Craftsman 315.175980 User manual

PERATOR'S MAN AL
MANUAL DEL OPERADOR
19.2 VOLT WET/DRY CANISTER
ASPIRADORA PARA USO
EN SECO/HOMEDO, 19,2 V
VAC
Model No.
315.1 75980
NQmero de modelo
315.175980
WARNING: Toreduoethe
risk of injury,the user must read and
understand the operator's manual
before using this product.
ADVERTENCIA: Para
reducir el riesgo de lesiones, el usuario
debe leer y comprender el manual del
operador antes de usar este producto.
Customer Help Line: 1-800-932-3188
Tel_fono de atenci6n al consumidor: 1-800-932-3188
BATTERIES AND CHARGERS
SOLD SEPARATELY
LAS BATERJAS Y LOS
CARGADORES SE VENDEN
POR SEPARADO
Sears Brands Management Corporation, 3333 Beverly Rd., Hoffman Estates, IL 60179 USA
Visit the Craftsman web page: www.sears.com/craftsman
Visite el sitio web de Craftsman: www.sears.com/craftsman
987000-752
10-20-10 (REV:05)
Save this manual for future reference
Guarde este manual para futuras consulta

ENGLISH
[] Warranty ...................................................................... 2
[] Introduction ................................................................. 2
[] Important Safety Instructions ................................. 3-4
[] Symbols ...................................................................... 5
[] Features ...................................................................... 6
[] Assembly ................................................................ 6-7
[] Operation ................................................................ 7-8
[] Maintenance ......................................................... 9-10
[] Accessories ............................................................... 10
[] Illustrated Parts List .................................................. 11
[] Figure Numbers (Illustrations) ................................... i-ii
[] Parts Ordering/Service ................................ Back Page
ESPANOL
[] Garant[a ...................................................................... 2
[] Introducci6n ................................................................ 2
[] Instrucciones importantes de seguridad ................ 3-4
[] S[mbolos ..................................................................... 5
[] Caracter[sticas ............................................................ 6
[] Armado ................................................................... 6-7
[] Funcionamiento ...................................................... 7-9
[] Mantenimiento ...................................................... 9-11
[] Accesorios ................................................................ 11
[] Figura numeras (ilustraciones) .................................. i-ii
[] Pedidos de piezas/servicio ................... P_g. posterior
CRAFTSMAN® ONE YEAR LiMiTED WARRANTY
FOR ONE YEAR from the date of purchase, this product is warranted against any defects in material or workmanship. With
proof of purchase, defective product will be replaced free of charge.
For warranty coverage details to obtain free replacement, visit the web site: www.craftsman.com.
This warranty does not cover the filters, which are expendable parts that can wear out from normal use within the warranty
period.
This warranty is void ifthis product isever used while providing commercial services or ifrented to another person.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Sears Brands Management Corporation, Hoffman Estates, IL 60179
GARANT(A LIMITADA DE CRAFTSMAN POR UN ANO
Este producto tiene garant[a pot cualquier defecto en material o mano de obra DURANTE UN ANO desde la fecha de compra.
Los productos defectuosos se remplazar_n sin cargo si presenta un comprobante de pago.
Si desea conocer los detalles de la cobertura de la garantia para conseguir reparaciones o recambios, visite el sitio
Web: www.craftsman.com
Esta garantfa no cubre la filtros, que es una pieza fungible que puede desgastarse pot el uso normal durante el
perfodo de garantfa.
La garantfa pierde validez si este producto se utiliza mientras se prestan servicios comerciales o si se alquila a otra persona.
Esta garantfa le otorga derechos legales espedficos y tambi_n puede gozar de otros derechos que varfan seg0n el estado.
Sears Brands Management Corporation, Hoffman Estates, IL 60179
This tool has many features for making its use more pleasan_ and enjoyable. Safety, performance, and dependability
have been given top priority in the design of this product making it easy to maintain and operate.
Esta herramienta ofrece numerosas caracter[sticas para hacer m_s agradable y placentero su uso. En el disefio de
este producto se ha conferido prioridad a la seguridad, el desempefio y la fiabilidad, por Io cual se facilita su manejo y
mantenimiento.

SAVE THESE
WARNING! READANDUNDER-
STAND ALL iNSTRUCTiONS. Failure to follow
all instructions listed below, may result in electric
shock, fire and/or serious personal injury.
When using an electrical appliance, basic precautions
should always be followed, including the following:
READ ALL INSTRUCT(ONS BEFORE US(NG THIS
APPLIANCE
A WARNING: Toreducetheriskofelec-
tricshock DO NOT expose to rain. Store indoors.
•Dress properly. Do not wear loose clothing or
jewelry. Contain long hair. Keep your hair and
clothing away from moving parts. Loose clothes,
jewelry, or long hair can be caught in internal moving
parts.
•Do not overreach. Keep proper footing and balance
at all times. Proper footing and balance enables better
control of the canister vac in unexpected situations. Do
not use on a ladder or unstable support.
•Use safety equipment. Dust mask must be used for
appropriate conditions.
• Always wear eye protection with side shields
marked to comply with ANSI Z87.1. Following this
rule will reduce the risk of serious personal injury.
•Do not allow children to operate canister vac or
play with canister vac as a toy. Close attention is
necessary when used near children.
•Use this product ONLY for its intended use as
described in this manual. Use only the attachments
recommended in this manual.
•If product is not working properly, has been
dropped, damaged, left outdoors, or dropped into
water, return to your nearest service center.
•Do not handle charger plug or canister vac with wet
hands.
•Do not put any objects in ventilation openings. Do
not use with any opening blocked. Keep openings free
of dust, lint, hair, and anything that may reduce air flow.
•NEVER vacuum materials such as hot coals,
cigarette butts, matches, burning or smoking
ashes, etc.
•DO NOT use to pick up flammable or combustible
liquids, such as gasoline, or use in areas where
they may be present.
•Do not use without dust bowl or filter in place.
iNSTRUCTIONS
•Turn off all controls before unplugging from or
plugging into an electrical outlet for charging.
•Use extra care when using on stairs.
•Do not use to pick up hard objects such as nails,
screws, coins, etc. Damage or injurycould result.
•Do not incinerate this appliance even if it is severely
damaged. The batteries can explode in a fire.
•Canister vac does not have to be plugged into an
electrical outlet, therefore it is always in operating
condition. Be aware of possible hazards when using
the canister vac or when changing accessories.
•Remove battery when the vacuum is not in use and
before servicing.
•Use only the charger recommended for your
canister vac. Do not substitute any other charger. Use
of another charger could cause batteries to explode
causing possible serious injury.
•Use battery only with charger listed. For use with
19.2V nicke(-cadmium and 19.2V (ithium-ion battery
packs, see tool/appliance/battery pacWcharger cor-
relation supplement 988000-272.
•Do not place canister vac or batteries near fire or
heat. They may explode.
•The product should be charged in alocation where the
temperature is more than 50°F but less than 100°F.
•Under extreme usage or temperature conditions,
battery leakage may occur. If liquid comes in
contact with skin, wash at least 10 minutes then seek
immediate medical attention.
•Batteries can explode in the presence of a source
of ignition, such as a pilot light. To reduce the risk of
serious personal injury, never use any cordless product
in the presence of an open flame. An exploded battery
can propel debris and chemicals. If exposed, flush with
water immediately.
•Protect your lungs. Wear a face or dust mask if the
operation is dusty. Following this rule will reduce the
risk of serious personal injury.
•Check for misalignment or binding of moving parts,
breakage of parts, and any other condition that may
affect the product's operation. If damaged, have the
product serviced before using. Many accidents are
caused by poorly maintained products.
• Use only accessories that are recommended by the
manufacturer for your model. Accessories that may
be suitable for one canister vac may create a risk of
injury when used on another canister vac.
3-English

