Craftsman evolv 113.175550 User manual

owner's
manual
MODEL NO.
113.175550
Serial
Number
Model and serial
numbers may be
found on the lid.
You should record
both model and serial
numbers in a safe
place for future use.
AWARNING:
FOR YOUR
SAFETY,
READ ALL
INSTRUCTIONS
CAREFULLY
SAVE THIS
MANUAL
FOR FUTURE
REFERENCE J
evolv TM
m
9 GALLON
WET/DRY VAC
•safety
•assembly
•operation
•maintenance
•repair parts
•Espahol - pagina 15
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
Part No. SP6756 Printed in Mexico

Warranty
rCraftsman Evolv Power Tool Full Warranty
If this Craftsman Evolv product fails due to a defect in material or
workmanship within one year from the date of purchase, return it to any
Sears store or other Craftsman Evolv outlet in the United States for free
replacement.
This warranty does not cover bags or filters, which are expendable parts.
This warranty is void if this product is ever used for commercial or rental
purposes.
This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state.
Sears, Roebuck and Co., Hoffman Estates, IL 60179
IMPORTANT SAFETY INSTRUCTIONS
Safety is a combination of using common
sense, staying alert, and knowing how your
Wet/Dry Vacuum cleaner ("Vac") works.
Safety Signal Words
_. DANGER: Indicates a hazardous
situation which, if not avoided, will result
in death or serious injury.
WARNING: Indicates a hazardous
situation which, if not avoided, could
result in death or serious injury.
_k CAUTION: Indicates a hazardous
situation which, if not avoided, could
result in minor or moderate injury.
When using your Vac, always follow basic
safety precautions including the following:
A WARNING -Toreduce
• Sparks inside the motor can ignite
flammable vapors or dust. To reduce
the risk of fire or explosion, do not use
near combustible liquids, gases, or
dusts, such as gasoline or other fuels,
lighter fluid, cleaners, oil-based paints,
natural gas, coal dust, magnesium
dust, grain dust, aluminum dust, or gun
powder.
• Do not vacuum anything that is burning
or smoking, such as cigarettes,
matches, or hot ashes.
• Do not vacuum drywall dust, cold
fireplace ash, or other fine dusts with
standard filter. These may pass
through the filter and be exhausted
back into the air. Use a fine dust filter
instead.
the risk of fire, electric shock, or injury: •
• Read and understand this manual and
all labels on the Vac before operating.
• Use only as described in this manual. •
• Do not leave Vac running while
unattended - you may fail to notice
important signs indicating abnormal
operation such as loss of suction, •
debris/liquid exiting exhaust, or
abnormal motor noises. Immediately
stop using Vac if you notice these •
signs.
• Do not leave Vac while plugged in.
Unplug from outlet when not in use and
before servicing.
To reduce the risk of inhaling toxic
vapors, do not vacuum or use near
toxic or hazardous materials.
To reduce the risk of electric shock, do
not expose to rain or allow liquid to
enter motor compartment. Store
indoors.
Do not allow to be used as a toy. Close
attention is necessary when used by or
near children.
Do not use with a torn filter or without
the filter installed except when
vacuuming liquids as described in this
manual. Dry debris ingested by the
impeller may damage the motor or be
exhausted into the air.

• TurnoffVacbeforeunplugging.
• Toreducetheriskofinjuryfrom
accidentalstarting,unplugpowercord
beforechangingorcleaningfilter.
• Donotunplugbypullingoncord.To
unplug,grasptheplug,notthecord.
• Donotusewithdamagedcord,plugor
otherparts.IfyourVacisnotworking
asitshould,hasmissingparts,has
beendropped,damaged,leftoutdoors,
ordroppedintowater,callcustomer
service.
• Donotpullorcarrybycord,usecord
ashandle,closeadooroncord,orpull
cordaroundsharpedgesorcorners.
DonotrunVacovercord.Keepcord
awayfromheatedsurfaces.
• Donothandleplug,switch,ortheVac
withwethands.
ThisVacisdouble-insulated,eliminat-
ingtheneedforaseparategrounding
system.Useonlyidenticalreplacement
parts.Readtheinstructionsfor
ServicingDouble-InsulatedWet/Dry
Vacs.
• Useonlyextensioncordsthatarerated
foroutdooruse.Extensioncordsin
poorconditionortoosmallinwiresize
canposefireandshockhazards.
Toreducetheriskofthesehazards,
besurethecordisingoodcondition
andthatliquiddoesnotcontactthe
connection.Donotuseanextension
cordwithconductorssmallerthan16
gauge(AWG)insize.Toreducepower
loss,usea14gaugeextensioncordif
25to50ftlongand12gaugefor50ft
orlonger.
• Donotputanyobjectintoventilation
openings.Donotvacuumwithany
ventilationopeningsblocked;keepfree
ofdust,lint,hairoranythingthatmay
reduceairflow.
• Keephair,looseclothing,fingers,and
allpartsofbodyawayfromopenings
andmovingparts.
• Toreducetheriskoffalls,useextra
carewhencleaningonstairs.
• Toreducetheriskofpersonalinjuryor
damagetoVac,useonlyCraftsman
recommendedaccessories.
• Whenusingasablower:
-Directairdischargeonlyatworkarea.
-Donotdirectairatbystanders.
-Keepchildrenawaywhenblowing.
-Donotuseblowerforanyjobexcept
blowingdirtanddebris.
-Donotuseasasprayer.
-Wearsafetyeyewear.
• Toreducetheriskofeyeinjury,wear
safetyeyewear.Theoperationofany
utilityVacorblowercanresultinfor-
eignobjectsbeingblownintotheeyes,
whichcanresultinsevereeye
damage.
CAUTION:
To reduce the risk of hearing damage,
wear ear protectors when using for
extended time or in a noisy area.
For dusty operations, wear dust mask.
Static shocks are common when the
relative humidity of the air is low.
Vacuuming fine debris with your Vac
can deposit static charge on the hose
or Vac. To reduce the frequency of stat-
ic shocks in your home or when using
this Vac, add moisture to the air with a
humidifier.
Observe the following warnings that
appear on the motor housing of your Vac:
._ DOUBLE INSULATED
GROUNDING NOT REQUIRED.
WHEN SERVICING USE ONLY
IDENTICAL REPLACEMENT PARTS.
_, WARNING: For your own safety,
read and understand owner's manual.
Do not run unattended. Do not pick up
hot ashes, coals, toxic, flammable or
other hazardous materials. Do not use
around explosive liquids or vapors.
_, WARNING: To reduce the risk of
electric shock - do not expose to rain -
store indoors.
SAVE THIS MANUAL

