, The perimeter handle
system allows easy polishing of
horizontal and vertical surfaces. Hold tool
with the cord hanging free (See Figure 8),
6. Apply wax in a thin, even coat. Too
much wax does not add any more
protection and only makes the wax
removal more difficult.
7. The random orbit motion of the
buffer/polisher provides wax application
that cannot be duplicated, not even
"by hand".
IMPORTANT: DO NOT apply excessive
pressure against the work surface with
this tool. The random orbital motion
feature on this tool will perform better
Fig. 7
1'.3
LEFT RIGHT
2_4
when less pressure is applied. Applying
excessive pressure will slow the random
orbital motion and reduce the effectiveness of the tool.
8. It is easiest to apply the wax to the entire surface before starting the removal
phase; however, follow the specific recommendations of the wax or polish
being used. 8
iii;:!!
iiilii

APPLYING WAX ONTO SURFACE TO BE POLISHED cont. (See Figure 9)
9. Shut "Off" the buffer/poisher when
you have finished applying wax with
applicator bonnet.
10, Remove the wax applicator bonnet
and use it to hand polish all the
hard-to-reach surfaces (under
bumpers, around door handles, etc.).
(See Figure 9.)
11. Properly dispose of wax applicator
bonnet.
ATTACHING THE POLISHING BONNETTOTHE FOAM PAD
(See Figure 10)
WARNING: When changing accessories,
BE SURE that the switch is in the
(OFF) position and the cord is unplugged,
1. Place the terry cloth bonnet on foam
pad as shown in Fig. 10.
2. ALWAYS make sure that the elastic
strip on the bottom of the bonnet is
securely tucked on the underside of the
foam pad,
BUFFING AND POLISHING -REMOVING THE WAX FROM THE SURFACE
(See Figure 11)
NOTE; Remove wax in the same order
as it was applied.
1. Place extension cord over your shoulder.
2. Turn buffer/polisher "On".
3. Buff and polish (remove wax) when it
has dried to an even haze.
NOTE; For best results, use long,
sweeping strokes in a criss--cross pattern
when removing wax.
_> <Ej;£-iiiiiiiiii:.:.
4. Buff and polish the entire surface until all dried wax is removed, Remove the
bonnet from time to time and shake out the dried wax residue. A bonnet with
excess residue will cause streaking. You may need to replace the bonnet with
a new one if you can't get it clean enough to avoid streaking.
5. Use a clean terry cloth bonnet for final buffing and polishing. Or use a foam
polishing bonnet (sold separately) for the ultimate "showroom shine
9

IMPORTANT: DO NOT apply excessive pressure against the work surface with
this tool. The random orbital motion feature on this tool will perform better when
less pressure is applied. Applying excessive pressure will slew the random
orbiting motion and reduce the effectiveness of the tool.
CAR CARE TIPS
1. Wash and polish the car 3 to 4 times a year to help ensure paint protection.
2. Wash the car at least every 2 weeks with a car wash solution which will not
harm the finish or strip the wax. AVOID washing with household detergents.
3. Wash with a clean sponge and dry with a terry cloth towel to help prevent
dirt from scratching the paint. Start on the top and work down.
4. Remove bugs, bird droppings, tree sap and tar from the car's surface on a
daily basis.
5. ALWAYS make sure that the car's surface is cool before washing.
6. Avoid parking near sprinklers, because water spots are difficult to remove.
7. ALWAYS keep glass cleaner chemicals away from painted surfaces.
Spray the cleaner onto a towel, NOT directly on the windows.
10