[] Product service must be performed only by
qualified repair personnel. Service or maintenance
performed by unqualified personnel could result in a
risk of injury.
[] When servicing product, use only identical
replacement parts. Follow instructions in the
Maintenance section of this manual. Use of
unauthorized parts or failure to follow Maintenance
instructions may create a risk of electric shock or
injury.
[] When battery pack is not in use, keep it away from
other metal objects like paper clips, coins, keys,
nails, screws, or other small metal objects that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause
burns or a fire.
[] Do not crush, drop or damage battery pack. Do
not use a battery pack or charger that has been
dropped or received a sharp blow. A damaged
battery is subject to explosion. Properly dispose of a
dropped or damaged battery immediately.
[] Do not charge battery tool in a damp or wet loca-
tion. Following this rule will reduce the risk of electric
shock.
[] Save these instructions. Refer to them frequently and
use them to instruct others who may use this hand vac.
If you loan someone this hand vac, loan them these
instructions also to prevent misuse of the product and
possible injury.
4 - English

The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL MEANING
_, Indicates an imminently hazardous situation, which, if not avoided, will result in
DANGER: death or serious injury.
,_ WARNING: Indicates a potentially hazardous situation, which, if not avoided, could result in
death or serious injury.
,_ CAUTION: Indicates a potentially hazardous situation, which, if not avoided, may result in minor
or moderate injury.
CAUTION: (Without Safety Alert Symbol) Indicates a situation that may result in property dam-
age.
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL
A
0
@
V
min
==-==_
no
.../min
NAME DESIGNATION/EXPLANATION
Safety Ale_
Read Operator's Manual
Eye Protection
Wet Conditions Alert
Recycle Symbols
Volts
Minutes
Direct Current
No Load Speed
Per Minute
Indicates a potential personal injury hazard.
To reduce the risk of injury, user must read and understand
operator's manual before using this product.
Always wear eye protection with side shields marked to comply
with ANSI Z87.1.
Do not expose to rain or use in damp locations.
This product uses nickel-cadmium (Ni-Cd) and lithium-ion
(Li-ion) batteries. Local, state, or federal laws may prohibit disposal
of batteries in ordinary trash. Consult your local waste authority
for information regarding available recycling and/or disposal
options.
Voltage
Time
Type or a characteristic of current
Rotational speed, at no load
Revolutions, strokes, surface speed, orbits etc., per minute
5 - English

PRODUCT SPECIFICATIONS
Motor ............................................................... 19.2 Volt DC Hose Length .................................................................. 5 ft.
Collection Capacity .............................................. 2 Gallons Hose Diameter ........................................................ 1-1/4 in.
KNOW YOUR CANISTER VAC
See Figure 1, page L
The safe use of this product requires an understanding of
the information on the tool and in this operator's manual
as well as a knowledge of the project you are attempt-
ing. Before use of this product, familiarize yourself with all
operating features and safety rules.
ATTACHMENTS
The vacuum attachments can perform a variety of tasks
and are easily stored in the detachable tool storage belt.
BLOWER FEATURE
The canister vac can also serve as a blower.
DETACHABLE TOOL STORAGE BELT
This detachable tool storage belt stores the attachments
when not in use and can be secured in a variety of places
for ease of use.
DRAIN PLUG
The drain plug on the back of the canister vac is used to
quickly drain liquids from the collection container.
LARGE CAPACITY COLLECTION CONTAINER
The collection container can hold up to 2 gallons of waste.
VACUUM HOSE ASSEMBLY
The detachable hose is flexible and can use a variety of
attachments.
WET/DRY CAPABILITY
The canister vac can be used to vacuum either wet or dry
waste.
UNPACKING
This product has been shipped completely assembled.
[] Carefully remove the tool and any accessories from the
box. Make sure that all items listed in the packing list
are included.
WARNING: DO not use this product if it is
not completely assembled or if any parts appear to
be missing or damaged. Use of a product that is not
properly and completely assembled could result in
serious personal injury.
[] Inspect the tool carefully to make sure no breakage or
damage occurred during shipping.
[] Do not discard the packing material until you have
carefully inspected and satisfactorily operated the tool.
[] If any parts are damaged or missing, please call
1-800-932-3188 for assistance.
PACKING LIST
Wet/Dry Canister Vac with Dry User Filter
Vacuum Hose
Wide Nozzle with Squeegee
Floor Brush
Crevice Tool
Car Nozzle
Wand
Detachable Tool Storage Belt
Dry Use Filter (2)
Wet Use Foam Filter
Operator's Manual
WARNING: anypartsaredamagedor
missing do not operate this product until the parts
are replaced. Use of this product with damaged or
missing parts could result in serious personal injury.
6 - English