Introduction
This Wet/Dry Vac is intended for
household use. It may be used for light
vacuuming of wet or dry media and may
also be used as a blower. The light
weight design allows usage for most
Table of Contents
Section Page
Warranty ........................ 2
Important Safety Instructions ......... 2
Introduction ...................... 4
Table of Contents ................. 4
Assembly ........................ 4
Carton Contents List ............. 4
Caster/Caster Foot Caster Assembly. 5
Vac Assembly ................... 5
Insert Hose ..................... 6
Accessory Storage ............... 6
Operation ........................ 6
Polarized Plug .................. 7
Vacuuming Dry Materials .......... 7
Vacuuming Liquids ............... 7
small household vacuuming chores.
Familiarize yourself with the following
product features and read the entire
owner's manual for specific usage of
your new Wet/Dry Vac.
Section Page
Emptying the Dust Drum .......... 8
Blowing Feature ................. 8
Maintenance ..................... 9
Filter .......................... 9
Filter Cleaning .................. 9
Filter Removal and Replacement .... 9
Cleaning a Dry Filter ............ 10
Cleaning a Wet Filter ............ 10
Cleaning and Disinfecting
the Wet/Dry Vac .............. 10
Casters ....................... 10
Storage ....................... 10
Repair Parts ..................... 12
Assembly
Remove entire contents of carton. Check
each item against the Carton Contents
List. Notify your Sears Store or Sears
Service Center immediately if any parts
are damaged or missing.
Carton Contents List
Key Description ............. Qty.
A Vac Assembly .............. 1
B Pos-I-Lock _ Hose Assembly ...1
C Utility Nozzle ............... 1
D Extension Wands ........... 2
E Car Nozzle ................ 1
F Caster Foot w/Storage ....... 4
G Caster .................... 4
H Owner's Manual ............ 1

Assembly (continued)
Caster/Caster Foot Assembly
1. Remove the powerhead assembly from
the dust drum and set aside.
2. Turn the dust drum upside down on the
floor.
3. Insert the caster feet into the bottom of
drum, as shown (4 places).
4. Push on the caster foot until the foot is
flush with bottom of the dust drum.
5. Insert the caster stem into the socket of
the caster foot, as shown (4 places).
6. Push on the caster until the ball on the
caster stem is inserted all the way into
the socket. You will hear the ball snap
into the socket and the caster will
swivel easily when positioning is
correct.
7. Turn the drum upright.Caster
Caster Stem
Caster Ball
Pin >
Foot
Drum
Vac Assembly
1. Line up front of powerhead assembly
with Vacuum port located on the front
of the drum.
NOTE: Powerhead assembly must be
aligned with drum for proper attachment.
2. Place powerhead assembly on top of
drum.
3. Be sure powerhead assembly
completely covers the top of the drum
so leakage does not occur.
Powerhead
Assembl
Push Down
and Pull Out
Flexible
Locking Tab
(located
under latch) Vacuum Port
4. Push down on top of handles to cause
flexible locking tabs to hook onto the
drum lip.
5. Make sure that the locking tabs are
snapped into place to prevent the lid
from coming off (see detail below).
6. To remove the powerhead assembly,
reverse above directions.
Flexible Locking
Tab Pulled Out
/
Flexible _4 J
Locking Tab/_'; i ; ._"
Powerhead
Assembl'
Push Down
and Pull Out
Flexible
Locking Tab
(located
under latch)
I I

