Crate&Barrel VENTURA User manual

HARDWARE
TOOLS REQUIRED
COMPONENTS
Made in China - r08 Page 1 of 4
Thank you for purchasing the Ventura Umbrella. This
page lists all the contents included in the box. Please
take time to identify the hardware as well as the
individual components of this product. As you unpack
and prepare for assembly, place the contents on a
carpeted or padded area to protect them from damage.
Note: 2 people are required to safely assemble this product.
VENTURA UMBRELLA
Missing hardware?
Please call 800.606.6387 for replacements.
4 - bolts
allen wrench
(included)
1- upright
1 - umbrella
assembly
1 - knob
1 - base 1 With the assistance of another adult, fit upright into
corresponding hole of base as shown. Secure with 4 bolts
using an allen wrench. Do not over tighten the bolts.
ASSEMBLY
base
upright NOTE: Do not over
tighten the bolts
underside
of base
Customer Service 800.967.6696 |Latest instructions available at www.crateandbarrel.com
(We recommend the use of hand tools instead of power tools)

Made in China - r08 Page 2 of 4
VENTURA UMBRELLA
2 Making sure the umbrella is in the closed position, fit pole
of umbrella over pole of base assembly as shown. With
assistance of another adult, align hole on each pole, and
secure poles with the knob. Turn knob clockwise to fasten.
umbrella
pole
base
assembly
closed
position
knob
NOTE: Make sure
umbrella is in the
closed position
before assembling
3 A) Push curved pole up until button A fits into correspond-
ing hole and locks into position.
B) Push the vertical pole up until button B fits into correspond-
ing hole and locks into position.
curved
pole
B
A
button A
button B
vertical pole
cylinder
B
4 A) Push in button C and lift curved pole all the way up.
B) Push the cylinder all the way down until it locks into
place. Umbrella assembly is now complete.
curved
pole
A
button C
5 Lift handle up and slide entire housing assembly as far
up as it can go. Push handle down to lock assembly into
place.
unlocked
locked
HANDLE POSITION
housing
assembly
Customer Service 800.967.6696 |Latest instructions available at www.crateandbarrel.com

Made in China - 08 Page 3 of 4
VENTURA UMBRELLA
2 Press button to release umbrella frame. Carefully pull on
umbrella frame to remove and set aside.
button
umbrella
frame
umbrella
frame
4 A) Fit cord of umbrella stand through umbrella frame and
secure umbrella frame to stand. Make sure button of
umbrella frame fully engages hole of stand.
B) Re-attach hook to umbrella frame.
hook
umbrella frame
button umbrella
frame
umbrella
stand
A
B
cover
(sold separately)
cover
(sold separately)
3 Fit cover (sold separately) onto umbrella frame as
shown.
INSTRUCTIONS TO INSTALL
AND REMOVE COVER
1 Release hook from umbrella frame as shown.
hook
umbrella frame
Customer Service 800.967.6696 |Latest instructions available at www.crateandbarrel.com

Made in China - 08 Page 4 of 4
VENTURA UMBRELLA
CLEANING & CARE
Clean surfaces with a dry or damp soft cloth.
Do not use abrasive cleaners. Crank handle of curved pole to open cover as shown.
cover
NOTE: Before opening the
umbrella, make sure to separate the
frame of the umbrella first. If the
frame is intertwined, it might break
when being cranked up.
To change angle of the cover, lift handle and move housing
assembly down the pole. Push handle down to secure.
Umbrella stand can only move forward or backward.
Depending on the direction, carefully lift the corresponding
handle and move to desired location.
INSTRUCTIONS
TO MOVE THE
UMBRELLA
STAND
Lift handle
Lift
handle
NOTE: Umbrella stand can only
move forward and backward
INSTRUCTIONS
TO OPEN AND ADJUST
UMBRELLA STAND
5 Fit each rib into corresponding pocket of cover.
Assembly is now complete.
To remove cover, please reverse steps 1-5.
cover
(sold separately)
pocket
rib