WARNING: Do not attempt to modify this
product or create accessories not recommended for
use with this product. Any such alteration or modi-
fication is misuse and could result in a hazardous
condition leading to possible serious personal injury.
WARNING: Toprevent accidentalstart-
ingthat could cause serious personal injury, always
remove the battery pack from the product when as-
sembling parts.
A
WARNING: DO not allow familiarity with
this product to make you careless. Remember that
a careless fraction of a second is sufficient to inflict
serious injury.
WARNING: Always wear eye protection
with side shields marked to comply with ANSI Z87.1.
Following this rule will reduce the risk of eye injury.
APPLICATIONS
You may use this tool for the purposes listed below:
Vacuum Functions:
[] Light-duty vacuuming of wet or dry surfaces
Blower Functions:
[] Clearing hard surfaces such as driveways and walkways
[] Keeping decks and driveways free from leaves and
pine needles
WARNING: Always remove battery
pack from your tool when you are assembling parts,
making adjustments, cleaning, or when not in use.
Removing battery pack will prevent accidental start-
ing that could cause serious personal injury.
INSTALLING BATTERY PACK
See Figures 2 -3, page iL
[] Place the power switch in the OFF (O) position.
[] Place the battery pack in the canister vac.
[] Make sure the latches on each side of the battery pack
snap in place and that battery pack is secured in the
canister vac before beginning operation.
REMOVING BATTERY PACK
See Figures 2 -3, page ii,
[] Place the power switch in the OFF (O) position.
[] Locate latches on side of battery pack and depress
both sides to release battery pack.
[] Remove battery pack from the canister vac.
This product will accept Craftsman® 19.2 V lithium-ion
battery packs and Craftsman® 19.2 V nickel-cadmium
battery packs.
For complete charging instructions, refer to the Operator's
Manual for the battery packs and chargers for your
models.
BATTERY PROTECTION FEATURES
Craftsman® 19.2 V lithium-ion batteries are designed with
features that protect the lithium-ion cells and maximize
battery life. Under some operating conditions, these built-
in features may cause the battery and the tool it is power-
ing to act differently from nickel-cadmium batteries.
During some applications, the battery electronics may
signal the battery to shut down, and cause the tool to stop
running. To reset the battery and tool, release the trigger
and resume normal operation.
IAHA_I_| I kl f__.
,vv_rlJll_lJll|_ll%_, Battery tools are always
in operating condition. Therefore, switch should
always be in the OFF (O } position when not in use
or carrying at your side.
STARTING/STOPPING THE CANISTER VAC
See Figures 3, page ii.
[] To start the canister vac, place the power switch in the
ON (I) position.
[] To stop the canister vac, place the power switch in the
OFF (O) position.
HOSE ATTACHMENT
See Figure 4, page iL
[] To attach the hose, push tapered end of hose into
opening of the vacuum port.
[] To remove the hose, hold the tapered end and pull
hose from vacuum port.
USING THE ATTACHMENTS
See Figure 5, page iL
Vacuuming can be performed with either the hose alone
or the hose and vacuum attachments together.
[] Turn off the canister vac.
[] Insert the attachment into the front end of the hose,
making sure the attachment is firmly in place.
[] To remove, hold the attachment and pull from hose.
7 - English

Thevacuumattachmentsaredesignedforthefollowing
applications:
[] Thewidenozzlewithsqueegeeisusedtovacuum
large,fiat,dry,orwetsurfaces.
[] Thefloorbrushisusedtovacuumcarpetedsurfaces.
[] Thewandisusedasahandleinvacmodeandasa
blowertubeinblowermode.Thewandcanalsofunc-
tionasanextensiontoanyofthecanistervacattach-
ments.
[] Thecarnozzleisusedforcarinteriorsorforvacuum-
ingsmallsurfaceareas.Thecarnozzlecanalsobe
usedwiththewandwhilethecanistervacisinblower
modeforwidenedairflow.
[] Thecrevicetoolisusedtovacuumnarrow,hardto
reachplaces.
DETACHABLE TOOL STORAGE BELT
See Figure 6, page iL
When not in use, the vacuum attachments provided
with the canister vac can be placed in the storage areas
located in the tool belt. The belt can also be attached and
secured in a variety of places for ease of use.
DRY VACUUMING
WARNING: NEVE.vacoommate.-
als such as hot coals, cigarette butts, matches,
burning or smoking ashes, etc.
Vacuum only items small enough to fit through the hose or
the attachment. When vacuuming, make sure that the dry
use filter stays in place. The performance of the canister
vac will decrease with a full collection container. Upon
emptying the collection container, check to see if the dry
use filter needs replacing.
NOTE: The canister vac is shipped ready for dry use
vacuuming. To equip the canister vac for wet use, see
Switching Filters in the MAINTENANCE section of this
manual.
WET VACUUMING
The canister vac can be used to vacuum small amounts
of liquid. However, use caution when vacuuming larger
amounts of liquid, as this could cause possible problems.
When wet or dry vacuuming, make sure the drain plug is
firmly in place.
When wet vacuuming, be aware that your canister vac
is equipped with a check ball inside the filter unit hous-
ing. This check ball is specially designed to work with
wet vacuuming applications to shut the suction off when
the collection container reaches full capacity. When the
suction shuts off due to a full collection container, turn the
canister vac OFF and empty the collection container as
shown in MAINTENANCE.
NOTE: When wet vacuuming, it is necessary to change
the filter from the dry use filter to the included wet use
foam filter. To equip the canister vac for wet use, see
Switching Filters in the MAINTENANCE section of this
manual.
WARNING: When vacuuming liquid,
make sure the canister vac does not get sub-
merged or doused in liquid, which could cause
shock, vacuum failure, or personal injury.
USING THE CANISTER VAC AS A BLOWER
See Figure 7, page ft.
WARNING: Never use blower near
fires, fireplaces, hot ashes, barbecue pits, etc.,
which may cause fire to spread.
At all times, the canister vac blows air through the blower
port as part of the exhaust system. However, you can use
the canister vac as a blower by attaching the wand to the
blower port.
Remove the battery pack from the canister vac.
Remove the hose from the tank if attached.
[]
[]
[]
[]
[]
[]
Remove the detachable tool storage belt.
Remove the motor unit from the collection container
assembly by lifting the latches simultaneously.
Remove the wand from the hose if attached.
To attach the wand, push larger end of wand into the
opening of the blower port. For wider air flow, attach
the car nozzle to the end of the wand.
[] To remove the wand, pull wand from opening in blower
port.
To keep from scattering debris, blow around the outer
edges of a debris pile. Never blow directly into the center
of a pile.
Use rakes and brooms to loosen debris before blowing. In
dusty conditions, slightly dampen surfaces when water is
available.
Watch out for children, pets, open windows, or freshly
washed cars, and blow debris safely away.
After using blowers or other equipment, CLEAN UP! Dis-
pose of debris properly.
8 - English