Assembly (continued)
Insert Hose
Insert the hose locking end of the "Pos-I-
Lock®'`hose into the inlet of the Vac. The
hose should snap into place. To remove
the hose from the Vac, press the release
button in the hose assembly and pull the
hose out of the Vac inlet, as shown.
Release
Button
Press
and Pull
Accessory Storage
Your accessories may be stored in the
storage locations on the caster feet.
The hose may be stored by wrapping it
around the unit.
Caster Feet
Storage
Operation
_, WARNING: To reduce the risk of fire, explosion, or damage to Vac:
•Do not leave Vac running while unattended - you may fail to notice important signs
indicating abnormal operation such as loss of suction, debris/liquid exiting
exhaust, or abnormal motor noises. Immediately stop using Vac if you notice
these signs.
• Do not leave Vac plugged-in when not in use.
• Do not continue running when float has cut off suction.
• Do not operate Vac in areas with flammable gases, vapors or explosive dust in the
air. Sparks inside the motor can ignite airborne flammables. Flammable gases
and vapors include: lighter fluid, solvent-type cleaners, oil-based paints, gasoline,
alcohol, or aerosol sprays. Flammable dusts include: coal, magnesium,
aluminum, grain, or gun powder.
• Do not vacuum up explosive dusts, flammable liquids, or hot ashes.
• Do not use Vac as a sprayer.
Ak WARNING: To reduce the risk of electric shock or injury:
• Do not expose to rain or allow liquid to enter motor compartment. Store indoors.
• Do not handle plug, switch, or Vac with wet hands.
• Do not service Vac while it is plugged-in. If your Vac is not working as it should,
has missing parts, has been dropped, damaged, left outdoors, or dropped into
water, return it to an independent service center or call customer service.
• When using an extension cord, use only outdoor-rated cords that are in good
condition. Do not allow the connection to come into contact with liquid.
• Do not vacuum toxic materials to reduce the risk of inhaling the vapors or dust.

Operation (continued)
Polarized Plug
To reduce the risk of electric shock, this
Vac has a polarized plug (one blade is
wider than the other). This plug will fit in a
polarized outlet only one way. If the plug
does not fit fully in the outlet, reverse the
plug. If it still does not fit, contact a quali-
fied electrician to install the proper outlet.
Do not change the plug in any way.
After you plug the power cord into the
outlet, turn the unit on by pushing the
switch from position "O" to position "1".
The symbols used on the switch actuator
are international "On & Off" symbols. "O"
is the symbol for "OFF" and "1"is the
symbol for "ON".
=OFF I=ON
Vacuuming Dry Materials
1. The filter must always be in correct
position to reduce the risk of leaks and
possible damage to Vac.
2. When using your Vac to pick up very
fine dust, it will be necessary for you to
empty the drum and clean the filter at
more frequent intervals to maintain
peak Vac performance.
NOTE: A dry filter is necessary to pick up
dry material. If you use your Vac to pick
up dust when the filter is wet, the filter will
clog quickly and be very difficult to clean.
The optional Craftsman HEPA Rated
Material Filter, stock number 17912
will do a better job stopping very fine
particles than the 17816 filter.
Vacuuming Liquids
Ai, WARNING: Do not operate without
filter cage and float, as they prevent
liquid from entering the impeller and
damaging the motor.
1. When picking up small amounts of
liquid the filter may be left in place.
2. When picking up large amounts of
liquid we recommend that the filter be
removed. If the filter is not removed,
it will become saturated and misting
may appear in the exhaust.
3. When the liquid in the drum reaches a
predetermined level, the float mecha-
nism will rise automatically to cut off
air-flow. When this happens, turn off
the Vac, unplug the power cord, and
empty the drum. You will know that the
float has risen because Vac airflow
ceases and the motor noise will
become higher in pitch, due to
increased motor speed.
4. After using the Vac to pick up liquids,
the filter must be dried to reduce the
risk of possible mildew and damage to
the filter.
IMPORTANT: To reduce the risk of
damage to the Vac do not run motor with
float in raised position.

Operation (continued)
Emptying the Drum
1. Remove the lid. Pull the flexible latches
outward on each side of the lid to
release from the drum.
2. While holding the latches out, lift the
top assembly up and away from the
drum.
3. Lay top assembly upside down on a
clean area while emptying drum or
changing filter.
4. Dump the drum contents into the
proper waste disposal container.
AWARNING: To reduce the risk of
back injury or falls, do not lift a vac
heavy with liquid or debris. Scoop or
drain enough contents out to make the
Vac light enough to lift comfortably.
Blowing Feature
Your Vac features a blowing port. It can
blow sawdust and other debris. Follow
the steps below to use your Vac as a
blower.
A WARNING: Always wear safety
eyewear complying with ANSI Z87.1
(or in Canada, CSA Z94.3) before
using as a blower.
AWARNING: To reduce the risk of
injury to bystanders, keep them clear
of blowing debris.
A CAUTION: Wear a dust mask if
blowing creates dust which might be
inhaled.
A CAUTION: To reduce the risk of
hearing damage, wear ear protectors
when using the Vac/Blower for
extended time or in a noisy area.
1. Locate blowing port of your Vac.
2. Insert the locking end of the "Pos-I-
Lock ®''hose into the blowing port of the
Vac. The hose should snap into place.
To remove the hose from the Vac,
press the release button in the hose
assembly and pull the hose out of the
Vac inlet.
3. (Optional) Attach extension wand to
opposite end of hose.
4. Turn Vac on and you are ready to use
your Vac as a blower.
Craftsman recommended accessories are
available at Sears retail stores and
sears.com. The Sears Car Nozzle Stock
No. 17839 is recommended for blowing
debris.
Hose
\_ Blowing