A[]
WARNING: When servicing, use only []
identical replacement parts. Use of any other parts
may create a hazard or cause product damage. []
WARNING: A,waysweareyeprotection
with side shields marked to comply with ANSI Z87.1.
Failure to do so could result in objects being thrown
into your eyes resulting in possible serious injury.
WARNING: To avoid serious personal
injury, always remove the battery pack from the tool
when cleaning or performing any maintenance.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use.
Use clean cloths to remove dirt, dust, oil, grease, etc.
WARNING: Do not at anytime let
brake fluids, gasoline, petroleum-based products,
penetrating oils, etc., come in contact with plastic
parts. Chemicals can damage, weaken or destroy
plastic which may result in serious personal injury.
Remove the filter and filter unit.
Remove the filter by removing the retention band and
pulling filter off of the filter unit.
Replace wet or dry filter with appropriate one by sliding
new filter over filter unit.
[] Reattach retention band.
REMOVING DRY PICK-UP
See Figure 8, page ii,
The collection container should be checked, emptied, and
cleaned periodically to obtain maximum efficiency.
[] Remove the battery pack from the canister vac.
[] Lift the tabs on the side of the canister vac. Pull the
collection container down and off to separate it from
the motor housing.
[] Remove filter unit from tank assembly.
[] Empty the collection container; wash out if necessary.
Before reattaching to the canister vac, make sure all
pieces are completely dry.
[] To reattach, snap the collection container into the slots
on the motor housing.
REMOVING LIQUID WASTE
See Figures 8 -9, page ii.
Removing pick-up can be completed in two ways.
Only the parts shown on the parts list are intended to
be repaired or replaced by the customer. All other parts
should be replaced at an Authorized Service Center.
REPLACING AND CLEANING THE FILTER
See Figure 8, page ii.
[] Remove the battery pack from the canister vac.
[] Lift the tabs on the side of the canister vac. Pull the
collection container down and off to separate it from
the motor housing.
[] Remove the filter unit.
[] Remove the filter by removing the retention band and
pulling filter off of the filter unit.
[] Shake or lightly brush any dust or dirt off the filter.
[] Replace dry filter or switch to wet filter if needed.
To clean:
[] To replace, slide new filter over filter unit and reattach
retention band.
[] Empty the filter, filter unit, and collection container;
wash if necessary. Before reattaching to the canister
vac, make sure all pieces are completely dry.
SWITCHING FILTERS
See Figure 8, page iL
[] Remove the battery pack from the canister vac.
To remove liquid pick-up by removing the collection
container:
[] Lift the tabs on the side of the canister vac. Pull the
collection container down and off to separate it from
the motor housing.
[] Empty the collection container; wash if necessary.
Before reattaching to the canister vac, make sure all
pieces are completely dry.
To remove pick-up using the drain plug:
[] Remove the battery pack from the canister vac.
[] Remove the drain plug.
[] Tip canister vac to drain liquid.
[] Replace the drain plug.
CAUTION: oo not allow liquid pick up
to remain in the collection container for extended
periods of time. Moisture can develop in the motor
compartment and shorten the life of the motor.
CAUTION: Do not turn unit upside
down, as liquid may enter the motor unit.
[] Lift the tabs on the side of the canister vac. Pull the
collection container down and off to separate it from
the motor housing.
9 - English

REPLACEMENTFUSE
See Figure 10, page ii.
In the event the fuse in the canister vac blows, it will need
to be replaced. Look for replacement fuses where you
purchased this product.
[] Remove the battery pack from the canister vac to ac-
cess fuse housing.
[] Remove the current fuse and discard. Use a pair of
fuse pullers if necessary.
[] Use only 30 amp JAT blade type automotive fuse to re-
place the blown fuse. If canister vac still will not work,
take it to an authorized service center for repair.
STORAGE (1 MONTH OR LONGER)
[] Clean all foreign material from the canister vac.
[] Empty the collection container before storage.
[] Store indoors in a place that is inaccessible to chil-
dren. Keep away from corrosive agents such as garden
chemicals and de-icing salts.
BATTERY PACK REMOVAL AND PREPARATION
FOR RECYCLING
WARNING: Uponremoval, coverthe
battery pack's terminals with heavy-duty adhesive
tape. Do not attempt to destroy or disassemble
battery pack or remove any of its components.
Nickel-cadmium batteries must be recycled or
disposed of properly. Also, never touch both termi-
nals with metal objects and/or body parts as short
circuit may result. Keep away from children. Failure
to comply with these warnings could result in fire
and/or serious injury.
The following recommended accessories are currently available at retail stores:
917888 Wet Use Foam Filter
916949 Dry Use Filter
-,,-WARNING: Current attachments and accessories available for use with this tool are listed above. Do
not use any attachments or accessories not recommended by the manufacturer of this tool. The use of attachments
or accessories not recommended can result in serious personal injury.
10 - English