Maintenance
Filter
WARNING: To reduce the risk of
injury from accidental starting, unplug
power cord before changing or
cleaning filter.
NOTE: This filter is made of high quality
paper designed to stop very small parti-
cles of dust. The filter can be used for
small amounts of liquid pick up or dry
pick up. Handle the filter carefully when
removing to clean or installing it. Creases
in the filter pleats may occur from installa-
tion but creases will not affect the per-
formance of the filter.
Filter Cleaning
Your filter should be cleaned often to
maintain peak vac performance.
Be sure to dry the filter before storing or
picking up dry debris.
IMPORTANT: After cleaning, check the
filter for tears or small holes. Do not use
a filter with holes or tears in it. Even a
small hole can cause a lot of dust to
come out of your vac. Replace it
immediately.
Filter Removal and Replacement
WARNING: Do not operate without
filter cage and float, as they prevent
liquid from entering the impeller and
damaging the motor. For dry material
pick-up, do not operate without the fil-
ter in place to reduce the risk of dam-
age to the motor.
Filter Installation:
1. Carefully slide the Qwik Lock TM filter
over the filter cage and press down on
the outside edge of the filter until the
rubber gasket on the bottom of the filter
seats securely around the base of the
filter cage and against the lid.
2. Align the small center hole in the top of
the filter over the Qwik Lock TM stud on
the filter cage. Press firmly on top of
the filter near the stud to allow the filter
to snap over the ball on the end of the
stud. The filter is now attached.
integrated
Filter Plate PUSH
with Center.. DOWN PULL
Hole _ uP
Filter _'_Rubber
Tabs(2)IIIIIIIIIIIII Gasketat
IIIIIIIIIIIII Bottom of
I_.__._. LIIIJlIIIII[I Filter (cutaway
__)) ___._'---_ awik Lock TM
Filter j _
NOTE: Failure to properly seat the
bottom gasket could result in debris
bypassing the filter.
Filter Removal:
1. Hold the filter tabs of the Qwik Lock TM
filter in each hand.
2. With one thumb on the Qwik Lock TM
stud, which protrudes through the inte-
grated filter plate, lift up on the filter
tabs while pushing down on the stud.
3. This action will cause the filter to
release from the filter cage. Slide filter
off cage.

Maintenance (continued)
Cleaning A Dry Filter
Some removal of dry debris can be
accomplished without removing the filter
from the Vac. Slap your hand on top of
the powerhead assembly while the Vac is
turned off.
For best cleaning results due to accumu-
lated dust, clean the filter in an open
area. Cleaning SHOULD be done out-
doors and not in the living quarters.
After filter removal from Vac, remove the
dry debris by gently tapping the filter
against the inside wall of your dust drum.
The debris will loosen and fall.
For thorough cleaning of dry filter with
fine dust (no debris), run water through it
as described under "Cleaning A Wet
Filter".
Cleaning A Wet Filter
After filter is removed, run water through
the filter from a hose or spigot. Take care
that water pressure from the hose is not
strong enough to damage filter.
Cleaning and Disinfecting the
Wet/Dry Vac
To keep your Wet/Dry Vac looking its
best, clean the outside with a cloth
dampened with warm water and mild
soap.
To clean the drum:
1. Dump debris out.
2. Wash drum thoroughly with warm water
and mild soap.
To disinfect the drum:
1. Pour 1 gallon of water and 1 teaspoon
chlorine bleach into the drum.
2. Let solution stand for 20 minutes,
carefully swishing every few minutes,
making sure to wet all inside surfaces
of the drum.
3. Empty drum after 20 minutes. Rinse
with water until bleach smell is gone.
Allow drum to dry completely before
sealing the motor on the drum.
Casters
If your casters are noisy, you may put a
drop of oil on the roller shaft to make them
quieter.
Storage
Before storing your Vac, the drum should
be emptied and cleaned. The cord should
be wrapped around the unit and the hose
should be stored as described in this
manual. Accessories should be kept in the
same area as the Vac so they can be
readily available. The Vac should be stored
indoors.
Cord Wrap ._.._j_----.__
Power Cord _
3. Wipe out with dry cloth.
Before prolonged storage or as needed
(i.e., waste water pick up) the drum
should be disinfected.
_. WARNING: To assure product
SAFETY and RELIABILITY, repairs
and adjustment should be performed
by Sears Parts and Repair Service
Centers, always using Sears replace-
ment parts.
10