[CRAFTSMAN 19.2 VOLT CANISTER VAC - MODEL NUMBER 315.175980
The model number will be found on a label attached to the motor housing. Always mention the model ]
number in all correspondence regarding your CANISTER VAC or when ordering repair parts. J
SEE BACK PAGE FOR PARTS ORDERING iNSTRUCTiONS
412
11
t210
/9
/
!
8
Key PaN
No. Number
1 019023001056
2 019023001057
3 019023001041
4 019023001045
5 019023001048
6 019023001042
7 019023001043
8 019023001052
9 019023001051
10 019023001049
11 019023001050
12 019023001055
13 019023001059
14 019023001075
987000752
PARTS LiST
Description Qty.
Logo Label ...................................................................................................... 1
Data Label ....................................................................................................... 1
Drain Plug ....................................................................................................... 1
Vacuum Hose .................................................................................................. 1
Detachable Tool Storage Belt ......................................................................... 1
Wet Use Foam Filter ........................................................................................ 1
Dry Use Filter .................................................................................................. 1
Wide Nozzle with Squeegee ........................................................................... 1
Crevice Tool .................................................................................................... 1
Wand ............................................................................................................... 1
Car Nozzle ....................................................................................................... 1
Floor Brush ..................................................................................................... 1
Switch Label ................................................................................................... 1
Warning Label ................................................................................................. 1
Operator's Manual (Not Shown) (019023001068) ........................................... 1
11 - English

12-English

A
\
\
B
I\i
K\
A- Vacuum hose(mangueradeaspiradora)
B - Drain plug (tapon dedrenaje)
C- Collectioncontainer (contenedordecaptacion)
D- Detachabletool storage belt (cinturon desmontabledelalmacenaje
de herramientas)
E - Wet usefoamfilter (filtro dehumedo)
F - Dry usefilter (filtro paraseco)
G- Wide nozzlewith squeegee(boquilla anchacon limpiador degoma)
H- Floor brush (cepillopara pisos)
I - Crevicetool (boquilla para hendidurasangostas)
J - Carnozzle(boquilla paracarros)
K- Wand(tubo)

A
CB
A- Depresslatchesto releasebatterypack
(pulsar los pestillos parasoltar el paquetede
baterias)
B- Latches(pestillos)
C- Battery pack(bateria)
A
A- Powerswitch (interruptor)
B- On(I) [encendido(I)]
C- Off (0) [apagado(0)]
B
A- Hose(manguera)
B- Vacuumport(aberturadelasopladora)
A
/
DJ !
A- Wand(tubo)
B - Wide nozzlewith squeegee(boquilla ancha
con limpiador degoma)
C- Carnozzle(boquilla paracarros)
D- Crevicetool (boquilla para hendiduras
angostas)
E - Floor brush (cepillo parapisos)
A- Toolbelt (cinturon de herramientas)
A
\
A - Blowerport (aberturade la sopladora)
B- Wand(tubo)
_E
A- Tab(orejeta)
B- Filterunit (unidaddelfiltro)
C- Wet usefoamfilter (filtro deespumapara
humedotubo)
D- Dry usefilter (filtro paraseco)
E - Retention band(bandaderetencion)
F - Collectioncontainer (contenedorde
captacion)
A
° \
A- Fusehousing (alojamientodelfusible)
B - Replacementfuse (fusible derepuesto)

GUARDE ESTAS INSTRUCCIONES
iADVERTENCIA! LEA Y
COMPRENDA TODAS LAS INSTRUCCIONES.
El incumplimiento de las instrucciones se_aladas
enseguida puede causar descargas el_ctricas,
incendios y lesiones serias.
AI utilizar un aparato el_ctrico, deben seguirse ciertas
precauciones b_sicas, como las siguientes.
LEA TODAS LAS INSTRUCCIONES ANTES
DE USAR ESTE APARATO
AADVERTENCIA: Para reducir el
riesgo de una descarga electrica NO exponga la
unidad a la Iluvia. Guarde la unidad en el interior.
•Vistase de manera apropiada. No vista ropas
holgadas ni porte joyas. Rec6jase el cabello siesta
largo. Mantenga el cabello y la ropa alejados de las
piezas m6viles. Las ropas holgadas y las joyas, as[
como el cabello largo, pueden ser atrapados por las
piezas m6viles internas.
• No se estire demasiado. Mantenga una postura
firme y buen equilibrio en todo momento. La postura
firme y el buen equilibrio permiten un mejor control de
la aspiradora en situaciones inesperadas. No utilice
la unidad al estar en una escalera o en un soporte
inestable.
•Use equipo de seguridad. Se debe usar mascarilla
contra el polvo en las condiciones que asf Io requieran.
•No permita que ningt_n ni_o utilice o juegue con
la aspiradora como si fuera un juguete. AI ser
usado este producto cerca de los ni_os, debe tenerse
extrema precauci6n.
•Utilice este producto SOLAMENTE para los fines
especificados en este manual. Solamente utilice
accesorios recomendados en este manual.
•Si el producto no esta funcionando
adecuadamente, se dej6 caer, se daSo, se dej6 a la
intemperie, o se dej6 caer dentro del agua, regr_selo al
centro de servicio mas cercano.
•No maneje con manos mojadas la clavija del
cargador o la aspiradora.
•No ponga ningt_n objeto en las ventilas. No use la
unidad con ninguna abertura bloqueada. Mantenga las
aberturas libres de polvo, pelusa, pelo y cualquier cosa
que pueda reducir el flujo de aire.
•NUNCA aspire materiales con brasas calientes,
colillas de cigarrillos, f6sforos, cenizas candentes o
humeantes, etc.
•NO utilice la unidad para recoger liquidos
inflamables o combustibles, como gasolina, ni la
utilice en lugares donde dichos liquidos puedan
estar presentes.
•No use la unidad sin que el colector de polvo y el
filtro se encuentren en su lugar.
•Apague todos los controles antes de desenchufar
o enchufar la unidad en una toma de corriente para
cargarla.
•Tenga cuidado extremo al utilizar la unidad en
escaleras.
•No use la unidad para recoger objetos duros como
clavos, tornillos, monedas, etc. Pueden producirse
da_os o lesiones.
• No incinere este aparato, incluso siesta dahado
seriamente. Las baterfas pueden estallar e
incendiarse.
•La aspiradora no tiene que estar enchufada en una
toma de corriente, por Io tanto siempre esta en
condiciones de funcionamiento. Est_ consciente de
los posibles peligros cuando est_ usando la aspiradora
o cuando est_ cambiando los accesorios de la misma.
•Cuando no est_ usandose la aspiradora y antes de
darsele servicio debe retirarse la bateria.
•Solamente utilice el cargador recomendado para la
aspiradora. No utilice ningOn otro cargador. El empleo
de cualquier otro cargador podrfa causar el estallido de
las baterias y posibles lesiones graves.
• Cargue las baterias solamente con el cargador
indicado. Para utilizar con paquetes de baterias de
n[quel-cadmio de 19,2 V o de iones de litio de 19,2 V,
consulte el folleto de la herramienta/aparato/paquete de
bater[as/cargador complementario 988000-272.
•No coloque la aspiradora ni las baterias cerca del
fuego odel calor. Pueden explotar.
•El producto debe cargarse en un lugar donde la
temperatura est_ entre 10 y 38 °C (50 ylO0 °F).
•En condiciones extremas de uso o temperatura es
posible que se derrame fluido de la bateria. Si el
liquido entra en contacto con la piel, lavese cuando
menos durante 10 minutos y busque atenci6n m_dica
de inmediato.
•Las baterias pueden explotar en presencia de
fuentes de inflamaci6n, como los pilotos de gas.
Para reducir el riesgo de lesiones serias, nunca use
un producto inalambrico en presencia de llamas
expuestas. La explosi6n de una bateria puede lanzar
fragmentos y compuestos quimicos. Si ha estado
expuesto a la explosi6n de una bateria, lavese de
inmediato con agua.
3- Espa_ol