Notes
11

Repair Parts
9 Gallon Wet/Dry Vac
Model Number 113.175550
Always order by Part Number - Not by Key Number
WARNING
SERVICING OF DOUBLE-INSULATED WET/DRY VAC
In a double-insulated Wet/Dry Vac, two systems of insulation are provided instead
of grounding. No grounding means is provided on a double-insulated appliance, nor
should a means for grounding be added. Servicing a double-insulated Wet/Dry Vac
requires extreme care and knowledge of the system, and should be done only by
qualified service personnel. Replacement parts for a double-insulated Wet/Dry Vac
must be identical to the parts they replace. Your double-insulated Wet/Dry Vac is
marked with the words "DOUBLE INSULATED" and the symbol _-] (square within
a square) may also be marked on the appliance.
To reduce the risk of injury from electrical shock, unplug power cord before
servicing the electrical parts of the Wet/Dry Vac.
Key 9 Gallon
No. PaN No.
1 832086
2 832625-1
3 833264
4 832630
5 832631
6 829719-11
7 832979-2
8 820563-4
9 510082
10 832259-1
11 823201-2
12 17816
13 832953-1
14 832084
15 331605
16 17835
17 17839
18 17834
19 17825
20 SP6756
Description
Rocker, Switch
Cover Motor
Motor
Gasket Motor Upper
Gasket Motor Lower
Cord with Terminals
Lid
Screws
Collector Scroll Assembly
Gasket Lid
Filter Cage Assembly
Filter
Drum
Caster Foot with Storage
Caster
Utility Nozzle
Car Nozzle
Extension, Wands
Pos-I-Lock _ Hose
Owner's Manual
1-Stock Item - May Be Secured Through The Hardware Department Of Most Sears Retail Stores
*Only Available at SEARS.com and SEARSPARTSDIRECT.com
12

Repair Parts (continued)
9 Gallon Wet/Dry Vac
Model Number 113.175550
17\
13

Notes
14

manual
del usuari0
NO. DEMODELO
113.175550
NQmero
de serie
Los nOmeros de modelo y
de serie se pueden
encontrar en la tapa.
Usted debe anotar los
n_meros tanto de modelo
como de serie en un lugar
seguro para uso futuro.
_ADVERTENCIA:
evolv TM
mASPIRADORA
_._s° PARA MOJADO/SECO
SEGURIDAD
LEADETENIDAMENTE
TODASLAS
INSTRUCCIONES
GUARDEESTE
MANUAL
PARAREFERENCIA
FUTURA
DE 9 GALONES
• seguridad
•ensamblaje
•funcionamiento
•mantenimiento
•piezasderepuesto
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
No. de piezaSP6756 Impreso en M_xico

Garantia
rGarantiacompletapara herramientasel_ctricasCraftsmanEvolv
Si este productoCraftsmanEvolvfalla debidoa un defectode materialode
fabricaciOndentrodelplazodeunanoa partir delafechadecompra,devu_lvaloa
cualquiertiendaSearsuotro puntodeventaCraftsmanEvolvenlosEstadosUnidos
paraobtenerunreemplazogratis.
Estagarantianocubrelasbolsasni losfiltros,quesonpiezasperecederas.
Estagarantiaqueda anuladasi este productose utilizaalgunavez para fines
comercialesodealquiler.
Estagarantialeconfierea ustedderechoslegalesespecificosy esposibleque usted
tengatambi_notrosderechosquevariandeunestadoaotro.
Sears RoebuckandCo..HoffmanEstates.IL60179
INSTRUCCIONESDESEGURIDADIMPORTANTES
Laseguridades una combinaciOndesentidocoman
permaneceralertay saber cOmofunciona la
aspiradoraparamojado/seco (% aspiradora").
Palabrasde serialdeseguridad
A. PELIGRO:indica unasituaciOnpeligrosa que,sl
no seevita, ¢ausar_ la muerte o lesionesgraves
,_ ADVERTENCIA:indica unasituaciOnpeligrosa
que,si no se evita, podriacausar la muerteo lesiones
graves
PRECAUCION:indica una situaciOnpeligrosa que,
si no se evita, pudiera causarlesionesleves o
moderadas.
Ouandoutilice la aspiradora paramojado/seco, siga
siempre lasprecaucionesb_sicasde seguridad,
incluyendo lassiguientes:
AADVERTENCIA-
Para reducir el riesgo de incendio, sacudidas
el_ctricas olesiones:
• Leay entiendaeste manualdel usuarioy todas las
etiquetasqueest_n colocadasen la aspiradora
antesde utilizarla.
• Utilice la aspiradoraQnicamentede la manera que
se describeen este manual.
• Nodeje la aspiradoraen marcha mientras est_
desatendida.Ustedpodria no notar se_ales
importantes que indiquen unfuncionamiento
anormal, tal como p_rdida de succiOn,residuos o
liquido que salenpor el escapeo ruidosanormales
del motor. Dejede usar la aspiradorainmediata-
mente si observaestas se_ales.
• Noabandone laaspiradora cuandoest_ enchufada.
DesenchQfeladel tomacorrientecuando no la est_
utilizando y antes de realizarservicio derevision.
• Las chispasquese producen enel interior del
motor puedenincendiar los vaporesinflamables
o el polvo. Para reducir el riesgode incendioo
explosion: No use laaspiradora cercade liquidos,
gasescombustibles,o polvos explosivos como
gasolinau otros combustibles, liquido encendedor,
limpiadores,pinturas a basedeaceite, gas natural,
polvo decarbon, polvo demagnesio, polvo de
granos decereal,polvo dealuminio o pOlvora.
• No recojacon laaspiradora nadaqueest_ardiendo
o humeando,como cigarrillos, fOsforos o cenizas
calientes.
• No recojacon laaspiradora polvode pareddetipo
seconi cenizafria de chimeneao otros polvos finos
con un filtro estAndar.Estosmateriales pueden
pasar por el filtro y ser expulsados devuelta al aire.
Utilice unfiltro parapolvofino en lugar de unfiltro
estAndar.
• Parareducir el riesgode inhalarvaporestOxicos,
no recojacon la aspiradoramaterialestOxicoso
peligrosos ni la usecercade dichos materiales.
• Parareducir el riesgodedescargas el_ctricas,no
expongala aspiradoraa la Iluvia ni deje que entren
liquidos en el compartimiento del motor. Guardela
aspiradoraen unlugar interior.
• No permita que la aspiradorase utilice como un
juguete.Se necesitaprestarmMima atenciOn
cuandosea utilizadapor ni_os ocerca de_stos.
• No use la aspiradoracon unfiltro desgarrado osin
tenerel filtro instalado,exceptocuando recojacon
ellaliquidos de la maneraquese describeen este
manual. Los residuos secosabsorbidos por el
impulsor podrian da_arel motor o ser expulsados
devueltaal aire.
16

• Apaguela aspiradoraantesde desenchufarla.
• Para reducir el riesgode lesionesdebidas a un
arranqueaccidental,desenchufeel cordon de
energiaantesde cambiar o limpiarel filtro.
• Nodesenchufe la aspiradoratirando del cord6n.
Paradesenchufarla,agarreel enchufey no el
cord6n.
• No use la aspiradoracon el cordon da_ado,el en-
chufe da_adou otras piezasda_adas.Si la aspira-
dora no funciona como debe, le faltan piezas,se ha
caido,hasido da_ada,se hadejado a la intemperie
o se ha caidoal agua, Ilamea servicio al cliente.
• Notire de la aspiradorausando el cord6n ni la Ileve
por el cord6n, ni useel cordon como asa, ni cierre
unapuertasobre el cord6n, ni tire del cord6n
alrededor debordes o esquinasafilados. Nopase la
aspiradoraen marchasobre el cordon. Mantengael
cord6n alejado de lassuperficies calientes.
• No manejeel enchufe,el interruptor ola aspiradora
con las manos mojadas.
• Estaaspiradoratieneaislamiento doble, Iocual
elimina la necesidadde un sistema independiente
deconexi6n atierra. Utilice anicamentepiezasde
repuesto id_nticas.Lealas instruccionesde servicio
de revisionde lasaspiradorasparamojado/seco
con aislamiento doble.
• Utilice anicamentecordonesde extensi6nque
tengancapacidadnominal parauso a la intemperie.
Los cordones deextensi6nqueest_n enmalas
condiciones otengan un tama_o dealambre
demasiadopeque_opueden crearpeligros de
incendioy descargasel_ctricas. Para reducir el
riesgo deestos peligros, asegQresede queel
cord6n est_ enbuenascondiciones y queel liquido
no entreen contacto con la conexi6n. No utiliceun
cord6n de extensi6nquetenga conductores con un
diAmetromenor al calibre 16(AWG). Parareducir la
p_rdida depotencia, utilice uncordon deextensi6n
decalibre 14si la Iongitudes de 25 a50 pies,y de
calibre12 si la Iongitud es de50 pies o mAs.
• No ponga ningan objetoen las aberturasdeventila-
ci6n. No recojanadacon la aspiradoracuando
cualquierade lasaberturas deventilaci6n est_
bloqueada;mantengadichas aberturaslibres de
polvo, pelusa,pelo o cualquier cosaque pueda
reducir el flujo deaire.
• Mantengael pelo, la ropaholgada,los dedosy
todas laspares del cuerpo alejadosde las
aberturasy de laspiezasm6viles.
• Parareducir el riesgodecaidas, tengacuidado
adicional al limpiar enescaleras.
• Parareducir el riesgode lesionescorporales o
da_osa la aspiradora,utilice anicamente
accesorios recomendadospor Craftsman.
• Cuandoutilice la aspiradoracomo soplador:
Dirija la descargade aire solamente haciael Area
detrabajo.
No dirija el airehacialas personasqueest_n
presentes.
Mantengaalejadosa los ni_os durantela
operaciOnde soplado.
No utilice el soplador paratrabajosque no sean
soplar suciedady residuos.
No use la aspiradoracomo rociador.
Use protecciOnocularde seguridad.
• Parareducir el riesgode lesionesenlos ojos,use
protecciOnoculardeseguridad.LautilizaciOndecual-
quieraspiradorautilitariaosopladorutilitariopuede
hacerque sesoplenobjetosextraffoshacialosojos,
Iocualpuedecausardaffosgravesen losojos.
_, PRECAUCION:
• Para reducir el riesgo de daSosa la audici6n, use
protectores de oidos cuando utilice la aspiradora
durante muchas horas seguidas o cuando la
emplee en un Arearuidosa.
• Paraoperacionesque generanpolvo,use unamAs-
caraantipolvo.
• Las descargasde estAticason comunes cuando
la humedad relativadel aire es baja.Si recoge
residuos finos con la aspiradora, se puededeposi-
tar carga estAticaenla manguerao en la aspirado-
ra. El mejor remediopara reducir la frecuenciade
lasdescargasde estAticaensu casaocuando use
estaaspiradoraes aSadir humedadal aire con un
humidificador.
Sigalas siguientes advertenciasque aparecenen la
cajadel motor de la aspiradora.
._ ISLAMIENTODOBLE.NO SEREQUlERE
CONEXlONATIERRA.
CUANDOHAGASERVICIO DE REVISIONDE
LAASPIRADORA,UTILICE0NICAMENTEPIEZASDE
REPUESTOIDt_NTICAS.
A_, ADVERTENCIA:Parasu propia seguridad,
lea y entienda el manual del operador. Notenga
en marcha la aspiradora desatendida. No recoja
cenizas calientes,carb6n caliente, materiales
t6xicos ni inflamables ni otros materiales
peligrosos. No use la aspiradora alrededor de
liquidos ovapores explosivos.
,_. ADVERTENCIA:Parareducir el riesgo de
sacudidas el_ctricas, no exponga la aspiradora
la Iluvia y almac_nelaen interiores.
GUARDEESTEMANUAL
17