•Prot_jase los pulmones. Use una careta o
mascarilla contra el polvo si la operaci6n genera
mucho polvo. Con el cumplimiento de esta regla se
reduce el riesgo de lesiones corporales de gravedad.
• Revise para vet si hay desalineaci6n o atoramiento
de piezas moviles, ruptura de piezas o toda otra
condici6n que pueda afectar el funcionamiento
del producto. Si se daha el producto, haga que
le den mantenimiento antes de volver autilizarlo.
Numerosos accidentes son causados por productos
mal cuidados.
•$61o utilice accesorios recomendados pot el
fabricante para cada modelo en particular.
Accesorios que pueden ser adecuados para una
aspiradora pueden significar un riesgo de lesiones si se
emplean con otra.
• El servicio del producto s61o debe ser efectuado
por personal de reparacion calificado. Todo servicio
o mantenimiento efectuado por personal no calificado
puede significar un riesgo de lesiones.
• AI dar servicio a la unidad, s61o utilice piezas
de repuesto identicas. Siga las instrucciones
sehaladas en la secci6n Mantenimiento de este
manual. El empleo de piezas no autorizadas o el
incumplimiento de las instrucciones de mantenimiento
puede significar un riesgo de descarga el_ctrica o de
lesiones.
•Cuando no se use el paquete de baterias
mant_ngalo alejada de otros objetos de metal
como clips para papel, monedas, Ilaves, clavos,
tornillos u otros objetos de metal pequeSos que
puedan realizar una conexion entre los terminales.
Realizar un cortacircuito en los terminales de la bateria
puede provocar quemaduras o un incendio.
• No aplaste, deje caer o dahe el paquete de baterias.
No utilice el paquete de baterias ni el cargador si
ban sufrido una caida o un golpe contundente. Las
baterfas da_adas pueden sufrir explosiones. Deseche
de inmediato toda baterfa que haya sufrido una ca(da o
que haya sido da_ada.
• No cargue herramientas de baterias en lugares
mojados o ht_medos. Con el cumplimiento de esta
regla se reduce el riesgo de una descarga el_ctrica.
•Guarde estas instrucciones. Cons01telas con
frecuencia y empl_elas para instruir a otras personas
que puedan utilizar esta aspiradora de mano. Si presta
a alguien esta aspiradora de mano, facil[tele tambi_n
las instrucciones.
4- EspaSol

Lassiguientespalabrasdese_alizaci6nysussignificadostienenelobjetodeexplicarlosnivelesderiesgorelacionados
conesteproducto.
SiMBOLO SENAL SIGNIFICADO
Indicaunasituaci6npeligrosainminente,lacual,sinoseevita,causar_
PELIGRO: la muerte o lesiones serias.
Indica una situaci6n peligrosa posible, la cual, si no se evita, podrfa causar
ADVERTENClA: la muerte o lesiones serias.
PRECAUClON: Indica una situaci6n peligrosa posible, la cual, si no se evita, podrfa causar
lesiones menores o leves.
PRECAUClON" (Sin el sfmbolo de alerta de seguridad) Indica una situaciOn que puede
producir da5os materiales.
Es posible que se empleen en este producto algunos de los siguientes sfmbolos. Le suplicamos estudiarlos y aprender
su significado. Una correcta interpretaci6n de estos sfmbolos le permitir_ utilizar mejor y de manera m_s segura el
producto.
SiMBOLO
A
0
@
V
min
m
===
no
.../min
NOMBRE
Alerta de seguridad
Lea el manual del operador
Protecci6n ocular
Alerta de condiciones h0medas
Symboles reciclar
Volts
Minutos
Corriente continua
Velocidad en vacfo
Por minuto
DENOMI NACIC)N/EXPLICACIC)N
Indica un peligro posible de lesiones personales.
Para reducir el riesgo de lesiones, el usuario debe leery comprender
el manual del operador antes de usar este producto.
Siempre p6ngase protecci6n ocular con protecci6n lateral con la
marca de cumplimiento de la norma ANSI Z87.1.
No exponga la unidad a la Iluvia ni la use en lugares h0medos.
Este producto contiene baterfas de nfquel-cadmio (Ni-Cd) o iones
de litio (Li-ion). Es posible que algunas leyes municipales, estatales
o federales prohfban desechar las baterfas de nfquel-cadmio
en la basura normal. Consulte alas autoridades reguladoras de
desechos para obtener informaci6n en relaci6n con las alternativas
de reciclado y desecho disponibles.
Voltaje
Tiempo
Tipo o caracterfstica de corriente
Velocidad de rotaci6n, en vacfo
Revoluciones, carreras, velocidad superficial, 6rbitas, etc.,
por minuto
5- Espa_ol