Introducci6n
Esta aspiradora est,. dise_ada para uso dom6stico
solamente. Se puede utilizar para la recogida ligera
de medios mojados o secos y tambi6n puede
utilizarse como soplador. El dise_o liviano permite
la utilizaci6n para realizar la mayoria de las tareas
dom6sticasdeaspiraci6npeque_as.Familiaricese
conlassiguientescaracteristicasdelproductoy lea
todoel manualdelusuarioparaobtenerinstruc-
clonessobrelautilizaci6nespecificadesunueva
aspiradoraparamojado/seco.
Indice
Secci6n P_gina Secci6n P_gina
Garantia .............................. 16
Instrucciones de seguridad importantes ..... 16
Introducci6n .......................... 18
Indice ................................ 18
Ensamblaje ............................. 18
Contenido de la caja de cart6n ............ 18
Ensamblaje de las ruedecillas/patas
para ruedecilla ........................ 19
Ensamblaje de la aspiradora .............. 19
Introduzca la manguera .................. 20
AImacenamiento de accesorios ............ 20
Funcionamiento ......................... 20
Enchufe polarizado .................... 21
Recogida de materiales secos
con la aspiradora ...................... 21
Recogidadeliquidosconlaaspiradora...... 21
Vaciadodeltamborparapolvo............. 22
Dispositivodesoplado .................. 22
Mantenimiento.......................... 23
Filtro ................................. 23
Limpiezadelfiltro ...................... 23
Remoci6ny reemplazodelfiltro .......... 23
Limpiezadeunfiltro seco ................ 24
Limpiezadeunfiltro mojado.............. 24
Limpiezay desinfecci6nde
laaspiradoraparamojado/seco.......... 24
Ruedecillas............................ 24
Almacenamiento....................... 24
Piezasderepuesto ...................... 26
Ensamblaje
Saquetodoel contenidodela cajadecart6n.
Aseg_resede queno falte ning_narticulo
utilizandolalista delcontenidodela caja.
Notifiqueinmediatamentea sutiendaSearso
Centrode ServicioSearssi algunapiezaest,.
da_adao falta.
Lista
Clave
A
B
C
D
E
F
G
H
delcontenidodela cajadecart6n
Descripci6n Cant.
Ensamblajedelaaspiradora.......... 1
MangueraPos-I-Loc_ .............. 1
Boquillautilitaria .................. 1
Tubosextensores.................. 2
Boquillaparaauto ................. 1
Piede ruedecillacon_.rea
dealmacenamiento............... 4
Ruedecilla ....................... 4
Manualdel usuario ................ 1
18