ESPECIFICACIONES DEL PRODUCTO
Motor .......................................................... 18 V, corr. cont. Longitud de la manguera ...................... 1,5 metros (5 pies)
Capacidad de captaci6n ........................... 7,5 L (2 galones) Diametro de la manguera .................. 31,8 mm (1-1/4 pulg.)
FAMILIARJCESE CON SU ASPIRADORA
Vea la figura 1,pagina L
El uso seguro que este producto requiere la comprensi6n
de la informaci6n impresa en la herramienta y en el
manual del operador asf como ciertos conocimientos
sobre el proyecto a realizar. Antes de usar este
producto, familiadcese con todas las caracteristicas de
funcionamiento y normas de seguridad.
ADITAMENTOS
Los aditamentos de la aspiradora pueden Ilevar a cabo
una variedad de tareas y se almacenan facilmente en el
cintur6n desmontable del almacenaje de herramientas.
CARAOTERJSTIOA DE SOPLADORA
La aspiradora tambi_n puede servir como una sopladora.
ClNTUR()N DESMONTABLE DEL ALMACENAJE
DE HERRAMIENTAS
Almacena los aditamentos cuando no se estan utilizando
y puede ser sujeto en un amplia variedad de lugares para
facilidad de uso.
TAPON DE DRENAJE
El tap6n de drenaje en la parte trasera de la aspiradora
se utiliza para drenar rapidamente los liquidos del
contenedor de captaci6n.
CONTENEDOR DE CAPTACION DE GRANDE
CAPACIDAD
El contenedor de captaci6n tiene capacidad de hasta
7,5 L (2 galones) de desechos.
CONJUNTO DE LA MANGUERA DE ASPIRADORA
La manguera desmontable es flexible y puede utilizar una
amplia variedad de aditamentos.
CAPACIDAD PARA USO EN SECO/HUMEDO
La aspiradora puede ser utilizada para aspirar desechos
secos o hOmedos.
DESEMPAQUETADO
Este producto se empaca completamente armado.
[] Extraiga cuidadosamente de la caja la herramienta y
los accesorios. Compruebe que est_n presentes todos
los art[culos enumerados en la lista de empaquetado.
ADVERTENCIA: Nouseeste
producto si no est_ totalmente ensamblado o
si alguna pieza falta o est_ daSada. Si utiliza un
producto que no se encuentra ensamblado de forma
correcta y completa, puede sufrir lesiones graves.
[] Inspeccione cuidadosamente la herramienta, para
verificar que no haya sufrido ninguna rotura o da_o
durante el transporte.
[] No deseche el material de empaquetado hasta que
haya inspeccionado la herramienta con cuidado y la
haya utilizado satisfactoriamente.
[] Si hay piezas da_adas o faltantes, s[rvase Ilamar al
1-800-932-3188, donde le brindaremos la asistencia
necesaria.
LISTA DE EMPAQUETADO
Aspiradora para uso en seco/h0medo con filtro para seco
Manguera de aspiradora
Boquilla ancha con limpiador de goma
Cepillo para pisos
Boquilla para hendiduras angostas
Boquilla para carros
Tubo
Cintur6n de herramientas desmontable
Filtro para seco (2)
Filtro de espuma para h0medo
Manual del operador
6- Espa_ol

A
ADVERTENCIA: s_falta o est_
da_ada alguna pieza, no utilice este producto sin
haber reemplazado la pieza. Usar este producto con
partes da_adas o faltantes puede causar lesiones
serias al operador.
ADVERTENCIA: Nointente
modificar este producto ni hacer accesorios
no recomendados para la misma. Cualquier
alteraci6n o modificaci6n constituye maltrato el
cual puede causar una condici6n peligrosa, y como
consecuencia posibles lesiones corporales serias.
ADVERTENCIA: Para evitar un
arranque accidental que puede causar lesiones
corporales graves, siempre desmonte de la
herramienta el paquete de bater[as al montarle
piezas a aqu_lla.
AADVERTENCIA: Nopermita que
su familarizaci6n con las herramientas Io vuelva
descuidado. Tenga presente que un descuido de un
instante es suficiente para causar una lesi6n grave.
ADVERTENCIA: S empre
p6ngase protecci6n ocular con protecci6n lateral
con la marca de cumplimiento de la norma ANSI
Z87.1. Con el cumplimiento de esta regla se reduce
el riesgo de posibles lesiones oculares.
USOS
Esta herramienta puede emplearse para los fines
enumerados abajo:
Funciones de aspirado:
[] Limpieza liviana con aspiradora de superficies
hOmedas o secas
Funciones de sopladora:
[] Limpieza de superficies duras como los caminos de
entrada y aceras
[] Mantener terrazas y caminos de entrada libres de hojas
y agujas de pino
Este producto acepta los paquetes de bater[as Craftsman de
iones de litio de 19,2 V y los paquetes de bater[as Craftsman
de n[quel-cadmio de 19,2 V.
Para ver las instrucciones de carga completas, consulte
los manuales del operador para su bater[a y el cargador
modelos.
CARACTERiSTICAS DE PROTECClON DE LAS
BATERiAS
Las bater[as de iones de litio Craftsman de 19,2 V est_n
diseSadas con caracter[sticas que protegen las celdas de
iones de litio y maximizan la duraci6n de las bater[as.
Si la herramienta se detiene durante el uso, suelte el
gatillo para reiniciarla y reanude el funcionamiento. Si aun
as[ no funciona, se debe recargar la bater[a.
INSTALACION DEL PAQUETE DE BATERiAS
Vea la figuras 2 et 3, pagina ft.
[] Coloque el interruptor de corriente en la posici6n de
OFF (APAGADO) (0).
[] Coloque el paquete de bater[as en el aspiradora. Alinee
el saliente del paquete de bater[as respecto a la ranura
del recept_culo para bater[as del aspiradora.
[] Aseg0rese de que los pestillos a ambos lados del
paquete de bater[as calcen en su lugar con un
chasquido y que el paquete de bater[as quede firme en
el aspiradora antes de empezar a usarlo.
REMOClON DEL PAQUETE DE BATERiAS
Vea la figuras 2 et 3, pagina ii.
[] Coloque el interruptor de corriente en la posici6n de
OFF(O).
[] Localice los pestillos situados en el costado del
paquete de bater[as y opr[malos en ambos lados para
liberar _ste del aspiradora.
[] Retire del aspiradora el paquete de bater[as.
AADVERTENCIA: Lasherramientas
de baterias siempre est_n en condiciones de
funcionamiento. Por Io tanto, siempre debe estar
asegurado el interruptor cuando no est_ us_ndose
o el operador Io lleve por un lado.
7- Espa_ol

ENCENDIDO Y APAGADO DE LA ASPIRADORA
Vea la figura 3, pagina ii.
• Para arrancar el aspiradora, coloque el interruptor de
corriente en la posiciOn de ON (ENCENDIDO) (I).
• Para detener el aspiradora, coloque el interruptor de
corriente en la posici6n centro, o de OFF (APAGADO)
1o).
ADITAMENTO DE MANGUERA
Vea la figura 4, pagina ii.
•Para acoplar la manguera, empuje el extremo c6nico
de la manguera en la abertura del conducto de
succi6n.
• Para quitar la manguera, sujete el extremo c6nico y tire
de la manguera del conducto de succi6n.
EMPLEO DE LOS ADITAMENTOS
Vea la figura 5, pagina ii.
La aspiradora puede usarse ya sea s61ocon la manguera
o con la manguera y los aditamentos para la aspiradora.
• Apague la aspiradora.
• Introduzca el aditamento en el extremo delantero de
la manguera, asegurandose de que el primero haya
quedado firmemente en su lugar.
• Para quitar, sujete el aditamento y tire de la manguera.
Los aditamentos de la aspiradora estan diseSados para
las siguientes aplicaciones:
• La boquilla ancha con limpiador de goma se utiliza para
aspirar superficies hOmedas o secas, grandes y planas.
• El cepillo para pisos se utiliza para aspirar superficies
con alfombra.
• El tubo se utiliza como un mango en el modo de
aspirado y como tubo de sopladora en el modo de
sopladora. El tubo puede servir tambi_n como una
extensi6n para cualquiera de los aditamentos de la
aspiradora.
• La boquilla para hendiduras anchas se utiliza para el
aspirado en superficies pequeSas.
• La boquilla para hendiduras angostas se utiliza para
aspirar en lugares angostos de dificil acceso.
ClNTURON DESMONTABLE DEL ALMAOENAJE
DE HERRAMIENTAS
Vea la figura 6, pagina ii.
Cuando no se est_n utilizando los aditamentos de
aspiradora proporcionados con _sta, pueden colocarse en
las zonas de almacenamiento ubicadas en el cintur6n de
herramientas. El cintur6n tambi_n puede ser acoplado y
sujetado en una amplia variedad de lugares para facilidad
de uso.
ASPIRADO EN SECO
AADVERTENCIA: NUNOA
aspire materiales con brasas calientes, colillas
de cigarrillos, f6sforos, cenizas candentes o
humeantes, etc.
Aspire solamente elementos Io suficientemente peque_os
para caber a trav_s de la manguera o el aditamento.
Aseg0rese que el filtro para seco est_ en su lugar al
momento de aspirar. El desempeSo de la aspiradora
disminuira al tener Ileno el contenedor de captaci6n.
Despu_s de vaciar el contenedor de captaci6n, revisar si
el filtro para seco necesita ser cambiado.
NOTA- La aspiradora se embarca lista para aspirar en
seco. Para preparar la aspiradora con dep6sito para
materiales hOmedos, consulte Cambiar interruptores en
la secciOn MANTENIMIENTO de este manual.
ASPIRADO DE SUPERFICIES MOJADAS
La aspiradora puede utilizarse para aspirar pequeSas
cantidades de I[quido. No obstante, tenga precauci6n al
aspirar grandes cantidades de I[quido ya que puede causar
problemas posibles. Aseg0rese que el tap6n de drenaje
esta firmemente en su lugar al aspirar h0medo o seco.
AI aspirar h0medo, tenga presente que su aspiradora esta
equipara con una bola de retenci6n dentro del alojamiento
del filtro. Esta bola de retenci6n esta especialmente
diseSada para trabajar con las aplicaciones de aspirado
en h0medo, de tal manera que apaga la succi6n al
momento de que el contener de captaci6n esta Ileno.
Cuando la succi6n se apaga debido a que el contenedor
de captaci6n esta Ileno, apague (OFF) la aspiradora
y vac[e el contenedor como se muestra en la secci6n
MANTENIMIENTO.
NOTA: AI aspirar en h0medo, es necesario cambiar el
filtro para seco al filtro de espuma para h0medo incluido.
Para preparar la aspiradora con dep6sito para materiales
hOmedos, consulte Cambiar interruptores en la secciOn
MANTENIMIENTO de este manual.
,ADVERTENCIA: A,aspirar
I[quidos, asegOrese que la aspiradora no se
sumerja o moje, Io que puede causar una
descarga, falla de la aspiradora o lesiones
personales.
UTILIZACI()N DE LA ASPIRADORA COMO
SOPLADORA
Vea la figura 7, pagina ii.
ADVERTENCIA: Nunca use
el soplador cerca de fuego, fogones, cenizas
calientes, parilla de barbacoa etc. ya que podr[a
causar que el fuego se propague.
8- EspaSol