Ensamblaje(continuaci6n)
Ensamblajedelas ruedecillas/patas
para ruedecilla
1. Quiteelensamblajedel cabezaldelmotordel
tamborparapolvoy p6ngaloa unlado.
2. Pongaeltamborparapolvoenposici6n
invertidasobreel piso.
3. Introduzcalaspataspararuedecillaenla partein-
feriordeltambor,talcomosemuestra(4lugares).
4. Ejerzapresi6nsobrela patapararuedecillahasta
quela pataest6al rasconlaparteinferiordel
tamborparapolvo.
5. Introduzcael v_.stagodela ruedecillaenel
recept_.culode lapatapararuedecilla,tal como
semuestra(4lugares).
6. Ejerzapresi6nsobrela ruedecillahastaquela
boladelv_.stagodela ruedecillase introduzca
deltodoenel recept_.culo.Sepodr_,oir comola
bolaencajaenel recept_.culoconunchasquido
y la ruedecillaoscilar_,f_.cilmentecuandoel
posicionamientoseacorrecto.
7. Pongaeltamborenposici6nvertical.
de la
ruedecilla
Boladelaruedecilla
Pata
ruedecilla
Pasador
parapolvo
Ensamblajedela aspiradora
1. Alineelapartedelantera(ladodela etiqueta)
delensamblajedelcabezaldelmotorconel
orificiodeaspiraci6nubicadoenla parte
deianteradeltambor.
NOTA:Elensamblajedelcabezaldelmotordebe
estaralineadoconeltamborparaiograruna
sujeci6napropiada.
2. Coloqueel ensambiajedelcabezaldelmotor
sobreiapartesuperiordeltambor.
3. Aseg[iresedequeel ensambiajedel cabezaldel
motorcubracompietamenteia partesuperior
deltambor,paraquenoseproduzcanfugas.
Ensamblaje del
cabezal del motor
Empuje hacia
abajo la lengiieta
de fijaci6n
flexible
(ubicada bajo
la muesca) y
tire de ella
hacia feera
tambor
Orificio de aspiraciOn
4. Empujehaciaabajosobrelasasasparahacer
quelasleng_Jetasdefijaci6nflexiblesse
enganchenenel rebordedeltambor.
5. Aseg[iresedequelasleng_Jetasdefijaci6nest6n
acopladasapresi6nensu sitioparaevitarquela
tapasedesprenda(veael detallem_.sabajo).
6. Paraquitarel ensamblajedelcabezaldelmotor,
inviertalasinstruccionesqueanteceden.
LengUeta de fijaci6n flexible
tirada hacia feera
\
Lengiieta de
fijaci6n flexible
Ensamblajedel
cabezaldelmotor
Empujehaciaabajo
la lengiieta de
fijaci6n flexible
(ubicada bajo la
muesca) y tire de
ella hacia feera
19

Ensamblaje(continuaci6n)
Introduzcala manguera
Introduzca el extremo defijaci6n de la manguera
"Pos-I-Lock ®"en la entrada de la aspiradora. La
manguera deberia acoplarse a presi6n en su sitio.
Para sacar la manguera de la aspiradora, oprima el
bot6n de liberaci6n ubicado en el ensamblaje dela
manguera y tire de la manguera hasta sacarla de la
entrada de la aspiradora, de la manera que se
muestra en la ilustraci6n.
\\
Bot6nde
liberaci6n
Oprima el
_bot6ny tire de
lamanguera
Almacenamientode accesorios
Los accesorios se pueden almacenar en las ubica-
clones de almacenamiento situadas en los pies de
ruedecilla. La manguera se puede almacenar
enroll_.ndola alrededor de la unidad de la manera
que se muestra en la ilustraci6n.
zArea de
almacenamientoen
lospiesde ruedecilla
Funcionamiento
A_. ADVERTENCIA:Para reducirel riesgode incendio,explosi6n o dafiosa la aspiradora:
•No deje la aspiradora en marcha mientras est_ desatendida. Usted podria no notar se_ales importantes
que indiquen un funcionamiento anormal, tal como p_rdida de succi6n, residuos o liquido que salen
por el escape o ruidos anormales del motor. Deje deusar la aspiradora inmediatamente si observa
estas seSales.
• No deje la aspiradora enchufadacuando no se est_ utilizando.
• No continue usando la aspiradora cuando el fiotador haya cortado la succi6n.
• No utilice la aspiradora en_reas con gases inflamables, vapores infiamables o polvo explosivo en el
aire. Las chispas generadasdentro del motor pueden incendiar los materiales infiamables suspendidos
en el aire. Los gases inflamables y los vapores infiamables incluyen: liquido encendedor, limpiadores
tipo solvente, pinturas a base de aceite, gasolina, alcohol o rociadores tipo aerosol. Los polvos inflam-
ables incluyen: polvo de carb6n, polvo de magnesio, polvo de aluminio, polvo de grano de cereal o
p61vora.
• No recoja con la aspiradora polvos explosivos, liquidos inflamables ni cenizas calientes.
• No use la aspiradora como un rociador.
,_, ADVERTENCIA:Para reducirel riesgode descargasel6ctricaso lesiones:
• Noexpongala aspiradoraa la Iluvia ni dejeque entre liquido en el compartimiento del motor. Almacenela
aspiradora enun lugar interior.
• No manejeel enchufe, el interruptor o la aspiradoracon las manosmojadas.
• No hagaservicio deajustesy reparacionesde la aspiradoramientrasest_ enchufada.Sila aspiradora no
estAfuncionando como deberia, lefaltan piezas,se ha caido, estAda_ada,se hadejado ala intemperieo
se hacaido al agua, devu_lvalaaun centro de servicio independienteo Ilamea servicio al cliente.
• Cuandoutilice un cord6n de extension,utilice anicamentecordonescon capacidadnominal parauso a la
intemperiequeest_nen buenascondiciones.No deje quela conexi6nentre encontacto con liquido.
• No recojacon la aspiradora materialest6xicos, parareducir el riesgode inhalar losvapores oel polvo.
20
